ASUS A4L2 User Manual

Notebook PC
Hardware User’s Manual
E1701b / Dec 2004
Safety Statements
Federal Communications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to the following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruc­tions, may cause harmful interference to radio communications. However, there is no guarantee that inter ­ference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING! The use of a shielded-type power cord is required in order to meet FCC emission limits and to prevent interference to the nearby radio and television recep­tion. It is essential that only the supplied power cord be used. Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment.
Reprinted from the Code of Federal Regulations #47, part 15.193, 1993. Washington DC: Office of the Federal Register, National Archives and Records Administration, U.S. Government Printing Office.
Power Safety Requirement
Products with electrical current ratings up to 6A and weighing more than 3Kg must use approved power cords greater than or equal to: H05VV-F, 3G, 0.75mm
2
or H05VV-F, 2G, 0.75mm2.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.
This Class B digital apparatus complies with Canadian ICES-003. (Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.)
For use with AC Adaptor Model (Pour Utiliser Avec Modele): PA-1121-02 (120W), ADP-90FB (90W), ADP-65DB (65W)
Safety Statements
Nordic Cautions (for Notebook PC with Lithium-Ion Battery)
CAUTION! Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions. (English)
A TTENZIONE! Rischio di esplosione della batteria se sostituita in modo errato. Sostituire la batteria con un una di tipo uguale o equivalente consigliata dalla fabbrica. Non disperdere le batterie nell’ambiente. (Italian)
VORSICHT! Explosionsgetahr bei unsachgemäßen Austausch der Batterie. Ersatz nur durch denselben oder einem vom Hersteller empfohlenem ähnlichen T yp. Entsorgung gebrauchter Batterien nach Angaben des Herstellers. (German)
ADVARSELI! Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering. Udskiftning må kun ske med batteri af samme fabrikat og type. Levér det brugte batteri tilbage til leverandøren. (Danish)
VARNING! Explosionsfara vid felaktigt batteribyte. Använd samma batterityp eller en ekvivalent typ som rekommenderas av apparattillverkaren. Kassera använt batteri enligt fabrikantens instruktion. (Swedish)
VAROITUS! Paristo voi räjähtää, jos se on virheellisesti asennettu. V aihda paristo ainoastaan laitevalmistajan sousittelemaan tyyppiin. Hävitä käytetty paristo valmistagan ohjeiden mukaisesti. (Finnish)
ATTENTION! Il y a danger d’explosion s’il y a remplacement incorrect de la batterie. Remplacer uniquement avec une batterie du mêre type ou d’un type équivalent recommandé par le constructeur. Mettre au rebut les batteries usagées conformément aux instructions du fabricant. (French)
ADVARSEL! Eksplosjonsfare ved feilaktig skifte av batteri. Benytt samme batteritype eller en tilsvarende type anbefalt av apparatfabrikanten. Brukte batterier kasseres i henhold til fabrikantens instruksjoner . (Norwegian)
(Japanese)
Macrovision Corporation Product Notice
This product incorporates copyright protection technology that is protected by method claims of certain U.S.A. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
CDRH Regulations
The Center for Devices and Radiological Health (CDRH) of the U.S. Food and Drug Administration implemented regulations for laser products on August 2, 1976. These regulations apply to laser products manufactured from August 1, 1976. Compliance is mandatory for products marketed in the United States.
WARNING: Use of controls or adjustments or performance of procedures other than those specified herein or in the laser product installation guide may result in hazard­ous radiation exposure.
3
Safety Statements
Safety Statements
The following safety precautions will increase the life of the Notebook PC. Follow all precautions and instructions. Except as described in this manual, refer all servicing to qualified personnel. Do not use damaged power cords, accessories, or other peripherals. Do not use strong solvents such as thinners, benzene, or other chemicals on or near the surface.
Disconnect the AC power and remove the battery pack(s) before cleaning. Wipe the Notebook PC using a clean cellulose sponge or chamois cloth dampened with a solu­tion of nonabrasive detergent and a few drops of warm water and remove any extra moisture with a dry cloth.
DO NOT place on uneven or unstable work surfaces. Seek servicing if the casing has been damaged.
DO NOT place or drop objects on top and do not shove any foreign objects into the Notebook PC.
DO NOT press or touch the display panel. Do not place together with small items that may scratch or enter the Note­book PC.
DO NOT expose to strong magnetic or electrical fields.
DO NOT leave the Notebook PC on your lap or any part of the body while the Notebook PC is turned ON or is charging in order to prevent discom­fort or injury from heat exposure.
DO NOT expose to or use near liq­uids, rain, or moisture. DO NOT use the modem during an electrical storm.
DO NOT expose to dirty or dusty en­vironments. DO NOT operate during a gas leak.
DO NOT expose to extreme temperatures above 50˚C (122˚F) or to direct sunlight. Do not block the fan vents!
DO NOT expose to extreme tempera­tures (below 0˚C (32˚F), otherwise the Notebook PC may not boot.
DO NOT throw batteries in fires as they may explode. Check local codes for special battery disposal instruc­tions.
Safe Operating Temperatures: This notebook PC should be used in envi­ronments with ambient temperatures
0°C/32°F
between 0°C/32°F and 30°C/86°F.
30°C/86°F
4
Safety Statements
Transportation Precautions
T o prepare the Notebook PC for transport, you should turn it OFF and disconnect all external periph­erals to prevent damage to the connectors. The hard disk drive’s head retracts when the power is
turned OFF to prevent scratching of the hard disk surface during transport. Therefore, you should not transport the Notebook PC while the power is still ON. Close the display panel and check that it is latched securely in the closed position to protect the keyboard and display panel.
Cover Your Notebook PC
Use a carrying case such as the one supplied with your Notebook PC to protect it from dirt, water, shock, and scratches.
NOTE: The surface glaze is easily dulled if not properly cared for. Be careful not to rub or scrap the Notebook PC surfaces when transporting your Notebook PC.
Charge Your Batteries
If you intend to use battery power, be sure to fully charge your battery pack and any optional battery packs before going on long trips. Remember that the power adapter charges the battery pack as long as it is plugged into the computer and an AC power source. Be aware that it takes much longer to charge the battery pack when the Notebook PC is in use.
Airplane Precautions
Contact your airline if you want to use the Notebook PC on the airplane. Most airlines will have restric­tions for using electronic devices. Most airlines will allow electronic use only between and not during takeoffs and landings.
CAUTION! There are three main types of airport security devices: X-ray machines (used on items placed on conveyor belts), magnetic detectors (used on people walk­ing through security checks), and magnetic wands (hand-held devices used on people or individual items). Y ou can send your Notebook PC and diskettes through airport X­ray machines. However, it is recommended that you do not send your Notebook PC or diskettes through airport magnetic detectors or expose them to magnetic wands.
5
Safety Statements
CTR 21 Approval (for Notebook PC with built-in Modem)
Danish
Dutch
English
Finnish
French
German
Greek
Italian
Portuguese
Spanish
Swedish
6
Safety Statements
UL Safety Notices
Required for UL 1459 covering telecommunications (telephone) equipment intended to be electrically connected to a telecommunication network that has an operating voltage to ground that does not exceed 200V peak, 300V peak-to-peak, and 105V rms, and installed or used in accordance with the National Electrical Code (NFPA 70).
When using the Notebook PC modem, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following:
Do not use the Notebook PC near water, for example, near a bath tub, wash bowl, kitchen sink or
laundry tub, in a wet basement or near a swimming pool.
Do not use the Notebook PC during an electrical storm. There may be a remote risk of electric shock
from lightning.
Do not use the Notebook PC in the vicinity of a gas leak.
Required for UL 1642 covering primary (nonrechargeable) and secondary (rechargeable) lithium bat­teries for use as power sources in products. These batteries contain metallic lithium, or a lithium alloy, or a lithium ion, and may consist of a single electrochemical cell or two or more cells connected in series, parallel, or both, that convert chemical energy into electrical energy by an irreversible or revers­ible chemical reaction.
Do not dispose the Notebook PC battery pack in a fire, as they may explode. Check with local codes for
possible special disposal instructions to reduce the risk of injury to persons due to fire or explosion.
Do not use power adapters or batteries from other devices to reduce the risk of injury to persons due to
fire or explosion. Use only UL certified power adapters or batteries supplied by the manufacturer or authorized retailers.
Notebook PC Optical Drive
Laser Safety Information
Internal or external optical drives sold with this Notebook PC contains a CLASS 1 LASER PRODUCT (LASER KLASSE 1 PRODUKT). Laser classifications can be found in the glossary at the end of this user’s manual.
WARNING: Making adjustments or performing procedures other than those specified in the user’s manual may result in hazardous laser exposure. Do not attempt to disas­semble the optical drive. For your safety, have the optical drive serviced only by an authorized service provider.
Service warning label
CAUTION: INVISIBLE LASER RADIATION WHEN OPEN. DO NOT STARE INTO BEAM OR VIEW DIRECTLY WITH OPTICAL INSTRUMENTS.
7
Contents
1. Introducing the Notebook PC ................................................................11
About This User’s Manual ..................................................................................................... 12
Notes For This Manual..................................................................................................... 12
Preparing your Notebook PC ................................................................................................ 13
2. Knowing the Parts.................................................................................. 15
Top Side ................................................................................................................................ 16
Bottom Side........................................................................................................................... 18
Left Side................................................................................................................................ 20
Right Side.............................................................................................................................. 21
Rear Side .............................................................................................................................. 22
Front Side.............................................................................................................................. 23
3. Getting Started ....................................................................................... 25
Using the Battery Pack..........................................................................................................26
Installing and Removing the Battery Pack ....................................................................... 26
Charging the Battery Pack ............................................................................................... 27
Battery Care..................................................................................................................... 27
Operating Systems................................................................................................................ 27
Support Software ............................................................................................................. 27
Power Connection................................................................................................................. 29
Powering ON The Notebook PC ...................................................................................... 29
The Power-On Self Test (POST)...................................................................................... 29
Power Management - “Stand By” & “Hibernate” ................................................................... 30
Power Management......................................................................................................... 30
Restarting or Rebooting ................................................................................................... 31
Powering OFF the Notebook PC ..................................................................................... 32
Using the Keyboard............................................................................................................... 33
Colored Hot Keys............................................................................................................. 33
Microsoft Windows™ Keys .............................................................................................. 34
Keyboard as a Numeric Keypad ...................................................................................... 35
Keyboard as Cursors ....................................................................................................... 35
Instant Launch Keys and Status Indicators........................................................................... 36
Instant Launch Keys ........................................................................................................ 36
Status Indicators (Front) .................................................................................................. 37
Status Indicators (Inside) ................................................................................................. 38
CD Player Control Buttons and Indicator ......................................................................... 38
8
Contents
4. Using the Notebook PC ......................................................................... 41
Pointing Device ..................................................................................................................... 42
Using the Touchpad ......................................................................................................... 42
Touchpad Usage Illustrations ........................................................................................... 43
Caring for the Touchpad................................................................................................... 44
Optical Drive.......................................................................................................................... 45
PC Card (PCMCIA) Socket ................................................................................................... 47
32-bit CardBus Support ................................................................................................... 47
Inserting a PC Card (PCMCIA) ........................................................................................ 48
Removing a PC Card (PCMCIA)...................................................................................... 48
Flash Memory Card Reader............................................................................................. 49
Internal 10/100 Network (Gigabit on selected models) .................................................... 50
Internal Modem ................................................................................................................ 51
AC Power System .................................................................................................................52
Battery Power System........................................................................................................... 52
Charging the Battery Pack ............................................................................................... 52
Using Battery Power ........................................................................................................ 52
Using Battery Power ........................................................................................................ 53
Power Management Modes .................................................................................................. 54
Full Power Mode & Maximum Performance .................................................................... 54
ACPI................................................................................................................................. 54
Suspend Mode................................................................................................................. 54
Power Management Modes .................................................................................................. 54
Full Power Mode & Maximum Performance .................................................................... 54
ACPI................................................................................................................................. 54
Suspend Mode................................................................................................................. 54
Power Management Modes .................................................................................................. 54
Full Power Mode & Maximum Performance .................................................................... 54
ACPI................................................................................................................................. 54
Suspend Mode................................................................................................................. 54
Power Savings ................................................................................................................. 54
Power State Summary ..................................................................................................... 55
Notebook PC Upgrades ........................................................................................................ 56
System Memory Expansion ............................................................................................. 56
Hard Disk Drive Upgrades ............................................................................................... 57
System Fans and Processor............................................................................................ 57
Thermal Power Control .................................................................................................... 57
Processor Upgrades ........................................................................................................ 57
9
Contents
Appendix..................................................................................................... 59
Optional Accessories............................................................................................................. 60
USB Hub (Optional) ......................................................................................................... 60
USB 2.0 Slim Combo Drive (Optional)............................................................................. 60
Wireless LAN Cardbus Card or USB ............................................................................... 61
USB Flash Memory Disk.................................................................................................. 61
USB Communication Cable ............................................................................................. 61
USB Floppy Disk Drive .................................................................................................... 62
USB Keyboard and Mouse .............................................................................................. 62
Optional Connections............................................................................................................63
Monitor Out Connection ................................................................................................... 63
External Audio Connections ............................................................................................. 63
Printer Connection ........................................................................................................... 64
IEEE1394 Connection...................................................................................................... 64
Securing Your Notebook PC ............................................................................................ 64
DVD-ROM Drive Information................................................................................................. 65
Internal Modem Compliancy ................................................................................................. 66
Glossary................................................................................................................................ 68
Notebook PC Information...................................................................................................... 74
10
1. Introducing the Notebook PC
About This User’s Manual Notes For This Manual Preparing your Notebook PC
11
1 Introducing the Notebook PC
About This User’s Manual
You are reading the Notebook PC User ’s Manual. This User ’s Manual provides information on the various components in the Notebook PC and how to use them. The following are major sections of this User’s Manuals:
1. Introducing the Notebook PC
Introduces you to the Notebook PC and this User’s Manual.
2. Knowing the Parts
Gives you information on the Notebook PC’s components.
3. Getting Started
Gives you information on getting started with the Notebook PC.
4. Using the Notebook PC
Gives you information on using the Notebook PC’s components.
5. Appendix
Introduces you to optional accessories and gives additional information.
Notes For This Manual
This User’s Manual was created using Macintosh versions of Adobe® PageMaker™ 6.52, Adobe Photoshop™ 5.5, Adobe® Illustrator® 8.0, and Macromedia® Freehand™ 8.0.1. The body text type used in this manual is “Times” (MAC) or “T imes New Roman” (Windows™) and headings are “Helvetica” (MAC) or “Arial” (Windows™). A few notes and warnings in bold are used throughout this guide that you should be aware of in order to complete certain tasks safely and completely. These notes have different degrees of importance as described below:
TIP: Tips and useful information for completing tasks.
NOTE: Tips and information for spe­cial situations.
< > [ ]
WARNING! Important information that must be followed for safe operation.
IMPORTANT! Vital information that must be followed to prevent damage to data, components, or persons.
T ext enclosed in < > or [ ] represents a key on the keyboard; do not actually type the < > or [ ] and the enclosed letters.
®
12
Introducing the Notebook PC 1
Preparing your Notebook PC
These are only quick instructions for using your Notebook PC. Read the later pages for detailed infor­mation on using your Notebook PC.
1. Unlock the battery.
LockUnlock
2. Connect the AC Power Adapter
[3]
[1]
3. Open the Display Panel 4. Turn ON the Notebook PC
[2]
(1) Slide the display release button (2) Lift the display panel with one hand while
holding the system portion with your other
hand.
Press the power button and release. (In Windows XP, this button can also be used to
safely turn OFF the Notebook PC.)
13
1 Introducing the Notebook PC
14
2. Knowing the Parts
Top Side Bottom Side Left Side Right Side Rear Side Front Side
15
2 Knowing the Parts
Top Side
Refer to the diagram below to identify the components on this side of the Notebook PC. Details are given starting from the top and going clockwise.
Display Panel Latch
Release
Display Panel
Audio Speaker
(on selected models)
Audio Speaker
Air Vents
Air Vents Air Vents
CD Control Buttons
(see section 3)
Status
Indicators
Audio Speaker (on selected models)
Audio Speaker Instant Keys /
Power Switch Keyboard
Touchpad
Display Panel Latch Release
Spring-loaded latch mechanism on the front of the Notebook PC locks the display panel in the closed position when the Notebook PC is not in use. To open the display panel, slide the latch release with your thumb and lift up the display panel with the same thumb. Slowly tilt the display panel forward or backward to a comfortable viewing angle.
WARNING! When opening, do not force the display panel down to the table or else the hinges may break! Never lift the Notebook PC by the display panel!
16
Knowing the Parts 2
Display Panel
The display panel functions the same as a desktop monitor. The Notebook PC uses an active matrix TFT LCD, which provides excellent viewing like that of desktop monitors. Unlike desktop monitors, the LCD panel does not produce any radiation or flickering, so it is easier on the eyes.
Audio Speakers
The built-in speaker system allows you to hear audio without additional attachments. The multimedia sound system features an integrated digital audio controller that produces rich, vibrant sound (results improved with external stereo headphones or speakers). All audio features are software controlled.
Instant Keys
Instant keys allow you to launch frequently used applications with one push of a button. Details pro­vided later in this manual.
Power Switch
The power switch allows powering ON and OFF the Notebook PC and recovering from STD. Push the switch once to turn ON and once to turn OFF the Notebook PC.
Keyboard
The keyboard provides full-sized keys with comfortable travel (depth at which the keys can be de­pressed) and palm rest for both hands. T wo W indows™ function keys are provided to help ease naviga­tion in the Windows™ operating system.
Touchpad and Buttons
The touchpad with its buttons is a pointing device that provides the same functions as a desktop mouse. A software-controlled scrolling function is available after setting up the included touchpad utility to allow easy Windows or web navigation.
Status Indicators
Status indicator details are described in section 3.
17
2 Knowing the Parts
Bottom Side
Refer to the diagram below to identify the components on this side of the Notebook PC. Details are given starting from the top and going clockwise.
Air Vents Air Vents
Bottom Cover Screw
Bottom
Cover
Screw
Air Vents
Cover Screw
Air Vents Air VentsBottom
Air Vents
Name Card Holder
Air Vents
Bottom Cover Screw
IMPORT ANT! The bottom of the Notebook PC can get very hot. Be careful when han­dling the Notebook PC while it is in operation or recently been in operation. High temperatures are normal during charging or operation. DO NOT PUT THE NOTEBOOK PC ON THE LAP OR OTHER P ARTS OF THE BODY T O AVOID INJURY FROM THE HEAT .
18
Knowing the Parts 2
Air Vents
The air vents allow cool air to enter and warm air to exit the Notebook PC.
IMPORTANT! Make sure that paper, books, clothing, cables, or other objects do not block any of the air vents or else overheating of the Notebook PC may occur.
Bottom Cover Screws
This notebook PC contains easy to install/upgrade components under the bottom cover. Several screws must be removed to open the bottom cover.
IMPORTANT! For electrical safety reasons, you must remove the phone (modem) cable before removing the bottom cover.
19
2 Knowing the Parts
Left Side
Refer to the diagram below to identify the components on this side of the Notebook PC.
®
Kensington Lock Port USB Ports
Battery Power Switch
Shut down switch
DC Power Input Jack
Mic Input
Head Output
Kensington® Lock Port
The Kensington® lock port allows the Notebook PC to be secured using Kensington® compatible Note­book PC security products. These security products usually include a metal cable and lock that prevent the Notebook PC to be removed from a fixed object. Some security products may also include a motion detector to sound an alarm when moved.
Power (DC) Input
The supplied power adapter converts AC power to DC power for use with this jack. Power supplied through this jack supplies power to the Notebook PC and charges the internal battery pack. To prevent damage to the Notebook PC and battery pack, always use the supplied power adapter.
2.0
USB Port (2.0/1.1)
The Universal Serial Bus is compatible with USB 2.0 or USB 1.1 devices such as keyboards, pointing devices, video cameras, modems, hard disk drives, printers, monitors, and scanners connected in a series up to 12Mbits/sec (USB 1.1) and 480Mbits/sec (USB 2.0). USB allows many devices to run simultaneously on a single computer, with peripherals such as USB keyboards and some newer moni­tors acting as additional plug-in sites or hubs. USB supports hot-swapping of devices so that peripher­als can be connected or disconnected without restarting the computer.
Microphone Input Jack (Mic In)
The mono microphone jack (1/8 inch) can be used to connect an external microphone or output signals from audio devices. Use this feature for video conferencing, voice narrations, or simple audio recordings.
Headphone Output Jack (Phone Out)
The stereo headphone jack (1/8 inch) is used to connect the Notebook PC’s audio out signal to ampli­fied speakers or headphones. Using this jack automatically disables the built-in speakers.
20
Knowing the Parts 2
Right Side
Refer to the diagram below to identify the components on this side of the Notebook PC.
PC Card Slot PC Card Eject Flash Memory Slot
Optical Drive
Emergency
Eject
Electronic
Eject
SIR Port
1394 Port
USB Ports
PC Card Slot
One PCMCIA 2.1 compliant PC Card socket is available to support one type I/II PC card. The socket supports 32-bit CardBus. This allows accommodation of Notebook PC expansion options such as memory cards, ISDN, SCSI, Smart Cards, and wireless network adapters.
Optical Drive
The Notebook PC comes in various models with different optical drives. The Notebook PC’s optical drive may support compact discs (CD) and/or digital video discs (DVD) and may have recordable (R) or re-writable (RW) capabilities. See the marketing specifications for details on each model.
Flash Memory Slot
Normally a PCMCIA or USB memory card reader must be purchased separately in order to use memory cards from devices such as digital cameras, MP3 players, mobile phones, and PDAs. This Notebook PC has a built-in memory card reader that can read the several flash memory cards. More information is provided in section 4 of this manual.
1394 Port
IEEE1394 is a high speed serial bus like SCSI but has simple connections and hot-plugging capabilities like USB. The interface IEEE1394 has a bandwidth of 100-400 Mbits/sec and can handle up to 63 units on the same bus. IEEE1394 is also used in high-end digital equipment and should be marked “DV” for Digital V ideo port.
SIR Port (Standard Infrared)
The standard infrared (IrDA) communication port allows convenient wireless data communication with infrared-equipped devices or computers. This allows easy wireless synchronization with PDAs or mobile phones and even wireless printing. If your office supports IrDA networking, you can have wireless connection to a network anywhere provided there is a direct line of sight to an IrDA node.
2.0
USB Port (2.0/1.1) (see “Left Side”)
21
2 Knowing the Parts
Rear Side
Refer to the diagram below to identify the components on this side of the Notebook PC.
Modem Port LAN Port
Monitor Port
TV Out Port
Parallel Port
Air Vents
Modem Port
The RJ-11 telephone port supports an RJ-11 telephone cable. The internal modem supports up to 56K V.90 transfers. The built-in connector allows convenient use without a dongle.
IMPORT ANT! The built-in modem does not support the voltage used in digital phone systems. Do not connect the modem port to a digital phone system or else damage will occur to the Notebook PC.
LAN Port (100/10)
The RJ-45 LAN port supports an RJ-45 Ethernet cable. The internal LAN supports 100BASE-TX/ 10BASE-T standards. The built-in RJ45 port allows convenient use without additional adapters.
Display (Monitor) Output
The 15-pin D-sub monitor port supports a standard VGA-compatible device such as a monitor or pro­jector to allow viewing on a larger external display.
Parallel Port
The 25-pin D-sub parallel/printer port supports native parallel devices such as laser/inkjet printers, or parallel-adapted device such as external hard drives, removable drives, or scanners.
TV-Out Port
For times when you need a really big display , try the TV-Out function. TV-Out allows a high definition connection to a television or video projection device using a Super VHS (S-Video) cable (not pro­vided). An adapter is provided for use with RCA inputs available on all standard video devices. This port support NTSC or PAL formats.
22
Front Side
Refer to the diagram below to identify the components on the front side of the Notebook PC.
Display Panel Latch
Release
Air Vents Air Vents
Display Panel Latch Release
Spring-loaded latch mechanism on the front of the Notebook PC locks the display panel in the closed position when the Notebook PC is not in use. To open the display panel, slide the latch release with your thumb and lift up the display panel with the same thumb. Slowly tilt the display panel forward or backward to a comfortable viewing angle.
WARNING! When opening, do not force the display panel down to the table or else the hinges may break! Never lift the Notebook PC by the display panel!
Air Vents
The air vents allow cool air to enter and warm air to exit the Notebook PC.
IMPORTANT! Make sure that paper, books, clothing, cables, or other objects do not block any of the air vents or else overheating of the Notebook PC may occur.
23
Loading...
+ 53 hidden pages
