User’s manual

CL4940/CD4930 Big button/big display telephone/answering system with caller ID/call waiting

Congratulations

on your purchase of this AT&T product. Before using this AT&T product, please read the Important safety information section on page 52 of this manual. Please thoroughly read this user’s manual for all the feature operations and troubleshooting information necessary to install and operate your new AT&T product. You can also visit our website at www.telephones.att.com or

call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

Model number: CL4940/CD4930

Type: Big button/big display telephone/answering system with caller ID/call waiting

Serial number: _________________________________________________________

Purchase date: _________________________________________________________

Place of purchase: ______________________________________________________________

Both the model and serial numbers of your AT&T product can be found on the bottom of the telephone base.

Save your sales receipt and original packaging in case it is necessary to return your telephone for warranty service.

Telephones identied with this logo have reduced noise and interference

when used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083 Compliant Logo is a trademark of the Telecommunications Industry Association. Used under license.

the AT&T logo are trademarks of AT&T Intellectual Property licensed to Advanced American Telephones, San Antonio, TX 78219. Printed in China.

Parts checklist

Your telephone package contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary.

adapter installed

Coiled handset cord

Abridged user’s manual

CL4940/CD4930 Big button/big display telephone/ answering system with caller ID/ call waiting

HandsetTelephone base with power

Telephone line cord

Wall-mount bracket

This abridged user’s manual provides you with basic installation and use instructions.

Please refer to the online user’s manual for a full set of installation and operation instructions at www.telephones.att.com/manuals. Before using this AT&T product, please read Important safety information on page 22 of this abridged user’s manual.

Abridged user’s manual

User’s manual

CL4940/CD4930 Big button/big display telephone/

answering system with caller ID/ call waiting

Table of contents

Getting started

Quick reference guide .............................. 1

Installation ........................................................3

Telephone installation .............................4

Installation options .....................................6

Tabletop to wall-mount

installation ............................................6

Wall-mount to tabletop

installation ............................................8

Telephone settings

Telephone settings .................................. 10

Set date/time ........................................ 10

Ringer volume ........................................11

Language ...................................................11

LCD contrast ............................................12

Dial mode ...................................................12

Telephone operation

Line power mode (no AC power) ....13

To make a call during a power

failure .....................................................13

To answer a call during a power

failure .....................................................13

Telephone operation .............................. 14

Making a call ...........................................14

On hook dialing (predialing)......... 14

Answering a call .................................... 14

Switching between handset and

speakerphone .................................14

Ending a call ............................................14

Last number redial ..............................15

Equalizer .....................................................15

Options while on calls ............................ 16

Volume control ..................................... 16

Call waiting............................................... 16

Mute ............................................................. 16

Chain dialing.............................................17

Audio Assist® .......................................... 18

Temporary tone dialing .................. 18

Getting started

Quick reference guide

MENU/SELECT

Press in idle mode to enter the main menu (page 10).

While in the menu, press

to conrm or save an

entry or setting.

Press to select a highlighted item.

CALL LOGq

Press to display the caller ID history (page 29).

Press to scroll down while in menus or lists.

While entering names or numbers, press to move

the cursor to the le.

REPEAT

During message playback, press to repeat the message currently playing (page 40).

During message playback, press twice to play the previous message (page 40).

Press in idle mode to record a memo (page 41).

PLAY/STOP

Press to start or stop message playback (page 40).

DIRECTORYp

Press to display the directory (page 20).

Press to scroll up while in menus or lists.

While entering names or numbers, press to move the cursor to the right.

SKIP

Press to skip a message during message playback (page 40).

ANS ON

Press to turn the answering

system on or o

(page 35).

CANCEL

While in a menu, press to cancel an operation, back up to the previous menu or exit the menu display.

REDIAL/PAUSE

Press to display the last number dialed (page 15).

While using the handset or speakerphone, press to dial the last number dialed (page 15).

While entering numbers, press to insert a three-second dialing pause. (pages 22, 23, and 31).

While storing numbers in the speed dial memory or directory, press to copy the last number dialed before entering any numbers (pages 19 and 23).

DELETE X

While reviewing the redial history, directory, or caller ID history, press to delete the displayed entry (pages 15, 22 and 30, respectively).

During playback, press to delete a message or announcement (pages 40 and 35).

Press twice in idle mode to delete all old messages (page 40).

Press to delete digits or characters when entering numbers or names.

Getting started

Quick reference guide

/EQUALIZER

During an outside call, message or announcement playback, press to change the audio quality to best suit your hearing (page 15).

SPEED DIAL

Press in idle mode to display the speed dial list (page 25).

FLASH

Press to put your current call on hold and take the new call when you receive a call waiting alert (page 16).

TONE

Press to switch to tone dialing temporarily during a call if you have pulse service (page 18).

When reviewing directory entries, press to move towards the end of the telephone number (page 20).

Extra large tilt display

Move the top of the display forward or backward to adjust the angle of the screen for maximum visibility.

AUDIO ASSIST®

Voices will sound louder and clearer if you press AUDIO ASSIST® while you are on a call using the handset (page 18).

pVOLUMEq

During message playback or call screening, press to adjust the listening volume (pages 40 and 39).

While in idle mode, press to adjust the base ringer volume (page 11).

While on a call, press to adjust the listening volume (page 16).

# (pound key)

When reviewing directory entries, press to move towards the beginning of the telephone number (page 20).

Press repeatedly to display other dialing options when reviewing a caller ID log entry (page 30).

Audio Assist® is a registered trademark of Advanced American Telephones.

MUTE

During a call, press to mute the microphone.

Press again to resume your conversation (page 16).

MIC

Microphone.

SPEAKER

Press to make or answer a call using the speakerphone (page 14).

Press to switch between speakerphone and handset (page 14).

Getting started

Installation

You must install the power adapter before using the telephone.

Install the telephone base close to a telephone jack and a power outlet not

controlled by a wall switch. The telephone base can be placed on a at surface

or vertically mounted on the wall (see pages 6-9).

If you subscribe to high-speed Internet service (DSL - digital subscriber line)

through your telephone line, you must install a DSL lter between the telephone

line cord and the telephone wall jack (see page 4). The lter prevents noise and caller ID problems caused by DSL interference. Please contact your DSL service

provider for more information about DSL lters.

Your product may be shipped with a protective sticker covering the telephone base display, remove it before use.

For customer service or product information, visit our website at

STOP!

See pages 4-5 for easy instructions.

www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

Avoid placing the telephone base too close to:

Communication devices such as television sets, VCRs, or cordless telephones.



Excessive heat sources.



Noise sources such as a window with trac outside, motors, microwave



ovens, refrigerators, or uorescent lighting.

Excessive dust sources such as a workshop or garage.



Excessive moisture.



Extremely low temperature.



Mechanical vibration or shock such as on top of a washing machine or work



bench.

Getting started

Telephone installation

Install the telephone, as shown below.

The telephone is ready for tabletop use. If you want to change to wall-mounting, see Installation options on page 6 for details.

Plug one end of the coiled handset cord into the handset jack on the le side

1. of the telephone base. Plug the other end into the jack on the bottom of the handset.

Plug one end of the telephone line cord into the telephone line jack on the

2. bottom of the telephone base. Route the telephone line cord through the slot. Plug the other end of the telephone line cord into a telephone wall jack or a DSL lter.

Plug the power adapter into an electrical outlet not controlled by a

3. wall switch.

Electrical outlet not controlled by a wall switch

Telephone wall jack

DSL lter (not included)

is required if you have DSL high-speed Internet service.

Route the power adapter cord and the telephone line cord through the slots.

Getting started

Telephone installation

Adjust the angle of the screen to reach maximum visibility.4.

NOTES:

Use only the power adapter provided with this product. To obtain a



replacement, visit our website at www.telephones.att.com or call

1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

The power adapter is intended to be correctly oriented in a vertical or oor



mount position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling, under-the-table or cabinet outlet.

You can use this telephone without the power adapter installed. See Line



power mode on page 13.

Aer you rst install your telephone, the system will prompt you to set the



date and time, and outgoing announcement. You can press CANCEL to skip the setting. The telephone displays its model number when in idle mode.

Getting started

Installation options

If you want to mount your telephone on a wall, use the provided wall-mount bracket to connect with a standard dual-stud telephone wall-mounting plate. If you do not have this mounting plate, you can purchase one from many hardware or consumer electronics retailers. Professional assistance may be required to install the mounting plate.

Tabletop to wall-mount installation

To install the telephone base in the wall-mount position, make sure you rst

unplug the power adapter cord and telephone line cord from the telephone base and wall outlets.

Li the handset and place it aside. Hold down the switch hook on the

1. telephone base, then slide the handset tab upwards to remove it from the slot. Rotate the handset tab 180 degrees. Push the handset tab down into the slot so it locks into position.

Switch hook

Handset tab

Align the tabs on the wall-mount bracket to the slots at the back of the

2. telephone base. Insert tab A on the top into its corresponding slot and click tabs B into their corresponding slots.

Getting started

Installation options

Plug one end of the telephone line cord into the telephone line jack on

3. the bottom of the telephone base. Plug the other end into a telephone

wall jack or a DSL lter. Bundle the telephone line cord and secure it with a

twist tie. Plug the power adapter into an electrical outlet not controlled by a

4. wall switch.

Electrical outlet not controlled by a wall switch

Route the power adapter cord through the slot.

Telephone wall jack

DSL lter (not included)

is required if you have DSL high-speed Internet service.

Place the telephone just above the studs on the wall-mounting plate. Slide

5. the telephone down until it is held securely on the wall-mounting plate. Place the handset on the telephone base.

Adjust the screen angle for maximum visibility. 6.

Getting started

Installation options

Wall-mount to tabletop installation

To change the telephone base from the wall-mount position to tabletop position, follow the steps.

Slide the telephone base upwards, then remove the telephone from the

1. wall-mounting plate.

Unplug the large end of the power adapter from the electrical outlet.

2. Remove the power adapter cord from the slot. Unplug the smaller end from the power jack on the bottom of the telephone base. Unplug the telephone line cord from the wall jack and the telephone base. Untie the bundled telephone line cord.

Li the handset and place it aside. Hold down the switch hook on the

3. telephone base, then slide the handset tab upwards to remove it from the slot. Rotate the handset tab 180 degrees. Push the handset tab down into the slot so it clicks into position.

Switch hook

Handset tab

Getting started

Installation options

Push the two tabs at the bottom of the wall-mount bracket, as indicated, and

4. remove the wall-mount bracket from the telephone.

Plug one end of the telephone line cord into the telephone line jack on the

5. bottom of the telephone base. Plug the other end into a telephone wall jack

or a DSL lter. Plug the small end of the power adapter into the power jack

on the bottom of the telephone base. Plug the large end into an electrical outlet not controlled by a wall switch. Route both cords through the slots.

Electrical outlet not controlled by a wall switch

Telephone wall jack

DSL lter (not included)

is required if you have DSL high-speed Internet service.

Route the power adapter cord and the telephone line cord through the slots.

Adjust the screen angle for maximum visibility. 6.

Telephone settings

Use the menu to change the telephone settings:

Press MENU/SELECT on the telephone when it is not in use to enter the main menu.

1. Press CALL LOGq or DIRECTORYp to scroll to the feature to be changed. When

2. scrolling through the menu, the > symbol indicates the selected menu item.

Press MENU/SELECT to select the highlighted item.

NOTE: Press CANCEL to cancel an operation, back up to the previous menu or exit the menu display. Press and hold CANCEL to return to idle mode.

Set date/time

The answering system announces the day and time of each message prior to playing it. Before using the answering system, set the date and time as follows. If you subscribe to caller ID service, the day, month and time are set automatically with each incoming call. The year must be set so that the day of the week can be calculated from the caller ID information.

To set the date and time manually:

When the telephone base is in idle mode, press

1. MENU/SELECT to enter the main menu.

Press CALL LOGq or DIRECTORYp to scroll to

2. Set date/time and then press MENU/SELECT.

Press CALL LOGq or DIRECTORYp to select the month,

3. then press MENU/SELECT, or enter the number using the dialing keys.

Press CALL LOGq or DIRECTORYp to select the day,

4. then press MENU/SELECT, or enter the number using the dialing keys.

Press CALL LOGq or DIRECTORYp to select the year,

5. then press MENU/SELECT, or enter the number using the dialing keys, then press MENU/SELECT to move on to set the time.

Press CALL LOGq or DIRECTORYp to select the hour,

6. then press MENU/SELECT, or enter the number using the dialing keys.

Press CALL LOGq or DIRECTORYp to select the minute, then press

MENU/SELECT, or enter the number using the dialing keys.

Press CALL LOGq or DIRECTORYp to highlight AM or PM, or press 2 for AM

8. or 7 for PM. Then, press MENU/SELECT to conrm. There is a conrmation tone and the screen returns to the previous menu.

Caller ID log

>Set date/time

Set date

?M/DD/2015

Set time

?H:MM --

NOTES:

If you want to make correction, press CANCEL to go back to the previous field.



If the clock is not set when a message is recorded, the system announces, “Time and day not



set,” before it plays the message.

Telephone settings

Ringer volume

You can set the ringer volume level to one of four levels or turn the ringer o. When the ringer is o, appears on the screen.

Press pVOLUMEq when the telephone is not in use.

-OR-

Press MENU/SELECT in idle mode to enter the main menu.

1. Use CALL LOGq or DIRECTORYp to scroll to Ringer

2. volume, then press MENU/SELECT.

Press CALL LOGq or DIRECTORYp, or pVOLUMEq to

3. sample each volume level.

Press MENU/SELECT to save your preference. There

is a conrmation tone and the screen returns to the

previous menu.

NOTES:

If the ringer volume is set to off, the telephone base is silenced for all incoming calls.



You can temporarily adjust the ringer volume when the telephone is ringing. The next



incoming call rings at the preset volume.

Set date/time

>Ringer volume

Ringer volume

Language

You can select the language used for all screen displays.

Press MENU/SELECT in idle mode to enter the main menu.

1. Use CALL LOGq or DIRECTORYp to scroll to Language,

2. then press MENU/SELECT.

Press CALL LOGq or DIRECTORYp to highlight English,

3. Français or Español.

Press MENU/SELECT. The screen displays a

4. conrmation message.

Press MENU/SELECT again to conrm. There is a

conrmation tone and the screen returns to the

previous menu.

NOTE: If you accidentally change the LCD language to French or Spanish, you can reset it back to English without going through the French or Spanish menus. Press MENU/SELECT in idle mode, then enter 3645474#. There is a confirmation tone.

Ringer volume

>Language

>English

Francais

Telephone settings

LCD contrast

You can set the contrast of the screen to one of four levels.

Press MENU/SELECT in idle mode to enter the main menu.

1. Use CALL LOGq or DIRECTORYp to scroll to

2. LCD contrast, then press MENU/SELECT.

Press CALL LOGq or DIRECTORYp to choose from 1, 2,

3. 3 or 4.

Press MENU/SELECT to save your preference. There

is a conrmation tone and the screen returns to the

previous menu.

Dial mode

The dial mode is preset to touch-tone dialing. If you have pulse (rotary) service, you must change the dial mode to pulse dialing before using the telephone.

Language >LCD contrast

4 >3

To set the dial mode:

1. Press MENU/SELECT in idle mode to enter the main menu.

2. Use CALL LOGq or DIRECTORYp to scroll to Dial mode, then press MENU/SELECT.

3. Use CALL LOGq or DIRECTORYp to highlight Touch tone or Pulse, then press MENU/SELECT. There is a confirmation tone and the screen returns to the previous menu.

LCD contrast >Dial mode

>Touch tone Pulse

Telephone operation

Line power mode (no AC power)

This telephone provides minimal functionality during a power failure. When AC power is not available, the screen is blank and many telephone features do not function. Only touch-tone dialing and handset volume adjustment are supported. The telephone uses power from the telephone line to enable you to make and answer calls using only the handset and dialing keys.

To make a call during a power failure

Li the handset and wait for the dial tone. The screen shows NO AC POWER.

1. Dial a telephone number using the dialing keys. Wait to hear each key tone

2. and make sure the digit appears on the screen before pressing the next dialing key.

To answer a call during a power failure

Li the handset.



NOTE: The screen does not show incoming caller ID information during a power failure.

Telephone operation

Making a call

Li the handset or press SPEAKER, then enter the telephone number.

The screen displays the elapsed time as you talk (in hours, minutes and seconds).

On hook dialing (predialing)

Enter the telephone number. Press DELETE X to make corrections when

1. entering the telephone number.

Li the handset or press SPEAKER.

Answering a call

Li the handset or press SPEAKER.



Switching between handset and speakerphone

To switch from handset to speakerphone during a call:

Press SPEAKER, then place the handset in the telephone base.



Elapsed time

0:00:05

9/16

10:34

To switch from speakerphone to handset during a call:

Li the handset.



Ending a call

Press SPEAKER, or place the handset in the telephone base.

Telephone operation

Last number redial

The telephone stores the last telephone number dialed (up to 32 digits).

To redial a number:

To display the most recently called number, press

1. REDIAL/PAUSE when the telephone is not in use.

Li the handset or press SPEAKER to call.

-OR-

Li the handset or press SPEAKER.

1. Press REDIAL/PAUSE to dial the number.

To delete a redial entry:

While the screen displays the redial number, press DELETE X to delete



the number from the redial memory. The screen shows Deleted with a confirmation tone.

NOTES:

The screen shows only the last 15 digits if the number has more than 15 digits.



If the redial list is empty, you will see Redial empty on the screen and hear an error tone when



you press REDIAL/PAUSE.

Redial

885-883-2445

Equalizer

The telephone equalizer enables you to change the quality of the audio to best suit your hearing.

While on a call, or listening to a message or announcement, press /EQUALIZER to select one of the four equalizer settings, Natural (default setting), Treble 1, Treble 2 or Bass. The screen shows EQ changed to Natural, EQ changed to Treble 1, EQ changed to Treble 2 or EQ changed to Bass, respectively. The current setting shows on the screen for 2 seconds.

NOTES:

The current equalizer setting remains unchanged until a new setting is selected.



If you press /EQUALIZER in idle mode, the telephone shows To change EQ set during call



with an error tone.

Telephone operation

Options while on calls

Volume control

You can set the listening volume to one of ve levels. While on a call, press pVOLUMEq to adjust the listening volume. The volume level indicator briey displays on the screen to indicate the setting.

Handset volume

When you are on a call using the handset, press

qVOLUME to decrease or VOLUMEp to increase the

9/16 10:34

handset listening volume.

Speaker volume

When you are on a call using the speakerphone, press

qVOLUME to decrease or VOLUMEp to increase the

Speaker volume

speaker volume.

Call waiting

If you subscribe to call waiting service from your telephone service provider, and someone calls while you are already on a call, you hear two beeps.

Press FLASH to put your current call on hold and take the new call.



Press FLASH at any time to switch back and forth between calls.



NOTE: Missed call waiting calls are counted as missed calls.

Mute

Use the mute function to turn o the microphone. You can hear the caller, but

the caller cannot hear you.

To mute a call:

While on a call, press MUTE. When mute is on, the MUTE light turns on.



To end mute a call:

Press MUTE again. When mute is o, the MUTE light turns o.



NOTE: Switching between the handset and speakerphone cancels the mute function.

+ 46 hidden pages

AT and T CL4940, CD4930 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Getting started

Quick reference guide

Installation

Telephone installation

Installation options

Telephone settings

Telephone settings

Set date/time

Ringer volume

Language

LCD contrast

Dial mode

Telephone operation

Line power mode (no AC power)

To make a call during a power failure

To answer a call during a power failure

Telephone operation

Making a call

On hook dialing (predialing)

Answering a call

Switching between handset and speakerphone

Ending a call

Last number redial

Equalizer

Options while on calls

Volume control

Call waiting

Mute
