Queue Config

To add or remove a QoS queue, click on the corresponding Add or Remove
button. Click on Save / Reboot after removing a selection.

The QoS queue configured here will apply to incoming IP packets. Items that
need to be configured include the following—

• Queue configuration status— select disable or enable

• Queue— select Null or leave blank

• Queue precedence— select integers 1, 2, or 3

QoS Classification

You can configure the Quality of Service to apply different priorities to
traffic on the router. Click on Add to view the Add Network Traffic Class

Rule screen.

42
Zhone Bonded Channel
User Manual
Version 1.1
Document #: BD-ZU0007-11

The following screen allows you to add a network traffic class rule.

43
Zhone Bonded Channel
User Manual
Version 1.1
Document #: BD-ZU0007-11

Routing

Default Gateway

You can enable automatic assigned default gateway on the Routing – Default
Gateway screen. As default, the box is checked for automatic assigned
default gateway to be enabled. Click the Save / Apply button to enable or
disable this feature.

If automatic assigned default gateway is not selected, then enter the
preferred default gateway IP address or select the interface.

44
Zhone Bonded Channel
User Manual
Version 1.1
Document #: BD-ZU0007-11

Static Route

Use the Routing – Static Route screen to add a static route to the routing
table.

Enter the route information and click on Save/Apply. No reboot is required.

45
Zhone Bonded Channel
User Manual
Version 1.1
Document #: BD-ZU0007-11

RIP

If RIP is enabled, the router operation can be configured as active or
passive.

DNS

DNS Server

Use the DNS Server screen to request automatic assignment of a DNS or to
specify a primary and secondary DNS.

46
Zhone Bonded Channel
User Manual
Version 1.1
Document #: BD-ZU0007-11

If the automatic assigned DNS checkbox is not selected, then enter the
primary and secondary DNS Server IP addresses as illustrated below.

Dynamic DNS

Dynamic DNS (D-DNS) allows you to have your own permanent domain name
linked to your dynamic IP address. To configure a dynamic DNS, click on
Add. If you have already created a dynamic DNS that you want to delete,
click on Remove.

47
Zhone Bonded Channel
User Manual
Version 1.1
Document #: BD-ZU0007-11

The below screen allows you to set up the Dynamic DNS provider. Note that
you will have to first register at the Dynamic DNS site that you wish to use.
Select from either

DynDNS.org or TZO. Then enter the hostname and the

interface that you want to establish the D-DNS address to. Enter the
username / password for the D-DNS account that you have signed up for and
then click on Save / Apply.

ADSL

There are three major items in the ADSL settings:

Modulation Methods

Six modulation methods for different linking speed are supported by the
6211 ADSL router: G.Dmt Enabled, G.lite Enabled, T1.413 Enabled, ADSL
Enabled, Annex L Enabled, and ADSL2+ Enabled. Set this value only as
directed by your ISP.

Capability

Do not change these settings unless directed by your ISP.

48
Zhone Bonded Channel
User Manual
Version 1.1
Document #: BD-ZU0007-11

DSL Advanced Settings

The test mode can be selected from the DSL Advanced Settings page. Test
modes are as follows—

• Normal

• Reverb

• Medley

• No retrain

• L3
