ASUSTeK Computer TF700T Users Manual
ASUS Transformer Pad
User Manual
TF700/TF0070 Series
EXXXX
ASUS is devoted to creating environment-friendly products/
packagings to safeguard consumers’ health while minimizing
the impact on the environment. The reduction of the number
of the manual pages complies with the reduction of carbon
emission.
For the detailed user manual and related information, refer
to the user manual included in the device or visit the ASUS
Support Site at http://support.asus.com/
There are three main types of airport security devices: X-ray machines (used
on items placed on conveyor belts), magnetic detectors (used on people
walking through security checks), and magnetic wands
(hand-held devices used on people or individual items). You can send your
ASUS Transformer Pad through airport X-ray machines. But do not send
your ASUS Transformer Pad through airport magnetic detectors or expose
it to magnetic wands.
Airplane Precautions
Ask an airline personnel if you want to use your ASUS Transformer Pad onboard
an aircraft. Most airlines have restrictions for using electronic devices. Most
airlines allow electronic use only between and not during takeos and landings.
Charging Your Batteries
If you intend to use battery power, be sure to fully charge your battery pack
before going on long trips. Remember that the power adapter charges the
battery pack as long as it is plugged into the computer and an AC power source.
Be aware that it takes much longer to charge the battery pack when the ASUS
Transformer Pad is in use.
Fully charge the battery up to eight hours for the rst-time use. The battery
reaches its maximum capacity after one full charging and discharging cycle.
+eXXXX_TF700_TF0070_series_UM.in1 1 5/16/12 6:11:34 PM
ASUS Transformer Pad Manual
2
Package Contents
• If any of the items is damaged or missing, contact your retailer.
• The bundled power plug varies with country or region.
ASUS Transformer Pad USB Charger
User Manual
USB Dock cable User Manual
Cleaning cloth Warranty Card
+eXXXX_TF700_TF0070_series_UM.in2 2 5/16/12 6:11:36 PM
ASUS Transformer Pad Manual
3
Your ASUS Transformer Pad
11
2
1
12
3
5
4
6
8
10
9
14
13
15
7
12
+eXXXX_TF700_TF0070_series_UM.in3 3 5/16/12 6:11:37 PM
ASUS Transformer Pad Manual
4
1
Power button
Press and hold the Power button for one second to power on your
ASUS Transformer Pad.
When the ASUS Transformer Pad is powered on, press the Power
button to put the ASUS Transformer Pad into sleep mode or wake it
up from sleep mode.
Press the Power button for one second to display the shutdown
dialog box, and tap OK.
Battery charge indicator (dual-color)
Dim: The power charger is not plugged in the ASUS Transformer Pad.
Green: The battery level is up to 100%
Orange: The ASUS Transformer Pad is in battery charging mode.
2
Volume key
Press this button to increase or decrease the system volume.
3
SIM card slot
Insert a SIM card into this slot.
4
Micro SD Card Slot
Insert Micro SD card into this slot.
5
Reset button
If the system becomes unresponsive, use a paper clip to press the
reset button and force the ASUS Transformer Pad to restart.
Forcing the system to restart may result in data loss. We strongly
recommend that you back up your important data regularly.
6
Micro HDMI port
Insert a micro HDMI cable into this port to connect to a highdenition multimedia interface (HDMI) device.
7
Headphone output/Microphone input combo jack
The stereo combo jack (3.5mm) connects the ASUS Transformer Pad’s
audio out signal to amplied speakers or headphones. Using this jack
automatically disables the built-in speaker.
The jack is also designed to connect the microphone used for voice
narrations or simple audio recordings.
+eXXXX_TF700_TF0070_series_UM.in4 4 5/16/12 6:11:37 PM
