ASUSTeK Computer TF300TL Users Manual
ASUS Transformer Pad
1
ASUS Transformer Pad QSG
TF300TL 3G Connection Manager
E7220
Installing SIM card
1. Use a straightened paper clip to press the SIM card tray eject button.
2. Remove the tray from the slot. Orient and place the SIM card on the tray.
15060-06G00000
3. Firmly push the SIM card tray back to the slot.
ASUS Transformer Pad
2
Conguring APN settings
Your ASUS Transformer Pad automatically detects and connects to the
3G network once you install the SIM card. If not, follow the instructions to
manually congure the Access Point Name (APN) settings on your ASUS
Transformer Pad.
To congure APN settings
1. Tap the Apps menu on the top right corner of the Home Screen and tap
Settings.
2. Tap More... under Wireless & networks on the left panel and tap
Mobile networks.
1. The 3G antenna is placed on the top side of your ASUS Transformer
Pad.
2. ASUS Transformer Pad supports the Long Term Evolution Standard
(LTE), the wireless standard for high-speed data transfer. Your ASUS
Transformer Pad’s LTE icon varies with dierent mobile service
providers/carriers.
ASUS Transformer Pad
3
3. Tap Access Point Names.
4. Tap the service or network you would like to connect to.
