Notebook PC User Manual
Tablet
Your Notebook PC comes with a tablet that suit your mobile needs. The tablet is also equipped with its own features for work and play which can be accessed using touch screen gestures.
Top View
Ambient light sensor
Touch screen
panel
Camera
Camera indicator
E9349_T100TAR_UM_14pages.indd 2 2014/7/4 下午 03:55:33
Rear View
MicroSD card slot
Audio
speaker
Micro USB
2.0 port
Micro HDMI
port
Microphone
Headphone output/Microphone input combo jack port
Battery charge indicator
Power button
Volume button
Windows® button
Audio speaker
Notebook PC User Manual
Bottom Side
Hinge hole
Dock port
Hinge hole
Mobile dock
Connecting the mobile dock to your tablet allows you to use both devices as a Notebook PC. The mobile dock provides additional input features to your tablet via its touchpad and keyboard functions.
NOTE: The keyboard's layout may vary per region or country.
Top View
Latch hook
Dock connector
Latch hook
Hinge
Release button
Keyboard
Touchpad
E9349_T100TAR_UM_14pages.indd 3 2014/7/4 下午 03:55:33
Notebook PC User Manual
Left Side
1
2
USB 3.0 port
Getting started
1. Dock the tablet to the mobile dock.
E9349_T100TAR_UM_14pages.indd 4 2014/7/4 下午 03:55:33
Notebook PC User Manual
2. Charge your Notebook PC.
A. Connect the micro USB cable to the power adapter.
B. Plug the micro USB connector into your Notebook PC.
C. Plug the power adapter into a grounded power outlet.
Charge the Notebook PC for 8 hours before using it in battery mode for the rst time.
IMPORTANT! The power adapter and its specication may vary with your package. We recommend you to use the bundled power adapter.
3. Press the power button.
E9349_T100TAR_UM_14pages.indd 5 2014/7/4 下午 03:55:34
Notebook PC User Manual
Safety notices for your Notebook PC
WARNING!
The bottom of the Notebook PC can get warm to hot while in use or while charging the battery pack. When working on your Notebook PC, do not place it on surfaces that can block the vents.
CAUTION!
• This Notebook PC should only be used in environments with ambient temperatures between
5°C (41°F) and 35°C (95°F).
• Refer to the rating label on the bottom of your Notebook PC and ensure that your power
adapter complies with this rating.
• The power adapter may become warm to hot while in use. Do not cover the adapter and keep
it away from your body while it is connected to a power source.
IMPORTANT!
• Ensure that your Notebook PC is connected to a grounded power adapter before turning it
on for the rst time.
• When using your Notebook PC on power adapter mode, the socket outlet must be near to the
unit and easily accessible.
• Locate the input/output rating label on your Notebook PC and ensure that it matches the
input/output rating information on your power adapter. Some Notebook PC models may have multiple rating output currents based on the available SKU.
• The power adapter and its specication may vary with your package. We recommend you to
use the bundled power adapter.
• Power adapter information:
- Input voltage: 100-240Vac
- Input frequency: 50-60Hz
- Rating output current: 2A (10W)/3A (15W)
- Rating output voltage: 5V
WARNING!
Read the following precautions for your Notebook PC’s battery:
• Only ASUS-authorized technicians should
remove the battery inside the device.
• The battery used in this device may present
a risk of re or chemical burn if removed or disassembled.
• Follow the warning labels for your personal
safety.
• Risk of explosion if battery is replaced by an
incorrect type.
• Do not dispose of in re. • Keep the battery and other small
• Never attempt to short-circuit your
Notebook PC’s battery.
• Never attempt to dissamble and
reassemble the battery.
• Discontinue usage if leakage is found.
• This battery and its components must be
recycled or disposed of properly.
components away from children.
E9349_T100TAR_UM_14pages.indd 6 2014/7/4 下午 03:55:34
Notebook PC User Manual
Copyright Information
You acknowledge that all rights of this Manual remain with ASUS. Any and all rights, including without
limitation, in the Manual or website, are and shall remain the exclusive property of ASUS and/or its
licensors. Nothing in this Manual intends to transfer any such rights, or to vest any such rights to you.
