Model No. 40201142

Whiskey Barrel Fountain

with Planter

Instruction Manual

Due to ongoing product development

the actual product or products may vary from

the illustrations or photos shown within this manual.

NOTE: This product is intended for residential, non-commercial use.

311011rev1

Read the instructions and precautions before use of this product

Please keep this instruction manual for future reference

Made in China

Distributed by:

World Factory, Inc.

Westlake, TX 76262

For warranty information, please refer to the back page of

this instruction manual.

Limited Warranty

World Factory, Inc. Products for Home Use

World Factory, Inc. (Seller) warrants to the original Buyer only, that each Astonica Product will be free from defects in material and workmanship for a period of one (1) year from date of purchase.

SELLER’S SOLE OBLIGATION AND BUYER’S EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE THE REPAIR OR REPLACEMENT OF PARTS, WITHOUT CHARGE, WHICH ARE DEFECTIVE IN MATERIAL OR WORKMANSHIP. ANY PARTS AS DETERMINED BY THE

SELLER WHICH HAVE BEEN MISUSED; ABUSED OR DAMAGED EITHER DIRECTLY OR INDIRECTLY FROM REPAIRS OR ALTERATIONS ATTEMPTED BY UNAUTHORIZED PERSONS; IMPROPER MAINTENANCE, NEGLECT OR ACCIDENT ARE NOT COVERED BY THIS LIMITED WARRANTY. This warranty does not apply to damage, heat-induced coloration changes, scratching or alteration due to normal use or weathering. To make a claim under this Limited Warranty, you must return the complete product with proof of purchase, transportation prepaid, to any World Factory, Inc. authorized service center. Call 1-888-422-7800 for the location of the nearest authorized service center.

Additional Limitations

THIS LIMITED WARRANTY DOES NOT APPLY TO ACCESSORY OR CONSUMABLE ITEMS RELATED TO THIS PRODUCT. ALL IMPLIED WARRANTIES SHALL BE LIMITED IN DURATION TO ONE (1) YEAR FROM DATE OF PURCHASE. IN NO EVENT SHALL SELLER BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO LIABILITY FOR LOSS OF PROFITS, ARISING FROM THE SALE OR USE OF THIS PRODUCT.

If any provision of this Limited Warranty is for any reason held to be invalid or unenforceable, such provision shall not affect any other provision herein, this Limited Warranty shall be construed as if such invalid and/or unenforceable provision had never been contained herein.

This warranty gives you special legal rights, and you may also have other rights which vary from state to state.

This Warranty contains the entire agreement between Seller and Buyer and supersedes any and all prior agreements, arrangements, or understandings between the parties relating to product warranty.

Page 2

A Barrel 1

B Hand Pump with Pipe 1

C Electric Pump 1

D Screw 3

ELECTRICAL SAFETY INSTRUCTIONS WARNING! ELECTRICAL SHOCK. Read and understand all instructions. Failure to follow all

instructions listed below, may result in electrical shock, ﬁre and/or serious personal injury.

Grounding Instructions

This fountain must be plugged into a 3-wire, 3-prong outlet that is properly working and has been installed and grounded in accordance with all local, state or federal codes and ordinances.

DANGER: IMPROPER INSTALLATION OF THE GROUNDING PLUG CAN RESULT IN A RISK OF

ELECTRICAL SHOCK. Check with a qualiﬁed electrician or serviceman if the grounding instructions are not completely understood, or if doubt as to weather the product is properly grounded. Do not modify the plug provided; if it will not ﬁt the outlet, have a proper outlet installed by a qualiﬁed electrician. Do not use any type of adapter with this product.

PARTS & HARDWARE LIST

PART # DESCRIPTION QUANTITY

Carefully remove the contents from the package. If any parts are missing do not attempt to use the product until they have been obtained and correctly installed.

CAUTION: Do not over tighten fasteners.

ASSEMBLY INSTRUCTIONS

1. (SEE FIGURE 1) Attach hand pump with pipe (B) to barrel (A) using screw (D) in three places as shown.

2. (SEE FIGURE 2) Place electric pump (C) in the barrel (A) and connect the other end of the clear tube to the electric pump spout (C).

3. (SEE FIGURE 3) Fill the barrel (A) with water; if possible use distilled water to ﬁll tub. Plug power cord into properly grounded 120V AC outlet.

Parts Detail

Outdoor Use Extension Cords.

1. When product is used outdoors, use only extension cords marked for outdoor use.

2. Use only UL listed extension cords. Never use damaged or altered extension cords.

3. Follow extension cord manufacturer safety instruction.

Extension Cords

1. Make sure your extension cord is in good condition.

2. When using extension cords, be sure to use one heavy enough to carry the current your product requires. An undersized cord will cause a drop in line voltage resulting in power loss and overheating. Reference Table 1 on the bottom of this page for the correct size to use depending on cord length and nameplate Ampere rating. If in doubt, use the next heavier gage. The smaller the gage number, the heavier the cord.

AMP Load Volts Extension Cord Length 120V 25' 50' 100' 150' AWG 1-5 18 16 16 14 6-10 18 16 14 12 10-12 14 14 14 12 12-16 14 12

Not recommended

Table 1. Minimum Recommended Extension Cord Gauge (AWG) Chart

Figure 1

Figure 3

Figure 2

Grounded Outlets
