Notebook PC
Hardware Userʼs Manual
E4737/ May 2009
Contents
Table of Contents
1. Introducing the Notebook PC
About This Userʼs Manual ...............................................................................6
Notes For This Manual ........................................................................................... 6
Safety Precautions ..........................................................................................7
Preparing your Notebook PC...........................................................................9
2. Knowing the Parts
Top Side.........................................................................................................12
Bottom Side ...................................................................................................15
Left Side ........................................................................................................17
Right Side ......................................................................................................19
Front Side ......................................................................................................20
3. Getting Started
Power System ...............................................................................................22
Using AC Power ...................................................................................................22
Powering ON the Notebook PC ........................................................................... 23
The Power-On Self Test (POST) ..........................................................................23
Checking Battery Power ...................................................................................... 24
Charging the Battery Pack ................................................................................... 24
Power Options ..................................................................................................... 25
Power Management Modes ................................................................................. 26
Sleep and Hibernate ............................................................................................26
Thermal Power Control ........................................................................................ 26
Special Keyboard Functions ..........................................................................27
Colored Hot Keys ................................................................................................. 27
Microsoft Windows Keys ......................................................................................29
Multimedia Control Keys (on selected models) ...................................................30
Switches and Status Indicators .....................................................................31
Switches...............................................................................................................31
Status Indicators .................................................................................................. 32
4. Using the Notebook PC
Pointing Device..............................................................................................34
Using the Touchpad .............................................................................................34
2
Contents
Table of Contents (Cont.)
Touchpad Usage Illustrations ...............................................................................35
Caring for the Touchpad .......................................................................................37
Automatic Touchpad Disabling .............................................................................37
Storage Devices ............................................................................................38
Hard Disk Drive ....................................................................................................38
Memory (RAM).....................................................................................................38
Flash Memory Card Reader ................................................................................39
Connections...................................................................................................40
Network Connection ............................................................................................40
Wireless LAN Connection (on selected models) .................................................41
Windows Wireless Network Connection .............................................................. 42
Bluetooth Wireless Connection (on selected models) ......................................... 43
Appendix
Optional Accessories ................................................................................... A-2
Optional Connections ........................................................................................ A-3
Bluetooth Mouse Setup (optional) ..................................................................... A-4
Operating System and Software.................................................................. A-6
System BIOS Settings ....................................................................................... A-6
Common Problems and Solutions ..................................................................... A-9
Windows Vista Software Recovery .................................................................. A-16
Glossary .................................................................................................... A-18
Declarations and Safety Statements ......................................................... A-22
Notebook PC Information .......................................................................... A-32
3
Contents
4
1. Introducing the Notebook PC
About This Userʼs Manual
Notes For This Manual
Safety Precautions
Preparing your Notebook PC
There may be differences between your Notebook PC and the drawings shown in
this manual. Please accept your Notebook PC as being correct.
Photos and icons in this manual are used for artistic purposes only and do not
show what is actually used in the product itself.
5
1 Introducing the Notebook PC
About This Userʼs Manual
You are reading the Notebook PC Userʼs Manual. This Userʼs Manual provides
information on the various components in the Notebook PC and how to use them. The
following are major sections of this Userʼs Manuals:
1. Introducing the Notebook PC
Introduces you to the Notebook PC and this Userʼs Manual.
2. Knowing the Parts
Gives you information on the Notebook PCʼs components.
3. Getting Started
Gives you information on getting started with the Notebook PC.
4. Using the Notebook PC
Gives you information on using the Notebook PCʼs components.
5. Appendix
Introduces you to optional accessories and gives additional information.
Notes For This Manual
A few notes and warnings in bold are used throughout this guide that you should be aware of in order
to complete certain tasks safely and completely. These notes have different degrees of importance as
described below:
NOTE: Tips and information for special situations.
TIP: Tips and useful information for completing tasks.
IMPORTANT! Vital information that must be followed to prevent damage to data,
components, or persons.
WARNING! Important information that must be followed for safe operation.
< >
Text enclosed in < > or [ ] represents a key on the keyboard; do not actually type the
< > or [ ] and the enclosed letters.
[ ]
6
Introducing the Notebook PC 1
Safety Precautions
The following safety precautions will increase the life of the Notebook PC. Follow all precautions and
instructions. Except as described in this manual, refer all servicing to qualified personnel.
IMPORTANT! Disconnect the AC power and remove the battery pack(s) before
cleaning. Wipe the Notebook PC using a clean cellulose sponge or chamois cloth
dampened with a solution of nonabrasive detergent and a few drops of warm water
and remove any extra moisture with a dry cloth.
DO NOT place on uneven or unstable work surfaces. Seek servicing if
the casing has been damaged.
DO NOT press or touch the display
panel. Do not place together with
small items that may scratch or enter
the Notebook PC.
DO NOT expose to dirty or dusty environments. DO NOT operate during
a gas leak.
DO NOT leave the Notebook PC on
your lap or any part of the body in
order to prevent discomfort or injury
from heat exposure.
SAFE TEMP: This Notebook PC
should only be used in environments
with ambient temperatures between
10°C (50°F) and 35°C (95°F)
DO NOT place or drop objects on
top and do not shove any foreign
objects into the Notebook PC.
DO NOT expose to strong magnetic
or electrical fields.
DO NOT expose to or use near
liquids, rain, or moisture. DO NOT
use the modem during an electrical
storm.
Battery safety warning:
DO NOT throw the battery in fire.
DO NOT short circuit the contacts.
DO NOT disassemble the battery.
INPUT RATING: Refer to the rat-
ing label on the bottom of the Notebook PC and be sure that your power
adapter complies with the rating.
DO NOT use damaged power cords,
accessories, or other peripherals.
When replacing or upgrading the battery, hard drive, and memory, always
visit an authorized service center or
retailer for this Notebook PC.
DO NOT carry or cover a Notebook PC that is powered ON with any materials that will
reduce air circulation such as a carrying bag.
DO NOT use strong solvents such
as thinners, benzene, or other chemicals on or near the surface.
Incorrect installation of battery may
cause explosion and damage the
Notebook PC.
7
1 Introducing the Notebook PC
DO NOT throw the Notebook PC in municipal waste. This product has been designed
to enable proper reuse of parts and recycling. The symbol of the crossed out wheeled
bin indicates that the product (electrical, electronic equipment and mercury-containing
button cell battery) should not be placed in municipal waste. Check local regulations for
disposal of electronic products.
DO NOT throw the battery in municipal waste. The symbol of the crossed out wheeled
bin indicates that the battery should not be placed in municipal waste.
Transportation Precautions
To prepare the Notebook PC for transport, you should turn it OFF and disconnect all external peripherals to prevent damage to the connectors. The hard disk driveʼs head retracts when the power
is turned OFF to prevent scratching of the hard disk surface during transport. Therefore, you should
not transport the Notebook PC while the power is still ON. Close the display panel and check that it is
in the closed position to protect the keyboard and display panel.
CAUTION! The Notebook PCʼs surface is easily dulled if not properly cared for. Be
careful not to rub or scrape the Notebook PC surfaces.
Cover Your Notebook PC
Purchase a carrying bag to protect the Notebook PC from dirt, water, shock, and scratches.
Charge Your Batteries
If you intend to use battery power, be sure to fully charge your battery pack before going on long trips.
Remember that the power adapter charges the battery pack as long as it is plugged into the
computer and an AC power source. Be aware that it takes much longer to charge the battery pack
when the Notebook PC is in use.
Airplane Precautions
Contact your airline if you want to use the Notebook PC on the airplane. Most airlines will have
restrictions for using electronic devices. Most airlines will allow electronic use only between and not
during takeoffs and landings.
CAUTION! There are three main types of airport security devices: X-ray machines
(used on items placed on conveyor belts), magnetic detectors (used on people
walking through security checks), and magnetic wands (hand-held devices used on
people or individual items). You can send your Notebook PC and diskettes through
airport X-ray machines. However, it is recommended that you do not send your
Notebook PC or diskettes through airport magnetic detectors or expose them to
magnetic wands.
8
1
2
3
Introducing the Notebook PC 1
Preparing your Notebook PC
These are only quick instructions for using your Notebook PC. Read the later pages for detailed
information on using your Notebook PC.
1. Connect the AC Power Adapter
2. Open the Display Panel
3. Adjust the Display Panel 4. Turn ON the Notebook PC
IMPORTANT! When opening, DO NOT
force the display panel down to the table
or else the hinges may break! Never lift
the Notebook PC by the display panel!
The power switch turns ON and OFF the Notebook PC or putting the Notebook PC into sleep
or hibernation modes. Actual behavior of the
power switch can be customized in Windows
Control Panel > Power Options > System Settings.
9
1 Introducing the Notebook PC
10
2. Knowing the Parts
Basic sides of the Notebook PC
There may be differences between your Notebook PC and the drawings shown in
this manual. Please accept your Notebook PC as being correct.
Photos and icons in this manual are used for artistic purposes only and do not
show what is actually used in the product itself.
11
2 Knowing the Parts
Top Side
Refer to the diagram below to identify the components on this side of the Notebook PC.
The keyboard differs for each territory.
1
2
3
4
12
5
6
7
8
9
Knowing the Parts 2
1
2
3
4
5
Microphone (Built-in)
The built-in mono microphone can be used for video conferencing, voice narrations, or simple
audio recordings.
Camera (on selected models)
The built-in camera allows picture taking or video recording. Can be used with video
conferencing and other interactive applications.
Camera Indicator
The camera indicator shows when the built-in camera is in use. The camera may be auto-activated
by supported software.
Display Panel
The display panel functions the same as a desktop monitor. The Notebook PC uses
an active matrix TFT LCD, which provides excellent viewing like that of desktop
monitors. Unlike desktop monitors, the LCD panel does not produce any radiation or
flickering, so it is easier on the eyes. Use a soft cloth without chemical liquids (use
plain water if necessary) to clean the display panel.
Express Gate Key
Pressing this button will launch Express Gate. Refer to the Express Gate Userʼs Manual for details.
This key functions as the instant key for Power4Gear Hybrid when in Windows environment.
6
7
Power Switch
The power switch turns ON and OFF the Notebook PC or putting the Notebook PC into
sleep or hibernation modes. Actual behavior of the power switch can be customized in
Windows Control Panel “Power Options.”
Status Indicators (top)
Status indicators represent various hardware/software conditions. See indicator details in
section 3.
13
2 Knowing the Parts
8
9
Keyboard
The keyboard provides full-sized keys with comfortable travel (depth at which the
keys can be depressed) and palm rest for both hands. Two Windows function keys are
provided to help ease navigation in the Windows operating system.
Touchpad and Buttons
The touchpad with its buttons is a pointing device that provides the same functions as a
desktop mouse. A software-controlled scrolling function is available after setting up the
included touchpad utility to allow easy Windows or web navigation.
14
Knowing the Parts 2
Bottom Side
Refer to the diagram below to identify the components on this side of the Notebook PC.
The bottom side may vary in appearance depending on model.
121
WARNING! The bottom of the Notebook PC can get very hot. Be careful when handling the Notebook PC while it is in operation or recently been in operation. High
temperatures are normal during charging or operation. Do not use on soft surfaces
such as beds or sofas which may block the vents. DO NOT PUT THE NOTEBOOK
PC ON YOUR LAP OR OTHER PARTS OF THE BODY TO AVOID INJURY FROM THE
HEAT.
15
2 Knowing the Parts
1
2
Audio Speaker
The built-in stereo speaker system allows you to hear audio without additional attachments. The multimedia sound system features an integrated digital audio controller
that produces rich, vibrant sound (results improved with external stereo headphones or
speakers). Audio features are software controlled.
Flash Memory Slot
Normally an external memory card reader must be purchased separately in order to use
memory cards from devices such as digital cameras, MP3 players, mobile phones, and PDAs.
This Notebook PC has a built-in high-speed memory card reader that can conveniently read
from and write to many flash memory cards as mentioned later in this manual.
16
1 2 3 4 5 6
Knowing the Parts 2
Left Side
Refer to the diagram below to identify the components on this side of the Notebook PC.
1
2
3
Power (DC) Input
The supplied power adapter converts AC power to DC power for use with this jack. Power
supplied through this jack supplies power to the Notebook PC and charges the internal
battery pack. To prevent damage to the Notebook PC and battery pack, always use the
supplied power adapter. CAUTION: MAY BECOME WARM TO HOT WHEN IN
USE. BE SURE NOT TO COVER THE ADAPTER AND KEEP IT AWAY FROM
YOUR BODY.
Air Vents
The air vents allow cool air to enter and warm air to exit the Notebook PC.
IMPORTANT! Ensure that paper, books, clothing, cables, or other objects
do not block any of the air vents or else overheating may occur.
Display (Monitor) Output
Use the provided adapter to convert this proprietary display output port to a 15-pin D-sub
monitor port, which supports a standard VGA-compatible device such as a monitor or projector to allow viewing on a larger external display.
This is not an IEEE 1394 port. DO NOT connect an IEEE 1394 cable to this port.
17
2 Knowing the Parts
HDMI
4
HDMI Port
HDMI (High-Definition Multimedia Interface) is an uncompressed all-digital
audio/video interface between any audio/video source, such as a set-top box, DVD
player, and A/V receiver and an audio and/or video monitor, such as a digital television (DTV). Supports standard, enhanced, or high-definition video, plus multichannel digital audio on a single cable. It transmits all ATSC HDTV standards and
supports 8-channel digital audio, with bandwidth to spare to accommodate future
enhancements or requirements.
5
6
LAN Port
The RJ-45 LAN port with eight pins is larger than the RJ-11 modem port and supports
a standard Ethernet cable for connection to a local network. The built-in connector allows convenient use without additional adapters.
USB Port (2.0/1.1)
The USB (Universal Serial Bus) port is compatible with USB 2.0 or USB 1.1 devices such
as keyboards, pointing devices, cameras, hard disk drives, printers, and scanners connected
in a series up to 12Mbits/sec (USB 1.1) and 480Mbits/sec (USB 2.0). USB allows many
devices to run simultaneously on a single computer, with some peripherals acting as additional plug-in
sites or hubs. USB supports hot-swapping of devices so that most peripherals can be connected or
disconnected without restarting the computer.
18
21
3D
Knowing the Parts 2
Right Side
Refer to the diagram below to identify the components on this side of the Notebook PC.
1
3D
Headphone Output Jack
The stereo headphone jack (1/8 inch) is used to connect the Notebook PCʼs audio out signal to
amplified speakers or headphones. Using this jack automatically disables the built-in speakers.
2
USB Port (2.0/1.1)
The USB (Universal Serial Bus) port is compatible with USB 2.0 or USB 1.1 devices such
as keyboards, pointing devices, cameras, hard disk drives, printers, and scanners connected
in a series up to 12Mbits/sec (USB 1.1) and 480Mbits/sec (USB 2.0). USB allows many
devices to run simultaneously on a single computer, with some peripherals acting as additional plug-in
sites or hubs. USB supports hot-swapping of devices so that most peripherals can be connected or
disconnected without restarting the computer.
19
3 421 1
2 Knowing the Parts
Front Side
Refer to the diagram below to identify the components on this side of the Notebook PC.
1
2
3
4
Audio Speaker
The built-in stereo speaker system allows you to hear audio without additional attachments. The multimedia sound system features an integrated digital audio controller
that produces rich, vibrant sound (results improved with external stereo headphones or
speakers). Audio features are software controlled.
Flash Memory Slot
Normally an external memory card reader must be purchased separately in order to use
memory cards from devices such as digital cameras, MP3 players, mobile phones, and PDAs.
This Notebook PC has a built-in high-speed memory card reader that can conveniently read
from and write to many flash memory cards as mentioned later in this manual.
Power Indicator
The power indicator lights when the Notebook PC is turned ON and blinks slowly when the Notebook
PC is in the Suspend-to-RAM (Sleep) mode. This indicator is OFF when the Notebook PC is turned
OFF or in the Suspend-to-Disk (Hibernation) mode.
Bluetooth/Wireless Indicator
This is only applicable on models with internal Bluetooth (BT) and built-in wireless LAN. This indicator will light to show that the Notebook PCʼs built-in Bluetooth (BT) function is activated. When
the built-in wireless LAN is enabled, this indicator will also light. (Windows software settings are
necessary.)
20
3. Getting Started
Using AC Power
Using Battery Power
Powering ON the Notebook PC
Checking Battery Power
Powering Options
Power Management Modes
Special Keyboard Functions
Switches and Status Indicators
There may be differences between your Notebook PC and the drawings shown in
this manual. Please accept your Notebook PC as being correct.
Photos and icons in this manual are used for artistic purposes only and do not
show what is actually used in the product itself.
21
1
2
3
3 Getting Started
Power System
Using AC Power
The Notebook PC power is comprised of two
parts, the power adapter and the battery power
system. The power adapter converts AC power
from a wall outlet to the DC power required by
the Notebook PC. Your Notebook PC comes with
a universal AC-DC adapter. That means that you
may connect the power cord to any 100V-120V as
well as 220V-240V outlets without setting switches or using power converters. Different countries
may require that an adapter be used to connect the
provided US-standard AC power cord to a different standard. Most hotels will provide universal
outlets to support different power cords as well as
voltages. It is always best to ask an experienced
traveler about AC outlet voltages when bringing
power adapters to another country.
You can buy travel kits for the Notebook PC that includes power and modem adapters for almost every country.
WARNING! DO NOT connect the AC power cord to an AC outlet prior to connecting
the DC plug to the Notebook PC. Doing so may damage the AC-DC adapter.
IMPORTANT! Damage may occur if you use a different adapter to power the Notebook PC or use the Notebook PCʼs adapter to power other electrical devices. If
there is smoke, burning scent, or extreme heat coming from the AC-DC adapter,
seek servicing. Seek servicing if you suspect a faulty AC-DC adapter. You may damage both your battery pack(s) and the Notebook PC with a faulty AC-DC adapter.
This Notebook PC may come with either a two or three-prong plug depending on
territory. If a three-prong plug is provided, you must use a grounded AC outlet or
use a properly grounded adapter to ensure safe operation of the Notebook PC.
WARNING! THE POWER ADAPTER MAY BECOME WARM TO HOT WHEN IN USE.
BE SURE NOT TO COVER THE ADAPTER AND KEEP IT AWAY FROM YOUR BODY.
Unplug the power adapter or switch off the AC outlet to minimize the power
consumption when the Notebook PC is not in use.
22
Getting Started 3
Powering ON the Notebook PC
The Notebook PCʼs power-ON message appears on the screen when you turn it ON. If necessary, you
may adjust the brightness by using the hot keys. If you need to run the BIOS Setup to set or modify
the system configuration, press [F2] upon bootup to enter the BIOS Setup. If you press [Tab] during
the splash screen, standard boot information such as the BIOS version can be seen. Press [ESC] and
you will be presented with a boot menu with selections to boot from your available drives.
Before bootup, the display panel flashes when the power is turned ON. This is part
of the Notebook PCʼs test routine and is not a problem with the display.
IMPORTANT! To protect the hard disk drive, always wait at least 5 seconds after
turning OFF your Notebook PC before turning it back ON.
WARNING! DO NOT carry or cover a Notebook PC that is powered ON with any materials that will reduce air circulation such as a carrying bag.
The Power-On Self Test (POST)
When you turn ON the Notebook PC, it will first run through a series of software-controlled diagnostic tests called the Power-On Self Test (POST). The software that controls the POST is installed
as a permanent part of the Notebook PCʼs architecture. The POST includes a record of the Notebook
PCʼs hardware configuration, which is used to make a diagnostic check of the system. This record is
created by using the BIOS Setup program. If the POST discovers a difference between the record and
the existing hardware, it will display a message on the screen prompting you to correct the conflict by
running BIOS Setup. In most cases the record should be correct when you receive the Notebook PC.
When the test is finished, you may get a message reporting “No operating system found” if the hard
disk was not preloaded with an operating system. This indicates that the hard disk is correctly detected
and ready for the installation of a new operating system.
Self Monitoring and Reporting Technology
The S.M.A.R.T. (Self Monitoring and Reporting Technology) checks the hard
disk drive during POST and gives a warning message if the hard disk drive requires servicing. If any critical hard disk drive warning is given during bootup,
backup your data immediately and run Windows disk checking program. To run
Windowʼs disk checking program: click Start > select Computer > right-click
a hard disk drive icon > choose Properties > click the Tools tab > click Check
Now > click Start. You can also select “Scan ... sectors” for more effective scan
and repair but the process will run slower.
IMPORTANT! If warnings are still given during bootup after running a software disk
checking utility, you should take your Notebook PC in for servicing. Continued use
may result in data loss.
23
3 Getting Started
Checking Battery Power
The battery system implements the Smart Battery standard under the Windows environment, which
allows the battery to accurately report the amount of charge left in the battery. A fully-charged battery
pack provides the Notebook PC a few hours of working power. But the actual figure varies depending
on how you use the power saving features, your general work habits, the CPU, system memory size,
and the size of the display panel.
Screen captures shown
here are examples only and
may not reflect what you
see in your system.
You will be warned when
battery power is low. If you
continue to ignore the low
battery warnings, the Notebook PC eventually enters
suspend mode (Windows
default uses STR).
Left-click the battery icon
WARNING! Suspend-to-RAM (STR) does not last long when the battery power is
depleted. STR is not the same as power OFF. STR requires a small amount of power
and will fail and lose data if no power is available due to complete battery depletion
or no power supply (e.g. removing both the power adapter and battery pack).
Right-click the battery icon
Pointer over the battery icon
without power adapter.
Pointer over the battery icon
with power adapter.
Charging the Battery Pack
Before you use your Notebook PC on the road, you will have to charge the battery pack. The battery
pack begins to charge as soon as the Notebook PC is connected to external power using the power
adapter. Fully charge the battery pack before using it for the first time. A new battery pack must
completely charge before the Notebook PC is disconnected from external power. It takes a few hours
to fully charge the battery when the Notebook PC is turned OFF and may take twice the time when
the Notebook PC is turned ON. The battery status indicator on the Notebook PC turns OFF when the
battery pack is charged.
The battery starts charging when the charge remaining in the battery drops below
95%. This prevents the battery from charging frequently. Minimizing the recharge
cycles helps prolong battery life.
The battery stops charging if the temperature is too high or the battery voltage is
too high.
24
