ASUSTeK Computer EPC1004DN Users Manual
Eee PC
User Manual
Windows® XP Edition
Eee PC 1004DN
E4361
Table of Contents
Table of Contents ......................................................................................................................ii
About This User’s Manual ......................................................................................................iv
Notes for This Manual .............................................................................................................iv
Safety Precautions.....................................................................................................................v
Knowing the Parts
Top Side ....................................................................................................................................1-2
Bottom Side .............................................................................................................................1-5
Right Side .................................................................................................................................1-6
Left Side ....................................................................................................................................1-7
Front Side ................................................................................................................................. 1-8
Rear Side ................................................................................................................................... 1-9
Keyboard Usage ...................................................................................................................1-10
Touchpad Usage ..................................................................................................................1-12
Multi-finger gesture input .................................................................................1-12
Getting Started
Powering on your Eee PC ................................................................................................... 2-2
First-time Startup ..................................................................................................................2-3
Desktop .....................................................................................................................................2-4
ASUS EeePC Tray Utility .......................................................................................................2-5
Enabling and Disabling Devices .......................................................................2-5
Adjusting the display resolution .......................................................................2-6
Network Connection ............................................................................................................2-7
Configuring a wireless network connection.................................................2-7
Local Area Network ................................................................................................2-8
Browsing web pages ...........................................................................................2-11
Using the Eee PC
ASUS Update ...........................................................................................................................3-2
Updating the BIOS through the Internet ....................................................... 3-2
Updating the BIOS through a BIOS file ........................................................... 3-3
ii
Table of Contents
Bluetooth Connection ......................................................................................................... 3-4
Super Hybrid Engine ............................................................................................................3-6
Super Hybrid Engine Modes...............................................................................3-6
Eee Storage ..............................................................................................................................3-7
Support DVD & System Recovery
Support DVD information ..................................................................................................4-2
Running the support DVD ...................................................................................4-2
Drivers menu ............................................................................................................4-3
Utilities menu ...........................................................................................................4-3
Contact ....................................................................................................................... 4-3
Other information ..................................................................................................4-3
System Recovery....................................................................................................................4-4
Using the Support DVD ........................................................................................4-4
Using Recovery Partition .....................................................................................4-5
Boot Booster............................................................................................................................4-6
Appendix
Declarations and Safety Statements ..............................................................................A-2
Federal Communications Commission Statement .....................................A-2
FCC Radio Frequency (RF) Exposure Caution Statement .........................A-3
Declaration of Conformity(R&TTE directive 1999/5/EC)...........................A-4
CE Mark Warning ....................................................................................................A-4
IC Radiation Exposure Statement for Canada ..............................................A-4
Wireless Operation Channel for Different Domains ..................................A-6
France Restricted Wireless Frequency Bands ...............................................A-6
UL Safety Notices ....................................................................................................A-7
Power Safety Requirement .................................................................................A-8
Nordic Lithium Cautions (for lithium-ion batteries)...................................A-9
Copyright Information ...................................................................................................... A-11
Limitation of Liability ........................................................................................................A-12
Service and Support .......................................................................................................... A-12
ASUS Eee PC
iii
About This User’s Manual
You are reading the Eee PC User’s Manual. This User’s Manual provides
information regarding the various components in the Eee PC and how to
use them. The following are major sections of this User’s Manual:
1. Knowing the Parts
Provides information on the Eee PC’s components.
2. Getting Started
Provides information on getting started with the Eee PC.
3. Using the Eee PC
Provides information on using the Eee PC’s utilities.
4. Support DVD and System Recovery
Gives you information on support DVD contents and system
recovery.
5. Appendix
Gives you safety statements.
The actual bundled applications differ by models and territories.
There may be differences between your Eee PC and the pictures
shown in this manual. Please accept your Eee PC as being correct.
Notes for This Manual
A few notes and warnings are used throughout this guide, allowing you
to complete certain tasks safely and effectively. These notes have different
degrees of importance as follows:
WARNING! Important information that must be followed for safe
operation.
IMPORTANT! Vital information that must be followed to prevent
damage to data, components, or persons.
TIP: Tips for completing tasks.
NOTE: Information for special situations.
iv
Table of Contents
Safety Precautions
The following safety precautions will increase the life of the Eee PC. Follow
all precautions and instructions. Except as described in this manual, refer
all servicing to qualified personnel. Do not use damaged power cords,
accessories, or other peripherals. Do not use strong solvents such as
thinners, benzene, or other chemicals on or near the surface.
Disconnect the AC power and remove the battery pack(s) before
cleaning. Wipe the Eee PC using a clean cellulose sponge or chamois
cloth dampened with a solution of nonabrasive detergent and a
few drops of warm water and remove any extra moisture with a dry
cloth.
DO NOT place on uneven
or unstable work surfaces.
Seek servicing if the casing
has been damaged.
DO NOT expose to dirty or
dusty environments. DO
NOT operate during a gas
leak.
DO NOT press or touch the
display panel. Do not place
together with small items
that may scratch or enter
the Eee PC.
DO NOT leave the Eee PC
on your lap or any part
of the body to prevent
discomfort or injury from
heat exposure.
DO NOT place or drop objects
on top and do not shove any
foreign objects into the Eee
PC.
DO NOT expose to strong
magnetic or electrical fields.
DO NOT expose to or use near
liquids, rain, or moisture. DO
NOT use the modem during
electrical storms.
Battery safety warning: DO
NOT throw the battery in
fire. DO NOT short circuit the
contacts. DO NOT disassemble
the battery.
ASUS Eee PC
v
SAFE TEMP: This Eee PC
should only be used
in environments with
ambient temperatures
between 5°C (41°F) and
35°C (95°F)
INPUT RATING: Refer to the
rating label on the bottom
of the Eee PC and be sure
that your power adapter
complies with the rating.
DO NOT carry or cover a
Eee PC that is powered
ON with any materials that
Incorrect installation of
battery may cause explosion
and damage the Eee PC.
will reduce air circulation
such as a carrying bag.
DO NOT throw the Eee PC in municipal waste. This product has
been designed to enable proper reuse of parts and recycling. The
symbol of the crossed out wheeled bin indicates that the product
(electrical, electronic equipment and mercury-containing button
cell battery) should not be placed in municipal waste. Check local
regulations for disposal of electronic products.
DO NOT throw the battery in municipal waste. The symbol of the
crossed out wheeled bin indicates that the battery should not be
placed in municipal waste.
Transportation Precautions
To prepare your Eee PC for transport, you should turn it OFF and
disconnect all external peripherals to prevent damage to the
connectors. The hard disk drive’s head retracts when the power is turned
OFF to prevent scratching of the hard disk surface during transport.
Therefore, you should not transport your Eee PC while the power
is still ON. Close the display panel to protect the keyboard and display
panel.
The Eee PC’s surface is easily dulled if not properly cared for. Be careful
not to rub or scrape surfaces when transporting your Eee PC. You can put
your Eee PC in a carrying case for protection from dirt, water, shock, and
scratches.
vi
Table of Contents
Charging Your Batteries
If you intend to use battery power, be sure to fully charge your battery
pack and any optional battery packs before going on long trips.
Remember that the power adapter charges the battery pack as long as it is
plugged into the computer and an AC power source. Be aware that it takes
much longer to charge the battery pack when the Eee PC is in use.
Remember to fully charge the battery (8 hours or more) before first use
and whenever it is depleted to prolong battery life. The battery reaches its
maximmum capacity after a few full charging and discharging cycles.
Airplane Precautions
Contact your airline if you want to use the Eee PC on the airplane. Most
airlines have restrictions for using electronic devices. Most airlines allow
electronic use only between and not during takeoffs and landings.
There are three main types of airport security devices: X-ray
machines (used on items placed on conveyor belts), magnetic
detectors (used on people walking through security checks), and
magnetic wands (hand-held devices used on people or individual
items). You can send your Eee PC and diskettes through airport X-ray
machines. However, it is recommended that you do not send your
Eee PC or diskettes through airport magnetic detectors or expose
them to magnetic wands.
ASUS Eee PC
vii
viii
Table of Contents
Top Side
Bottom Side
Right Side
Left Side
Rear Side
Keyboard Usage
Touchpad Usage
Knowing the Parts
1
Top Side
Refer to the illustration below to identify the components on this side of
the Eee PC.
The top side may vary in appearance depending on model.
1
2
1-2
8
7
The keyboard differs for each territory.
3
4
5
6
Chapter 1: Knowing the Parts
1
Built-in Camera
2
Display Panel
3
Power Switch
The power switch allows powering ON and OFF the Eee PC and
recovering from STR. Press the switch once to turn ON and hold
it to turn OFF the Eee PC. The power switch only works when the
display panel is opened.
Power Indicator
The power indicator lights when the Eee PC is turned ON and
blinks slowly when the Eee PC is in the Save-to-RAM (Suspend)
mode. This indicator is OFF when the Eee PC is turned OFF.
KeyboardKeyboard
4
The keyboard differs depending on model.
Fingerprint Scanner
5
The built-in fingerprint scanner allows use of security software
using your fingerprint as your identification key.
6
Touchpad and Buttons
The touchpad and its buttons comprises a pointing device that
provides the same functions as a desktop mouse.
7
Status Indicators
Power Indicator
The power indicator lights when the Notebook PC is turned
ON and blinks slowly when the Notebook PC is in the
Suspend-to-RAM (Sleep) mode. This indicator is OFF when
the Notebook PC is turned OFF or in the Suspend-to-Disk
(Hibernation) mode.
Battery Charge Indicator
The battery charge indicator (LED) shows the battery
charging status as follows:
(Continued on the next page)
ASUS Eee PC
1-3
Powered ON / Standby mode
High battery power
(95%–100%)
Medium battery power
(11%–94%)
Low battery power
(0%–10%)
With Adapter Without Adapter
Green ON Off
Orange ON Off
Orange Blinking Orange Blinking
Powered OFF
High battery power
(95%–100%)
Medium battery power
(11%–94%)
Low battery power
(0%–10%)
With Adapter Without Adapter
Green ON Off
Orange ON Off
Orange Blinking Off
The Battery Charge Indicator will not light when the battery is
removed from your Eee PC.
Hard Disk Drive (HDD) Indicator
The hard disk drive indicator blinks when data is written to
or read from the disk drive.
Capital Lock Indicator
Indicates that capital lock [Caps Lock] is activated when
lighted.
/ Wireless/Bluetooth Indicator
This is only applicable on models with built-in wireless
LAN/Bluetooth. When the built-in wireless LAN/Bluetooth is
enabled, this indicator lights.
Super Hybrid Engine Key
8
Press this key to switch among various power saving modes. The
selected mode is shown on the display.
1-4
Chapter 1: Knowing the Parts
Bottom Side
Refer to the illustration below to identify the components on this side of
the Eee PC.
The bottom side may vary in appearance depending on model.
21 3
4
The bottom of the Eee PC can get very hot. Be careful when
handling the Eee PC while it is in operation or recently been in
operation. High temperatures are normal during charging or
operation. DO NOT use on soft surfaces such as beds or sofas, which
may block the vents. DO NOT PUT THE Eee PC ON YOUR LAP OR
OTHER PARTS OF THE BODY TO AVOID INJURY FROM THE HEAT.
Battery Lock - Spring
1
The spring battery lock keeps the battery pack secure. When
the battery pack is inserted, it will automatically lock. When
removing the battery pack, this spring lock must be retained in
the unlocked position.
ASUS Eee PC
1-5
2
Battery Pack
The battery pack is automatically charged when connected
to an AC power source and maintains power to the Eee PC
when AC power is not connected. This allows use when moving
temporarily between locations. Battery time varies by usage and
by the specifications for this Eee PC. The battery pack cannot be
disassembled and must be purchased as a single unit.
Battery Lock - Manual
3
The manual battery lock is used to keep the battery pack secured.
Move the manual lock to the unlocked position to insert or
remove the battery pack. Move the manual lock to the locked
position after inserting the battery pack.
Reset Button (Emergency)
4
In case your operating system cannot properly turn OFF or restart,
the reset button can be depressed with a pin or a straightened
paper clip to restart the Eee PC.
The reset button is available on selected models.
Right Side
Refer to the illustration below to identify the components on this side of
the Eee PC.
1-6
32
1
Optical Drive
1
The Notebook PC comes in various models with different optical
drives. The Notebook PC’s optical drive may support compact
discs (CD), digital video discs (DVD), or both and may have
recordable (R) or rewritable (RW) capabilities.
Chapter 1: Knowing the Parts
2
USB Port (2.0/1.1)
The USB (Universal Serial Bus) port is compatible with USB 2.0 or
USB 1.1 devices such as keyboards, pointing devices, cameras, and
storage devices, connected in a series up to 12Mbits/sec (USB 1.1)
and 480Mbits/sec (USB 2.0). Also, the USB supports hot-swapping
function.
3
LAN Port
The eight-pin RJ-45 LAN port (10/100M bit) supports a standard
Ethernet cable for connection to a local network. The built-in
connector allows convenient use without additional adapters.
Left Side
Refer to the illustration below to identify the components on this side of
the Eee PC.
1 2
Power (DC) Input
1
3
4 5 7
The supplied power adapter converts AC power to DC power
for use with this jack. Power supplied through this jack supplies
power to the Eee PC and charges the internal battery pack. To
prevent damage to the Eee PC and battery pack, always use the
supplied power adapter.
2
Display (Monitor) Output
The 15-pin D-sub monitor port supports a standard VGA-
compatible device such as a monitor or projector to allow
viewing on a larger external display.
ASUS Eee PC
6
1-7
3
Air Vents
The air vents allow cool air to enter and warm air to exit the Eee
PC.
Ensure that pa per, books, clothing, cables, or other objects do
not block any of the air vents or else overheating may occur.
4
USB Port (2.0/1.1)
5
Microphone Jack
The microphone jack is designed to connect the microphone
used for Skype, voice narrations, or simple audio recordings.
Headphone Output Jack
6
The 1/8” stereo headphone jack (3.5mm) connects the Eee PC’s
audio out signal to amplified speakers or headphones. Using this
jack automatically disables the built-in speakers.
7
ExpressCard Slot
One 26pin Express card slot is available to support one
ExpressCard/34mm or one ExpressCard/54mm expansion card.
Front Side
Refer to the illustration below to identify the components on this side of
the Eee PC.
1-8
1 2
1
Memory Card Slot
The built-in memory card reader can read MMC/SD and MS-PRO
cards.
2
Audio Speaker System
Chapter 1: Knowing the Parts
Rear Side
Refer to the illustration below to identify the components on this side of
the Eee PC.
21
1
Battery Pack
The battery pack is automatically charged when connected
to an AC power source and maintains power to the Eee PC
when AC power is not connected. This allows use when moving
temporarily between locations. Battery time varies by usage and
by the specifications for this Eee PC. The battery pack cannot be
disassembled and must be purchased as a single unit.
Kensington® Lock port
2
The Kensington® lock port allows the Eee PC to be secured
using Kensington® compatible security products. These security
products usually include a metal cable and lock that prevent the
Eee PC to be removed from a fixed object.
ASUS Eee PC
1-9
Keyboard Usage
Special Function Keys
The following defines the colored hot keys on the Eee PC’s keyboard. The
colored commands can only be accessed by first pressing and holding the
function key while pressing a key with a colored command. Some function
icons appear in the Notification area after activation.
The Hot Key locations on the function keys may vary depending on
model but the functions should remain the same. Follow the icons
whenever your hot key locations do not match the manual.
zzZ Icon (F1): Places the Eee PC in suspend mode
(Save-to-RAM).
Radio Tower (F2): Wireless Models Only: Toggles
the internal wireless LAN or Bluetooth (on selected
models) ON or OFF with an on-screen-display.
When enabled, the corresponding wireless indicator
will light.
The default setting is WLAN ON / Bluetooth OFF.
Touchpad (F3): Toggles the touchpad ON/OFF.
Resolution Selection (F4): Press to adjust the display
resolution.
The Touchpad (<Fn> + <F3>) and Resolution Selection (<Fn> +
<F4>) functions are available on selected models.
1-10
Sun Down Icon (F5): Decreases the display brightness.
Sun Up Icon (F6): Increases the display brightness.
Crossed Screen Icon (F7): Turns off the display backlight.
Chapter 1: Knowing the Parts
Loading...
