PANAMETRICS
25DL Multi-Mode
Ultrasonic Thickness Gage
with Internal Datalogger
Easy to use
Uses contact, delay line, and
immersion transducers
Application Auto-Recall
with Stored Standard and
Custom Setups
Wide thickness range
Measures most materials
Resolution up to 0.0001"
(0.001mm)
Handheld
Large backlit display
Alarm functions
Long battery life
Inches/mm
Alphanumeric datalogger
Multiple on-screen languages
Computer interface
Two year warranty
The Panametrics Advantage
Quality takes priority at Panametrics. When
you purchase a Panametrics thickness gage,
you’ll also receive the advantage of more than
thirty years of experience in manufacturing
ultrasonic testing equipment of outstanding
workmanship. We are continuously on the
forefront of ultrasonic technology, introducing
innovative solutions. The 25DL is the latest
example of Panametrics’ commitment to bring
you state-of-the-art products.
High Precision Thickness Measurements
with Reliability and Simplicity
The 25DL Ultrasonic Thickness Gage makes extremely accurate thickness
measurements (0.0001″ or 0.001mm resolution) in most engineering materials.
It is also designed with one basic goal in mind — simplicity
of operation regardless of the complexity of your applications.
The Model 25DL utilizes ultrasound to make accurate
thickness measurements on most materials including steel,
plastic, rubber, glass, and composites in just seconds. This
easy-to-use handheld gage provides instant digital readings
on a large backlit LCD. An internal datalogger stores over 5000
thickness readings with alphanumeric identification codes
which later can be uploaded to a computer
or directly sent to a printer.
25DL
Worldwide
Applications Assistance
For a free application evaluation, please
send a sample of your material to our
extensive testing lab at Panametrics’
headquarters in Waltham, MA, or to
one of our many sister companies
and sales agents worldwide.
