Astoria 1 GR JUN User Manual

The Astoria PERLA AEP semi-automatic espresso/
cappuccino machine is engineered with the latest features
in terms of ergonomics and ease to use. Recognized
worldwide for its reliability and performance with a large
boiler and powerful heating element, it can supply a
constant flow of dry steam for the preparation of espresso
based drinks in the busiest coffee shop. This model dispenses
coffee servings from each brewing head with independent
semiautomatic switches.

The

PERLA AEP

espresso and

cappuccino

coffee machine.

AEP 3 GROUPS

STAINLESS STEEL

General Espresso Equipment Corporation

Supplier of the most complete line of espresso, cappuccino coffee machines, coffee grinders and accessories.
7912 Industrial Village Road - Greensboro, N.C. 27409 - Tel. [phone] - Fax [phone]
www.astoria.com - e-mail: [e-mail]

The Perla AEP semi-automatic model features: quality proven, built-in
adjustable rotary vane pump driven by a quiet, water cooled 1/5 hp.
electric motor, automatic water filler, see-through water level glass,
two (junior excluded) high output multidirectional stainless steel wands
with antiburning sleeves, dual setting main switch to power the heating
element after the filling of the boiler.
The Perla AEP semi-automatic is equipped with heat exchangers,
thermocompensated group heads with preinfusion technology and electric
cup warmer.

technical specifications

Frame Construction: Electroplated steel assembled without

welding

Steam Wand: Stainless steel

Outer Body: Baked enamel steel

Equipment kit: Regenerable s/s water softener and connecting

hoses 3/8”.

Color: stainless steel.

Electrical Cord Length: 6 ft.

Motor Pump: Built-in water cooled motor and adjustable

vane pump.

data specifications 1 GR JUN 2 GR 3 GR 4 GR

Boiler Capacity
Voltage
Amps Rating
Heating Element
Total Wattage
Width
Depth
Height
Cup Height (group head to drain tray) inch 5” 3/4
Top cups holding surface
Net Weight
Shipping Weight with Water Softener

qts 6 11,1 18 24,3
V / Hz 110 V / 50 - 60 Hz 220 V / 50 - 60 Hz
Amp 18,4 18,2 23,2 23,2
W 2.000 4.000 5.000 5.000
W 2.330 4.330 5.330 5.330
inch 15” 30” 39” 1/2 48” 3/4
inch 22” 1/4
inch 22” (w/4’’ Adjustable legs)

inch 14” 3/4 x 12” 1/4 14” 3/4 x 26” 14” 3/4 x 35” 1/4 14” 3/4 x 44” 3/4
lbs 128 147 182 213
lbs 148 191 238 271

Astoria espresso/cappuccino machines are “ UL”
listed for safety.

Astoria espresso/cappuccino machines are “ ETL”
listed for sanitation under “NSF-4” standards.

water connections

junior excluded

drain

water inlet

GEnERAl ESPRESSO
EqUiPmEnt CORPORAtiOn

It is the policy of General Espresso Equipment Corporation to continuously improve the
products that we sell. For this reason, we reserve the right to make changes in
specifications, data and design without notice.

5”

6”

12”

distributed by:

code 02801200
