ASUSTeK Computer J201 User Manual

Asus J201

User Manual

Contents

Welcome 6

Left View 7 Package Contents 7 Overview 8

Features 8 Speciﬁ cations 9 Menu Map 10

Getting Started 13

Inserting the SIM card and battery 13 Charging the battery 14

Low Battery Indicators 14 Turning the phone on/off 14 Function Keys 15

Unlocking the keypad 16 Standby Mode 16 Using the Menu 17 Text Entry 19

Basics 19

Choosing text entry methods 19

Redialing a Number 23 Call Logs 23

Returning a Missed Call 23 Call Log Options 24

Deleting Call Logs 24 Call Time/Cost 24 Options During a Call 25 Other call options 25

Phonebook 26

Adding Contacts 26

Adding a New Entry 26 Searching for a Contact 26

Quick Find 26

Search Entry 26 Copying and Moving 27 Deleting Contacts 27 Caller Groups 28 Extra Number 29 Phonebook Settings 29

My vCard 30

Calls 22

Making a call 22

Making International Calls 22 Answering a Call 22 Answer Mode 22 Canceling an Incoming Call 23 Diverting a Call 23

Messages 31

SMS 31

Composing an SMS Message 31 Common Words 32 Message Settings 32 SMS Counter 33

MMS 33

Writing an MMS Message 33

Viewing an MMS Message 34

Using Templates 34

Message Settings 34 Chat 36 E-mail 37 Voice Mail 37 Cell Broadcast 38 Input Methods 38

Manner 39

Manner Settings 39

Settings 40

Phone Settings 40

Date/Time 40

Power On/Off Timer 40

Input Method 40

Language 40

Default Encoding 41

Shortcuts 41

Greeting Text 41

Speed Dial 41

Auto Datetime Update 41 Display Settings 42

Themes 42

Wallpaper 42

Sub Wallpaper 42

Screen Saver 43

Power On Animation 43

Power Off Animation 43

Main Idle Screen 43 Tone Settings 44 Call Settings 44

Hide My Number 45

Call Waiting 45

Call Forwarding 45

Call Barring 45

Line Switching 45

Call Time Reminder 46

Call Time Display 46

Auto Redial 46

Closed User Group 46

Call Filter 47 Network Settings 47

Preferred Network 47

Network Selection 47

Band Selection 47

GPRS Connection 47 Bluetooth Settings 48

Power 48

Search Audio Device 48

My Device 48

Bluetooth Settings 48

Disconnect Device 48 Security Settings 49

SIM Lock 49

Phone Lock Code 49

Auto Keypad Lock 49

Fixed Dialing 49

Barred Dialing 50

Change Password 50 Restore Factory Settings 50

Camera 51

Taking Photos 51

Zoom Function 51

Viewing and Managing

Photos 51

Photo Capture Settings 52

Camera Settings 52 Image Settings 52 Effect 52 Add Frame 53 Multi-Capture 53 Capture Timer 53 Self Capture 53 Restore Default 53

Recording Videos 53

Zoom Function 54

Viewing and Managing

Videos 54

Full-Screen Mode 54 Rewind and Fast Forward 54 Video Playback Speed 54 Volume 55 Capturing a Still Photo 55

Video Capture Settings 55

Camcorder Settings 55 Video Settings 55 Effect 56 Restore Default 56

Photo Artist 56

Media Center 58

Audio Player 58

Adding music ﬁ les 58

Editing Music Files 58 FM Radio 59

FM Radio Options 59 Java 60

Java Settings 60 Games 60

Game Setting 61 Melody Composer 61 Tone Settings 61

Organizer 62

Alarm 62 Calendar 62 Tasks List 63 Calculator 63 World Clock 63 Voice Recorder 63 Image editor 64 Stopwatch 64 File Manager 64 Units Converter 65 Currency Exchange 65 Health Manager 65

Network 67

Service Provider Settings 67 WAP 67

Browsing WAP pages 67

Scrolling 67

Viewing Links 67

WAP Settings 67 WAP Push 68

Data Account 68

Appendix 69

Additional Information 69 European Notice 69 RF Exposure Information (SAR) 69 Proper Disposal 70

Welcome

Congratulations on your purchase of an Asus J201 cell phone. The following illustration displays the features found on the front of your phone.

Receiver

Screen

Enter key: Displays the main menu;

conﬁ rms selection of a menu item

Joystick: Includes up, down, right,

left keys for on-screen navigation

Left soft key: Displays the main

menu; selects left menu items

Call key: Answers a call; displays

previously dialed numbers

Left joystick key: Displays the

camera menu; scrolls left through

menu items

Up joystick key: Displays the SMS inbox; scrolls up through menu items

Right soft key: Displays phone book when idle; selects right menu items

Power/end key: Turns power on or off; ends a call; exits menu

Right joystick key: Displays the Media Center menu; scrolls right through menu items

Down joystick key: Displays your shortcuts menu; scrolls down through menu items

Left View Package Contents

Headset In

Welcome

Captures photos

Increases or decreases the volume for calls, key tones, or playing media ﬁ les.

J201 handset 720 mAh Li-ion

battery

USB cable

Quick Start Guide

Quick start guide

Stereo headset

warranty card

Warranty card

Travel charger

User Manual

User manual

Handset Manager

Manual

Handset Manager

manual

Handset Manager

CD-ROM

Overview

The J201 is a stylish and fashionable new phone from Asus, with all the functions and utilities to make it a useful tool in today’s mobile world. The J201 comes equipped with a built-in megapixel camera, MMS/SMS messaging capability, Bluetooth capability, FM radio, organizer, java games, audio player, WAP, and GPRS. The J201’s audio player enables you to play back your favorite music.

Features

• Wide variety of calling and messaging functions

• Built-in mega-pixel camera

• Media center with audio player, FM radio receiver, and games for your entertainment

• MMS and SMS messaging capability

• Bluetooth capability

• Personal information organizer with alarm, calendar, calculator and other useful tools to manage your time

• WAP and GPRS capability to check e-mail or browse web services

Speciﬁ cations

System supported GSM900/1800/1900, Class 10

Size 81.5 x 43 x 23.5 mm

Weight 90g

Battery 720 mAh Li-ion

Standby Time 200 ~ 300 hours

Talk Time 2.5 ~ 5 hours

Color Silver, White

Display Main: 1.8-inch, 262K colors, TFT, 128 x 160, Sub: 1.1-inch, 65K colors, CSTN, 96 x 64

Camera 1.3 Megapixel CMOS

Supports video recording

4/6/9 continuous shots

WAP Supports WAP 1.2.1 and WAP 2.0

Java Supports J2ME (CLDC 1.0 + MiDP 2.0)

Built-in Java games

Messaging Supports SMS, EMS, MMS

Ring tone 64 polyphonic ring tones

Supports SMF (standard MIDI format) and MP3

Phone book 300 sets + SIM card

Caller ID with photos

10 sets for speed dialing

Record Record an unlimited number of ﬁ les, up to memory capacity

Calendar 100 Sets

Internal Memory 128MB

PIM tool Alarm, Calendar, Tasks List, Calculator, World Clock, Voice Recorder, Image Editor,

Stopwatch, etc.

Welcome

Note: All speciﬁ cations are subject to change without further notice.

Menu Map

Network

• WAP

• Data Account

Messages

• SMS

• MMS

• Chatting Rooms

• Email

• Voice Mail

• Cell Broadcast

• Input Methods

Manner

• General

• Meeting

• Indoor

• Outdoor

• Headset

Settings

• Phone Settings

Date/Time Power On/Off Timer Input Method Language Default Encoding Shortcut Greeting Text Speed Dial Auto Datetime Update LED

• Display Settings

 Themes  Wallpaper  Sub Wallpaper  Screen Saver  Power On Animation  Power Off Animation  Show Date and Time  Main Idle Screen  Brightness  Sub LCD Contrast  Backlight Timer

• Tone Settings

 Incoming Ringtone  Alarm Tone  Power On  Power Off  Flip Open  Flip Close  Message Tone  Key Tone

• Call Settings

 Hide My No.  Call Waiting  Call Forwarding  Call Barring  Line Switch  Call Time Reminder  Call Time Display  Auto Redial  Closed User Group  Call Filter

• Network Settings

Video Settings Network Selection Preferred Networks Band Selection GPRS Connection

• Bluetooth

Power Search Audio Device My Device Settings

• Security Settings

SIM Lock Phone Lock Auto Keypad Lock Fixed Dial Barred Dial Change Password

• Restore Factory Settings

Camera

• Capture

 My Album  Camera Settings  Image Settings  Effect  Frame  Multi-Capture  Capture Timer  Self Capture Restore Default

• Video Recorder

My Video CamCorder Settings

Effect

Restore Default

• My Album

• My Video

• Photo Artist

Media Center

• Audio Player

• FM Radio

• Java Java Settings Games

• Game Settings

• Melody Composer

• Tone Settings

Organizer

• Alarm

• Calendar

• To Do List

• Calculator

• World Clock

• Sound Recorder

• Image Editor

• Stopwatch

Typical Stopwatch

nWay Stopwatch

• File Manager

• Units Converter

• Currency Converter

• Health Manager

BMI

Menstrual

Welcome

Phone Book

• Quick Search

• Search Entry

• Add

• Copy All

• Delete All

• Delete

• Caller Group

• Extra number

My Phone Number Service Number SOS Number

• Settings

Memory Status Default Storage Fields My vCard

Calls

• Missed Calls

• Dialed Calls

• Received Calls

• Delete Call Log

• Call Time

• Call Cost

• SMS Counter

• GPRS Counter

Getting Started

Inserting the SIM card and battery

When you register with a service provider, you receive a SIM card (Subscriber Identity Module card). Your phone must have a SIM card in order to make calls. The SIM card is a computer chip that contains your phone number, phonebook information, and service provider information. Handle it with care and do not bend it or expose it to static electricity or dirt. Be sure the power to your phone is off before you insert your SIM card.

The SIM card slot is situated underneath the battery. To insert the card, follow these steps:

1. Press the back cover and slide the cover off to remove it.

2. Remove the battery. The battery compartment has a notch at the top to make it easier to grasp and remove it.

Getting Started

3. Insert the SIM card into the holder with the correct orientation. The gold contacts of the SIM card should face down.

4. Place the battery back into the battery compartment noting the correct polarity.

5. Replace the battery cover. Place the back cover against the phone case, then slide it upwards to lock into place.

Caution:

• Use only the battery recommended by the manufacturer. Using an incompatible battery with the phone may cause risk of an explosion.

• Dispose of the used batteries as instructed by the manufacturer or ask your local authorities for assistance.

Charging the battery

Turning the phone on/off

1. Connect the charger plug to a power outlet.

2. Connect the charger to the socket at the bottom of the phone. The connector can only be inserted one way.

3. The phone will be turned on and charge the battery.

To turn the phone on, do the following:

1. Hold down the power/end

key until the

screen lights up.

2. If needed, enter your SIM card PIN code and press the Enter key.

To turn the phone off, do the following:

• Press the power/end

key and hold until

the phone shuts down.

Note: If you set an alarm using the Organizer menu and turn off the phone, the phone will turn itself on when the alarm is activated. After you disable the alarm, the phone prompts you if you want to keep the phone turned on or off. See the Organizer section for details about setting an alarm.

Note: If the battery has been deeply discharged, it may take

several minutes before the phone is turned on by the charger.

Low Battery Indicators

The battery indicator in the upper right corner of the screen indicates how much charge remains in the battery. As additional reminders, when the battery is low, the phone emits a double beep. The message “battery low” also appears on the screen.

Function Keys

The following table lists the phone keys and their functions.

Up joystick key

• Press to scroll up through menu items.

• Press to display the SMS inbox when the phone is in standby mode

Getting Started

Power/end key

• Hold to turn the phone on or off.

• Press to stop an incoming call or cancel a call you are dialing.

• Press to exit a menu or submenu.

Call key

• Press after dialing or answer calls.

• Press to open Call Logs and press again to redial the last number called.

Left soft key

• Press to display the menu.

• Press to perform the function currently displayed in the lower left corner of the screen.

• Press to move left while navigating menus.

Down joystick key

• Press to scroll down through menu items.

• Press to display a list of your shortcuts when the phone is in standby mode.

Left joystick key

• Press to scroll left through menu items.

• Press to display the Camera menu when the phone is in standby mode.

Right joystick key

• Press to scroll right through menu items.

• Press to display the Media Center menu when the phone is in standby mode.

Right soft key

• Press to view phone book when the phone is in idle mode.

• Press to perform the function currently displayed in the lower right corner of the screen.

• Press to move right while navigating menus.

Enter key

• Press to display the main menu.

• Press to conﬁ rm selection of a menu item when the phone is in standby mode.

Unlocking the keypad

Standby Mode

The keypad of the phone can be locked automatically after a speciﬁ c time interval to prevent tampering or accidental pressing of any buttons. Refer to Security Setup in the Settings section to learn how to lock the keypad.

To unlock the keypad, do the following:

1. The screen shows Unlock in the lower right corner of the screen. Select this option by pressing the right soft key which is just under the word Unlock on the screen.

2. Press the # key on the keypad to unlock the keypad as prompted on the screen.

The keypad is then unlocked.

When your phone is on, but not in use, it is in standby mode. During standby mode, the upper part of the display screen shows various icons.

The date and time is displayed at the lower center of the screen. Beneath the date and time are Menu in the left corner and Name in the right corner. Press the left soft key to view the main menu, and the right soft key to view the phone book.

The Standby screen icons are as follows:

Vertical bars indicate the strength of the GSM network signal. Four bars indicates that your current position has the best reception.

Line 1 or line 2 is selected for calls.

Indicates the ring mode selected for the phone:

Ring Only

Vibrate

Vibrate and Ring

Vibrate, then Ring

Lights only

Alarm has been set.

Using the Menu

A text message has been received (this icon ﬂ ashes if the SMS memory is full).

Indicates battery charge status.

Phone is using GPRS network.

Phone is in roaming mode.

Indicates a missed call.

Call divert is enabled.

Bluetooth handset is connecting.

Follow these tips to navigate through the menu and menu options.

• To view the menu, press the left soft key or the Enter key.

• Use the up, down, left, and right joystick

keys to move through the various menu items.

• The lower left corner of the screen

displays the name of the menu item currently selected while the lower right corner displays Back. Press the left soft key menu item) to select the menu item. Press the right soft key which is situated under Back to exit the menu.

(situated under the name of the

Getting Started

• Each menu item also displays a small

number beneath it. You can also press the number corresponding to a menu item, on the keypad to select the item.

• To quickly exit from the menu, press the

Power/End

• Use the joystick keys to select the

key.

submenu items and options. The right and left soft keys can also be used for selecting various options in submenus.

For example, to view missed calls, do the following:

1.Use the joystick keys to select Calls from the main menu.

2.Press the left soft key selection. The Calls submenu opens.

3.Press the left soft key Missed Calls option. A list of missed calls opens.

to conﬁ rm the

to select the

Settings: Lets you adjust phone settings such as call settings, themes, shortcuts, network settings, and security settings. You can also restore all settings to their factory default from this menu.

Camera: Enables you to take pictures as well as record video with your phone. You can also access all your pictures and videos from this menu item.

The following table provides a list of all the main menu items:

Network: Enables you to specify the WAP and data settings and set up GSM and GPRS settings. Enables access to the internet and to STK SIM card services.

Messages: Gives you access to messages received. Compose and send text (SMS) and multimedia (MMS) messages here. You can also check email, chat, and broadcast a message using this menu.

Manner: Enables you to select and customize the phone settings including the ring tone, volume, ring type, and answer mode.

Media Center: Consists of an audio player, FM radio, games, and a melody composer.

Organizer: Contains useful tools such as an alarm, a calendar for scheduling appointments, a to do list, and a simple calculator. You can also record memos, edit simple images, manage all your data using a ﬁ le manager, or convert units or currency

Phonebook: Enables you to manage names and telephone numbers for easy access and caller recognition.

Calls: Stores information about calls made, received, and missed.

Text Entry

When you add names to your phone book, send a text message, or use your WAP browser, you need to enter text. Your cell phone has several text entry methods. You can enter letters individually or with predictive text entry, which helps you complete words as you enter them. You can enter letters in upper case, lower case, or both, type simpliﬁ ed or traditional Chinese characters, or insert symbols.

Key Assigned Characters

. , - ? ! ‘ @ : # $ / _ 1

A B C 2

D E F 3

G H I 4

J K L 5

M N O 6

Getting Started

Basics

• Use the alphanumeric keypad to enter letters and numbers. Each key is assigned multiple characters.

• Select Clear, in the lower right corner of the screen, to delete a letter if you make a mistake.

• To enter spaces between words, press the

key, this will open the symbol table,

and you can choose the Press the enter key or press the left soft key to select and enter a space.

You can also view, select, and enter other

symbols by pressing the

The following table lists the characters assigned to the keys on the keypad:

9 space symbol.

key.

P Q R S 7

T U V 8

W X Y Z 9

0, opens symbol table

Choosing text entry methods

From any text entry screen, such as a text message window, select Options > Input Method. Select ABC Input (the default is capitalised ABC; press “*” to switch between upper case ABC and lower case abc) for entering letters one at a time. Select Smart Abc (the default is Abc; press “*” to switch between lower and upper case inputs) to let the phone predict the words you are typing, use the up and down joystick key to select the predicted words.

Multitap text entry

Multitap text entry enables you to enter individual letters one by one. This is ideal for

adding a phonebook entry or entering a WAP address.

When you press a key, the characters assigned to the key appear in the lower center of the screen. Press the key repeatedly to scroll through these characters. Pause for a moment and the selected letter appears on the screen. For practice, try entering text into a text message (SMS) as follows: From the menu, go to Messages > SMS > Write Message. Before entering text, ﬁ rst make sure that the entry method is set to multitap. Press Option > Input Method and select ABC Input. To enter the words “my phone” into the text entry area, follow these steps:

1.Press the

2.Press the

key to select m.

key three times to select y.

3.Press the right joystick key to enter a space.

4.Press

to enter p, then press

two times to enter h. Continue in this fashion until the word “phone” is entered.

Smart text entry

Smart text entry is a predictive text entry method. It uses a built-in dictionary to predict the word you are typing. You can choose the correct word by pressing the keys repetitively and scrolling through the words suggested by the phone. By reducing the number of keystrokes, the smart text entry method helps some users to type messages more quickly.

Whenever you press a key, a list of possible characters or character combinations is created. To enter text, use the up and down joystick keys to ﬁ nd the character combination you want. Press the right joystick key to proceed entering the next character. If you make a mistake, press Clear.

Here is an example of how to enter the word “baby” using smart text entry.

1.First press the

key. The letter a

appears on the screen.

2.Press the

key again quickly to go to the next suggestion which is ba. If you press the up/down joystick keys, the phone scrolls through all possible twoletter combinations of the letters a, b, and c.

3.Press the

key again quickly to display three-letter combinations of the letters a, b, and c.

4.Press the up/down joystick keys to scroll through the possible words. When you see the bab combination, press the right joystick key to proceed to the next letter.

5.Press the

key and the letter x appears. Press the up/down joystick keys to scroll through letter options and select y.

6.Press Option > Done when ﬁ nished.

Note: For smart text entry to work properly, ensure the language settings in your phone match the language you want to type in. For setting language, see Phone Setup under Settings.

Numeric text entry

Numeric text entry allows you to create a text message composed of numbers. To use this method, select Option > Input Method and then select Numeric. Now you can directly input the numbers using the keypad.

Symbols text entry

With this method, you can enter various types of symbols. Select Option > Input Method > Insert Symbols. A list of symbols is displayed. Use the joystick keys to select the desired symbol and select OK when done. You can also press the “0” key as a shortcut to open the symbol table.

Getting Started

Calls

Making a call

Follow these steps to place a call:

1.Enter the number you wish to dial using the keypad. If you make a mistake, select Clear to delete at any time. The right soft key the lower right screen; use this key to clear a number.

2.Press the Power/end the call and return to standby mode. Alternately, select Abort using the right soft key

3.Press the Call after you ﬁ nish dialing the number.

4.Press the Power/end the call.

Making International Calls

To dial an international call, do the following:

1. First enter a + by holding down the * key.

2. After the +, enter the international access code for the country you wish to dial, followed by the telephone number including the area code.

is just under the word Clear on

key to cancel

to cancel the call.

key to connect the call

key to disconnect

Answering a Call

When you receive a call, the phone alerts you by sounding the ring tone and vibration according to the speciﬁ ed ring tone and vibration settings. To answer the call, do the following:

1. Press the Call

2. Press the Power/end call and disconnect.

Alternately, select Option > Answer to answer the call.

key to answer the call.

key to end the

Answer Mode

The default setting for the phone is to answer when you press the Call

can also set the phone to pick up by pressing any key. To enable the phone to answer a call by pressing any key, select Manner and then choose the manner setting that you want.

For example, if you select General, then choose Personalize > Answer Mode > Any Key. Set the Any Key option to On to enable the setting.

Remember to Activate the manner setting to make sure that the answer mode is set.

key. However, you

+ 49 hidden pages

ASUSTeK Computer J201 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
