Dishwasher DFI664OPERATING INSTRUCTIONS

Contents

Eco

Speed mode

2:00

START

STOP

Display Start/Stop

Program mode selector

Navigation buttons for selecting a program

Option Delayed Start

Option Extra Dry

Main power switch

2Display panel
3Important safety instructions
4Before washing for the first time
5Loading the dishwasher

8Using the dishwasher
12Settings
14Care and maintenance instructions

Dear Customer,

Thank you for choosing this quality product from ASKO.

We hope it will meet your expectations and fulfill your needs for many years to come. Scandinavian design combines clean
lines, everyday functionality, and high quality. These are key characteristics of all our products and the reason they are
greatly appreciated throughout the world.

To get the most out of your new dishwasher, we recommend that you read the operating instructions before using it. The last
page also includes a Quick start guide.

16Troubleshooting
19Technical information
20Installation instructions
22Service
23Notes
24Quick start guide

Display panel

To switch on the dishwasher, press and hold the main power switch until the display lights up.

"Welcome to your new ASKO. This is a first time set up." is shown on the display the first time the dishwasher is switched on. It

is important that you choose the right settings to ensure good dishwashing results. See page 4.

2

Important safety instructions

SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE

WARNING!

When using your dishwasher, follow basic precautions, including the
following:

• Read all instructions before using the dishwasher.

• Use the dishwasher only for its intended function.

• Use only detergents or wetting agents recommended for use in

a dishwasher and keep them out of the reach of children.

• When loading items to be washed:

– locate sharp items so that they are not likely to damage the door

seal, and

– load sharp knives with the handles up to reduce the risk of
cut-type injuries.

• Do not wash plastic items unless they are marked “dishwasher
safe” or the equivalent. For plastic items not so marked, check
the manufacturer’s recommendations.

• Do not operate the dishwasher unless all enclosure panels are
properly in place.

• Do not tamper with controls.

• Do not abuse, sit on, or stand on the door or dish rack of the

dishwasher.

• To reduce the risk of injury, do not allow children to play in or on
a dishwasher.

• Under certain conditions, hydrogen gas may be produced in a
hot water system that has not been used for two weeks or more.
HYDROGEN GAS IS EXPLOSIVE. If the hot water system has not
been used for two weeks, before using the dishwasher turn on all
hot water faucets and let the water flow from each for several
minutes. This will release any accumulated hydrogen gas. As the
gas is flammable, do not smoke or use an open flame during this
time.

• Remove the door to the washing compartment when removing
an old dishwasher from service or discarding it.

• Read the grounding instructions in the installation instructions.

General

• Do not run the dishwasher while you are out of the home.

• Do not store or use combustible materials, gasoline, or other

flammable vapors and liquids in the vicinity of this or any other
appliance.

• Disconnect electrical power to dishwasher before servicing.

• Repairs should be done by a qualified technician.

• Should a child swallow dishwasher detergent or rinse aid, give

plenty to drink immediately, i.e., one or two glasses of milk or water.
Do not try to induce vomiting. Seek medical advice immediately:
Call the National Capital Poison Center at 1-800-222-1222.

• Always close the door and start the dishwasher as soon as you put
in the detergent.

• Always keep small children away from the machine when it is open.
There may be some detergent residue left inside the machine.

• If dishwasher detergent gets in someone’s eyes, rinse them with
plenty of water for at least 15 minutes.

Activate child lock (Kid Safe™)

You can activate the child lock (button lock) to prevent children from
starting the dishwasher. See the chapter Settings.

Winter storage/Transport

• Store the dishwasher where the temperature remains above freezing.

• Avoid long transport distances in very cold weather.

• Transport the dishwasher upright or laying on its back.

Overflow guard function

The overflow protection starts pumping out the machine and turns off
the water supply if the water level in the dishwasher exceeds the normal
level. If the overflow protection is triggered, turn off the water supply
and call the Customer Care Center.

Packing material

The packaging protects the product during transport. The packaging
material is recyclable. Separate the different packaging materials to
help reduce raw material use and waste. Your dealer can take the
packaging for recycling or direct you to the nearest recycling center.
The packaging is comprised of:

• Corrugated cardboard made from up to 100% recycled material.

• Expanded polystyrene (EPS) with no added chlorine or fluorine.

• Supports made from untreated wood.

• Protective plastic made from polyethylene (PE).

Disposal

• When the machine has reached the end of its service life and is to
be disposed of, it should immediately be made unusable. Pull out
the power cable and cut it as short as possible.

• The dishwasher is manufactured and labeled for recycling.

• Contact your municipality for information about where and how your

dishwasher can be recycled correctly.

WARNING!

This product may contain chemicals known to the state of California
to cause cancer or reproductive harm.

Installation

See the chapter Installation instructions.

Child safety

TIP!

Dishwasher detergents and rinse aids are corrosive, so always keep
them out of reach of children.

3

Before washing for the

Confirm setting

Select setting

Main power switch

first time

1. Checking water hardness

Contact the local water utility to check the water hardness in your area.
This is important to determine how much detergent and rinse aid to
use.

In general, more rinse aid and detergent are needed for hard water.

2. Basic settings

To switch on the dishwasher, press and hold the main power switch
until the display lights up.

"Welcome to your new ASKO. This is a first time set up." is shown
on the display. It is important that you choose the right settings to
ensure good dishwashing results.

Settings

Language1

Select the language to be shown on the display.

Rinse aid 0/1/2/3/4/52

Use rinse aid to improve wash and dry times. Also use rinse aid to

achieve clear and spotless results.

Select rinse aid dosage. The rinse aid dispenser can be adjusted

between 0 (Off) and 5 (High dosage).

Pre-selected at factory: 5

To change the chosen setting, see the chapter Settings.

4

Press to open

Loading the dishwasher

3. Top up with rinse aid

Use rinse aid to improve wash and dry times. Also use rinse aid to
achieve clear and spotless results.

1 Open the rinse aid compartment lid.

2 Carefully top up with rinse aid. Only add rinse aid to the level marked

max.

3 Wipe up any spilled rinse aid around the compartment.

4 Close the lid firmly.

Add rinse aid

When the rinse aid needs topping up, the above symbol lights on the
display.

After topping up, it may take a while before the symbol goes out.

NOTE!

Increase the rinse aid dosage:

• If the dishes have water marks.

Reduce the rinse aid dosage:

• If the dishes have a sticky white/blue film.

• If the dishes are streaked.

• Heavy foaming. If you have very soft water, the rinse aid can be

diluted 50:50 with water.

Energy-efficient dishwashing

Run programs only with a full load

Wait until the dishwasher is fully loaded before running a program, this
way you save energy. Use the Rinse and hold program to rinse the
dishes if there are any unpleasant odors while you wait for the
dishwasher to become fully loaded.

Run programs at a lower temperature

If the dishes are only lightly soiled, you can select a program with a
low temperature.

Select Green mode

The dishwasher has different program modes. To save energy and
water, use Green mode.

Better drying results are achieved if you open the door a little once the
program has ended. (If the dishwasher is built-in, the surrounding
furnishings must be resistant to any condensation from the dishwasher.)

Do not rinse under running water

Simply scrape off large food particles before loading the dishwasher.

Choose a green detergent

Read the environmental declaration on the packaging!

Connect to cold water

Connect the dishwasher to the cold water supply if the building is
heated using oil, electricity, or gas.

Connection to hot water supply

Connect the dishwasher to the hot water supply (max. 160 °F (70 °C))
if the building is heated using an energy-efficient means such as district
heating, solar power, or geothermal power. Choosing a hot water
connection cuts dishwashing times and reduces the dishwasher's
energy consumption.

NOTE!

Do not exceed the permitted water supply temperature. Certain
materials used in some cookware cannot withstand strong heat.

5

Fragile dishes

Some cookware is not dishwasher safe. This can be for several reasons.
Some materials cannot withstand high temperatures, others can be
damaged by dishwasher detergent.

Use caution with, for example, handmade items, fragile decoration,
crystal/glassware, silver, copper, tin, aluminum, wood, and plastic.
Look for the "Dishwasher safe" marking.

Fragile decoration

Porcelain with decoration on top of the glazing (the items feel rough)
should not be washed in a dishwasher.

Crystal/Glass

Wash fragile items made of crystal/glass, such as crystal glass from
Orrefors, using the gentle dishwashing program Crystal glass.
Remember to use a small amount of detergent and to place items so
that they do not touch each other during the wash.

Use rinse aid to improve wash and dry times. Also use rinse aid to
achieve clear and spotless results.

Hand-painted glassware, as well as antique and very fragile items,
should not be washed in a dishwasher.

Silver

Silver and stainless steel items should not come into contact, as the
silver can become discolored.

Aluminum

Aluminum can lose its shine if washed in a dishwasher. However, good
quality aluminum pans can be washed in a dishwasher, even if some
of the shine will be lost.

Cutlery with glued handles

Some types of glue are not dishwasher safe. In such cases, the handles
may loosen.

Points to consider

• All dirty surfaces should face in and down!

• Dishes should not be placed in or on each other.

• Angle dishes with hollows, such as cups, so that the rinse water

will run off. This is also important for plastic items.

• Place the upper basket in its highest position when dishwashing
very large plates.

• Make sure small items cannot fall through the dishwasher basket;
place them in the top cutlery tray.

NOTE!

Check that the spray arms can rotate freely.

The baskets

The dishwasher includes a top cutlery tray, an upper basket, and a
lower basket with a cutlery basket.

The basket appearance may differ depending on the configuration.

Top cutlery tray

The top cutlery tray accommodates cutlery, ladles, whisks, and other
utensils.

Raising the top cutlery tray

1 Remove the top cutlery tray.

2 Pull the two locking handles forward on each side to raise the top

cutlery tray.

Lowering the top cutlery tray

1 Make sure the upper basket is in the lowest position.

2 Remove the top cutlery tray.

3 Slide the two locking handles down and back to lower the top cutlery

tray.

Upper basket

Place glasses, cups, bowls, side plates, and saucers in the upper
basket. Place all soiled surfaces down! Place wine glasses on the wine
shelf. Place knives on the knife stand, if applicable.

6

Raising the upper basket

2

1

1 Pull out the upper basket.

2 Grab the sides of the upper basket with both hands and lift it up.

Lowering the upper basket

1 Pull out the upper basket.

2 While holding the basket, pull out the two locking handles on either

side to lower the upper basket.

Lower basket

Place plates, side plates, serving dishes, pots, and cutlery (in the
cutlery basket) in the lower basket.

Place pots and pans in the right rear of the lower basket for the best
cleaning results from the two rear spray nozzles (WideSpray™), which
are intended for these types of dishes.

Washing large plates

Move adjustable tines and their mounts to widen the distance between
the tine rows to adapt the lower basket to plates with a diameter greater
than 9 3/4" (25 cm).

Cutlery basket

Place cutlery with the handles facing down, except for knives, and
spread them out as much as possible. Ensure that spoons do not stack
inside each other.

The cutlery basket is best placed in the middle at the front of the lower
basket to best utilize dishwashing performance from the unique spray
nozzle (Power Zone Cutlery™), which is intended for the cutlery basket.

WARNING!

Knives and other pointed items must be placed with the points down
in the cutlery basket or horizontally in other baskets.

Fold-down section for small items

The cutlery basket has a fold-down section in the middle for small
items, or small shafts, such as electric whisk attachments.

Foldable tines

Lower the foldable tines when washing large pots. Release the foldable
tines by pressing the catch inward before adjusting their position.

Accessory

Buy an extra cutlery basket. The extra cutlery basket is flexible and
can be dismantled and attached to the lower basket or the large cutlery
basket to make an extra large cutlery basket. This accessory is
available where you bought the dishwasher.

7

Using the dishwasher

Press to open

Typical load for 10 place settings

Upper basket with 10 place settings AHAM DW-1

NOTE!

Ensure the upper basket is set to its lowest position.

Lower basket with 10 place settings AHAM DW-1

Add detergent

1 Prewash detergent compartment

2 Main wash detergent compartment

Detergent is added according to water hardness.

Follow the instructions on the detergent packaging.

Too much detergent can result in less effective dishwashing and also
entails greater environmental impact.

The detergent compartment must be dry when adding detergent. There
is one compartment for the prewash and one for the main wash. If
powder or liquid dishwasher detergent is used, add a small amount
of the detergent to the prewash compartment. Contact the detergent
manufacturer if you have questions about the detergent.

NOTE!

Use only dishwasher detergent! Liquid hand-washing detergent must
not be used as the foam that forms prevents the dishwasher from
operating effectively.

Dishwasher tablets

Halve the tablet if it is difficult to close the dispenser lid. There is a risk
that the detergent will not be released properly if the lid is tight and
cannot open correctly.

NOTE!

Dishwasher tablets are not recommended for short programs (less
than 75 minutes). Use powder or liquid dishwasher detergent instead.

All-in-one detergent

There are many types of all-in-one detergents on the market. Read
through the directions for these products carefully.

NOTE!

Optimal washing and drying results are achieved by using normal
detergent together with separately dispensed rinse aid.

8
