ATAS HBS090 User Manual

ATAS INTERNATIONAL, INC.

9 ¾”

1”

9”

Optional Sealant

SPECIFICATION DATA SHEET

1. PRODUCT NAME

RUMBA SHAKE

TM

HBS090

2. MANUFACTURER

ATAS INTERNATIONAL, INC.
Website: www.atas.com
Email: [e-mail]
Corporate Headquarters:
Allentown, PA 18106
Phone: [phone]
Fax: [phone]
Western Facility:
Mesa, AZ 85204
Phone: [phone]
Fax: [phone]
Southern Facility:
Maryville, TN 37801
Phone: [phone]

3. PRODUCT DESCRIPTION

Basic Uses:

With Rumba Shake, a Bermuda system,
the traditional vertical standing seams are
replaced by horizontal “stepped” reveals
spaced every 9”.

Composition & Materials:

Standard Oerings: Rumba Shake panels are
brake formed from .032 Aluminum; 24 gauge
Metallic Coated Steel.
Special Oerings: .040 Aluminum; 22 gauge
Metallic Coated Steel; 22 and 24 gauge 55%
Al-Zn alloy coated Steel with acrylic coating;
and 16 oz. Copper.

Sizes:

Rumba Shake panels are available with a 1”
height and in a 9 ¾” width, with a coverage
of 9” by panel length. Panel lengths are made
to customer specications, with a standard
length of 12’, and 2’ minimum to 20’ maximum
lengths available.

Colors & Finishes:

A choice of 30 stock colors is available in a
KYNAR 500® PVDF or HYLAR 5000® PVDF nish.
(Request color chart or chips). An anodized
nish is available in Clear or Dark Bronze.
Texture is smooth.

T-Bend Flexibility: ASTM D 4145
Mandrel Bend Flexibility: ASTM D 522
Impact Resistance: ASTM D 2794
Adhesion: ASTM D 3359
Water Immersion Resistance: ASTM D 870
Abrasion Resistance: ASTM D 968
Acid Resistance: ASTM D 1308
Acid Rain Resistance (Kesternich): ASTM G 87
or DIN 50018
Salt Spray: ASTM B 117
Cyclic Salt Spray: ASTM D 5894 and ASTM D
5487
Humidity Resistance: ASTM D 2247
Accelerated Weathering: ASTM D 822 and
ASTM G 155, ASTM G 151 or ASTM G 153
Color Retention, Florida Exposure:
ASTM D 2244
Chalking Resistance: ASTM D 4214
Cleveland Condensing Cabinet: ASTM D 4585
Cure Test, MEK Resistance: ASTM D 5402
Alkali Resistance, Sodium Hydroxide: ASTM D
1308 Procedure 7.2
Flame Spread Rating: ASTM E 84
Organic coatings meet requirements of AAMA
2605 when applied to aluminum.
Panel testing/ratings:
Uplift/Load: ASTM E 1592
Air Inltration: ASTM E 283
Water Penetration: ASTM E 331
UL Fire resistance rating design numbers: See
www.ul.com, le R12113, or contact ATAS for
current listing.
Impact Resistance: UL 2218
Galvanized Steel: ASTM A 653
55% Al-Zn alloy coated Steel: ASTM A 792
Aluminum: ASTM B 209
Copper: ASTM B 370
Coil Coating: ASTM A 755
Load Table available upon request.
Field Tested and Approved.

5. INSTALLATION

This panel is installed with at clips, 12” to 24”
on center. Recommended minimum slope
is 4:12. Optional factory sealant is available.
Installation manuals and hands-on training
via seminars are available through ATAS. Visit
www.atas.com for more information.

in matching color are also available for
fabrication of related accessories by the
installing contractor.

Cost:

Contact ATAS product distributors for current
pricing.

7. WARRANTY

Products coated with a uoropolymer, KYNAR
500® PVDF or HYLAR 5000® PVDF nish carry a
limited warranty against chalking and fading.

8. MAINTENANCE

Rumba Shake panels are virtually maintenance
free. Surface residue may be easily removed by
conventional cleaning methods. For painted
products, minor scratches should be touched
up with a matching paint, available from the
manufacturer.

9. TECHNICAL SERVICES

Complete technical information and literature
are available at www.atas.com. ATAS will assist
with design ideas and shop drawings.

10. FILING SYSTEM

• www.atas.com

• Additional product information is available

from the manufacturer upon request.

4. TECHNICAL DATA

KYNAR 500® PVDF or HYLAR 5000® PVDF based
nishes tested by paint supplier for:
Dry Film Thickness: ASTM D 1005, ASTM D
1400, ASTM D 4138 or ASTM D 5796
Specular Gloss: ASTM D 523
Pencil Hardness: ASTM D 3363

Rumba Shake
KYNAR 500® is a registered trademark of Arkema.
HYLAR 5000® is a registered trademark of Solvay Solexis, Inc.
© ATAS International, Inc. LRD0213 LAT722

TM

is a trademark of ATAS International, Inc.

6. AVAILABILITY & COST

Availability:

Rumba Shake panels are readily available
through ATAS product distributors. A
complete line of related components and
trim accessories is available to complete
the roof system. Flat sheet and/or coil stock
