Multi-function safety compliance analyzers with an enhanced graphic LCD provide complete test setup and results with
an easy-to-use interface. OMNIA
Ground Bond/Continuity, Insulation Resistance, Functional Run and Line Leakage tests. An optional internal scanner
is available for the 8104, 4-in-1 tester. An additional external modular scanner is available for use with all testers. All
testers come standard with USB and RS-232 interfaces. Ethernet, GPIB, and RS-485 interfaces are also available.
Model 8104
®
provides 4-in-1, 5-in-1 and 6-in-1 testing solutions. Testers include AC Hipot, DC Hipot,
OMNIA 4, 5 kV @ 40 mA AC, 5 kV @ 20 mA DC, IR Test, 40 Amp
-
Ground Bond & Optional HV & HC Scanner
OMNIA 5, 5 kV @ 40 mA AC, 5 kV @ 20 mA DC, IR Test, 40 Amp
Model 8105
-
Ground Bond & Functional Run Test
OMNIA 6, 5 kV @ 40 mA AC, 5 kV @ 20 mA DC, IR Test, 40 Amp
Model 8106
-
Ground Bond, Functional Run Test & Line Leakage Test
Features and Benefits
Patented SmartGFI
the operator from shock hazards
Real Current measurement allows
operators to monitor total and real
current on a single screen
Patented Prompt and Hold function
provides a unique method for performing
multiple steps during a test cycle
Line Leakage tester with 7 different
measuring devices and RMS or PEAK
leakage measurements
Can be easily connected to AR’s
SC6540, 620L or an APT Brand AC
Power Source to provide a customizable
test system
USB/RS-232, GPIB, Ethernet, or
RS-485 automation interfaces
available
Autoware Testing Software available for
complete Automation Control
Cold Resistance Feature for Line to
Neutral Continuity Testing
®
safety circuit protects
Patented CAL-ALERT
VERI-CHEK® features help
to ensure that your
instrument is calibrated
and stays within specs
Data storage card available for
storing and transferring test data
without a connection to a PC
50 Memories with 30 steps
per memory that can be
stored and recalled in any
alphanumeric combination
®
RAMP HI
testing for more effective
DC Hipot testing
Perform Hipot/Line Leakage
without changing test leads
Patented Graphic LCD and
intuitive menu system to
simplify the entire testing
process from set-up to results
0.5 µF < 3 kV
AC Output Waveform Sine Wave, Crest Factor = 1.3 - 1.5
Output Frequency 60 or 50 Hz, User Selecatable
(continued)
Dielectric Withstand Test Mode
Output Rating 5 kV @ 40 mAAC
5 kV @ 20 mADC
Voltage Setting Range: 0-5000 VAC
0-5000 VDC
Resolution: 1 V
Accuracy: ± (2% of setting + 5 V)
Voltage Display Range: 0.00 - 5.00 kV Full Scale
Resolution: 0.01 kV
Accuracy: ± (2% of reading + 10 V)
HI and LO-Limit AC Total Range: 0.000-9.999 mA
Resolution: 0.001 mA
Range: 10.00 – 40.00 mA
Resolution: 0.01 mA
Accuracy: ± (2% of setting + 2 counts)
AC Real Range: 0.000-9.999 mA
Resolution: 0.001 mA
Range: 10.00 – 40.00 mA
Resolution: 0.01 mA
Accuracy: ± (3% of setting + 50 µA)
DC Range: 0.0-999.9 µA
Resolution: 0.1 µA
Range: 1000 – 20000 µA
Accuracy: ± (2% of setting + 2 counts)
Current Display AC Total Range: 0.000 mA – 3.500 mA
Resolution: 0.001 mA
Range: 3.00 mA – 40.00 mA
Resolution: 0.01 mA
Accuracy: ± (2% of reading + 2 counts)
AC Real Range: 0.000 mA – 9.999 mA
Resolution: 0.001 mA
Range: 10.00 mA – 40.00 mA
Resolution: 0.01 mA
Accuracy: ± (3% of reading + 50 µA)
DC Range: 0.0 µA – 350.0 µA
Resolution: 0.1 µA
Range: 0.300 mA – 3.500 mA
Resolution: 0.001 mA
Range: 3.00 mA – 20.00 mA
Resolution: 0.01 mA
Accuracy: ± (2% of reading + 2 counts)
Ramp HI >20 mA peak maximum, ON/OFF selectable
Charge LO Range: 0.000 - 350 µA or Auto Set
DC Output Ripple ≤ 4% Ripple rms at 5 kV DC @ 20 mA, Resistive Load
Discharge Time ≤ 200 ms
Output Regulation ± (1% of output + 5 V) from no load to full load and over
input voltage range
Dwell Timer AC 0.4 - 999.9 sec (0 = Continuous)
DC 0.3 - 999.9 sec (0 = Continuous)
Ramp Timer Ramp -Up: AC 0.1 - 999.9 sec, DC 0.4 - 999.9 sec
Ramp-Down: AC 0.0 - 999.9 sec, DC 0.0,1.0 - 999.9 sec
Ground Continuity Current: DC 0.1 A ± 0.01 A, xed
Max. Ground Resistance: 1 Ω ± 0.1 Ω, xed
Ground Fault Interrupt GFI Trip Current: 450 µA max (AC or DC)
HV Shut Down Speed: < 1 ms
0.05 M – 999.9 M ± (2% of reading +2 counts)
1000 M – 9999 M ± (5% of reading +2 counts)
10000 M – 50000 M ± (15% of reading +2 counts)
HI and LO Limit Range: 0.05 M – 99.99 MΩ
Resolution: 0.01 M
Range: 100.0 M – 999.9 M
Resolution: 0.1 M
Range: 1000 M – 50000 M
Resolution: 1 M
(HI – Limit: 0 = OFF)
Accuracy: Same as Resistance Display Accuracy
DUT Power Voltage: 0 – 277 VAC Single Phase Unbalanced
(One Hot or Line conductor and One Neutral)
Current: 15 A AC max continuous
Short Circuit Protection: 23 AAC, Response Time < 3s
Delay Time Setting Range: 0.2 – 999.9 seconds
Dwell Time Set ting Range: 0.1 – 999.9 seconds
(0 = Continuous)
Trip Point Voltage: Volt-Hi
Settings Volt-LO Range: 0.0 – 277.0 VAC
Current: Amp-HI
Amp-LO Range: 0.0 – 15.00 AAC
Watts: Power-HI
Power-LO Range: 0 – 4200 W
Power Factor: PF-HI
PF-LO Range: 0.000 – 1.000
Leakage Current: Leak-HI
Leak -L O R ang e: 0.00 – 10.00 mA (0 = OFF)
OMNIA 8106 Line Leakage Test Mode
DUT Power Voltage: 0 – 277 VAC
Current: 15 AAC max continuous
Short Circuit Protection: 23 AAC, Response Time <3s
Leakage Current Current Display rms or PEAK
Range 1: 0.0 µA – 999.9 µA
Resolution: 0.1 µA/step
Range 2: 1000 µA – 6000 µA
Resolution: 1 µA/step
Accuracy rms: DC to 100 kHz
± (1.5% of reading +3 counts)
>100k to 1 MHz
± 5% of reading, (10.0 µA – 6000 µA)
Measuring Device
A UL544 Non Patient
B UL544 Patient
C UL2601-1, UL60601-1, IEC601-1, IEC60601-1 EN60601-1
D UL1563
E UL1950, UL3101, UL61010, IEC950, IEC1010, IEC
60950, IEC61010, IEC60335-1, IEC60990 Fig4-U2
H IEC60990 Fig5-U3
I IEC60990 Fig3-U1
Ground Fault Interrupt GFI Trip Current: 450 µA max (AC or DC)
HV Shut Down Speed: < 1 ms
General Specifications
Mechanical Bench or rack mount with tilt up front feet
Dimensions 3U (WxHxD) 16.93 x 5.24 x 19.69 in.
(430 x 133 x 500 mm)
