ASUSTeK Computer V66 Users Manual

Asus V66

User Manual

Contents

Welcome 5

Left View 6 Package Contents 6 Overview 7

Features 7 Specifications 9 Menu Map 9 Inserting the SIM card, mini SD card, and battery 11

Getting Started 11

Charging the battery 12

Low Battery Indicators 12 Turning the phone on/off 13 Function Keys 13

Unlocking the keypad 14 Standby Mode 15 Using the Menu 16 Text Entry 17

Basics 17

Choosing text entry methods 18

Calls 20

Making a call 20

Making International Calls 20 Answering a Call 20 Answer Mode 20 Canceling an Incoming Call 21 Diverting a Call 21

Redialing a Number 21 Call Logs 21

Returning a Missed Call 21 Call Log Options 22

Deleting Call Logs 22 Call Time/Cost 22 Options During a Call 23 Other call options 23 Adding Contacts 24

Adding a New Entry 24

Phonebook 24

Searching for a Contact 24

Quick Search 24

Search Entry 24 Copying and Moving 25 Deleting Contacts 25 Caller Groups 26 Extra Number 27 Phonebook Settings 27

My vCard 28 SMS 29

Composing an SMS Message 29

Messages 29

Common Words 30

Message Settings 30

SMS Counter 31

MMS 31

Writing an MMS Message 31 Viewing an MMS Message 32 Using Templates 32

Message Settings 32 Chat 33 E-mail 33 Voice Mail 34 Broadcast Message 34 Preferred Input 34

Settings 35

Manner 35

Manner Settings 35 Phone Settings 35 Shortcuts 35 Themes 36 Phone 36

Time and date 36

Handset Timer 36

Language 37

Preferred Input Method 37

Default Encoding Type 37

Display Settings 37

Greeting Text 37

Speed Dial 37

Arrow Key Settings 37

Auto Update of Date and Time 38 Call Settings 38

Hide My Number 38

Call Waiting 38

Call Forwarding 39

Call Barring 39 Line Switching 39 Call Time Reminder 39 Call Time Display 40 Auto Redial 40 Closed User Group 40 Call Filter 40

Network Settings 41

Network Selection 41 Preferred Network 41 Band Selection 41 GPRS Connection 41

Security Settings 42

SIM Lock 42 Phone Lock Code 42 Auto Keypad Lock 42 Fixed Dialing 42 Barred Dialing 42

Change Password 43 Factory Settings 43 Taking Photos 44

Camera 44

Zoom Function 44 Viewing and Managing

Photos 44

Photo Capture Settings 45

Camera Settings 45

Image Settings 45

Effect 46

Add Frame 46

Multi-Capture 46

Capture Timer 46 Default Storage 46 Restore Default 47

Recording Videos 47

Zoom Function 47

Viewing and Managing

Videos 47

Full-Screen Mode 48 Rewind and Fast Forward 48 Video Playback Speed 48 Volume 48 Capturing a Still Photo 48

Video Capture Settings 48

CamcorderSettings 48 Video Settings 49

Effect 49

CamcorderSettings 49 Default Storage 49 Restore Default 50

Media Center 51

Audio Player 51

Adding music files 51 Editing Music Files 51

FM Radio 52

FM Radio Options 52

Java 53

Java Settings 53

Games 54

Game Setting 54 Melody Composer 54 File Manager 55

Organizer 55

Viewing drive contents 55 Alarm 56 Calendar 56 Tasks List 56 Calculator 57 World Clock 57 Sound Recorder 57 Image editor 58 Stopwatch 58 Units Converter 58 Currency Converter 58 Health Manager 59 Service Provider Settings 60 WAP 60

Network 60

Browsing WAP pages 60 Scrolling 60 Viewing Links 60 WAP Settings 60

Data Account 61

Appendix 62

Additional Information 62 FCC Regulations 62 European Notice 62 RF Exposure Information (SAR) 63 Proper Disposal 64

Welcome

Congratulations on your purchase of an Asus V66 cell phone. The following illustration displays the features found on the front of your phone.

Speaker

Screen

Welcome

Enter key: Displays the main menu;

confirms selection of a menu item

Joystick: Includes up, down, right,

left keys for on-screen navigation

Left soft key: Displays the main

menu; selects left menu items

Call key: Answers a call; displays

previously dialed numbers

Left joystick key: Displays the

camera menu; scrolls left through

menu items

Up joystick key: Displays the SMS inbox; scrolls up through menu items

Right soft key: Displays phone book when idle; selects right menu items

Power/end key: Turns power on or off; ends a call; exits menu

Right joystick key: Displays the Media Center menu; scrolls right through menu items

Down joystick key: Displays your shortcuts menu; scrolls down through menu items

Left View Package Contents

Captures photos

Increases or decreases the volume for calls, key tones, or playing media files.

V66 handset 720 mAh Li-ion

USB cable

Accessory chain

User Manual

User manual

battery

Stereo headset Mini-SD card

Quick Start Guide

Quick start guide

Handset Manager

Manual

Handset Manager

manual

Travel charger

warranty card

Warranty card

Handset Manager

CD-ROM

Overview

The V66 is a stylish and fashionable new phone from Asus, with all the functions and utilities to make it a useful tool in today’s mobile world. The V66 comes equipped with a built-in camera, MMS/SMS messaging capability, organizer, java games, audio player, WAP, GPRS, and a mini SD card slot. In addition to the internal 30 MB phone memory, the mini SD card provides additional memory where you can store your contact information, messages, text, graphics, and audio files. The V66’s audio player enables you to play back your favorite music.

Features

• Wide variety of calling and messaging functions

• Built-in camera

• Media center with audio player, FM radio receiver, and games for your entertainment

• MMS and SMS messaging capability

• Personal information organizer with alarm, calendar, calculator and other useful tools to

manage your time

• WAP and GPRS capability to check e-mail or browse web services

Welcome

Specifications

System supported GSM900/1800/1900, Class 10 Size 99.8 x 43.8 x 18.7 mm Weight 90g Battery 720 mAh Li-ion Standby Time 200 ~ 300 hours Talk Time 2.5 ~ 4 hours Color Silver, Orange, Blue Display 1.8-inch, 256K colors, TFT, 128 x 160 Camera 300K pixel CMOS

Supports video recording

WAP Supports WAP 1.2.1 and WAP 2.0 Java Supports J2ME (CLDC + MiDP 1.0.3)

Messaging Supports SMS, EMS, MMS Ring tone 64 polyphonic ring tones

Phone book 300 sets + SIM card

Record Record an unlimited number of files, up to memory capacity Calendar 10 sets Internal Memory 30 MB External storage Mini-SD card PIM tool Alarm, calculator, worldwide clock, calendar, note, currency, timer, etc.

Note: All specifications are subject to change without further notice.

4/6/9/16 continuous shots

Built-in Java games

Supports SMF (standard MIDI format) and MP3

Caller ID with photos 10 sets for speed dialing 10 sets for voice messaging

Menu Map

Calls

• Missed Calls

• Dialed Calls

• Received Calls

• Delete Call Log

• Call Time

• Call Cost

• SMS Counter

• GPRS Counter

Phone Book

• Quick Search

• Search Entry

• Add New Entry

• Copy All

• Delete

• Delete All

• Caller Group

• Extra number

 Owner Number  Service Dial Number  SOS Number

• Settings

 Memory Status  Preferred Storage  Fields  My vCard

Messages

• SMS

• MMS

• Chat

• Email

• Voice Mail Server

• Broadcast Message

• Preferred Input

Settings

• Shortcuts

• Themes

• Phone Setup

 Time and Date  Schedule Power On/Off  Language  Preferred Input  Default Encoding  Display Characteristics

– Wallpaper – Screen Saver – Show Date and Time – Show Owner Number

 Contrast  Greeting Text  Speed Dial  Dedicated key  Auto update of date and time

• Call Setup

 Caller ID  Call Waiting  Call Divert  Call Barring  Line Switching  Call Time Reminder  Call Time Display  Auto Redial

Welcome

 Closed User Group  Call Filter

• Network Setup

 Network Selection  Preferred Networks  Band Selection  GPRS Connection

• Security Setup

 SIM Lock  Phone Lock  Auto Keypad Lock  Fixed Dial  Barred Dial  Change Password

• Restore Factory Settings

Camera

• Capture

 To Image Viewer  Camera Settings  Image Setting  Effect Setting  Add Frame  Cont Shot  Delay TimerStorage  Restore Default

• Video Recorder

 To Player  CamCorder Setting  Video Setting  Effect Setting  Storage  Restore Default

• My Album

• My Video

Media Center

• Audio Player

• FM Radio

• Java

• Java Setting

• Games

• Game Setting

• Melody Compose

Organizer

• Alarm

• Calendar

• To Do List

• Calculator

• World Clock

• Sound Recorder

• Image Editor

• Stopwatch

 Typical Stopwatch  nWay Stopwatch

• File Manager

• Units Converter

• Currency Converter

• Health

 BMI  Menstrual

Network

• Service Provider Settings

•WAP

• Data Account

Manner

Getting Started

Inserting the SIM card, mini SD card, and battery

When you register with a service provider, you receive a SIM card (Subscriber Identity Module card). Your phone must have a SIM card in order to make calls. The SIM card is a computer chip that contains your phone number, phonebook information, and service provider information. Handle it with care and do not bend it or expose it to static electricity or dirt. Be sure the power to your phone is off before you insert your SIM card.

The SIM card and the mini SD card slots are situated underneath the battery. To insert the cards, follow these steps:

1.Press the back cover and slide the cover off to remove it.

3.Lift the SIM card holder using your fingernail.

4.Insert the SIM card into the holder with the correct orientation. The gold contacts of the SIM card should face down.

5.Place the SIM card holder back in place.

6.To place the mini SD card, place the card in the slot with the gold contacts facing down.

Getting Started

2.Remove the battery. The battery compartment has a notch at the top to make it easier to grasp and remove it.

7.Secure the mini SD card in place with the metal clasp by moving it towards the card.

8.Place the battery back into the battery compartment noting the correct polarity.

9.Replace the battery cover. Place the back cover against the phone case, then slide it upwards to lock into place.

Caution:

• Use only the battery recommended by the manufacturer. Using an incompatible battery with the phone may cause risk of an explosion.

• Dispose of the used batteries as instructed by the manufacturer or ask your local authorities for assistance.

Charging the battery

1.Connect the charger plug to a power outlet.

2.Connect the charger to the socket at the bottom of the phone. The connector can only be inserted one way.

Note: For best battery performance, allow the battery to charge and discharge completely the first few times you use it.

Low Battery Indicators

The battery indicator in the upper right corner of the screen indicates how much charge remains in the battery. As additional reminders, when the battery is low, the phone emits a double beep. The message “battery low” also appears on the screen.

Note: If the battery has been deeply discharged, it may take several minutes before the battery level indicator is displayed.

T urning the phone on/off

To turn the phone on, do the following:

1.Hold down the power/end key until the screen lights up.

2.If needed, enter your SIM card PIN code and press the Enter key.

To turn the phone off, do the following:

• Press the power/end the phone shuts down.

Note: If you set an alarm using the Organizer menu and turn off the phone, the phone will turn itself on when the alarm is activated. After you disable the alarm, the phone prompts you if you want to keep the phone turned on or off. See the Organizer section for details about setting an alarm.

key and hold until

Function Keys

The following table lists the phone keys and their functions.

Power/end key

• Hold to turn the phone on or off.

• Press to stop an incoming call or cancel a call you are dialing.

• Press to exit a menu or submenu.

Call key

• Press to dial or answer calls.

• Hold to redial the last number called.

Left soft key

• Press to display the menu.

• Press to perform the function currently displayed in the lower left corner of the screen.

• Press to move left while navigating menus.

Right soft key

• Press to view phone book when the phone is in idle mode.

• Press to perform the function currently displayed in the lower right corner of the screen.

• Press to move right while navigating menus.

Getting Started

Up joystick key

• Press to scroll up through menu items.

• Press to display the SMS inbox when the phone is in standby mode

Down joystick key

• Press to scroll down through menu items.

• Press to display a list of your shortcuts when the phone is in standby mode.

Left joystick key

• Press to scroll left through menu items.

• Press to display the Camera menu when the phone is in standby mode.

Right joystick key

• Press to scroll right through menu items.

• Press to display the Media Center menu when the phone is in standby mode.

Enter key

• Press to display the main menu.

• Press to confirm selection of a menu item when the phone is in standby mode.

Unlocking the keypad

The keypad of the phone can be locked automatically after a specific time interval to prevent tampering or accidental pressing of any buttons. Refer to Security Setup in the Settings section to learn how to lock the keypad.

To unlock the keypad, do the following:

1.The screen shows Unlock in the lower right corner of the screen. Select this option by pressing the right soft key which is just under the word Unlock on the screen.

2.Press the # key on the keypad to unlock the keypad as prompted on the screen.

The keypad is then unlocked.

Standby Mode

When your phone is on, but not in use, it is in standby mode. During standby mode, the upper part of the display screen shows various icons.

The date and time is displayed at the lower center of the screen. Beneath the date and time are Menu in the left corner and Name in the right corner. Press the left soft key to view the main menu, and the right soft key to view the phone book.

The Standby screen icons are as follows:

Vertical bars indicate the strength of the GSM network signal. Four bars indicates that your current position has the best reception.

Line 1 or line 2 is selected for calls.

Alarm has been set.

A text message has been received.

A multimedia message has been received.

The SMS memory is full.

Indicates battery charge status.

Phone is using GPRS network.

Phone is in roaming mode.

Ringtone is enabled.

Ringtone is disabled.

Indicates a missed call.

Call divert is enabled,

Getting Started

Indicates the manner selected for the phone.

Using the Menu

Follow these tips to navigate through the menu and menu options.

• To view the menu, press the left soft key or the Enter key.

• Use the up, down, left, and right joystick

keys to move through the various menu items.

• The lower left corner of the screen

displays the name of the menu item currently selected while the lower right corner displays Back. Press the left soft

key (situated under the name of the menu item) to select the menu item. Press the right soft key which is situated under Back to exit the menu.

• Each menu item also displays a small

number beneath it. You can also press the number corresponding to a menu item, on the keypad to select the item.

• To quickly exit from the menu, press the

Power/End key.

• Use the joystick keys to select the submenu items and options. The right and left soft keys can also be used for selecting various options in submenus.

For example, to view missed calls, do the following:

1.Use the joystick keys to select Calls from the main menu.

2.Press the left soft key selection. The Calls submenu opens.

3.Press the left soft key Missed Calls option. A list of missed calls opens.

Network: Enables you to specify the WAP and data settings and set up GSM and GPRS settings. Enables access to the internet and to STK SIM

card services.

Messages: Gives you access to messages received. Compose and send text (SMS) and multimedia (MMS) messages here. You can also check email, chat, and broadcast a

message using this menu.

to confirm the

to select the

Manner: Enables you to select and customize the phone settings including the ring tone, volume, ring type, and

answer mode.

Settings: Lets you adjust phone settings such as call settings, themes, shortcuts, network settings, and security settings. You can also restore all settings to their factory default from

this menu.

Camera: Enables you to take pictures as well as record video with your phone. You can also access all your pictures and videos from this menu

item. Media Center: Consists of an audio

player, FM radio, games, and a melody composer.

Organizer: Contains useful tools such as an alarm, a calendar for scheduling appointments, a to do list, and a simple calculator. You can also record memos, edit simple images, manage all your data using a file

manager, or convert units or currency Phonebook: Enables you to manage

names and telephone numbers for easy access and caller recognition.

The following table provides a list of all the main menu items:

Calls: Stores information about calls made, received, and missed.

T ext Entry

When you add names to your phone book, send a text message, or use your WAP browser, you need to enter text. Your cell phone has several text entry methods. You can enter letters individually or with predictive text entry, which helps you complete words as you enter them. You can enter letters in upper case, lower case, or both, type simplified or traditional Chinese characters, or insert symbols.

Basics

• Use the alphanumeric keypad to enter letters and numbers. Each key is assigned multiple characters.

• Select Clear, in the lower right corner of the screen, to delete a letter if you make a mistake.

• To enter spaces between words, press the

key. The 9 space symbol appears.

Press the enter key or press the right soft key to select and enter a space. You can also view, select, and enter other

symbols by pressing the

key.

Getting Started

Key Assigned Characters

. , - ? ! ‘ @ : # $ / _ 1 A B C 2 D E F 3 G H I 4 J K L 5 M N O 6 P Q R S 7 T U V 8 W X Y Z 9 Space, 0

Choosing text entry methods

From any text entry screen, such as a text message window, select Options > Input

Method. Select Multitap (ABC for upper case abc for lower case letters or Abc for upper case

followed by lower case) for entering letters one at a time. Select Smart (ABC, Abc, or abc) to let the phone predict the words you are typing.

Multitap text entry

Multitap text entry enables you to enter individual letters one by one. This is ideal for adding a phonebook entry or entering a WAP address.

When you press a key, the characters ssigned to the key appear in the lower center of the screen. Press the key repeatedly to scroll through these characters. Pause for a moment and the selected letter appears on the screen. For practice, try entering text into a text message (SMS) as follows: From the menu, go to Messages > SMS > Write Message. Before entering text, first make sure that the entry method is set to multitap. Press Option and select Multitap abc. To enter the words “my phone” into the

text entry area, follow these steps:

1.Press the 6 key to select m.

2.Press the

key three times to select y.

3.Press 0 key, followed by the enter key or right soft key to enter a space.

4.Press

to enter p, then press 4 two

times to enter h. Continue in this fashion until the word “phone” is entered.

Smart text entry

Smart text entry is a predictive text entry method. It uses a built-in dictionary to predict the word you are typing. You can choose the correct word by pressing the keys repetitively and scrolling through the words suggested by the phone. By reducing the number of keystrokes, the smart text entry method helps some users to type messages more quickly.

Whenever you press a key, a list of possible characters or character combinations is created. To enter text, use the up and down joystick keys to find the character combination you want. Press the right joystick key to proceed entering the next character. If you make a mistake, press Clear.

Here is an example of how to enter the word “baby” using smart text entry.

1.First press the

key. The letter a

appears on the screen.

2.Press the

key again quickly to go to

the next suggestion which is ba. If you press the up/down joystick keys, the phone scrolls through all possible twoletter combinations of the letters a, b, and c.

3.Press the

key again quickly to

display three-letter combinations of the letters a, b, and c.

4.Press the up/down joystick keys to scroll through the possible words. When you see the bab combination, press the right joystick key to proceed to the next letter.

5.Press the

key and the letter x

appears. Press the up/down joystick keys to scroll through letter options and select y.

6.Press Option > Done when finished.

Note: For smart text entry to work properly, ensure the language settings in your phone match the language you want to type in. For setting language, see Phone Setup under Settings.

Numeric text entry

Numeric text entry allows you to create a text message composed of numbers. To use this method, select Option > Input Method and then select Numeric. Now you can directly input the numbers using the keypad.

Symbols text entry

With this method, you can enter various types of symbols. Select Option > Input Method > Insert Symbols. A list of symbols is displayed. Use the joystick keys to select the desired symbol and select OK when done.

Getting Started

Calls

Making a call

Follow these steps to place a call:

1.Enter the number you wish to dial using the keypad. If you make a mistake, select Clear to delete at any time. The right soft

key is just under the word Clear on the lower right screen; select this key to clear a number.

2.Press and hold down the Power/end

key to cancel the call and return to standby mode. Alternately, select Abort

using the right soft key to cancel the call.

3.Press the Call key to connect the call after you finish dialing the number.

4.Press the Power/end

nect the call.

Making International Calls

To dial an international call, do the following:

1. First enter a + by holding down the * key.

2. After the +, enter the international access code for the country you wish to dial, followed by the telephone number including the area code.

key to discon-

Answering a Call

When you receive a call, the phone alerts you by sounding the ring tone and vibration according to the specified ring tone and vibration settings. To answer the call, do the following:

1. Press the Call

2. Press the Power/end

call and disconnect.

Alternately, select Option > Answer to answer the call.

key to answer the call.

key to end the

Answer Mode

The default setting for the phone is to answer when you press the Call

can also set the phone to pick up by pressing any key. To enable the phone to answer a call by pressing any key, select Manner and then choose the manner setting that you want.

For example, if you select General, then choose Personalize > Answer Mode > Any Key. Set the Any Key option to On to enable the setting.

Remember to Activate the manner setting to make sure that the answer mode is set.

key. However, you

+ 44 hidden pages

ASUSTeK Computer V66 Users Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
