OPEN AIR COOLERS
THE IDEAL MERCHANDISER
FOR GRAB N' GO PROGRAMS
www.ahtusa.net
OPEN AIR MERCHANDISING FROM AHT:
PERFECT FOR SECONDARY LOCATIONS AND TO DRIVE IMPULSE
Merchandising Features
\ Unique design creates eye-catching
store display
\ Open front and large glass sides offer easy
product access and 180° product visibility
\ Integrated LED interior lighting for brilliant
product display
\ Illuminated LED header (in vertical models)
and large side graphic areas
\ Extra deep shelves offer maximum product
capacity
\ Adjustable dual-position shelves provide
flat or gravity fed positions (not available
in AC-XL SLIM)
\ Interchangeable cooling deck system can be changed out
in 15 minutes, allows for easy maintenance and service
\Energy efficient integrated LED lighting
\ Pull down night curtain
\ Air curtain technology uses less energy
and keeps products cooler
\ Low maintenance tube wire condenser
\ Hot gas evaporation system
\ Electronic temperature control
with digital readout
\ Low profile fixed rollers allow for easy
movement and cleaning in the store
\ 36 °F to +41 °F
AHT AC S
AHT AC W
Custom Graphics Night CurtainTemperature ranges
PURCHASES.
AHT AC M, AC XL & AC XL SLIM. With visibility on 3 sides, our Vertical models are
designed for large format C-Stores and Supermarkets. They provide retailers with a
Consumer Destination to promote a wide range of products.
AHT AC S and AC W. With its small footprint and high capacity,
our 59" high Low Profile models are the perfect solution for retail
placements near the check-out or on low profile end caps.
AHT AC M AHT AC XL AHT AC XL SLIM
Interchangeable Cooling Cassette
Optional LED Header for
AC XL and AC XL Slim
Cooling cassette
interchangeable
within 15 min.
\ Cooler does not need to be
(re)moved
\ No need to empty cooler
Model
External dimensions ( W x D x H) [inch]
Internal dimensio ns (W x D x H) [inch] 24.0/22.0/31.0 32.0/22.0/31.0
Volume net/gross [cu. ft.] 6.71/8.65 8.83/11.48
LED Lighting standard in all US cabinets LED (4 Vertical) LED (1 horizontal / 4 vertical)
Shelf dimensions (W x D) [inch] 24.02 x 12.6/15.35 32.28 x 12.6/15.35
Shelves [pc.] 1 Large and 2 small 1 Large and 2 small
Inner temperature range [°F] +36 to +41F +36 to +41F
Refrigerant type R404A R404A
Max. ambient temperature [°F] +61 to +81 +61 to +81
Weight net /gross [lb] 251/291 276/315
Loadability 40’ [Pcs.] 45 36
Nominal voltage/frequncy V/Hz 120/60 120/60
Nominal current A 10.5 10.5
Energy consumption
kWh/24h 16.5 18.6
BTU 56311 63478
27.8/32.2/ 58.9
Depth incl. backspacer
AHT AC S AHT AC W
36.0/32.2/58.9
Depth incl. backspacer
Model
External dimensions ( W x D x H) [inch]
Internal dimensi ons (W x D x H) [inch] 24.0/22.0/55.0 4 4.0/27.5/53.5 44.0/17.0/53.5
Volume net/gross [cu. ft.] 11.44/16.35 27.19/37.43 15.32/22.81
LED Lighting standard in all US cabinets LED (1 horizontal/6 vertical) LED (4 horizontal/6 vertical) LED (4 horizontal/6 vertical)
Shelf dimensions (W x D) [inch] 24.02 x 15.35 43.07 x 20.12 43.1 x 12.1
Shelves [pc.] 5 5 5
Inner temperature range [°F] +36 to +41F +36 to +41F +36 to +41F
Refrigerant type R404A R404A R404A
Max. ambient temperature [°F] +61 to +81 +61 to +75 +61 to +75
Weight net /gross [lb] 335 / 364 500/562 399/463
Loadability 40’ [Pcs.] 45 21 26
Nominal voltage/frequncy V/Hz 120/60 208–240/60 120/60 | 208-240/60
Nominal current A 14 8.7 11.5 | 9.4
Energy consumption
kWh/24h 21.3 28.3 26.5
BTU 72693 96582 90439
AHT AC M AHT AC XL AHT AC XL SLIM
28.2 x 32.4 x 77.7
Depth incl. backspacer
47.0 x 38.5 x 77.7
Depth incl. backspacer
47.0 x 27.2 x 77.7
Depth incl. backspacer
AHT Cooling Systems USA Inc.
3235 Industry Drive
North Charleston
SC 29418
Tel. 800-905-4768 (toll free) or
843-767-6855
ISO 9001, ISO 14001,
OHSAS 18001, SA 8000
approved according to NSF/ANSI 7
approved according to UL 471
Email sales@us.aht.at
www.ahtusa.net
Subject to technical modifications and typographical errors. Version: 01/2014
