ATD Tools Atd-81047 User Manual

Heavy Duty

Tool Box Creeper Seat

Operating Instructions & Parts Manual

Model Number

Atd-81047

U.S. Patent # D 586,132
Other Patents Pending

Capacity

450 lbs

This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.

!

! ADVERTENCIA

• Leer, comprender, y seguir las instrucciónes antes

de utilizar el aparato.

• El manual de instrucciónes y la información de

seguridad deben estar comunicado en lengua del
operador antes del uso.

• No seguir estas indicaciónes puede causar daños

personales o materiales.

Atd Tools Inc.

160 Enterprise Drive, Wentzville, MO 63385

! WARNING

To avoid pinch and laceration injuries:

•

Keep hands away from pinch and laceration

hazards points that are created during use!

•

Be alert and sober when using this product!

•

Sit centrally on seat pad ONLY. NEVER sit on

edge!

OIPM#81047-0310

Printed in China

Save these instructions. For your safety, read, understand, and follow the information provided with and on this
product before using. The owner and/or operator shall have an understanding of safe use / operating procedures
before attempting to use. The owner and/or operator shall be aware that the use of this product may require special

skills and knowledge. Instructions and safety information shall be conveyed in the operator’s native language before

use of this device is authorized. If any doubt exists as to the safe and proper use of this product as outlined in this
factory authorized manual, remove from service immediately.

Inspect before each use. Do not use if broken, bent, cracked, or damaged parts (including labels) are noted.
Any Tool Box Seat that appears damaged in any way, operates abnormally or is missing parts, shall be removed

from service immediately and the manufacturer notied. If you suspect that this product was subjected to a shock

load (a load dropped suddenly, unexpectedly upon it), immediately discontinue use until it has been checked by a
factory authorized service center (contact distributor or manufacturer for list of Authorized Service Centers). It is

recommended that an annual inspection be done by qualied personnel. Labels and owner’s manuals are available

from manufacturer (see Replacement Parts, page 4).

PRODUCT DESCRIPTION

This device is designed to support and transport, along a smooth and level surface, one person, tools, and equipment
weighing *450 lbs. or less for the purpose of performing automotive maintenance or service. This device is not
intended, designed or engineered to be used for any other purpose.

Rated Capacity: One (1) person weighing 450 lbs. or less- * includes person, tools, equipment, personal items

Do not use this device for any purpose other than that for which it is expressly intended.

!

SPECIFICATIONS

Model Rated Capacity

Atd-81047 450 lbs 18-1/4" x 14-1/8" x 18-7/8"

tool drawer

front tool tray

Overall Toolbox Dimension

Length, Width, Height

Tool Drawer Inner Dimension

Length, Width, Height

12-3/4" x 7-5/8" x 2-3/8"

seat

rear tool tray

hex key/philips screwdriver

combo tool

caster

Figure 1 - Model Atd-81047 Nomenclature
