Astoria Tanya SAE 2 User Manual

TANYA

SAE

Tanya

With simple yet balanced aesthetics, the Tanya SAE/2 automatic is the ideal solution for those seeking the best
combination of quality, simplicity and reliability. The Tanya features four programmable volumetric dosages of water for
coffee brewing from each group head, two multidirectional stainless steel steam wands and hot water tap. The Tanya
SAE/2 is equipped with redesigned thermal compensated group heads and a boiler with installed heat exchanger.

Think espresso.

Tanya SAE 2

TANYA

SAE 2gr.

Technical features

– Built-in motor pump-Automatic water refill (A.W.R.)
– Two stainless steel steam wands
– One hot water spout
– Rechargeable water softener
– Body with panels in stainless steel and in painted steel
– Boiler and pipes made in copper
– Dual gauges for boiler and pump pressure control

Equipment kit

– 2 double & 1 single portafilter
– Plastic tamper
– Spoon
– Connecting hoses
– Drain line
– Reducer
– Blind filter basket

Color

– Glossy Black/Stainless Steel

Technical specifications SAE 2

Boiler capacity qts 11

Heating element W 3,700

Total wattage W 3,750

Voltage V 220

Amps A 17

Width in 27.6”

Depth in 21.3”

Height in 20.5” (w/ 4” adjustable legs)

Cup height - tray to group head in 5.5”

Net weight lbs 132

Shipping weight with water softener lbs 176

Connections

It is the policy of General Espresso Equipment
Corporation to continuously improve the
products that we sell. For this reason,
we reserve the right to make changes in
specifications, data and design without
notice.

Astoria espresso/cappuccino machines
are “ UL” listed for safety.

Astoria espresso/cappuccino machines
are “ ETL” listed for sanitation under
“NSF-4” standards.

power cord

7.5”

drain

water
inlet

10”

8”

6.5”

3.5”3.5”

General Espresso Equipment Corporation

Supplier of the most complete line of espresso
cappuccino coffee machines, coffee grinders and accessories.

7912 Industrial Village Road - Greensboro, N.C. 27409
Tel. [phone] - Fax [phone]
www.usa.astoria.com - e-mail: [e-mail]

distributed by:

code 02991204 - 04/2012
