Astra 4525 User Guide

Download

Page 1

Owner’s Manual

BLANCHARD

JOHN

DIAL CHNGE

Mæstro 4525

••••

Page 2

Contents

Introduction 1

Unpacking the phone 2 Handset 3 Base 4

Installation 5

Choosing the best location 5 Connecting the telephone 5 Attaching the stand in the desk mount position 6 Attaching the stand in the wall mount position 7 Charging the handset battery 8 Quick charge 9 Battery level indicator 9 Battery saver mode 9 Changing the battery 10 Range of operation 10

Making basic calls 11

Using the handset 11 Putting a call on hold 11 Using display keys to access features 11

Personalizing your telephone 12

Improving call reception 12 Changing the security code 12 Alternate language 12 Handset ringer volume 13 Handset receiver volume 13 Base volume 13 Setting the area code 13

Page 3

Using the Callers List 14

Setting up the Callers List 15 Viewing the Callers List 15 Dialing from the Callers List 16 Copying a number to the Directory 16 Deleting items in the Callers List 16

Using advanced features 17

Other dialing methods 17 Redial List 17 Using the Call Timer 17 Making an intercom call 18 Call Waiting and Three Way Calling 18

Using the Directory 19

Dialing in the Directory 19 Viewing the Directory 19 Saving numbers 20 Entering names 20 Editing the Directory 21

Display and indicators 22

Display prompts 22 Handset lights 24 Base lights 24

Helpful hints 25 Regulatory information 27 Warranty information 31 Index

Page 4

Page 5

Introduction

Congratulations on your purchase of a Mæstro 4525 cordless telephone.

Walking and talking with cordless technology

With the Mæstro 4525 you are no longer tied to your phone. You can move from room to room, or even outside while on a call. Now you’re mobile!

Secure to roam your home

Mæstro 4525 provides 1 million different security codes so that only your handset will work with your base.

Access to Advanced Features

In addition, Mæstro 4525 provides you with advanced features to save you time, and provide you with information. Some of these features are:

Name and number directory

stores up to 30 personal numbers for easy dialing.

Number and name display

shows you the number you’re dialing. With Caller ID service (available from your telephone company), see the incoming caller’s name and number before you answer the call.

Caller’s list

service to keep track of everyone who called (up to 30 entries), and allows you to easily return their call.

works with Caller ID

Intercom

base from outside a room, or ring the handset so that you can ﬁnd it.

Redial

numbers you dialed.

Backlit display and lighted dial pad

even in the dark.

Any

calls quick and easy.

25 Channel Autoscan

to achieve optimum clarity.

By the way...

Cordless telephones transmit conversations using radio waves, so there is a possibility that your conversations will be overheard by others. They should not be treated as totally conﬁdential.

The base must be located where the signals will not be blocked by large metal objects (metal fencing, large applicances, etc), or interfered with by electronic devices (microwave ovens, computers, stereos, etc).

Your handset is powered by rechargeable batteries, which must be charged and maintained as described in the Installation chapter.

This guide covers

• a tour of your telephone

• installation and setup

• using your Mæstro 4525

allows you to call the

key remembers the last 3

lets you know who’s calling

key answer makes answering

allows you

Page 6

Unpacking the phone

Check to see that the following parts are included in the box. Keep the box for future use.

If any part is missing, contact the location where you obtained the phone.

Stand

Number card and lens

(factory-installed)

Handset Power adaptor Quick Reference Card

(factory-installed)

Base

Line cordBattery pack

Page 7

Handset

Antenna

Multipurpose light ((page 24)).

Two

display keys

instructions that appear above them on the display ((page 12),

activate

Backlit display shows call information, phone status prompts, and Directory items (page 18- 22).

if you have radio interference ((page 12)).

Handset volume control

loudness of the caller’s voice (page 13).

changes the channel

changes the

numbers and names ((page 20)).

lets you store and access 30

and names in the Directory

lets you store numbers

((page 11)) or exit a list ((page 14),

lets you hang up a call

person at the base ((page 18)).

((page 12)) or program a pause (page 20).

lets you talk to the

lets you place a call on hold

Navigation keys move around the display ((page 16)- 22).

individual characters ((page 17)- 22).

people who called (page 14-17).

[ ] < >

lets you delete list items or

lets you access a list of 30

last 3 numbers you dialed on the handset ((page 17)).

a call ((page 12)) although you may also press any key other than the arrow keys to answer calls.

Lighted dialpad.

let you

lets you call back the

lets you make or answer

to certain subscribed telephone company services (page 18).

Microphone

Metal contacts let you charge the handset (page 8).

Power switch

the handset when not in use for extended periods (page 8).

gives you access

lets you turn off

Page 8

Base

Handset hanger tab (page 7).

The Base light lets you know the handset is in use, there is an incoming call, or someone is on hold ((page 25)).

The Charge light lets you know that the handset is seated properly on the base ((page 8), 25).

Message light shows you have messages from your telephone company’s Voice Messaging service (page 25)

Callers light lets you know that you have new callers in the Callers List ((page 25)).

Microphone

e lets you hang up a call ((page 11)).

Intercom light (page 25)

Volume control, under the right edge, changes the volume for the speaker ((page 13)).

i lets you make or answer an intercom call. The light turns on at the same time ((page 18)).

Page 9

Installation

Choosing the best location

For best results:

• the base should be the only item plugged into the wall outlet

• the antenna should be fully extended

• the base should be centrally located, away from electrical equipment such as computers, refrigerators, fluorescent lights, stereos, etc.

• locate the base on an upper floor

• the handset should be kept as close to normal room temperature as possible

Connecting the telephone

Caution:

extend the antenna until installation is complete.

1. Plug the AC adaptor into a 120 V AC outlet and insert the small

plug into the DC 12 V jack on the back of the base (see

(page 30)).

For eye safety, do not

2. Plug one end of the telephone cord into a telephone wall jack

and the other end into the jack on the back of the base.

3. To keep the cords from being pulled out, route the cords in the channel under the base.

Note:

The AC outlet should not be controlled by a switch or connected to a power bar.

Page 10

Attaching the stand in the desk mount position

1. Fold the cords back as shown.

2. Lower the stand into the slots on the base, as shown below.

3. Slide the stand into the locked position.

4. Continue routing the cords in the channels on the stand.

5. Place the phone on a desk.

6. Pull the base antenna vertical and extend it all the way up.

7. Plug the AC adaptor into a 120 V AC outlet, which is not controlled by a switch or power bar.

Page 11

Attaching the stand in the wall mount position

1. Bring the line cord through the opening in the stand, then lower the stand into the slots on the base.

2. Slide the stand into the locked position, as shown below.

3. Plug the line cord into the wall jack. Line up the screws on the wall mount plate with the openings in the stand and slide the phone down until the mounting screws hold firmly.

4. Continue routing the cords in the channels on the stand.

5. Remove the tab from the base and reinsert it with the point up.

Make sure the tab is in all the way

. Hang the handset on the tab. If the charge light does not light up, and the handset is switched on, the tab has not been locked into position.

* We recommend that you use a wall mounting plate

(available at your phone retailer). If wall mounting without a plate, use the stand as a template for positioning screws in the wall.

Retirer

Remove

Charge

6. Pull the base antenna vertical and extend it all the way up.

Page 12

Charging the handset battery

When you ﬁrst plug in your phone, you will need to

battery for at least 5 hours

before you can use the handset. This is best done by charging overnight.

power switch

1. Leave the phone on the base as shown, with the charge light on and the

off.

charge the

Charge

Messages

Callers

End

Intercom

handset power switch

Note:

The handset power switch

is on the bottom of the handset.

2. After the battery is charged,

the handset power on

display will show:

NORTEL Maestro ENG ESPÑL

3. Select the language you want on the display by pressing the key under

ENG

for English or the key

under

ESPÑL

for Spanish.

turn

. The

Once you’ve selected your preferred language, the display will show:

Ready for use... NEXT

This idle display message will appear from now on unless other messages take priority, you’re using the handset, or the handset is sleeping (see Battery saver mode (page 10)). You can press the key

under

to view other display

messages. Now you’re ready to use the

handset! If the handset is not working or the

display keeps showing

again

, reset the handset. To do this,

Sorry! Try

follow the procedure for changing the security code ((page 12)).

Page 13

Note:

The next time you charge the handset, simply put it on the base. It is not necessary to turn the power OFF after the first charging session (see (page 9)).

Note: The handset should be stored

off the base.

longer if you allow it to run down completely between charges

the

Battery Low

the display.)

The battery will last

. (Leave it off the base until

prompt appears on

Quick charge

The Mæstro 4525 comes with a reduced charge time feature called “Quick charge”. Simply place the handset on the base (no need to turn the handset switch off). The Mæstro 4525 is able to determine how long the handset battery needs to recharge. When the handset is in the base and Quick charge is activated, the display message

battery charging...

displayed. A completely empty battery will

only take 4-5 hours to fully recharge. The handset may be left on the base even after Quick charge is ﬁnished. A “trickle” charge will keep the battery fully charged. During trickle charge you may view the Battery level indicator by pressing the

We recommend that you keep the handset as close to normal room temperature as possible. In cases of extreme heat or cold (outside in the heat or cold), the Battery level indicator may not display accurately. To ensure a fully charged battery, charge the handset for at least 5 hours. Battery life may be affected by continued exposure to extreme heat or cold.

will be

display key.

Note: Its recommended that you

only charge the battery once the

Battery low

message is displayed.

Page 14

Battery level indicator

You may check the battery level of your handset by pressing the NEXT

display key

when at the idle display. You may check this indicator when the handset is in or out of the base.

Battery

[ ]

NEXT Battery

[ ]

NEXT Battery

[ ]

- Battery is fully charged

- Battery is 2/3 charged

- -

- Battery is 1/3 charged

- -

Battery saver mode

The handset saves battery power by going into battery saver mode 45 seconds after the last key press. In this mode, the display “sleeps” (goes blank), but the handset still receives calls. When you use the handset again the display automatically “wakes up” (shows information). If it doesn’t, make sure the handset power switch is on.

Changing the battery

If you’ve charged the battery and the display still says the handset will not wake up, it’s time to replace the battery. New batteries are available from your phone retailer. Use either the GESPCH01 or the 3N-270AA Sanyo battery.

1. Move the handset power switch to OFF.

2. Slide the cover off the battery compartment.

Off

retirer

3. To remove a dead battery, pull firmly on the battery cords.

4. To install the new battery, insert the battery plug, making sure the black wire is on the left.

Battery low

remettre

5. Slide the battery into the compartment.

6. Replace the cover of the battery compartment.

7. Charge the new battery, as described on (page 8).

Page 15

Making basic calls

Range of operation

The actual operating range of your Mæstro 4525 can vary with the construction of your home, interference from household appliances, weather conditions, and other factors.

For best results:

• the base should be the only item plugged into the wall outlet

• the antenna should be fully extended

• the base should be centrally located, away from electrical equipment such as computers, refrigerators, fluorescent lights, stereos, etc.

• locate the base on an upper floor

• the handset should be kept as close as possible to room temperature

Using the handset

When you receive a call, the display shows caller information.

Note:

You must subscribe to Caller ID service from your local telephone company.

The handset power switch must be ON in order to receive or make calls.

To answer a call

When you hear the phone ring and see the multipurpose light flash:

1. Press

2. Press

Note:

dial pad. The display key will not answer a call.

the handset on the base.

The message will alternate on the display with the callers incoming name. Press the key to view the long distance number.

or any key on the

>, <

, and

to hang up or put

Long distance

display

To dial a number

1. Press

2. Dial the number.

3. Press

the handset on the base.

to hang up or put

Page 16

Personalizing your telephone

Putting a call on hold

The hold feature keeps your caller on the line so you can talk privately to someone in the room. If you forget that someone is on hold, the Mæstro 4525 releases the line after ﬁve minutes.

To put a call on hold

1. Make or answer a call.

2. Press h.

3. To take the call off hold, press t.

Using display keys to access features

Display keys are the two keys below the display on the handset.

555-1234

Improving call reception

The handset communicates with the base using one of a combination of 25-channels. Your Mæstro 4525 automatically scans for a clear channel each time you use the handset.

If you hear interference, static, or the message S and the Mæstro 4525 will automatically ﬁnd a new clear channel. The S key is on the left side of the handset.

Sorry! Try again

, press

Changing the security code

The security code ensures that someone else with a cordless handset cannot use your telephone line. There are 1 million different codes, of 6 digits in length.

Note: When the message

again

won’t disappear, try

recharging the battery.

Sorry! Try

DIAL CHNGE

The function of these keys is written above them in the display, and will depend on what feature you are using.

When a command (such as

CHNGE

) appears on the display, press the display key below to activate that command.

DIAL

Page 17

To change the security code

1. Place the handset on the base.

Handset ringer volume

You can choose from three volume settings for the handset ringer:

Low

, and

High

(the factory setting).

OFF

2. On the base, press and hold

i while also pressing Ion the handset. Hold

both keys for 5 seconds.

3. When the display shows

Security Code

display key.

4. Enter the new security code (6

digits).

5. Press the

the new code has been entered.

, press the

DONE

display key once

CHNGE

Alternate language

You can choose between English and Spanish for the handset display. English is the factory setting.

To change to Spanish

1. Turn OFF the power switch on the

handset.

2. After a few seconds, turn the

power switch back ON.

3. Press the

ESPÑL

display key.

To change the ringer volume

1. If the Handset Ring prompt is not on the display, press the display key until the prompt appears.

2. Press the time you press it, you hear the next ring setting.

3. Press e.

CHNGE

display key. Each

Handset receiver volume

The sliding volume control on the left side of the handset adjusts the volume level for what you hear on the handset. There are three settings: low volume , medium (middle position), and high volume .

Base volume

The sliding volume control under the right edge of the base sets the volume level for the base ringer and the base speaker. It can be set anywhere between Off, low volume

, and high volume .

Setting the area code

Y ou can enter one area code so that incoming local calls appear in the Callers List without it. This lets you

Page 18

Using the Callers List

dial local numbers directly from the Callers List without having to remove the area code ﬁrst.

To add or change the area code

1. Press c.

2. Press the

3. Press the (whichever appears on the display).

4. You can use a specific digit.

5. Press d to remove any existing digits.

OR Enter the three-digit number

using the dial pad.

6. Press the

CODE

display key.

ADD

CHNGE

display key

< or > to move to

DONE

display key.

To delete your area code

1. Press c.

2. Press

3. Press d.

4. If you want to delete the item,

CODE

confirm it by pressing the display key or press d again. If you don’t want to delete the item, press c or e.

Times are changing; there are more things to do that take you out of your home. You probably receive a lot of calls when you go out. When you get home, just scroll through your list of callers to see who called. Y ou can ﬁnd and respond to the important calls quickly (see (page 16)).

If you want to call one of the numbers as it appears on your display, you can save time just by pressing key under

t or pressing the

DIAL

on the display (see (page 16)). A will appear on the Time and Date screen for all entries you have called from the Callers List. You’ll know at a glance which calls you’ve returned.

To save time looking up a number in the future, you can permanently save numbers from the Callers List into your Directory ((page 17)). Once a number is in the Directory, it’s simple to retrieve it!

Note: You must subscribe to Caller ID service in order for the calls to register with the Callers List.

The Callers List holds up to 30 calls and is accessed using the handset.

Page 19

Callers List information is sorted



 



w



from oldest to newest. When the list is full, the oldest items are deleted to make room for the new callers.

When new calls come in, the Callers light on the base ﬂashes and the handset’s multipurpose light ﬂashes.

When you enter the Callers List, the display may show the following:

—

XX New Callers

—

XX Callers bumped

—

Callers = XX items

Note: For an example and explanation of what might appear on your display, see (page 22).

You can set up your Callers List to log all calls, no calls, or only those calls which you do not answer (see (page 15)).

Setting up the Callers List

You may set up the Callers List to:

1. Log all calls

(Call Log=All)

2. Log only those calls you didn’t

answer

(Call Log=Unanswered)

3. Log no calls

(Call Log=None)

Setting up the Callers List

1. Press c.

2. Press

3. Press

3. Press e.

LOG

CHNGE

until the second line of the display shows the set up you want:

all, none

, or

unanswered

To exit the Callers List at any time, press e or c.

If you are not sure what to do when you get into the Callers List, press

HELP

for some hints.

555-1152

DIAL EDIT

Sarah Pool-Alexa DIAL

R Zimmer DIAL

Dec 4 1x 9:02 am DIAL

555-2160

DIAL EDIT

555-1376

DIAL EDIT

Page 20

Viewing the Callers List

To view the Callers List

1. To see the Callers List heading, press c.

2. Use the between callers.

3. Use the between name, number, and time and date information.

4. To leave the Callers List at any time, press c or e.

The illustration below shows how the arrow keys move you up and down between callers, and left and right between name, number, and time and date screens.

[

and ] keys to move

and > keys to move

Dialing from the Callers List

You can return a call when it is displayed in the Callers List. A will appear on the Time and Date screen for all entries you’ve called from the Callers List.

To dial from the Callers List

1. Press c.

[

2. Use the caller.

3. Press the t.

Sometimes you must edit a number before it can be dialed (for example, you may have to add “1” to dial long distance). Changes are not saved in the Callers List. You may only edit numbers in the Callers List.

To edit before dialing

and ] keys to find the

DIAL

display key or

1. Press c.

[

2. Use the caller. Press number.

3. Press the

4. To erase digits, press d. To add digits, use the dial pad. To move sideways, press the

keys.

5. Press the see the updated number.

6. Press the t.

or ] keys to find the

or > to view the

EDIT

display key.

DONE

display key. You

DIAL

display key or

and

Page 21

Using advanced features

Copying a number to the Directory

To copy a number to the Directory

1. Press c.

2. Use the [ and ] keys to find the caller.

3. If the number requires editing, make the required changes.

4. Press the

5. Press s.

6. If there is no name for the number, you may enter a name See “Saving numbers” on page 20 or press the NO display key.

7. Press the

DONE

display key.

DONE

display key.

Deleting items in the Callers List

To delete in the Callers List

1. Press c.

2. If you want to delete everything in the list, go to step 3. If you want to delete just one item, use the

]

and

keys to find the caller.

3. Press d.

4. Confirm by pressing the OK display key or by pressing d again. If you’ve changed your mind, press

c or e.

[

Other dialing methods

Predial lets you view the number ﬁrst, before you dial it. It helps prevent dialing errors.

To predial a number

1. Enter the number using the dial pad.

2. If required, use move to a specific digit. Use d to erase digits.

3. Press the

DIAL

display key or

If you want to redial someone you last spoke with on the handset, you can use the Redial key.

Redial List

The Redial List lets you view the last 3 outgoing numbers. The last number dialed will automatically move to the 1st position in the list.

To redial a number

1. Press r.

2. Press [, ] or the key to move to the number you wish to dial.

3. Press t or the display key to dial that number.

Note: To delete a number in the

Redial List, press r, press d, then press the OK display key or press

d again.

display

DIAL

Page 22

Using the Call Timer

When you’re on a call, the display shows the channel you’re using in the lower left corner. After ten seconds on the call, it then begins to show how much time has passed in minutes and seconds. The timer starts counting as soon as you press

t, I or the

display key. It stops counting when you press e, although the elapsed time will be displayed for an additional 5 seconds.

DIAL

Making an intercom call

The intercom will let you make a call between the base and the handset. You cannot make any other type of call with the intercom feature. It also functions as a handset “beeper”, to help you locate the handset no matter where it may be hiding.

If you are on a regular call you can make an intercom call to the base. Your regular call will automatically be placed on hold.

To call on the intercom

1. Press i on the base or I on the handset.

To answer on the intercom

1. When you hear the handset or base ring and you see the Intercom light flashing, press i or I. On the handset, the display also indicates

Paging You...

Meanwhile, if a call comes in, just press t.

Note: If you call the base from the

handset, the handset display wil read

Paging base

Page 23

Using the Directory

Call W aiting and Three Way Calling

If you subscribe to Call Waiting or Three-Way Calling (not available in some areas), read the information from your telephone company for the exact procedures. Whenever it says to press the hook-switch, receiver button or Link, press f instead. This appears as

on the display.

You can store up to 30 frequentlycalled names and numbers in the Directory. When someone who is in your Directory calls, that person’s name and number appear on the display as you entered it into the Directory.

Note: You must subscribe to Caller ID service, available from your local telephone company.

All Directory items are sorted alphabetically by the ﬁrst word. If you want your Directory sorted by last name, enter the last name ﬁrst.

You can enter a name if you want. If you don’t enter a name, the item is sorted by number. All number items are sorted numerically at the beginning of the Directory listing.

When you are viewing items in the Directory, the list is circular. This means you can keep moving in one direction and come around to the beginning again.

Dialing in the Directory

Dialing from the Directory

1. Press D.

2. Use the [ and ] keys to find the number you wish to dial.

3. Press the t.

DIAL

display key or

Page 24

The following illustration shows



how the arrow keys move you to different screens in the Directory.

Grandma Hill DIAL CHNGE

Sam Manning DIAL CHNGE

T Jones DIAL CHNGE

555-1440

DIAL CHNGE

555-1234

DIAL CHNGE

1-425 555-7542 DIAL CHNGE

Viewing the Directory

To ﬁnd items in the Directory

1. To see the Directory list heading, press D.

2. To go directly to the items that begin with a particular letter, press the dial pad key that matches that letter. (The letters are printed on the dial pad keys.) Then, to see the other listings under that letter, press the (For example: ﬁ takes you to the first “J” listing, then the down arrow key takes you to the next “J” listing. first “K” listing.)

3. Use the up and down between items.

Use the left and right between names and numbers.

4. To leave the Directory at any time, press D or e.

ﬁﬁ

takes you to the

[

and ] keys to move

and > keys to move

]

key.

Saving numbers

To save a new number

1. Press s.

2. Enter the number using the dial pad. Numbers can have up to 16 digits. If you require a pause (for example, between a telephone number and an access code), press h where you want the pause.

Note: Each pause is 2 seconds.

3. Press the

4. If you don’t want to enter a name press

To enter a name, use the dial pad. (See Rules for entering names, on this page.)

If you make a mistake, use the d,

5. To quit and start over, press e.

6. Press the

To save a number from the display

1. Ensure that a number is on the display. It can be a predialed, redialed, or dialed Callers List number.

2. Press s.

3. Follow the instructions on the display.

4. If you entered a name, press the

DONE

Enter as many pauses as you need. A P indicates a pause has been entered.

DONE

display key.

DONE

, and > keys.

DONE

display key.

Page 25

Entering names

Editing the Directory

Rules for entering names

1. Press the key with the desired letter repeatedly until that letter

appears on the display. The letters are printed on the dial pad keys. Names can have up to 16 characters.

2. Advance to the next letter by pressing the

key or the

SKIP

display key.

3. Use

< to move backward to

insert or delete letters.

4. Press d to delete a letter.

5. Press the

[ or ]

to change the

case for each letter.

6. Press the

SPACE

display key to

enter a space between letters.

7. When you have finished, press the

DONE

display key.

Note: You don’t always have to

press the

key if the next letter is on a different key.

Example:

To enter the name

‡‡‡, °°

Ruth, press:

°, ››

Chart for special characters

The following symbols are not shown on your dial pad keys.

Symbol

& ‘ ( ) , - . Press

⁄

until the desired symbol is displayed.

To change a number

1. Press D.

2. Use the [ and ] keys to find the number you wish to change.

3. Press

to view the number.

4. While the number is on the display, press the

CHNGE

display key. The cursor appears under the first digit.

5. To insert digits, use the dial pad. (The existing digits will move to the right.)

To move the cursor sideways, press the

and > keys. To

erase digits, press d.

6. Press the

DONE

display key.

To add a name to an existing Directory item

1. Press D.

[

2. Use

3. Press >.

4. Press the

5. Follow the rules for entering

6. Press the

or ] to find desired entry.

ADD

display key.

names (page 21).

DONE

display key once

name has been entered.

Page 26

Display and indicators

Display prompts

To change a name

1. Press D.

2. Use [ and ] to find the name that you wish to change.

3. While the name is on the display, press the cursor appears under the first character.

4. To move the cursor left, press the

arrow key. To move the cursor right, press the erase letters, press d. To

Battery

insert letters, use the dial pad. To

[ ]

insert a space, press the

display key.

Battery

5. Press the

[ ]

- -

NEXT Battery

[ ]

- -

To delete a Directory item

1. Press D.

CHNGE

display key. The

arrow key. To

DONE

display key.

SPACE

Your handset display gives you instructions and information. If you want to know what to do about a particular display prompt, look it up in the following table. The prompts are listed in alphabetical order.

For other helpful hints, see (page 25).

Prompt Meaning

Battery Low

WARNING: You must recharge the handset.

Indicates battery is fully charged

Indicates battery is 2/3 full

Indicates battery is 1/3 full

2. Find the Directory item that you wish to delete.

3. Press d.

4. If you want to delete the item, confirm it by pressing the display key or by pressing d again. If you don’t want to delete the item, press D or e.

Battery charging...

Callers= XX items LOG CODE

Directory is full

Long distance

Displayed when Quick charge is active.

Callers List information: XX is the number of callers listed. Press to change set up; press

CODE

to change area

code. You are trying to add an

item to the Directory and it is full. Delete an item that you no longer use.

Caller information: The incoming call is from outside your local calling area.

LOG

Page 27

Prompt Meaning

No info available

No name

No number to save

Oct 12 2x 2:54 pm DIAL

Out of Range

(and the handset beeps)

Paging Base

Paging You

Caller information: The telephone company is unable to send caller information.

The Directory item has a number but no name. You may leave it as it is or add a name by pressing the key.

You have tried to copy a number to the Directory, but the Callers List item has an unknown or private number. These numbers cannot be saved. See “

name / number

page 23 Callers List information:

This is the time and date display. The caller called twice (2x), the last time was at 2:54 pm. Press the key to call.

WARNING: You have 30 seconds to move closer to the base before you lose the call. If you were making changes in the Directory or Callers List when you went out of range, those changes are lost after 30 seconds.

You (on the handset) are calling the base.

The base is calling the handset. Press I to answer the call.

ADD

Private

DIAL

display

” on

Prompt Meaning

Private name / number

Ready to use... NEXT

Redial empty

Rick Brown DIAL CHNGE

Ringer is High NEXT CHNGE

Caller information: The incoming caller has requested that the name (or number) not be shown.

Usual idle display prompt.

There are no numbers stored in the Redial key. Either you have deleted the items, have not dialed out, the handset has recently been turned on, or the power has been out. Dial using the dial pad, Callers List, or Directory instead.

Directory information: This is the name display of someone in the Directory. Press the

DIAL

display key to call, or press the display key to edit.

This is the volume level (

High, Low

the handset ringer.

CHNGE

, or

Off

) of

Page 28

Prompt Meaning

Sorry! Try again

Unknown number / name

XX Callers bumped

XX New Callers

555-1440

DIAL EDIT

555-1234

DIAL CHNGE

Make sure you are within range of the base, then repeat the procedure. If the prompt remains, reset the telephone by following the procedure for changing the security code (see (page 12)).

Caller information: The telephone company is unable to provide the number (or name) of this caller.

callers were removed from the Callers List to make room for new callers.

new calls have been added to the Callers List since you last checked it. Press c to access the list.

Callers List information: Press the key to call, or press the

EDIT

display key to edit.

Directory information: This is the number display of someone in the Directory. Press the

DIAL

display key to call, or press the display key to edit.

DIAL

CHNGE

display

Handset lights

Multipurpose light (top right corner)

Flash quickly

Flash You have a call on hold. Flash

slowly Flash

periodically

Intercom light

Flash quickly

You have an incoming call.

You have new callers.

If the handset is on battery saver mode, you have new callers.

You are sending or receiving an intercom call.

Page 29

Helpful hints

Base lights

Base light

Flash quickly

Flash You have a call on hold. Solid The handset is busy.

Charge light

Solid The handset battery is

Callers light

Flash slowly

Intercom light

Flash quickly

Solid You are on an intercom

You have an incoming call.

charging.

You have a new caller in your Callers List.

The base is calling the handset or the handset is calling the base.

call.

Locating the base.

For the best performance, locate the base centrally in your house, preferably in an open area, away from refrigerators, ﬂuorescent lights, TV’s, etc. In addition, the base should be plugged directly into a wall outlet that is not controlled by a switch. Do not use a power bar. Do not use a telephone line cord extension cord. Keep the handset in a location where it will be as close to standard room temperature as possible.

The phone doesn’t work.

Make sure the battery is installed properly in the handset. Make sure the battery is charged. Test the AC outlet; make sure it isn’t a switched outlet. Make sure the base is the only item plugged into the power outlet. Do not use a power bar. Reset the phone by changing the security code (see page 11).

Message light

Flash slowly

You have new messages.

You cannot get a call through.

You must subscribe to tone service from your local telephone company.

Page 30

The battery is low even after charging.

The battery of your telephone can be recharged and reused many times. If the battery fails even after charging for 5 hours, replace it with a new Sanyo battery pack GESPCH01 or a 3N-270AA. The use of other battery packs may cause serious damage or malfunctions.

There is static on the handset.

There may be interference. Press

S to change channels. If any

electrical equipment (such as a baby monitor) is in use, move away from it.

You pressed the Scan key and still have interference.

Keep pressing S until you ﬁnd a channel that is clear. Y ou may have moved to a channel that is busy on another phone (especially if you have more than one cordless phone).

The base should be plugged directly into a wall outlet, do not use a power bar.

The handset display says you're out of range, but you haven't moved.

The base may have lost power. Check that the power adaptor is plugged in. If it’s a power failure, you will lose your call after 30 seconds.

There may be radio interference caused by ﬂuorescent lights, electric motors, or computers. Turn these devices off, or move away from them.

The handset display is blank.

The handset may be in battery saver mode. Press any key to turn the display on. If that doesn’t work, the power may be off. Make sure the handset power switch is On and the battery is installed.

The display is in the other language.

Turn the handset power off, then

ENG

on. Press the English and the

display key for

ESPÑL

display key

for Spanish.

The Charge light isn't on when the handset is on the base.

The metal contacts on the handset aren't touching the contacts on the base. Place the handset on the base with the display facing up. Make sure the handset hanger tab has been inserted all the way.

Your held call is gone.

The telephone only holds a call for ﬁve minutes.

Page 31

Regulatory information

Language, ringer volume, and area code have changed back to the defaults.

The base has been without power for more than three days. Follow the procedures in the Personalizing your telephone section.

You can’t call on an extension phone.

Make sure that you haven’t left the line on hold at the cordless phone. To release the line, press t and then e.

The handset beeps.

Look at the display and do what is indicated.

What is a display key?

There are two keys below the display. When a command (such as

DIAL

CHNGE

) appears on the bottom line of the display, press the key below it to activate the command.

Radio/TV interference

Telephones equipped with electronic push-key dials generate and use radio frequency energy, and if not installed and used properly and in strict accordance with the manufacturer’s instructions, may cause interference to radio and television reception.

These telephones have been tested and found to comply with the limits for a Class B digital device in accordance with the speciﬁcations in Part 15 of the FCC rules. While these rules are designed to provide reasonable protection, there is no guarantee that interference will not occur in a particular installation. You can determine whether interference occurs by monitoring your radio or television reception while placing a call.

If your telephone causes interference, one of the following measures may correct the problem:

— Re-orient or relocate the receiving

TV or radio antenna, where this may be done safely.

— To the extent possible, move the

telephone and the radio or television farther away from each other, or connect the telephone and the radio or television to outlets on separate circuits.

— Consult the dealer or an experience

radio/television technician for additional suggestions.

Note: FCC registration does not constitute an expressed or implied guarantee of performance.

Page 32

Rights of the telephone company

If your telephone causes harm to the telephone network, the telephone company may stop your service temporarily or ask you to remove your equipment until the problem is resolved. If possible, they will notify you in advance. If advance notice is not practical, you will be notiﬁed as soon as possible and be given the opportunity to correct the situation. Y ou will also be informed of your right to ﬁle a complaint with the FCC.

Your telephone company may make changes in its facilities, equipment, operations or procedures that could affect the proper function of your telephone. If they do, you will be notiﬁed in advance to give you an opportunity to maintain uninterrupted telephone service.

Call 1-800-574-1611 for information on Aastra Telecom products.

Federal Communications Commission (FCC) notice

FCC registration number

This telephone equipment complies with Part 68, Rules and Regulations, of the FCC for direct connection to the Public Switched Telephone Network. (The FCC registration number appears on a sticker afﬁxed to the bottom of the telephone.)

Your connection to the telephone line must comply with these FCC rules:

— Use only an FCC standard RJ11W/

RJ14W or RJ11C/RJ14C network interface jack and FCC-compliant line cord and plug to connect this telephone to the telephone line. (To connect the telephone, press the small plastic tab on the plug at the end of the telephone's line cord. Insert into a wall or baseboard jack until it clicks. To disconnect, press the tab and pull out.)

— If a network interface jack is not

already installed in your location, you can order one from your telephone company. Order RJ11W/ RJ14W for wall-mounted telephones or RJ11C/RJ14C for desk or table use. In some states, customers are permitted to install their own jacks.

— Your telephone may not be

connected to a party line or coin telephone line. Connection to Party Line Service is subject to state tariffs. (Contact the state public utility commission, public service commission, or corporation commission for information.)

— It is no longer necessary to notify

the telephone company of your telephone's Registration and REN numbers. However, you must provide this information to the telephone company if they request it.

— If you make changes or modiﬁca-

tions not expressly approved by the manufacturer, you could void your authority to operate the equipment.

Page 33

— Equipment cannot be used on

public coin phone service provided by your telephone company. Connection to party line service is subject to state tariffs. (Contact the state public utility commission, public service commission or corporation commission for information.)

Signaling method

This unit’s push-key dial pad allows it to signal in tones (DTMF). It can complete calls to local and longdistance lines and can also complete long-distance calls using computer telephone systems such as MCI™ or SPRINT™.

MCI is a trademark of MCI. SPRINT is a trademark of United Telecommunications.

Ringer Equivalence Number

The FCC Registration label (on bottom of telephone) includes a Ringer Equivalence Number (REN), which is used to determine the number of devices you may connect to your telephone line. A high total REN may prevent telephones from ringing in response to an incoming call and may make placing calls difﬁcult. In most areas, a total REN of 5 should permit normal telephone operation. To determine the total REN allowed on your telephone line, consult your local telephone company.

Hearing aids

This telephone is compatible with hearing aids equipped with an appropriate telecoil option.

Page 34

Programming emergency numbers

When programming emergency numbers or making test calls to emergency numbers:

1. Remain on the line and brieﬂy

explain to the dispatcher the reason for calling before hanging up.

2. Perform such activities in the off-

peak hours, such as early morning or late evenings.

UL installation instructions

Warning: To avoid electrical shock hazard to personnel or damage to equipment, observe the following precautions when installing telephone equipment:

1. Never install telephone wiring

during a lightning storm.

2. Never install telephone jacks in wet

locations unless the jack is speciﬁcally designed for wet locations.

3. Never touch uninsulated telephone

wires or terminals unless the telephone line has been disconnected at the network interface.

4. Use caution when installing or

modifying telephone lines.

The exclamation point within an equilateral

triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

This symbol on the product is used to identify the following important information. Use only with:

— Aastra Telecom model

SPA-3545A-82 (Salom Electric)

power adaptor. OR — CSA-NRTL certiﬁed or UL listed,

CLASS 2 power source (12 Vac/200

mA max/50 or 60 Hz).

This product contains a NICKEL-CADMIUM

RECHARGEABLE BATTERY WHICH MUST BE RECYCLED OR DISPOSED OF PROPERLY. Recycling facilities may not be available in all areas. The enclosed battery is labeled indicating its type.

Important safety instructions

1. Read and understand all

instructions .

2. Follow the warnings and

instructions marked on the product.

3. Unplug this product from the wall

outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

Page 35

Warranty information

4. Do not use the base near water; for example, near a bath tub, wash bowl, kitchen sink, laundry tub, swimming pool, or in a wet basement.

5. Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious damage to the product.

6. This product should never be placed near or over a radiator or heat register. This product should not be placed in a built-in installation unless proper ventilation is provided.

7. Do not allow anything to rest on the power cord. Do not locate this product where the cord will be abused by people walking on it.

8. Do not overload wall outlets and extension cords as this can result in the risk of ﬁre or electric shock.

9. Never spill liquid of any kind on the product.

10. To reduce the risk of electric shock, do not disassemble this product. Have it sent to a qualiﬁed service person when some service or repair work is required.

11. Unplug the base from the wall outlet and refer servicing to qualiﬁed service personnel under the following conditions: a. when the power supply cord or

plug is damaged or frayed.

b. if the product has been exposed

to rain or water, or other liquid has been spilled on the product: disconnect and allow the product to dry out to see if it still operates; but do not open up the product.

c. if the product housing has been

damaged.

d. if the product exhibits a distinct

change in performance.

12. Avoid using the base during an electrical storm. There may be a remote risk of electric shock from lightning.

13. Do not use the telephone to report a gas leak in the vicinity of the leak.

14. CAUTION: To eliminate the possibility of accidental damage to cords, plugs, jacks, and the telephone; do not use sharp instruments during the assembly procedures.

15. Save these instructions.

Page 36

Coverage

Aastra Telecom warrants this product against defects in quality and workmanship for a period of twelve (12) months from the date of original purchase. Aastra Telecom shall, at no charge and at its option, repair or replace a defective telephone set or component thereof with a new or factory rebuilt telephone set or component, if returned within the warranty period.

If replacement parts are used in making repair, these parts may be refurbished or may contain refurbished materials. If it is necessary to replace the product, it may be replaced with a refurbished product of the same design and color. If it should become necessary to repair or replace a defective or malfunctioning product under this warranty, the provisions of the warranty shall apply to the repaired or replaced product until the expiration of ninety (90) days from the date of pickup, or the date of shipment to you of the repaired or replacement product or until the end of the original twelve (12) month warranty period, whichever is later. Proof of the original purchase date is to be provided with all telephone sets returned for warranty repair.

Exclusions

Aastra Telecom does not warrant this product to be compatible with the equipment of any particular telephone company. This warranty does not extend to damage to the product resulting from improper installation or

operation, alteration, accident, neglect, abuse, misuse, ﬁre or natural causes such as storms and ﬂoods, after the product is in your possession.

Aastra Telecom shall not be liable for any incidental or consequential damages, including but not limited to loss, damage, or expense directly or indirectly arising from the customer’s use of or inability to use this product, either separately or in combination with other equipment. This paragraph, however, shall not apply to consequential damages for injury to the person in the case of telephones used or bought for use primarily for personal, family, or household purposes.

The warranty sets forth the entire liability and obligations of Aastra Telecom with respect to breach of warranty, and the warranties set forth or limited herein are the sole warranties and are in lieu of all other warranties, expressed or implied, including warranties or ﬁtness for particular purpose and merchantability.

Repair information

If you have several telephones and you are having problems with all of them, or if your telephone works in some outlets and not in others, your problem may originate with the local telephone lines or with central ofﬁce equipment. Contact your local telephone company repair service listed in the front of your phone book.

Page 37

Should your telephone fail during the twelve-month warranty period, please return it for repair to the place of purchase, You will be responsible for shipping charges, if any, and for presenting proof of your telephone’s date of purchase.

If the terminal is covered by a Telephone Company Maintenance Agreement, follow the procedure set forth in the Maintenance Agreement for obtaining repair or replacement of the terminal.

If the terminal is no longer covered by the Aastra Telecom Inc. warranty, and is not covered by a Telephone Company Maintenance Agreement, you may return the terminal to the manufacturer for repair or refurbishment. Y ou will be billed for any repairs.

Repair to this equipment may only be made by Aastra Telecom Inc. and its authorized agents, and by others who may be authorized by the FCC.

Questions about the warranty or repairs, or the manufacturer's policy on repair and refurbishment should be directed to by calling (toll free) 1-800-574-1611.

State law provisions

This warranty gives you speciﬁc legal rights and you may have other rights which vary from state to state. Some states do not allow the exclusion of incidental or consequential damages or allow limitation of implied warranties or their duration, so that above exclusions or limitations may not apply.

Page 38

Index

Answering calls

any key 1,

Handset Antenna 3, 5, Area code Arrow keys 3, 15– Attaching the stand 6,

Base

Base light 4,

Callers light 4,

Description

Intercom light 4,

Locating 5,

Message light 4,

Volume control 4, Base lights Battery

Changing

Charging 8,

Level indicator

Replacing Battery disposal Battery Low 8, 22, Battery pack 2,

Call reception 12, Call timer Call Waiting Callers bumped 14, Callers key 3, Callers light 4, Callers List

Copying to Directory

Deleting items

Description 14–16, 22,

Dialing

4 25

Logging Setting up

Calls

Answering Holding

Making Channel, changing Charge light 4,

Problems Charging CHNGE display key 11, 12, 13, 15,

21, 23

Delete key 3, 16, 17, Desk mount DIAL display key 16, 17, 19, 22, 23,

Dialing

Directory 19–

Directory is full 22 Display 1, 3

Callers List

Astra 4525 User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
