Mounting hole pattern:
from 180mm to 800mm wide
®
from 125mm to 500mm high
Maximum weight carrying capacity:
91kg (200lbs)
TH-3070-UTFlat screen wall mount | tilt
The TH-3070-UT is highly durable and extremely strong. This
mount supports screens that weigh up to 91kg (200lbs) and
offers 15 degrees of tilt adjustment which can be set post installation. Very simple to install, the TV is held just 72.5mm (2.85”)
from the wall for a display that’s streamlined as well as flexible.
By adding a padlock your screen is safe and secure thanks to the
theft resistant design.
Product key features:
Adjustable tilt of 5° up and 15° down
Distance from wall: 72.5mm (2.85”)
Theft resistant design (requires one small padlock)
Comes with all mounting hardware for masonry, timber stud and dry wall installation
Supports heavy
displays weighing
up to 91kg (200lbs)
Adjustable tilt:
5° up and 15° down
Universal mounting
hole pattern
Post installation
horizontal adjustment
Can be mounted
to dry wall
Theft resitant design
(requires one small podlook)
®
Atdec Global www.atdec.com.au
Atdec North America www.atdec.com
Product information, single unit
Product Code
Load capacity
Material Color
TH-3070-UT
Package information, single unit
Size
88.5cm x 27.5cm x 7.5cm
(34.75" x 11" x 3")
Package information, master pack
Size
90cm x 30cm x 32cm
(35" x 11.75" x 12.5")
Technical drawings
Black91kg (200lbs) Steel
Ship weight UPC code Contents
6.84kg (16.2lbs)
881493004788
All hardware required for
installation supplied
Ship weight UPC Units per master pack
28kg (65lbs)
180mm to 800mm
(7” to 31.5”)
4881493004856
263mm
(10.35”)
200mm
(7.87”)
10mm
(0.39”)
68mm
(2.68”)
125mm to 500mm
(4.92” to 19.69”)
660mm
(26”)
845mm
(33.27”)
200mm
(7.87”)
125mm
(4.92”)
175mm
(6.89”)
43mm
(1.69”)
24mm
(0.95”)
32mm
(1.26”)
117.5mm
(4.63”)
10mm
(0.39”)
535mm
(21”)
56.5mm
(2.22”)
ADJUSTABLE TILT OF
-5° TO 15°
15°
250mm
(10”)
16mm
(0.63”)
-5°
Atdec mounts are designed, developed and tested in Australia. While all efforts
have been made to ensure the information in this brochure was correct as of the
date of printing, we reserve the right to change specifications without notice. Please
refer to the website for our full range along with the latest details on specifications,
compatibility and dealer location. Atdec and Telehook are registered trademarks
with all rights reserved. Copyright April 2013.
525mm (23”) OF HOR IZONTAL ADJUSTM ENT
from180mm (7”) to 800m m (31.5”)
