Asus T00C User Manual
User Manual
e8429-padfonemini.indd 1 11/18/13 8:53:09 AM
E8429
First Edition
Model: T00C
Copyright © 2013 ASUSTeK COMPUTER INC.
All Rights Reserved.
No part of this manual, including the products and software described in it,
may be reproduced, transmitted, transcribed, stored in a retrieval system,
or translated into any language in any form or by any means, except
documentation kept by the purchaser for backup purposes, without the
express written permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired,
modied or altered, unless such repair, modication of alteration is authorized
in writing by ASUS; or (2) the serial number of the product is defaced or
missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY
KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO
THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS,
ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR
ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
(INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS,
LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL
OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL
ARE FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT
TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT
BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES
THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND
SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be
registered trademarks or copyrights of their respective companies, and are
used only for identication or explanation and to the owners’ benet, without
intent to infringe.
e8429-padfonemini.indd 2 11/18/13 8:53:10 AM
Thank you for purchasing this ASUS product!
Before you start, ensure that you have read all the safety
information and operating instructions in this User Manual
to prevent injury or damage to your device.
NOTE: For the latest updates and more detailed information,
please visit www.asus.com.
Touch screen
display
Earpiece receiverFront camera
Touch keys
Getting started with the PadFone
mini 4.3
Front
Proximity and
ambient light
sensor
e8429-padfonemini.indd 3 11/18/13 8:53:10 AM
WARNING: If you plan to use your PadFone mini 4.3 with
a PadFone mini Station, we do not recommend adding a
protective lm or cover to your PadFone mini 4.3 as it can result
in difculty when inserting/removing the PadFone mini 4.3
to/from the PadFone mini Station. mini Station.Station.
Power Key
Side
Volume key
MicroUSB
Audio jack
Microphone24-pin connector
NOTE: The 24-pin connector is for connecting to the PadFone
mini Station and is not used for charging the PadFone mini 4.3.
e8429-padfonemini.indd 4 11/18/13 8:53:12 AM
Rear
Flashlight
Speaker
Rear camera Audio jack
Microphone 24-pin connector
e8429-padfonemini.indd 5 11/18/13 8:53:12 AM
Charging the PadFone mini 4.3
After installing your Micro-SIM card, we strongly
recommend that you charge your device fully before
powering it ON.
To charge your PadFone mini 4.3:
1. Connect the USB connector into the power adapter’s
USB port.
2. Connect the other end of the USB cable to the
PadFone mini 4.3.
3. Plug the power adapter into a wall socket.
NOTES:
• Use only the power adapter that came with your device.
Using a different power adapter may damage your device.
• Using the bundled power adapter and PadFone mini 4.3
signal cable to connect your PadFone mini 4.3 to a power
outlet is the best way to charge your PadFone mini 4.3.
• The input voltage range between the wall outlet and this
adapter is AC 100V - 240V. The output voltage of the micro
USB cable is DC 5.2V, 1.35A.
3
1
2
e8429-padfonemini.indd 6 11/18/13 8:53:13 AM
IMPORTANT: The rst time you power on your PadFone mini
4.3, you will see the Welcome screen. Touch the menu to select
your preferred language then touch Next Step. Follow the
onscreen instructions to set up your PadFone mini 4.3.
Turning your PadFone mini 4.3 on
or off
Press the power key at the side of your PadFone mini 4.3 to
power the device on or to power it off.
Power key
e8429-padfonemini.indd 7 11/18/13 8:53:14 AM
