ASUSTeK Computer RT1E00 User Manual

RT-AC1200G Dual Band

¨

2x2 Wireless-AC 1200 Gigabit

Router

Quick Start Guide

NA10332 / First Edition / May 2015

na10332_rt-ac1200g_qsg.indb 1 2015/6/8 11:50:49

Table of contents

English ............................................................................................................................. 3

繁體中文 ........................................................................................................................ 14

Français ........................................................................................................................... 25

Português .......................................................................................................................36

Español ............................................................................................................................ 47

na10332_rt-ac1200g_qsg.indb 2 2015/6/8 11:50:51

English

A quick look

1. Power LED 7. Power button

2. LAN 1~4 LED 8. USB 2.0 port

3. WAN (Internet) LED 9. Reset button

4. 2.4GHz LED / 5GHz LED 10. WAN (Internet) port

5. USB LED 11. LAN 1 ~ 4 ports

6. Power (DC-IN) port 12. WPS button

3

na10332_rt-ac1200g_qsg.indb 3 2015/6/8 11:50:52

English

Package contents

RT-AC1200G Wireless Router AC adapter

Network cable (RJ-45) Quick Start Guide

NOTE: If any of the items is damaged or missing, contact
your retailer.

NOTES:

• USB External HDD/Flash disk:

• The wireless router works with most USB HDDs/
Flash disks up to 4TB and supports read-write access for
FAT16, FAT32, NTFS, and HFS+.

• To safely remove the USB disk, launch the web GUI
(http://192.168.50.1), then in the Network Map page's
upper right corner, click the USB icon and click Eject
USB 2.0.

• Incorrect removal of the USB disk may cause data
corruption.

• For the list of le system and hard disk partitions that
the wireless router supports, visit

http://event.asus.com/networks/disksupport

• For the list of printers that the wireless router supports,

visit

http://event.asus.com/networks/printersupport

4

na10332_rt-ac1200g_qsg.indb 4 2015/6/8 11:50:52

English

Installing your router

IMPORTANT: Before installing the router, ensure that

Internet connection is available

1. Position your wireless router.

For the optimal wireless transmission between the wireless router
and connected wireless devices, ensure that you:

• Place the wireless router in a centralized area for a maximum
wireless coverage for the network devices.

• Keep the wireless router away from metal obstructions and away
from direct sunlight.

• Keep the wireless router away from 802.11g or 20MHz only Wi-Fi
devices, 2.4GHz computer peripherals, Bluetooth devices, cordless
phones, transformers, heavy-duty motors, uorescent lights,
microwave ovens, refrigerators, and other industrial equipment to
prevent signal interference or loss.

• Always update to the latest rmware. Visit the ASUS website at
http://www.asus.com to get the latest rmware updates.

• To ensure the best wireless signal, orient the four detachable
antennas as shown in the drawing below.

°

90

°

90

5

na10332_rt-ac1200g_qsg.indb 5 2015/6/8 11:50:52

English

2. Prepare your modem.

a. Unplug the AC adapter from the power outlet and disconnect it

from your cable/ADSL modem.

b. Disconnect the network cable from your cable/ADSL modem.
c. Reboot your computer (recommended).

Modem

c

a

b

WARNING! Before disconnecting the wires/cables, ensure

that your cable/ADSL modem has been turned o for at
least two minutes. If your modem has a backup battery,
remove it as well.

3. Set up your wireless environment.

RT-AC1200G

a

1

4

d

Modem

Internet

WAN

c

3

OFF!

LAN

2

b

6

na10332_rt-ac1200g_qsg.indb 6 2015/6/8 11:50:53

English

a. Insert your wireless router’s AC adapter to the DC-IN port and

plug it to a power outlet.

b. Using the bundled network cable, connect your computer to

your wireless router’s LAN port. Ensure that the WAN and LAN
LEDs are blinking.

c. Using another network cable, connect your modem to your

wireless router’s WAN port.

d. Insert your modem’s AC adapter to the the DC-IN port and plug

it to a power outlet.

4. Disable some settings on your computer.

a. Disable the proxy server, if enabled.
b. Set the TCP/IP settings to automatically obtain an IP address.
c. Disable the dial-up connection, if enabled.

NOTE: For more details on disabling your computer set-

tings, refer to Frequently Asked Questions (FAQs).

7

na10332_rt-ac1200g_qsg.indb 7 2015/6/8 11:50:53

English

Setting up your router using the Quick Internet
Setup Wizard

To set up your router using QIS ((Quick Internet Setup):

1. Press the power button at the back of your router. Ensure that
the Power, LAN and WAN LEDs are on.

2. Launch your web browser such as Internet Explorer, Firefox,
Google Chrome, or Safari.

NOTE: If QIS does not launch automatically, enter
http://192.168.50.1 or http://router.asus.com in the ad­dress bar and refresh the browser again.

3. Assign your router login name and password and click Next.
You will need this login name and password to log into RT­AC1200G to view or change the router settings. You can take
note of your router login name and password for future use.

4. The wireless router’s Quick Internet Setup (QIS) feature auto­matically detects if your ISP connection type is Dynamic IP,
PPPoE, PPTP, L2TP, and Static IP. Please obtain the necessary
information about your Internet connection type from your In­ternet Service Provider (ISP). If your connection type is Dynamic
IP (DHCP), QIS wizard will automatically direct you to the next
step.

NOTE: If your connection type is Static IP, choose Static
IP and click Next. Key in IP address, subnet mask, default

gateway and DNS server information provided by your ISP.
Click Next to proceed.

8

na10332_rt-ac1200g_qsg.indb 8 2015/6/8 11:50:53

English

5. Assign the network name (SSID) and security key for your

2.4GHz and 5GHz wireless connection. Click Apply when done.

6. Your Internet and wireless settings are displayed. Click Next to
continue.

7. Read the wireless network connection tutorial. When done,
click Finish.

NOTES:

• You can assign a network name with up to 32 characters.

• Watch the setup tutorial video if needed.

9

na10332_rt-ac1200g_qsg.indb 9 2015/6/8 11:50:53

English

Connect to the wireless network

There are two ways for your wireless clients (notebook, tablet
PC, smartphone and so on) to connect to RT-AC1200G’s wireless
network.

Connect to the wireless network manually

To connect to the wireless network manually:
To connect to the wireless network manually:

1. Enable the Wi-Fi function on your wireless client to scan for
available wireless networks.

2. Select the SSID or network name that you assigned to your RT­AC1200G’s network.

3. Enter the password and click Connect.

Connect to the wireless network through WPS

RT-AC1200G has a WPS (Wi-Fi Protected Setup) button for you to
connect your wireless client to RT-AC1200G’s network without
entering password.
To connect to the wireless network through WPS:

1. Press the WPS button at the back of RT-AC1200G. Refer to the
section A quick look for the location of the WPS button).

2. Press the WPS button of your wireless client within two min­utes or follow the WPS instructions that came with the wireless
client. When connecting via WPS, the WPS LED on your router
blinks fast.

3. Wait until your router’s WPS LED turns into a solid light indicat­ing a successfully connection between your router and your
wireless client.

10

na10332_rt-ac1200g_qsg.indb 10 2015/6/8 11:50:53

English

Managing the router via the ASUSWRT web GUI

Your wireless router comes with the intuitive ASUSWRT web
graphical user interface. ASUSWRT allows you to easily congure
its various features through a web browser such as Internet Explor­er, Firefox, Safari, or Google Chrome.

NOTE: Use the search bar on the bottom of the interface
to get more information from ASUS technical support site
http://support.asus.com.

IMPORTANT:

• For more details on using your
router's Web GUI, refer to the user
manual.

• Alway check and upgrade rmware
to the latest version for better
experience.

• Visit ASUS Networking video
channel for tutorial videos on
featured functions.

11

na10332_rt-ac1200g_qsg.indb 11 2015/6/8 11:50:53

English

Frequently Asked Questions (FAQs)

After following the steps, I still cannot access the wireless
router’s web graphics user interface (web GUI) to congure the
wireless router settings.

Ensure that your PC's proxy settings are disabled and your PC'S
IP address is obtained from the DHCP server automatically. for
details on disabling the proxy settings, visit the ASUS Support site
at http://support.asus.com. For details on using the DHCP server to
obtain IP addresses automatically, refer to your Windows® or Mac
operating system's help feature.

The client cannot establish a wireless connection with the
router.

Out of Range:

• Put the router closer to the wireless client.

• Try to change the channel settings.

Authentication:

• Use wired connection to connect to the router.

• Check the wireless security settings.

• Press the Reset button at the rear panel for more than ve
seconds.

Cannot nd the router:

• Press the Reset button at the rear panel for more than ve
seconds.

• Check the setting in the wireless adapter such as SSID and
encryption settings.

Cannot access the Internet via wireless LAN adapter.

• Move the router closer to the wireless client.

• Check whether the wireless adapter is connected to the correct

wireless router.

12

na10332_rt-ac1200g_qsg.indb 12 2015/6/8 11:50:53

English

• Check whether the wireless channel in use conforms to the
channels available in your country/area.

• Check the encryption settings.• Check if the ADSL or Cable con­nection is correct.

• Retry using another Ethernet cable.

If the ADSL “LINK” light blinks continuously or stays o,
Internet access is not possible - the Router is unable to
establish a connection with the ADSL network.

• Ensure that all your cables are all properly connected .

• Disconnect the power cord from the ADSL or cable modem,
wait a few minutes, then reconnect the cord.

• If the ADSL light continues to blink or stays OFF, contact your
ADSL service provider.

Network name or encryption keys are forgotten.

• Try setting up the wired connection and conguring the wire­less encryption again.

• Press the Reset button of the wireless router for more than ve
seconds.

• Factory default settings:

User name / Pass­word: admin / admin

IP address:

192.168.50.1

SSID:
Check the rating label
on the back side of
your router

Where can I nd more information about the wireless router?

• User Manual in the support CD

• Online FAQ site: http://support.asus.com/faq

• Technical Support site: http://support.asus.com

• Customer Hotline: Refer to the Support Hotline in this Quick
Start Guide

13

na10332_rt-ac1200g_qsg.indb 13 2015/6/8 11:50:53

繁體中文

認識您的 RT-AC1200G 無線路由器

1.

2.

3.

4.

5.

6.

電源指示燈 7. 電源按鈕
LAN 1~4 指示燈 8. USB 2.0 連接埠
WAN（網際網路）指示燈 9. 重置按鈕

2.4GHz 指示燈 / 5GHz 指示燈 10.

USB 指示燈 11.

電源輸入埠（DC-IN） 12. WPS 按鈕

WAN（網際網路）
連接埠

LAN 1 ~ 4 網路連
接埠

14

na10332_rt-ac1200g_qsg.indb 14 2015/6/8 11:50:54

繁體中文

包裝內容物

RT-AC1200G 無線路由器  RJ45 網路線
電源變壓器   快速使用指南

注意：若以上列出的任何一項配件有毀損或是短缺的情
形，請儘速聯絡您的經銷商。

注意：

• USB 外接硬碟 / 隨身碟：

• 此無線路由器相容大多數容量高達 2TB 的 USB 硬
碟 / 隨身碟，並支援 FAT16、FAT32、EXT2、EXT3
與 NTFS 的存取。

• 欲安全移除 USB 磁碟，請登入網頁圖形使用者介

http://192.168.50.1

面 （
頁面的右上角點選 USB 圖示並選擇 退出 USB 磁碟

2.0。

• 錯誤移除 USB 碟將會導致資料遺失。

• 請造訪 http://event.asus.com/networks/disksupport
獲得此無線路由器所支援的檔案系統與硬碟磁區清
單。

），接著在「網路地圖」

• 請造訪 http://event.asus.com/networks/printersupport

獲得此無線路由器所支援的印表機清單。

15

na10332_rt-ac1200g_qsg.indb 15 2015/6/8 11:50:54

繁體中文

安裝您的路由器

重要！安裝路由器之前，請確認網際網路連線可用。

1. 放置您的路由器

為獲得無線路由器與所連線的網路裝置之間的最佳無線傳送訊
號，請確認以下幾點：

• 建議將路由器放置在中心區域，以覆蓋所有無線行動裝置。

• 請勿將裝置放在靠近金屬物品與陽光直射的地方。

• 請遠離其它 802.11g 或 20MHz Wi-Fi 裝置、2.4GHz 電腦周邊

• 請按照下圖所示擺放路由器上的四根可拆卸式天線以獲得最

• 請經常更新至最新版本韌體。您可以登入華碩官網 http://

裝置、 藍芽裝置、無線室內電話、傳送器、重型發動機、日
光燈、微波爐、電冰箱與其他工業裝置，以防止訊號干擾或
丟失。

佳前後訊號覆蓋。

tw.asus.com 獲得最新韌體。

°

90

°

90

16

na10332_rt-ac1200g_qsg.indb 16 2015/6/8 11:50:54

繁體中文

2. 準備數據機

a: 拔掉 AC 變壓器的電源並斷開與有線 / ADSL 數據機的連接。
b: 拔掉您有線 / ADSL 數據機的網路線。
c: 重新開啟您的電腦（建議執行）。

Modem

c

警示！請在斷開數據纜線與網路線之前，確認您的有線
/ ADSL 已關閉超過二分鐘。若您的數據機有備用電池，
請一併移除。

3. 設定無線環境

a

1

4

d

a

Modem

b

Internet

RT-AC1200G

WAN

c

3

OFF!

LAN

2

b

17

na10332_rt-ac1200g_qsg.indb 17 2015/6/8 11:50:54

繁體中文

a: 將無線路由器的 AC 變壓器插入電源輸入埠（DC-IN）並插上

b: 用另一條網路線將您的數據機連接至無線路由器的 WAN 連接

c: 將數據機的 AC 變壓器插入電源輸入埠（DC-IN）並插上電

d: 使用附贈的網路線將您的電腦連接至您的無線路由器的 LAN

4. 關閉電腦中的某些設定

a. 關閉代理伺服器。
b. 設定 TCP/IP 自動取得 IP 位址。
c. 關閉撥號連線。

電源。

埠。

源。

連接埠。

注意：更多資訊請參閱「常見問題解答（FAQs）」。

18

na10332_rt-ac1200g_qsg.indb 18 2015/6/8 11:50:54

繁體中文

使用網路設定精靈（QIS）設定路由器

依據以下步驟進行設定：

1. 按下路由器後側的電源按鈕。確定電源指示燈、LAN 指示燈以
及 WAN 指示燈亮起。

2. 開啟一個網路瀏覽器，如 Internet Explorer、Firefox、Safari 或
Google Chrome。

注意：若網路設定精靈（QIS）未能自動開啟，請在您
的網路瀏覽器中輸入 http://192.168.50.1 或 http://router.
asus.com 並重新載入頁面。

3. 為路由器設定登入名稱與密碼，接著點選 Next。您需要使用

此名稱與密碼來登入 RT-AC1200G 檢視並變更路由器設定。
記錄下路由器登入名稱與密碼以備日後使用。

4. 此路由器的網路設定精靈（QIS）可自動偵測 ISP 連線類

型：自動取得 IP、PPPoE、PPTP、L2TP 與固定 IP。請從您
的 ISP 獲得網路連接類型的相關資訊。若您的網路連線類型
為「自動取得 IP」（DHCP），網路設定精靈（QIS）將自動
引導您進入下一步。

注意：若您的網路連線類型為固定 IP，選擇「Static IP」
並點選 Next。輸入 IP 位址、子網路遮罩、預設閘道以及
DNS 伺服器資訊。點選 Next 繼續。

19

na10332_rt-ac1200g_qsg.indb 19 2015/6/8 11:50:55

繁體中文

5. 指定網路名稱 (SSID) 與安全密鑰以連接 2.4GHz 與 5GHz 無

6. 畫面將顯示您的網路與無線設定。點選 Next 繼續。

7. 閱讀無線網路連線教程。完成後點選 Finish。

線網路。完成後點選 Apply。

注意：

•

您可以指定一個多達 32 字元的網路名稱。

•

若有需要，觀看設定視訊教程。

20

na10332_rt-ac1200g_qsg.indb 20 2015/6/8 11:50:55
