Atdec TH-PS-D Technical specs

TH-PS-D

C

L

Short Throw Projector Wall Mount | Dual Stud

General Features

Maximum Weight:

25kg (55lbs)

Tilt Adjustment: Roll Adjustment: Color: Warranty:

ARM ±5° MOUNT ±20° MOUNT ±5° Silver 10 years

Dimensions

Technical Specifications

Ø8.5mm
(0.33”)

68mm
(2.7”)

25.50mm
(1”)

167mm
(6.6”)

432mm (17”)

C

L

167mm
(6.6”)

545mm (21.5”)

10mm
(0.4”)

216.5mm
(8.5”)

248mm
(9.7”)

248mm
(9.8”)

41mm
(1.6”)

182mm
(7.16”)

1480mm (58.2”)

1215mm (47.8”)

1397mm (55”)

C

L

99mm Max.
(3.9”)

92mm Min.
(3.6”)

+5°

-5°

The Support Arm can be
adjusted by +/- 5° to account
for wall slope or individual
projector characteristics.

Dimensions

R220mm Max.

Ø75mm

(3”)

Bolt Circle

Ø6.5mm

(0.25”)

62mm Min.

(2.4”)

(8.7”)

Ø157.5mm

(6.2”)

100mm
(4”)

Ø100mm (4”)
Bolt Circle

1.5NPT

85mm
(3.3”)

69mm Max.

(2.7”)

4-LEG MINIMUM DISTANCE:

Ø300mm

(12”)

3-LEG MINIMUM DISTANCE:

Ø200mm

(8”)

Ø5.5mm

(0.2”)

Roll Adjustment:

Ø130mm (5”)
Bolt Circle

Ø75mm (3”)
Bolt Circle

+5°

-5°

FRONT VIEW SIDE VIEW

Tilt Adjustment:

Note: Depending on where
the projector is mounted
along the support arm and
if the projector extends from
the centre of the mount
more than 8”/200mm, the
tilt adjustment achievable on
the mount may be reduced.

+20°

-20°

No portion of this document or any artwork contained herein should be reproduced in any way without the express written consent of Atdec Pty Ltd.

Due to continuing product development, the manufacturer reserves the right to alter specifications without notice. Published 11.01.13 ©
