Model No: 50105607
Ashelina 3 - Piece Bistro Set
Instruction Manual
Due to ongoing product development
the actual product or products may vary from
the illustrations or photos shown within this manual.
Page 2
Table Assembly
1.(SEE FIGURE 1) Place table top (A)
upside down on a flat non-scratch
surface.
2.Using a flat head screw driver,
thread studs (G) into the three holes
at bottom of table top (A).
3.Attach table legs to studs on bottom
of table top with flat washers (J) and
hex nuts (K).
4.Do not fully tighten fasteners.
5.(SEE FIGURE 2) Position center ring (C)
over studs (H) in table legs (B) and secure
with flat washers (J) and hex nuts (K).
6.Turn table upright on a flat level surface
and tighten all fasteners.
Chair Assembly
1.(SEE FIGURE 3) Using a flat head
screw driver, thread studs (I) into
holes in bottom of chair backs (D) and
studs (H) in chairs seats (E) until seated.
2.Insert studs in chair backs (D) through
holes in chair seats (E) and secure
with flat washers (J) and hex nuts (K).
3.Fit one chair leg (F) over studs in
bottom of chair seat (E) and secure
with flat washers (J) and hex nuts (K).
Repeat for the other legs.
REQUIRED TOOLS (NOT INCLUDED)
Flat Drive Screwdriver
PARTS & HARDWARE LIST
ASSEMBLY INSTRUCTIONS
PART # DESCRIPTION QUANTITY
A 1Table Top
B 3Table Leg
C 1Center Ring
D 2Chair Back
Chair SeatE 2
Chair LegF 8
Stud, 8mm x 30G 3
Flat Washer, 8mm
I 4
Stud, 8mm x 25H 19
Hex Nut, 8mm
J 26
A
B
C
D
E
F
G
H
J
K
Carefully remove the contents from the package. If any parts are missing do not
attempt to use the product until they have been obtained and correctly installed.
CAUTION: Do not over tighten fasteners.
CAUTION: Do not over tighten fasteners.
IF YOU HAVE ANY PROBLEMS OR QUESTIONS CONCERNING THIS PRODUCT,
DO NOT RETURN IT TO YOUR RETAILER. CONTACT CUSTOMER SERVICE AT
1-888-424-3354.
J
K
J
K
J
K
B
H
H
A
B
B
B
J
J
J
K
K
K
G
G
G
C
Figure 1
I
Figure 2
Figure 3
F
E
D
K
J
I
K
J
H
K
Stud, 8mm x 35
26
H
2
1
