THE EV-07S PERSONAL GPS
TRACKER FROM ASTA GPS
TRACKERS
STEP BY STEP SET UP GUIDE
BY ASTA GPS TRACKERS
EV-07S PACKAGE CONTENTS
• EV-07S PERSONAL TRACKING
DEVICE.
• FREE UK PAY AS YOU GO SIM.
• USB POWER CABLE.
• 3 PIN UK 13A USB CHARGING
PLUG.
• LANYARD.
• USB DOCKING CHARGER.
• USER MANUAL.
EV-07S KEY FEATURES
• REAL TIME TRACKING VIA FREE
ON-LINE WEB BASED TRACKING
PLATFORM AND FREE SMART
PHONE APPS.
• FALL DETECTION WITH INSTANT
EMERGENCY MESSAGE AND CALL
FUNCTION.
• 2 WAY CALLING.
• 3 PRE-SET EMERGENCY CONTACTS
NUMBERS.
• INSTANT SOS ALERT SMS MESSAGE
WITH GOOGLE MAPS LINK.
• GEO-FENCE PRE-SET BOUNDRIES
WITH INSTANT ALERT.
• WATERPROOF TO IPX6
• THE EV-07S HAS BUILT-IN U-BLOX
GPS AND GSM/GPRS
TECHNOLOGY.
SETTING UP YOUR EV-07S GPS TRACKER FOR
THE FIRST TIME
• FOR THE FIRST TIME CHARGING WE
RECOMMEND CHARGING FOR 2 TO 3 HOURS
IN THE SUPPLIED USB CHARGING DOCK.
• PLUG THE USB LEAD IN TO THE BACK OF THE
USB CHARGING DOCK AND CONNECT THE
OTHER END TO A USB PORT ON YOUR PC OR
LAPTOP.
• OR CONNECT USB CABLE TO THE SUPPLIED
USB 13AMP 3 PIN PLUG AND CONNECT TO A
POWER OUTLET.
• PLACE THE EV-07S PERSONAL GPS TRACKER IN
TO THE USB CHANGING DOCK AND THE RED
LED LIGHTS UP IN THE FRONT OF THE
DOCKING STATION.
SWITCHING THE EV-07S GPS TRACKER
ON AND OFF
• TO TURN THE EV-07S ON:
• PRESS THE SIDE POWER BUTTON FOR 1
SECOND, ALL THE LED’S WILL FLASH RAPIDLY.
• THE EV-07S WILL TURN ON AUTOMATICALLY
BY PLACING IT IN THE USB CHARGING DOCK
OR CONNECTING THE USB CABLE DIRECTLY.
• TO GET AN INITIAL LOCATION, USE OUT
DOORS OR NEAR A WINDOW, SO THE EV-07S
MAY FIX ON TO A SATELITE.
• TO TURN OFF THE EV-07S:
• PRESS AND HOLD THE SIDE POWER BUTTON
AND THE SOS BUTTON TOGETHER FOR 1
SECOND UNTILL THE LED’S TURN OFF.
WHAT DO THE LIGHTS MEAN? BLUE
LED
• BLUE LED ON - THE DEVICE IS
CHARGING.
• BLUE LED BLINKING
QUICKLY – BATTERY POWER IS
BELOW 15%.
• BLUE LED IS OFF OR
BLINKING SLOWLY – THE
DEVICE HAS BEEN FULLY
CHARGED OR NOT CHARGING.
WHAT DO THE LIGHTS MEAN? GSM
GREEN LED
• GREEN LED LIGHT SHOWS A SINGLE
FLASH RAPIDLY EVERY 3 SECONDS –
THE EV-07S IS CONNECTED TO THE GSM
NETWORK.
• GREEN LED SHOWS A DOUBLE FLASH
RAPIDLY EVERY 3 SECONDS – THE
DEVICE IS REGISTERED TO THE GPRS
NETWORK.
• GREEN LED SHOWS A SLOW FLASH
EVERY 3 SECONDS – THE EV-07S IS
CONNECTING TO THE GSM NETWORK.
• GREEN LED IS ON AND IS NOT
FLASHING – NO SIM CARD IS DETECTED.
WHAT DO THE LIGHTS MEAN? GPS
BLUE LED
• BLUE LED SHOWS A SINGLE
FLASH EVERY 3 SECONDS – THE
EV-07S HAS A GPS POSITIONING
FIX.
• BLUE LED SHOWS A SLOW FLASH
EVERY 3 SECONDS (EVERY 1
SECOND ON AND 3 SECONDS
OFF) – THE EV-07S HAS NO GPS
FIX.
• BLUE LED OFF (WHEN NOT
CHARGING) – THE GPS CHIP IS
SLEEPING.
SETTING YOUR EV-07S DEVICE USER
NAME FOR SMS CONTENT
• TO MAKE IDENTIFYING YOUR EV-07S PERSONAL GPS TRACKING DEVICE
EASIER, WE WOULD RECOMMEND ASSIGNING A USER NAME.
• TO SET DEVICE USER NAME TEXT name1, FOLLOWED BY THE NAME YOU
WOULD LIKE TO SET.
• FOR EXAMPLE - YOU HAVE GIVEN THE EV-07S TO YOUR MUM AS SHE LIVES
ON HER OWN. SEND A TEXT MESSAGE TO THE EV-07S DEVICE WITH
name1,mum AND HIT SEND.
• THE EV-07S WILL THEN REPLY WITH A TEXT MESSAGE STATING “add name
ok!”
• TO DELETE THE ASSIGNED NAME TEXT name0 TO THE EV-07S.
EV-07S CONFIGURATION AND
OPERATION BY SMS
• 1. TO SET THE AUTHORIZED NUMBERS – NOTE: IT IS NOT NESSESSARY TO SET ALL
THREE AURTHORIZED NUMBERS, HOWEVER A MINIMUM OF ONE MUST ALWAYS BE SET.
• OPEN THE TEXT MESSAGING ON YOUR PHONE AND SELECT THE EV-07S GPS TRACKER
FROM YOUR LIST OF CONTACTS (AMY SOS) AND SELECT CREATE TEXT MESSAGE.
• TO SET THE PRIMARY CONTACT TYPE A1, FOLLOWED BY THE PRIMARY CONTACT
NUMBER. A1,0161222888 WITH NO SPACES AND SELECT SEND MESSAGE. YOU WILL THEN
RECEIVE A TEXT REPLY STATING SET MOBILE NUMBER 1 OK!
• TO DELETE THE PRIMARY NUMBER, YOU CAN SEND A TEXT MESSAGE TO YOUR EV-07S
BY TEXTING A0.
• A1, PLUS PHONE NUMBER TO ADD AND A0 TO DELETE.
EV-07S CONFIGURATION AND
OPERATION BY SMS
• THE SAME PROCESS IS CARRIED OUT FOR THE REMAINING
AUTHERIZED CONTACTS BY CHANGING THE PRE-FIX AS
FOLLOWS.
• B1,0161222888 FOR CONTACT 2.
• C1,0161222888 FOR CONTACT 3.
• REMEMBER YOU CAN DELETE ANY OF THE AUTHERIZED
CONTACTS AT ANY TIME BY SELECTING THE CONTACT YOU
WISH TO DELETE BY TEXTING A0 B0 OR C0 TO THE EV-07S.
SETTING THE CORRECT TIME ON
YOUR EV-07S FOR YOUR LOCATION
• UTC TIME HAS BEEN SET AS DEFAULT ON YOUR EV-07S PERSONAL TRACKING DEVICE.
• CHANGING YOUR DEVICES TIME IS DONE BY SENDING THE EV-07S A TEXT MESSAGE CONTAINING
THE FOLLOWING INSTRUCTION.
• TZ+00 OR -00
• THE TIME DIFFERENCE YOU ARE SETTING IS DONE IN 2 DIGITS WITH A MAXIMUM OF 23 IN VALUE.
• THE + REPRESENTS EAST AND – REPRESENTS WEST.
• FOR EXAMPLE YOU ARE GOING ON A TRIP TO PARIS, YOU WILL NEED TO SEND A TEXT MESSAGE TO
YOUR EV-07S CONTAINING TZ+01
• YOUR EV-07S IS NOW SET 1 HOUR FORWARD, GIVING THE CORRECT TIME WHEN IN PARIS.
• ON YOUR RETURN YOU WISH TO RETURN YOUR EV-07S BACK TO UK TIME. THIS CAN BE DONE BY
SENDING A TEXT MESSAGE CONTAINING THE FOLLOWING – TZ-01
• YOU HAVE NOW MANAGED TO ALTER THE EV-07S TIME FORWARD 1 HOUR AND BACK 1 HOUR.
REQUESTING A CURRENT LOCATION
FROM THE EV-07S PERSONAL GPS TRACKER
• IF YOU WOULD LIKE TO FIND THE LOCATION OF THE EV-07S PERSONAL GPS TRACKING
DEVICE AT ANYTIME.
• SEND YOUR EV-07S A TEXT MESSAGE CONTAINING THE FOLLOWING REQUEST.
• LOC
• YOUR EV-07S WILL REPLY WITH A TEXT MESSAGE CONTAING THE FOLLOWING
INFORMATION.
• TIME, LATITUED, LONGDITUDE, SPEED, ALTITUDE AND BATTERY LEVEL, FOLLOWED BY
A GOOGLE MAP LINK.
• CLICK ON THE LINK WITHIN THE MESSAGE AND YOUR PHONE WILL OPEN GOOGLE
MAPS. IF YOU HAVE IT INSTALLED.
• THE EV-07S USER WILL THEN BE SHOWN ON THE MAP AT IT’S CURRENT LOCATION.
REQUESTING A CURRENT LOCATION
FROM THE EV-07S PERSONAL GPS TRACKER
• IF YOU WOULD LIKE ADDRESS DETAILS OF WHERE THE EV-07S
USER IS, TEXT THE FOLLOWING TO THE EV-07S DEVICE.
• ADD
• THIS FUNCTION NEEDS GPRS FUNCTION SUPPORT.
• THE EV-07S WILL REPLY “ADD, MUM, 3 HIGH ST, EXETER, UK;
EV-07S LOW BATTERY ALARM
• WHEN THE EV-07S BATTERY IS BELOW 15%, IT WILL SEND ALL THE PRE-SET
CONTACT NUMBERS A TEXT MESSAGE STATING THAT THE BATTERY IS
GETTING LOW.
• “BAT:LOW!”
• IF THE BATTERY FALLS BELOW 15%THE BLUE LIGHT WILL FLASH RAPIDLY TO
WARN THE USER TO CHARGE THE DEVICE AS SOON AS POSSIBLE.
• TO ACTIVATE THIS FUNCTION TEXT LOW1 TO THE EV-07S DEVICE.
• TO DISABLE THIS FUNCTION TEXT LOW0 TO THE EV-07S.
• THIS FUNCTION IS GREAT WHEN THE DEVICE IS USED BY YOUNG OR ELDERLY
USERS AS YOU WILL BE AWARE THE DEVICE NEEDS CHARGING EVEN IF THEY
FORGET. MEANING GREATER PIECE OF MIND.
SETTING THE EV-07S PIN LOCK
• IF YOU WOULD LIKE TO RESTRICT THE ABLILITY TO CHANGE THE
SETTINGS BY OTHER USERS YOU WILL NEED TO SEND A TEXT
MESSAGE TO THE EV-07S CONTAINING THE FOLLOWING
INFORMATION.
• 123456LOCK
• AFTER SENDING THIS COMMAND YOU WILL NEED TO INCLUDE
THE PIN CODE INFRONT OF EVERY COMMAND EXCEPT REBOOT
AND RESET.
• FOR EXAMPLE 123456LOC OR 123456A1 – THE DEFAULT PIN CODE IS
123456
CHANGING THE EV-07S PASSWORD
• CHANGING THE PASSWORD OR PIN CODE PROTECTING YOUR EV-07S IS SIMPLE
AND EASY TO DO.
• TEXT YOUR EV-07S PERSONAL GPS TRACKING DEVICE WITH THE FOLLOWING
MESSAGE.
• OLD PASSWORD + H + NEW PASSWORD.
• FOR EXAMPLE – 123456H666666
• YOUR PIN CODE HAS NOW BEEN CHANGED TO 666666. DON’T FORGET TO
WRITE DOWN YOUR CHOSSEN PIN CODE AS THIS WILL NOT BE REMOVED
WHEN CHANGING SIM CARDS.
• NEW PIN CODES MUST BE 6 DIGIT’S OR THE EV-07S WILL NOT RECOGNISE THE
PIN CONE.
SETTING THE EV-07S GEO-FENCE
ALARM
• THE EV-07S HAS THE ADILITY TO SET AN AREA THAT THE USER SHOULD STAY WITHIN. BY SENDING A TEXT
MESSAGE TO THE EV-07S GPS DEVICE AND AREA CAN BE SET FROM THE USERS CURRENT LOCATION.
• THIS FUNCTION IS GREAT WHEN THE USER HAS TENDENCIES TO WONDER OFF ON THEIR OWN WHILST OUT.
• THE FOLLOWING COMMANDS ARE USED BELOW.
• G+X,Y,Z,XXXM/KM
• G = IS FOR THE GEO-FENCE.
• X = THE NUMBER OF USERS THAT CAN SET THE GEO-FENCE (1~3)
• Y = 0 MEANS TURN THE FUNCTION OFF.
• Y = 1 MEANS TURN THE FUNTION ON.
• Z = 0 MEANS TO SET AN ALARM WHEN THE USER GOES OUTSIDE OF THE PRE-SET AREA.
• Z = 1 MEANS TO SET AN ALARM WHEN THE USER ENTERS THE PRE-SET AREA.
SETTING THE EV-07S GEO-FENCE
ALARM
• XXX = THE DISTANCE THE USER CAN GO FROM THEIR CURRENT LOCATION BEFORE AN
ALARM IS RAISED.
• M = MEANS METERS FROM CURRENT LOCATION WITH 100M AS THE MINIMUM SET
DISTANCE.
• KM = MEANS KILOMETERS FROM CURRENT LOCATION WITH 001 KILOMETER AS THE
MINIMUM DISTANCE.
• IF THE USER COMES IN TO OR GOES OUT OF THE PRE-SET AREA, A TEXT MESSAGE
ALERT WILL BE SENT TO ALL CONTACTS AND WILL CONTAIN A GOOGLE MAP LINK .
• TO TURN THIS FUNCTION OFF SIMPLY TEXT YOUR EV-07S THE FOLLOWING MESSAGE.
• G1,0 – G2,0 – G3,0
• G1 REPRESENTS CONTACT ONE, G2 CONTACT TWO AND G3 CONTACT THREE.
SETTING THE EV-07S MOVEMENT
ALERTS
• TO SET THE MOVEMENT ALERT, SIMPLY TEXT THE EV-07S THE FOLLOWING COMMAND.
• M1,100M/KM
• M1 = TURNS ON THE MOVEMENT ALERT FUNCTION.
• M = THE DISTACE IN METERS WITH THE MINIMUM SETTABLE BEING 100M
• KM = HOW MANY KILOMETERS THE DIVICE V CAN TRAVEL THIS 001KM BEING THE MINIMUM
DISTANCE.
• THIS WILL SET THE DISTANCE THE GPS DEVICE CAN TRAVEL BEFORE SETTING OFF A MOVEMENT
ALERT.
• THE GPS DEVICE MUST BE STATIONARY WHEN ACTIVATING THIS FUNCTION.
• TO DE-ACTIVATE THIS FUNTION, TEXT M0 TO YOUR EV-07S
• THIS FUNCTION IS GREAT FOR KEEPING TRACK OF YOUR VEHICLE AND PROPERTY.
SETTING THE EV-07S OVER-SPEED
ALERT
• TO SET THE MAXIMUM SPEED YOU WOULD LIKE THE USER TO STAY UNDER
CAN BE DONE BY SIMPLY SENDING THE FOLLOWING MESSAGE.
• SPEED1, + SPEED
• FOR EXAMPLE YOUR ASSIGNED EV-07S USER IS A LONE WORKER AND THEY
TRAVEL TO AND FROM DIFFERENT PLACES OF WORK. YOU WOULD LIKE TO
MAKE SURE THEY ARE ADHEARING TO THE ROAD SAFETY LAWS AND DO NOT
MISS USE THEIR COMPANY VEHICLE, YOU CAN SET A SPEED AT WHICH THE
USER SHOULD NOT EXEED. AN OVER-SPEED ALERT MESSAGE WILL BE SENT IF
THE USER TRAVELS BEYOND THE PRE-SET LIMIT, SAY 100KM PER HOUR.
• TO SET THIS FIGURE SEND SPEED1,100
• TO TURN OFF THIS FUNCTION SEND SPEED0
THE EV-07S LISTEN-IN FUNCTION
• IT IS POSSIBLE TO MAKE A SILENT CALL TO THE EV-07S GPS
TRACKER. THE EV-07S WILL ANSWER THE CALL AUTOMATICALLY,
ALLOWING THE CALLER TO HERE WHAT IS HAPPENING AROUND
THE TRACKER.
• THERE IS NO VOICE INDICATION THAT THE CALL IS IN PROGRESS.
• TO TURN ON THE LISTEN-IN FUNCTION TEXT L1 TO THE GPS
DEVICE.
• TO TURN OFF THE LISTEN-IN FUCTION TEXT L0 TO THE GPS
DEVICE.
THE EV-07S FALL DETECTION
FUNCTION
• IF THE USER OF THE EV-07S IS A LONE WORKER OR A PERSON THAT
SPENDS EXTENDED PERIODS OF TIME ON THEIR OWN.
• A SIMPLE FALL COULD PROGRESS VERY QUICKLY IN TO A DEVASTATING
RESULT IF GONE UN-NOTICED.
• ALL PRE-SET CONTACTS WILL BE ALERTED WITHOUT THE NEED FOR THE
USER TO ACTIVATE THE SOS BUTTON.
• TO ACTIVATE THIS FUNTION TEXT FL1 TO THE EV-07S.
• TO DEACTIVATE THIS FUNCTION TEXT F0 TO THE EV-07S.
• THE EV-07S MUST SENSE BOTH IMPACT AND ANGLE TO ACTIVATE ALERT.
THESE ARE JUST SOME OF THE
FUNCTION SETTINGS FOR THE
EV-07S
FOR MORE SETTINGS PLEASE REFER TO YOUR
EV-07S USER MANUAL
IF YOU FOUND OUR VIDEO HELPFUL, PLEASE HIT THE LIKE
BUTTON AND DON’T FORGET TO SUBCRIBE TO OUR CHANEL TO
GET NOTIFICATIONS WHEN WE UPLOAD A NEW VIDEO. LINKS ARE
IN THE DECRIPTION AND PLEASE WRITE YOUR COMMENTS IN THE
SECTION BELOW.
THANKS FOR WATCHING
ASTA GPS TRACKERS
Loading...
