A computing classic that empowers
Fast and ecient
ASUS X545 ensure everyday tasks are handled with ease. They are powered by up to 8th Generation
Intel Core i7 processors with NVIDIA GeForce MX230 discrete graphics. The dual storage design
features up to a 256GB SSD and 1TB HDD, with optional Intel Optane™ memory technology.
NanoEdge
86% S/B Ratio
Get a wider view of the world
The NanoEdge display gives ASUS X545 a
vast screen area for an immersive viewing
experience for work and play. Its wide-view
FHD panel features an anti-glare coating to
reduce unwanted distractions from irritating
glare and reflections, so you can truly focus on
what’s in front of you.
Powered by Intel® Core™ i7 Processor.
Learn more at: https://www.asus.com/Laptops/ASUS-Laptop-Series-Products/
7mm
thin bezel
83%
screen to body ratio
FOR YOUNGER CROWD | SMART PRACTICAL
Fingerprint SensorDiscrete Graphics Dual StorageIntel® Core™ i7 Processor
starting at $ xxxxxxxxx
* Specification may vary by model.
15.6”
Empower your dynamic lifestyle!
With an overall weight of just 1.9kg*, the extremely
portable ASUS X545 is the lightweight laptop that
keeps up with your fast-paced lifestyle. It looks good,
too, with its Transparent Silver or Slate Grey finish.
EAR HDD protection
The HDD features E A R™ HDD shock dampening protection is designed to protect your data from
physical impact. Laptop HDDs are generally more susceptible to physical damage compared to SSDs.
This active hard-drive protection feature automatically detects shock and vibration across all three axes
to effectively reduce the chances of HDD damage.
Reinforced chassis for your durability
X545 feature metal braces that provide chassis strengthening. Reinforcing underneath the
keyboard provides additional stiffness for a much more comfortable typing and touchpad
experience. Perpendicular braces along the edge of the chassis work like side impact protection
beams in automobiles to protect the hinge joint and internal components.
ASUS X545
• Windows 10 Home / Windows 10 Pro
• Up to 15.6” 16:9 Full HD (1920 x 1080) matte display
• NanoEdge display for immersive viewing
• Smaller chassis and stylish design available in 2 classic colors
• 7mm thin bezel for immersive 78% screen to body ratio
• 178° wide-view technology
• Weighs only 1.9 kg*
• Up to 10th Gen Intel® Core™ i7 processor
• Up to 12GB DDR4 2400MHz RAM
• Up to 256GB SSD + 1TB HDD storage
• Up to NVIDIA MX230 discrete graphics
• One-touch ngerprint login with Windows Hello
• Full-size backlit keyboard (optional) with 1.4mm key travel
• Integrated dual-band Wi-Fi 5 (802.11ac)
• 1 x USB 3.1, 2 x USB 2.0, 1 x HDMI, 1 x audio combo jack,
1 x microSD card reader
• Fast charging to 60% in 49 minutes
• 3X longer battery lifespan
• Harmon Kardon certified audio system with surround-sound
• 360.23 x 234.85 x 23.0mm
ASUS Laptop X545
Intel® Core™ i7-10510Y processor (8MB cache, up to 4.50GHz)
CPU
Operating System
On Board Memory
Memory Slot
Memory Max.
Storage
EMMC / ISSD
Display
External Video Display Modes
Discrete GPU
Integrated GPU
Video Memory
Video Camera
FingerPrint
Wireless
LAN
Card Reader
Interface
Audio
Weight (kg)
Dimension (cm)
AC Adapter
Battery
Replaceable Battery
Keyboard Type
Security
Warranty
Price
15.6” FHD 1920x1080, two-sided NanoEdge display, Wide View (optional), Anti-glare
65W AC Adapter: Output: 19V DC, 3.42A / Input: 100 -240 V AC, 50/60Hz universal
Intel® Core™ i5-10210U processor (6MB cache, up to 4.10GHz)
Intel® Core™ i3-10110Y processor (4MB cache, up to 4.00GHz)
64-bit Windows 10 Pro
Windows 10 Home
On board 4GB / 8GB / 12GB DDR4 + 1 x SODIMM
1
DDR4 2400MHz 12GB
128G / 256G PCIe SSD + 500GB / 1TB HHD
NA
HDMI
NVIDIA® MX110 / MX230
Intel® UHD Graphics 620
2GB VRAM
Yes
Yes (optional)
Wi-Fi 5 (802.11ac), Bluetooth® 4.2
NA
Type: MicroSD
2 x USB 3.1 Gen1
1 x USB 2.0
1 x HDMI 1.4
1 x MicroSD card slot
1 x Audio combo jack: headphone / mic
1 x RJ45 (10/100/1000)
Built-in array microphone
Built-in speaker
Harmon Kardon certified audio
1.9kg
360.23 x 234.85 x 23.0 mm
32Whr 2-cell battery
NO
Illuminated Chiclet Keyboard (optional)
Firmware TPM (fTPM)
Windows Hello, login with Fingerprint (optional)
BIOS Booting User Password Protection
