ASKO DBI663THS Specifications

DBI663THS

Condensation dry
Number of place settings: 16
Top tray for bowls and cutlery
Upper basket type: Premium
Lower basket type: Premium
Separate removable cutlery basket


Top tray functions

InstantLift™ - smart height adjustment of the top tray
Divisible and removable trays
Tray for knives and utensils


Upper basket functions

Tight mesh base
Multi position wine shelf left
Multi position wine shelf right
Fixed glass support
Wide knife stand
Guide rails with ball bearings


Lower basket functions

Foldable/divisible pin rows rear
Handle
Separate removable cutlery basket


Programs

Sanitation wash
Normal wash
Hygiene wash
ECO wash
Upper half
Lower half
Rinse & Hold
Time program
Plastic wash


Options

Delayed start: Delayed Start
Time set


Cleaning systems

Number of spray zones: 8
Number of spray arms: 3
Wide Spray™ - extra dishwashing power for pots and pans
Power Zone for the cutlery basket
SCS+ - Super Cleaning System+™
Aqua Level™ Sensor
Sensi Clean™ Sensor
Stainless steel spray arms


Features

8 Steel™ Construction
Rinse-aid indication: Rinse-aid indication
Time remaining indicator
Audio signal for the end of washing cycle
Steam Safe™
Hidden heater
Kid Safe™ - lockable controls
All in 1 tablet function


Water safety

Few sealing points outside the container
Long lasting seam welded tank
Waterproof external base
Exterior float - detects water leakage on the base
Aqua Detect™ Sensor
Stand-by water protection
Water inlet hose
Max time water intake
Sound alarm
Anti-block drain pump
Aqua Safe™


Installation

From front adjustable rear foot
Adjustable feet
Multi fit outlet hose
Fixed high loop outlet hose
Integrated anti-siphon device
Trim kit

EAN code: 3838782062308
code: 728603


General

Product: Dishwasher
Mode of installation: Built In
Size: ADA height compliant
Display type: LCD display
Number of programs: 11
Noise level: 44 dB(A)
Number of baskets: 3
Number of place settings: 16
EAN code: 3838782062308


Dimensions and installation

Height: 32 11/16 (831 mm)
Width: 24 (609 mm)
Depth: 22 (559 mm)
Packaging height: 35 1/16 (890 mm)
Packaging width: 25 3/16 (640 mm)
Packaging depth: 26 3/4 (680 mm)
Length electrical cord: 47 1/4 (1200 mm)
Length inlet hose: 64 3/16 (1630 mm)
Length outlet hose: 90 9/16 (2300 mm)
Net weight: 103 lbs
Gross Weight: 110 lbs


Technical information

Voltage: 120 V
Current: 15 A
Frequency: 60 Hz
Required inlet water pressure: 0,03-1 MPa


Consumption

Energy consumption/cycle: 1 kWh
Consumption in standby mode: 0,49 W
Consumption in off mode: 0,49 W

