Asus TF101 User Manual

E6640

Eee Pad User Manual

TF101/TF101G

Charging Your Batteries

If you intend to use battery power, be sure to fully charge your battery pack before going on long trips. Remember that the power adapter charges the battery pack as long as it is plugged into the computer and an AC power source. Be aware that it takes much longer to charge the battery pack when the Eee Pad is in use.

Remember to fully charge the battery (8 hours or more) before rst use and whenever it is depleted to prolong battery life. The battery reaches its maximum capacity after a few full charging and discharging cycles.

Airplane Precautions

Ask an airline personnel if you want to use your Eee Pad onboard an aircraft. Most airlines have restrictions for using electronic devices. Most airlines allow electronic use only between and not during takeos and landings.

There are three main types of airport security devices: X-ray machines (used on items placed on conveyor belts), magnetic detectors (used on people walking through security checks), and magnetic wands (hand-held devices used on people or individual items). You can send your Eee Pad through airport X-ray machines. But do not send your Eee Pad through airport magnetic detectors or expose it to magnetic wands.

Contents

Package Contents .............................................................................................. 4

Your Eee Pad......................................................................................................... 5

Charging the Eee Pad ....................................................................................... 8

Your Eee Pad mobile docking (optional) ................................................... 9

Docking the Eee Pad .......................................................................................12

Charging the Eee Pad on the docking ......................................................13

Basic ...................................................................................................................14

Unlock your Eee Pad ......................................................................................14

Desktop .............................................................................................................14

ASUS Launcher ................................................................................................15

Touch panel control .......................................................................................16

File Manager .....................................................................................................18

Market .............................................................................................................21

Settings ................................................................................................................22

Music ...................................................................................................................23

Image ...................................................................................................................24

Gallery .............................................................................................................24

Camera .............................................................................................................27

Mail ...................................................................................................................28

Email .............................................................................................................28

Gmail .............................................................................................................30

Reading ................................................................................................................ 31

MyLibrary ...........................................................................................................31

Locating ...............................................................................................................34

Places and Maps ..............................................................................................34

Documenting ....................................................................................................35

Polaris® Ofﬁce ..................................................................................................35

Sharing .................................................................................................................38

MyNet .............................................................................................................38

MyCloud .............................................................................................................40

ASUS Eee Pad Manual

Eee Pad PC Suite (on PC) ................................................................................47

MyDesktop PC Server....................................................................................47

ASUS Webstorage ...........................................................................................47

ASUS Sync .........................................................................................................48

Declarations and Safety Statements .........................................................50

Federal Communications Commission Statement .............................50

RF Exposure Information (SAR) ..................................................................50

IC Regulations ..................................................................................................51

IC Radiation Exposure Statement .............................................................51

CE Mark Warning .............................................................................................52

Power Safety Requirement .........................................................................52

ASUS Recycling/Takeback Services ..........................................................52

Limitation of Liability ......................................................................................54

ASUS Eee Pad Manual

Package Contents

User Manual

Eee Pad USB Charger

Power Plug Docking connector to USB cable

User Manual Warranty Card

• If any of the items is damaged or missing, contact your retailer.

• The power plug that comes with your Eee Pad may vary depending on your territory to t the wall outlet.

ASUS Eee Pad Manual

Your Eee Pad

8 9

ASUS Eee Pad Manual

Power button

The power button turns your Eee Pad on/o. Hold the power button for 2 seconds to power on your Eee Pad. When the Eee Pad is powered on, press the power button to put the Eee Pad into sleep mode or wake it up from sleep mode. Hold the power button for 0.5 second to display the shutdown dialog box. If the system becomes unresponsive, press and hold the power switch to force the Eee Pad to power o.

Forcing the system to power o may result in data loss. Please inspect your data to ensure there is no data loss. It is strongly recommended that important data be backed up regularly.

Volume Key

Press this button to increase or decrease the system volume.

SIM Card slot (on TF101G)

The SIM card compartment allows insertion of a mobile SIM card for 3G functions.

Use a straightened paper clip to press the opening beside the SIM card slot to eject the SIM card tray.

Built-in front Camera

Use the built-in camera for picture taking, video recording, video conferencing, and other interactive applications.

Touch Screen Panel

The touch screen panel allows you to operate your Eee Pad using multi-touch up to ten ngers.

Docking Connector

• Insert the power adapter into this port to supply power to your Eee Pad and charge the internal battery pack. To prevent damage to your Eee Pad and battery pack, always use the bundled power adapter.

• Connect the docking connector to USB cable to the Eee Pad and another system (notebook or desktop) for data transmission.

• Dock the Eee Pad to the mobile docking for extended functions, including keyboard, touchpad and USB interface.

ASUS Eee Pad Manual

Built-in rear Camera

Use the built-in camera for picture taking, video recording, and other interactive applications.

Headphone Output/Microphone Input Combo Jack

The stereo combo jack (3.5mm) connects the Eee Pad’s audio out signal to amplied speakers or headphones. Using this jack automatically disables the built-in speaker.

For microphone input function, the jack supports the headset microphone ONLY.

Microphone (Built-in)

The built-in mono microphone can be used for video conferencing, voice narrations, or simple audio recordings.

mini HDMI port

Insert a mini HDMI cable into this port to connect to a high-denition multimedia interface (HDMI) device.

Micro SD Card Slot

Insert Micro SD card into this slot

ASUS Eee Pad Manual

Charging the Eee Pad

• Use only the power adapter that comes with your device. Using a dierent power adapter may damage your device.

• Using the provided power adapter and USB cord to connect your Eee

Pad to a power outlet is the best way to charge the Eee Pad.

• The input voltage range between the wall outlet and this adapter is AC 100V–240V, and the output voltage of this adapter is DC 15V, 1.2A.

• To prolong battery life, fully charge the battery for up to 8 hours

when using the Eee Pad for the rst time and whenever the battery power is fully depleted.

• TF101 can be charged via the USB port on the computer only when

it is in sleep mode (screen o) or powered o.

• Charging through the USB port may take longer time to complete.

• If the computer does not provide enough power for charging Eee

Pad, use the wall outlet instead.

• TF101G CANNOT be charged via the USB port on the computer.

ASUS Eee Pad Manual

Your Eee Pad mobile docking (optional)

Home

PgDp

PgUp

End

Enter

Backspace

Tab

Caps Lock

Shift

Ctrl

Alt

The Eee Pad mobile docking is purchased separately.

1 3

4 3

ASUS Eee Pad Manual

Docking Connector

• Connect the docking connector to USB cable to the Eee Pad and another system (notebook or desktop) for data transmission.

Battery Charge Indicator (dual-color)

With AC adapter: Green ON: Battery power is between 95% and 100%.

Orange ON: Battery power is less than 95%.

Orange Blinking: Battery power is less than 10%.

Orange Blinking Quickly: Battery power is less than 3%.

Without AC adapter and with Eee Pad: Orange Blinking Quickly: Battery power is less than 3%.

Ensure to connect the power charger when the indicator starts blinking.

USB Port (2.0)

The USB (Universal Serial Bus) port is compatible with USB 2.0 or USB

1.1 devices such as keyboards, pointing devices, ash disk drive and

hard disk drives.

Memory Card Slot

This Eee Pad mobile docking has a built-in high-speed memory card reader that can conveniently read from and write to many ash memory cards.

Mobile docking latch

Move the mobile docking latch to the left to release the Eee Pad from the mobile docking.

ASUS Eee Pad Manual

Keyboard

The keyboard provides comfortable travel (depth at which the keys can be depressed) and palm rest for both hands.

The keyboard diers for each territory.

Touchpad and Buttons

The touchpad with its buttons is a pointing device that provides the same functions as a desktop mouse.

Special Keyboard Functions

The following denes the hot keys on the Eee Pad mobile docking’s keyboard. Some commands may have standalone function and some must combine with the function key <Fn>.

The Hot Key locations on the function keys may vary depending on model but the functions should remain the same. Follow the icons instead of the function keys.

Returns to the previous page.

Toggles the internal wireless LAN ON or OFF.

Toggles the internal Bluetooth ON or OFF.

Toggles the touchpad ON or OFF.

Decreases the display brightness

Increases the display brightness

Toggles the ambient light sensor ON or OFF

ASUS Eee Pad Manual

Captures the desktop image.

Home

PgDp

PgUp

End

Home

PgDp

PgUp

End

Initiates the web browser.

Opens the Settings screen.

Returns to the previous track when playing music.

Starts playing music from your playlist. Resumes or pauses the current music playing.

Fast forward or skip to the next track during the music playing.

Mutes the speaker.

Decreases the speaker volume.

Increases the speaker volume.

Locks the Eee Pad and put it into sleep mode.

Press <Fn> and arrow keys to scroll up and down or scroll to the start and end in documents.

ASUS Eee Pad Manual

Docking the Eee Pad

1. Align the Eee Pad with the mobile docking.

2. Firmly insert the Eee Pad into the socket until the it snaps in place and the Eee Pad is properly seated.

3. Ensure that the latch completely moves to the right.

When your Eee Pad is attached to the mobile docking, never pick up the Eee Pad alone. Always pickup the entire assembly by the bottom of the mobile docking.

ASUS Eee Pad Manual

Undocking the Eee Pad

1. Use one hand to move the latch to the left to release the Eee Pad and stabilize the mobile docking.

2. Use the other hand to remove the Eee Pad from the mobile docking.

ASUS Eee Pad Manual

Charging the Eee Pad on the docking

• Use only the power adapter that comes with your device. Using a dierent power adapter may damage your device.

• The input voltage range between the wall outlet and this adapter is AC 100V–240V, and the output voltage of this adapter is DC 15V, 1.2A.

• To prolong battery life, fully charge the battery for up to 8 hours

when using the Eee Pad for the rst time and whenever the battery power is fully depleted.

• The Eee Pad cannot be charged via USB when it is connected

to the mobile docking.

ASUS Eee Pad Manual

Basic

Unlock your Eee Pad

Tap and drag the lock out of the circle to unlock your Eee Pad.

Desktop

Open Google Text search Open Google Voice search

Customize desktop

Open Apps menu

Shortcuts Display the recent apps Return to Home (the desktop) Return to the previous screen

The desktop might update and change with Android OS.

Notication area & Settings

ASUS Eee Pad Manual

ASUS Launcher

Display the local weather information. Tap to customize the weather widget settings, including the location, update frequency.

Display your email inbox. Tap to congure

the email account for the rst time, and tap

to read the unread mail in the email inbox

Display local date

folder.

ASUS Eee Pad Manual
