I NST A L LATIO N AND OWNER' S MANUAL
Shower Door Model Numbe r :SD908
Please carefully read these instructions before you begin to install the products.
01 /12 Rev B
P/N:10055-06
Before you start
Thank you for purchasing your Aston shower door and tray. We hope that it will
provide you with years of satisfying use and enjoyment.
Please read this manual carefully because it contains information and instructions
about the proper installation of the unit. If you do not follow certain conditions of
installation and maintenance, your warranty may be affected.
Aston Shower door's and shower tray's feature:
ϒ⁄ Tempered Safety Glass
ϒ⁄ High quality hardware
ϒ⁄ Easy maintena n c e durable fiberglass re inforced ac rylic
1
Installation Gui de
Please read and follow the installation instructions and guidel ines in this section.
Failure to follow the recommended instructions and installation techniques may
lead to possible damage to the unit or the surrounding area and can affect
warranty claims.
3
36"
12
5"
75"
5"
3
12
36"
2"
1
2
ATTENTION: This unit requires assembly. A minimum of two people are
required for assembly, as several of the sections can be large and unstable until
assembled.
You will need the following tools:
ϒ⁄ Drill with screwdriver attachments
ϒ⁄ Caulk gun
ϒ⁄ Level (3 foot or longer is recommended)
ϒ⁄ Tape measure
ϒ⁄ Phillips head screw driver
ϒ⁄ Flat head screw driver
3
ϒ⁄ Bathroom rated silicone sealant
Before starting the installation, please ensure that you have inspected all
components of the unit and check for broken or damaged sections. If you find
damage, please contact your dealer or the manufacturer.
Locate the accessory and manual box and remove the individual screw and
hardware packages and lay them out in sequential order to aid in completing
the rest of the installation
4
Preparation of base
for installation of shower tray
The shower tray needs to sit on a flat level base for proper support. Ensure that
the area for the shower tray is properly prepared for installation.
Using the drawing provide place the floor drain in the proper location so that the
shower tray drain and the floor drain are in line after final installation.
Place the shower tray in the final installation position line up the drain holes and
check for level. If not level make adjustments to the floor at this time.
5
Assemble the glass panel
M5x16.5mm
M5x16.5mm
SCREW PACK
(1)
1. Remove and inspect all of t he gl ass panels. If any are broken, please cont act
yo ur deal er or the manu fac turer.
NOTE: The glass panels are labeled to indicate the direction for the top of the
glass panels.
2. Remove and inspect the aluminum top and bottom rails for t he glass
assembly.
NOTE: The alumi num rails are l abeled to di sti nguish the top and bot t om r ail and
their or i entation wit hin the assembly.
IMPOR TA NT: P le ase take note th at Scr ew Pac k contains several different
len gt hs of sc re ws each for a spec ific loc at ion wi thin the glass assembly.
Dur ing th e ne xt ste ps of as sembly, pa y cl ose attention so the correct screw
length is used in the correct l ocat ion. Failure to do t hi s ca n caus e da ma ge to
the glass panels and poss ibly result in leaks.
