PARADYNE ADSL Wireless Modem Router Manual
6218-A1-XXX Manual
PARADYNE
ADSL Wireless Modem Router
¾ Do not open the housing!
¾ Use only the power supply provided with this device.
¾ Use only the cables provided with this device and do
not perform any modification on them.
Rev 0.1
Nov, 25, 2004
Page 1
PARADYNE ADSL Wireless Modem Router Manual
Before you begin
Before installing your ADSL wireless modem router, please carefully check the following
requirements with your computer. This ADSL wireless modem router is equipped with four
10/100Mbps RJ-45 Ethernet switch ports and 802.11g wireless Access Point. You can connect to the
modem by Ethernet or wireless interface.
Unpacking and Inspection
Verify following items came with your ADSL Modem:
ADSL wireless modem router unit
RJ-11 ADSL phone cable
RJ-45 UTP cable
Quick Installation Guide
Accessories
Note: If any items are missing or damaged, please contact your local Sales Office for service.
System Requirements
IBM compatible, Macintosh or other OS-independent workstation supports TCP/IP.
An Ethernet port supports 10Mbps or 10/100Mbps TCP/IP connection on your PC.
For system configuration using the supplied web-based program: a web browser such
as Internet Explorer v5.5 or later
A wireless interface has installed properly on your PC, and it must support IEEE
802.11b or 802.11g wireless standard interface.
You can connect anyone of modem four switch ports on the rear panel to PC NIC
Ethernet port. If you want to allow multiple computers (more than four PCs) to enjoy
internet through ADSL Modem, please purchase a hub/switch to link directly Ethernet
port. You can contact your internet service provider to get more information on this.
Caution:
1. If you want to use private Ethernet UTP cables linking between wireless modem
router with PC, please make sure that cable quality must conform to Cat.5
upward and cable’s length can’t exceed over 100 meters.
2. Please make sure that wireless modem router’s wireless signal could be accessed
by wireless interface on PC, and without any interference by electromagnetic
wave device or obstacle is existed around the corner.
Page 2
PARADYNE ADSL Wireless Modem Router Manual
Getting Started
Hardware Installation
Please be sure to follow the steps in the sequence outlined below. Failure to do so could result in
improper operation or damage of your ADSL wireless modem.
Step 1: Connect a RJ-11 cable from wall phone jack feed to the connector “LINE” on the back of
the modem.
Step 2: Connect the AC adapter to the modem by inserting the barrel-shaped connector into the
mating power connector on the back of the modem, and plug in the adapter to a wall outlet
or a power strip.
Step 3: Connect any LAN port on the back of the modem with a UTP cable, and other end of
UTP cable directly link to RJ-45 port of your PC’s network card.
Step 4: Power on your PC and modem, now you are ready to configure PC.
Note: You also use wireless interface to configure your modem, don’t need step 3 to do and then
directly proceed step 4, but make sure your wireless card has installed driver properly.
Caution: Please do not power on your PC and modem before connecting
steps are finished as mentioned above.
Page 3
PARADYNE ADSL Wireless Modem Router Manual
1. Configuring Your Computers
1.1 Using Wired or Wireless Network Interface Card
Before you start to access this unit via Ethernet or Wireless, please have to configure your PC’s
TCP/IP address to be 192.168.1.x, where x could be any number between 2 to 254, subnet mask is
255.255.255.0, and Default gateway is 192.168.1.1 which is default IP address of ADSL modem.
Note:
By default the router of modem’s DHCP server is disable, this means that you can’t obtain an IP
address automatically once you’ ve configured your PC to obtain an IP address automatically.
You can enable its function after finishing configuration on this unit. But you must make sure
without two DHCP servers existing in a same LAN before your PC got IP automatically.
Windows® XP PCs:
1. In the Windows task bar, click the Start button, and then click Control Panel .
2. Double-click the Network Connections icon.
3. In the LAN or High-Speed Internet window, right-click on icon corresponding to your network interface card
(NIC) and select Properties. (Often this icon is labeled Local Area Connection ). The Local Area Connection
dialog box displays with a list of currently installed network items.
4. Ensure that the check box to the left of the item labeled Internet Protocol (TCP/IP) is checked, and click
.
5. In the Internet Protocol (TCP/IP) Properties dialog box, click the radio button labeled Use the following IP
address and type 192.168.1.x (192.168.1.20 is shown below as an example), 255.255.255.0 and 192.168.1.1 in
the IP address field, Subnet Mask field and Default gateway, respectively.
Page 4
PARADYNE ADSL Wireless Modem Router Manual
TCP/IP Property @ Windows XP
6. Click
twice to confirm your changes, and close the Control Panel .
Windows® 2000 PCs:
1. In the Windows task bar, click the Start button, point to Settings, and then click Control Panel .
2. Double-click the Network and Dial -up Connections icon.
3. In the Network and Dial -up Connections window, right-click the Local Area Connection icon, and then
select Properties.
The Local Area Connection Properties dialog box displays with a list of currently installed network
components. If the list includes Internet Protocol (TCP/IP), the protocol has already been enabled, please skip
to step 10 directly.
4. If Internet Protocol (TCP/IP) does not display as an installed component, click
5. In the Select Network Component Type dialog box, select Protocol , and then click
6. Select Internet Protocol (TCP/IP) in the Network Protocols list, and then click
.
.
.
You may be prompted to install files from your Windows 2000 installation CD or other media. Follow the
instructions to install the files.
7. If prompted, click
to restart your computer with the new settings.
8. After restarting your PC, double-click the Network and Dial-up Connections icon in the Control Panel.
9. In Network and Dial -up Connections window, right-click the Local Area Connection icon, and then select
Properties.
Page 5
PARADYNE ADSL Wireless Modem Router Manual
10. In the Local Area Connection Properties dialog box, select Internet Protocol (TCP/IP), and then click
.
11. In the Internet Protocol (TCP/IP) Properties dialog box, click the radio button labeled Use the following IP
address and type 192.168.1.x, 255.255.255.0 and 192.168.1.1 in the IP address field, Subnet Mask field and
Default gateway, respectively.
12. Click
twice to confirm and save your changes, and then close the Control Panel.
Windows® Me PCs
1. In the Windows task bar, click the Start button, point to Settings, and then click Control Panel .
2. Double-click the Network and Dial -up Connections icon.
3. In the Network and Dial -up Connections window, right-click the Network icon, and then select Properties.
The Network Properties dialog box displays with a list of currently installed network components. If the list
includes Internet Protocol (TCP/IP), the protocol has already been enabled, please skip to step 11 directly.
4. If Internet Protocol (TCP/IP) does not display as an installed component, click
5. In the Select Network Component Type dialog box, select Protocol, and then click
6. Select Microsoft in the Manufacturers box.
7. Select Internet Protocol (TCP/IP) in the Network Protocols list, and then click
You may be prompted to install files from your Windows Me installation CD or other media. Follow the
instructions to install the files.
.
.
.
8. If prompted, click
to restart your computer with the new settings.
9. After restarting your PC, double-click the Network and Dial-up Connections icon in the Control Panel .
10. In Network and Dial-up Connections window, right-click the Network icon, and then select Properties.
11. In the Network Properties dialog box, select TCP/IP, and then click
.
12. In the TCP/IP Settings dialog box, click the radio button labeled Use the following IP address and type
192.168.1.x, 255.255.255.0 and 192.168.1.1 in the IP address field, Subnet Mask field and Default gateway,
respectively.
13. Click
twice to confirm and save your changes, and then close the Control Panel.
Windows® 95, 98 PCs:
1. In the Windows task bar, click the Start button, point to Settings, and then click Control Panel .
2. Double-click the Network icon.
The Network dialog box displays with a list of currently installed network components. If the list includes
TCP/IP, the protocol has already been enabled. Please skip to step 9 directly.
