ATD Tools ATD7325 User Manual

MagicLift™
Service Jack,
Low Prole
Operating Instructions & Parts Manual
Model
ATD7325
U.S. Patent No’s. 6,199,379 • 5,946,912
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
!
Obey all safety messages that follow this symbol to avoid possible injury or death.
Capacity
! ADVERTENCIA
• Leer, comprender, y seguir las instrucciónes antes
de utilizar el aparato.
• El manual de instrucciónes y la información de seguridad deben estar comunicado en lengua del
operador antes del uso.
• No seguir estas indicaciónes puede causar daños
personales o materiales.
ATD Tools Inc.
160 Enterprise Drive, Wentzville MO 63385
! WARNING
To avoid crushing and related injuries:
NEVER work on, under or around a load supported only by a hydraulic
jack. ALWAYS use adequately rated jack stands.
Printed in China
ATD7325-M3 rev 07/10
SAFETY and GENERAL INFORMATION
Save these instructions. For your safety, read, understand, and follow the information provided with and on this
jack before using. The owner and/or operator of this equipment shall have an understanding of this jack and safe operating procedures before attempting to use. The owner and/or operator shall be aware that the use and repair of this product may require special skills and knowledge. Instructions and safety information shall be conveyed in the operator’s native language before use of this jack is authorized. If any doubt exists as to the safe and proper use of this jack, remove from service immediately.
Inspect before each use. Do not use if broken, bent, cracked, or damaged parts (including labels) are noted. Any jack that appears damaged in any way, operates abnormally or is missing parts, shall be removed from service immediately and the manufacturer notied. If you suspect that the jack was subjected to a shock load (a load dropped suddenly, unexpectedly upon it), immediately discontinue use until jack has been checked by a factory authorized service center (contact distributor or manufacturer for list of Authorized Service Centers). It is recommended that an annual inspection be done by qualied personnel. Labels and owner’s manuals are available from manufacturer.
PRODUCT DESCRIPTION
ATD MagicLift™ Low Prole Garage Jack is designed to lift, but not support, one end of a vehicle. The jack must be used in conjunction with a pair of appropriately rated jack stands. MagicLift™ Service Jack has a unique feature, which provides fast, no load lifts to the jacking point, at which time it lifts in approximately 0.75~2" increments.
NEVER use a hydraulic jack as a stand-alone device. After lifting, immediately support the lifted vehicle
!
with a pair of appropriately rated jack stands.
SPECIFICATIONS
Model Capacity Jack Size (L x W x H) Min. Height Max. Height Saddle Dia.
ATD7325 2 Ton 42-1/2" x 13-3/4" x 6-3/4" 2-1/2" 20" 4-7/8"
2
PREPARATION
Assembly
Insert handle into the handle sleeve. Tighten the bolt on handle sleeve to prevent accidental removal of handle while
in use.
Before Use
1. Verify that the product and application are compatible, if in doubt call ATD Tools Tech. Service (636) 327-9050.
2. Before using this product, read the operator's manual completely and familiarize yourself thoroughly with the product, its components and recognize the hazards associated with its use.
3. To familiarize yourself with basic operation of this
a. Clockwise until rm resistance is felt to further raise the load. b.
Counter-clockwise,
position used to lower the load.
4. Check to ensure that jack rolls freely. Raise and lower the unloaded saddle throughout the lifting range before putting into service to ensure the pump operates smoothly.
5. Replace worn or damaged parts and assemblies with ATD authorized replacement parts only. Lubricate as instructed in Maintenance Section.
but no more than 1/2 full turn
jack, locate and turn the release valve (handle):
turning. This is the ‘CLOSED’ release valve position
from the closed position. This is the ‘OPEN’ release valve
used to
Front Wheel
Handle
Lifting Arm
Saddle
Vent Screw
(under cover plate,
on reservoir)
Handle Sleeve
Rear Caster
Figure 1 - ATD7325 Nomenclature
3
! WARNING
Study, understand, and follow all printed materials provided with/on this product before use.
Do not exceed rated capacity.
• Use only on hard, level surface.
This is a lifting device only!
Immediately after lifting, support the load with
a pair of appropriately rated jack stands.
• Lift only on areas of the vehicle as specied by the vehicle manufacturer.
Do not move or dolly the vehicle while on the jack.
• No alterations shall be made to this product.
FAILURE TO HEED THESE MARKINGS MAY
RESULT IN PERSONAL INJURY AND/OR
PROPERTY DAMAGE!
To avoid crushing and related injuries:
Never work on, under or around a load supported
only by hydraulic jack.
Always use adequately rated jack stands.
• Chock each unlifted tire in both directions.
Do not use this device to lift, level, lower, support nor move a house, mobile home, travel trailer, camper or any building structure.
Be alert and sober when using this product. Do not operate under the inuence of drugs or alcohol.
! WARNING
X
OPERATION
Lifting
Only attachments and/or adapters supplied by the manufacturer shall be used. Lift only on area of the
!
vehicleasspeciedbythevehiclemanufacturer.
1. Follow the vehicle manufacturer’s recommended guidelines for lifting. Engage the emergency brake and chock each unlifted wheel in both directions to prevent inadvertent vehicle movement.
2.
Close the release valve by turning the handle clockwise until rm resistance is felt.
3. Refer to the vehicle manufacturer owner’s manual to locate approved lifting points on the vehicle. Center jack
saddle under lift point.
4. Verify lift point, then pump handle to contact lift point. To lift, pump handle until load reaches desired height.
5. Transfer the load immediately to appropriately rated jack stands.
pair of appropriately rated jack stands. Use one pair of jack stands per vehicle. Rated capacity is per pair only! Do not exceed rated capacity.
Lowering
you turn the handle counter-clockwise, the faster the load will come down. Maintain control of the rate of speed at which the load lowers at all times!
1. Raise load high enough to clear the jack stands.
2.
3. Slowly turn the handle counter-clockwise, but no more than 1/2 full turn. If the load fails to lower:
a. Use another jack to raise the vehicle high enough to reinstall jack stands. b. Remove the malfunctioning jack and then the jack stands. c.
4. After removing jack from under the load, fully lower the saddle to reduce ram exposure to rust and
NEVER use hydraulic jack as a stand alone
!
Be sure all tools and personnel are clear before
!
Remove jack stands carefully (always used in pairs).
Use the functioning jack to lower the vehicle.
contamination.
device! ALWAYS transfer the lifted load IMMEDIATELY to a
lowering load. Slowly open the release valve! The more
4
MAINTENANCE
Important: Use only good grade hydraulic jack oil. Avoid mixing different types of uid and Never use brake uid,
turbine oil, transmission uid, motor oil or glycerin. Improper uid can cause failure of the jack and the potential for sudden and immediate loss of load. We recommend Mobil DTE 13M or equivalent.
Adding oil
1. With saddle fully lowered set jack in its upright, level position. Locate and remove vent screw.
2. Fill with oil until ~3/16” above the inner cylinder as seen from the oil ller hole. If the oil level is too low, the jack
will not raise to its advertised maximum height. Reinstall the vent screw.
Changing oil
For best performance, replace the complete uid supply at least once per year.
1. With saddle fully lowered, remove the vent screw and drain the uid into a suitable container.
2. Fill with oil until ~3/16” above the inner cylinder as seen from the oil ller hole. Reinstall vent screw.
Note: Dispose of hydraulic uid in accordance with local regulations.
Lubrication
A periodic coating of light lubricating oil to pivot points, axles and hinges will help to prevent rust and assure that wheels, casters and pump assemblies move freely.
Cleaning
Periodically check the pump piston and ram for signs of rust/corrosion. Clean as needed and wipe with oily cloth.
Note: Never use sandpaper or abrasive material on these surfaces!
Storage
When not in use, store the jack with saddle fully lowered. This will help prevent rust and corrosion to those critical surfaces.
TROUBLESHOOTING
Symptom Possible Causes Corrective Action
Jack will not lift load
Jack will lift, but not maintain
pressure
Jack will not lower after unloading • Reservoir overlled
Poor lift performance • Fluid level low
Will not lift to full extension • Fluid level low • Ensure proper uid level
• Release valve not tightly closed
• Load is too heavy
• Release valve not tightly closed
• Hydraulic unit malfunction
• Linkages binding
• Hydraulic unit malfunction
• Ensure release valve tightly closed
• Consider higher capacity jack
• Ensure release valve tightly closed
• Discontinue use, contact ATD Technical Service
• Drain uid to proper level
• Clean and lubricate moving parts
• Ensure proper uid level
• Discontinue use, contact ATD Technical Service
5
REPLACEMENT PARTS
Not all components of the jack are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence. When ordering parts, give Model number, part number and description below. Call or write for current pricing: ATD Tools Inc. 160 Enterprise Drive, Wentzville, MO 63385. Tel:(636)327-9050 Fax:(636)327-9044
Replacement Parts Illustration for ATD7325
12
13
1
2
3
k
q
j
i
g
b
f
e
11
d
c
b
a
18R
r
h
25
8
10
l
m
20
9
22
19
24
23
p
o
n
21
6
18L
5
15
14
4
Figure 2 - Replacement Parts Illustration for ATD7325
6
16 17
7
Replacement Parts List for ATD7325
Item# Part# Description Qty.
1 G86301-0001 Saddle Pad 1 2 G86301-0017 Saddle 1 3 G86308-0001 Hydraulic Unit 1 4 G86301-0004 Front Wheel Assembly 2 5 G86301-0003 Rear Caster Assembly 2 6 G86301-0008 Handle Grip 1 7 G86301-0019 Handle Assembly 1
8 G86308-0003 Handle Sleeve 1 9 G48900-0024 Bolt, M10x16 1
10 G86308-0004 U-joint 1 11 G86301-0014 Vent Screw 1 12 G86301-0012 Return Spring, Lift Arm 2 13 G86308-0005 Cover 1 14 G86301-0023 Nut, M16 2 15 G86301-0024 Spring Washer, D16 2 16 G88009-0016 Bolt, M12 1 17 G86301-0032 Nut, M12 4
18R G59509-0016 Bolt, Handle Sleeve, RH side 1
18L G59509-0015 Bolt, Handle Sleeve, LH side 1
19 G59305-0006 Spring Washer, D20 2
20 G73500-0011 Pin D12 1 21 G73500-0012 Roller 1 22 G59305-0005 Spring Washer, D10 1 23 G69400-0004 Spring Pin 1 24 G69400-0003 Cap, Pump Piston 1 25 G73500-0010 Return Spring, Handle 1
** G86308-0000 Seal Kit (includes a thru r) 1
- ATD7325-M2 Manual -
- ATD7325-L0 Label -
**Repair Kit Contents:
Item Description Qty a O-ring 1 b O-ring 2 c Back-up Washer 1 d U-cup 1 e Back-up Washer 1 f O-ring 1 g O-ring 2 h Washer, Metal 2 i Oil Seal 1
(**) Replacement requires special skills, knowledge, and equipment. Only an authorized service center may
perform the repair and/or replacement of these items. Contact ATD technical service for list of service centers.
Item Description Qty j Back-up Washer 1 k O-ring 13x2.4 1 l O-ring 8x1.8 1 m O-ring 1 n Back-up Washer 1 o O-ring 17x2.65 1 p Back-up Washer 1 q Back-up Washer 1 r Oil Seal 1
7
ONE YEAR LIMITED WARRANTY
For a period of one (1) year from date of purchase, ATD Tools Inc. will repair or replace, at its option, without charge, any of its products which fails due to a defect in material or workmanship under normal usage. This limited warranty is a consumer's exclusive remedy.
Performance of any obligation under this warranty may be obtained by returning the warranted product, freight prepaid, to ATD Tools Inc. Warranty Service Department, 160 Enterprise Drive, Wentzville, MO 63385.
Except where such limitations and exclusions are specically prohibited by applicable law, (1) THE CONSUMER'S SOLE AND EXCLUSIVE REMEDY SHALL BE THE REPAIR OR REPLACEMENT OF DEFECTIVE PRODUCTS AS DESCRIBED ABOVE. (2) ATD Tools Inc. SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGE OR LOSS WHATSOEVER. (3) ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO ONE YEAR, OTHERWISE THE REPAIR, REPLACEMENT OR REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. (4) ANY MODIFICATION, ALTERATION, ABUSE, UNAUTHORIZED SERVICE OR ORNAMENTAL DESIGN VOIDS THIS WARRANTY AND IS NOT COVERED BY THIS WARRANTY.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specic legal rights, and you may also have other rights which vary from state to state.
ATD Tools Inc.
160 Enterprise Drive,
Wentzville MO 63385
636-327-9050
8
