FEATURES
Outdoor bullet camera
1080P Resolution Camera
SPECIFICATIONS
20m IR distance
AS-HDV-
20F
20m Outdoor Bullet Camera
Model Number
Image Sensor
Resolution
Signal System
Minimum Illumination
S/N Ratio
Synchronous System
IR Distance
IR Power On
Video Output
Power/Current
Lens
Weather Proof
Dimension (mm)
Weight (g)
Operating Conditions
AS-HDV-
1/3" Aptina 3.1MP CMOS Sensor
PAL / NTSC
0.01Lux/F1.2
More than 45dB
20 Meters
Photodiode AUTO Control
TVI / AHD
DC12V(+/550/(%10-mA
Board Len 3.6mm
220(W) x 65(H) x 55(D)
50+~10-℃ RH%95 MAX
20F
3MP
Internal
IP66
550
DISTRIBUTED BY:
Thank you for using our product.
www.aswar-g.com
www.facebook.com/aswarME
www.twitter.com/aswarME
NOTES:
Before providing power for the camera, please read this
user guide.
Do not attempt to disassemble the camera. If the
camera does not work, please contact us or your local
distributor.
OSD MENU CONNECTIONS INTRODUCTION
3D-NR ON/OFF
AE MODE
WB
DAY& NIG HT external / color / B&W / auto
ZONE
MASKING
MOTION
DIRECTION
VIDEO
STAN DAR D
LANGUAGE CHINESE / ENGLISH
LOAD DEFAULT
SOFT VERSION
SAVE&EXIT
EXIT
ENHANCE
MIRROR ON / OFF
FLIP ON / OFF
BRIGHTNESS 250 ...,20 ,10 ,0
ZOOM IN 5 ,4 ,3 ,2 ,1 ,0
COLOR
SENSITIVITY weak / low / middle / high
intelligent / global / center
center weight / black light
front / light / distinguish
AWB-PRO / AWB-TEMPORAL
AWB-AI / AWB-GW
AWB- CCT
sharpness / contrast /
saturation
mosaic / white / yellow / cyan
green / magenta / red / blue /
black
AREA NO.0 - AREA NO. 8
AREA NO.0 - AREA NO.4
PAL / NTSC
SCHEMATIC S
DVR
KEYBOARD
MENU
PRESS
AS-HDV-20F
POLARITY GUIDE
VIDEO
POWER
DC12V POWER SUPPLY
GND
VIDEO
DC12V
VIDEO
TROUBLESHOOTING
1. NO VIDEO OUTPUT AFTER PROVIDING POWER
Check power supply stability
Check power supply polarity
Check video cable signal from camera to DVR using a
ASWAR CCTV tester
Test camera output directly from camera to ASWAR CCTV
tester to ensure video cable and termination is correct
2. FLOWING INTERFERENCE RIPPLES ON VIDEO OUTPUT
Caused by power supply AC ripples, change power supply
Check monitor and DVR
3. CONTINUOUSLY CHANGING VIDEO BACKGROUND
COLORS
increase distance between lighting and camera
Use external synchronization on power supply
4. PICTURE SMEAR
Unstable power supply voltage, change the power supply
High impedance on cables, check cable quality and
termination
Congratulations for purchasing a ASWAR product. The ASHDV-20FHDV series is a feature-full product that adopts
the latest Sony sensor chip and driver. This camera enjoys
high resolution and real-time video capturing that is rich in color
and quality. It is also easy to install with a built-in -3axis bracket
making it both wall mount and ceiling mount.
“Please read this instruction manual carefully to ensure proper use of
the product.”
CAUTION: RISK OF ELECTRIC
SHOCK, DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER OR BACK. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
CAUTION: TO PREVENT ELECTRIC SHOCKS AND
RISK OF FIRE HAZARDS, DO NOT USE OTHER THAN
SPECIFIED POWER SOURCE.
NOTES:
Please note the camera’s storage and operating temperature
Avoid using the camera in environments of very high or very
low temperatures.
The operating temperature is °30-C to °60+C
(Recommended operating temperature is °10-C to °50+C)
Never make the camera face the sun or a bright object.
Do not mount the camera near by the radiator or heater.
Do not attempt to disassemble the camera. If the camera
does not work, please contact local distributor or our
company
