Askey Computer PKE1331BP User Manual

The Cable Modem, TC8305C / PKE1331BP-D49 (US-Dory-RoHS) is a cable gateway device

including following functionalities:

 DOCSIS 3.0 Cable Modem

 PacketCable2.0 eDVA

 4 port Gigabit Ethernet switch with advanced routing capability

 802.11n single band WiFi (2.4 GHz)

 USB 2.0 port with host controller

 2 FXS ports, compliant with Comcast ringing requirements

 Internal PSU

 Rackable 2-cell battery 2600maH

 eMTA supporting PacketCable 2.0 or EuroPacketCable

 IPv4/IPv6 router

 Remote management capabilities (SNMP, TR069, HNAP)

Wideband Full Solution with Battery Backup

This new generation of high-speed data service solutions introduces up to eight bonded

downstream channels and four bonded upstream channels, allowing operators to provide their

customers with four channels for data and four channels for dedicated Internet Protocol

TeleVision (IPTV).

High-Speed Wireless Interface

The TC8305C / PKE1331BP-D49 (US-Dory-RoHS) has an IEEE 802.11n wireless interface,

bring home networking to a completely new level and enabling real-time multimedia content

streaming over a Wi-Fi network everywhere in the home. The TC8305C / PKE1331BP-D49

(US-Dory-RoHS) also supports multiple SSIDs.

Voice Performance

The TC8305C / PKE1331BP-D49 (US-Dory-RoHS) is PacketCable 2.0 compliant and is

equipped with basic and extended CLASS features such as caller ID and call waiting.

Advanced Security

The integrated firewall provides Stateful Packet Inspection (SPI), and an integrated Intrusion

Detection and Prevention System (IDS) engine monitors a wide range of attack patterns, and

logs potential security breaches to a local cache or remote server.

To secure data exchange between the gateways and the cable operators’ servers, BPI+

communications privacy is used.

WPS

With Wi-Fi Protected Setup (WPS) users can easily connect with the TC8305C /

PKE1331BP-D49 (US-Dory-RoHS) wireless network by simply pushing a button or entering a

PIN code.

It allows home users to easily connect to a secure network without any complex configuration

and eliminates the need to remember or store their security information in an unsafe way.
