Slat Wall Adaptor
Installation Guide
AWM-WS
COMPONENT CHECKLIST
A
Bracket Assembly
(x1)
B
Screw
M6x10mm
(x2)
C
4mm Allen Key
(x1)
REQUIRED TOOLS
• All tools provided
WEIGHT RANGE
0 - 9.1kg
(0 - 20lbs)
IMPORTANT INFORMATION
! The AWM-W6 60 Wall Channel (sold separately) is required to complete this installation.
! Please ensure this product is installed as per these installation instructions.
! The manufacturer accepts no responsibility for incorrect installation.
! Ensure that the weight rating of the supporting wall or rail is sufficient.
AWM-WS Page 1 of 2
Assembly instructions
A
Bracket Assembly
(x1)
B
Screw
M6x10mm
(x2)
C
4mm Allen Key
(x1)
1. Install the adaptor into the slot and adjust the tension screw from above to lock
into place.
2. Attach the wall channel to the front of the Adaptor.
Note
AWM-W6 60 Wall Channel
sold separately.
NOTE: Installation of the adaptor is now complete! Refer to Arm installation guide for arm installation.
No portion of this document or any artwork contained herein should be reproduced in any way without
the express written consent of Atdec Pty Ltd. Due to continuing product development, the manufacturer
reserves the right to alter specifications without notice. ©20180830
atdec.com | atdec.co.uk | atdec.com.au
AWM-WS Page 2 of 2
