Before and when using the product, carefully read the following notes.
For your safety, do not operate the product while driving.
Use this product prudently. The product is intended to be used only as a navigation aid. It is
not for precise measurement of direction, distance, location or topography.
The calculated route is given for reference only. It is the your responsibility to follow the traffic
signs and local regulations along the roads.
When you get off the car, do not leave your device on the dashboard that is subject to direct
sunlight. The overheating of the battery might cause malfunction and/or danger.
GPS is operated by the United States government, which is solely responsible for the
performance of GPS. Any change to the GPS system might affect the accuracy of all GPS
equipment.
GPS satellite signals cannot pass through solid materials except glass. When you are inside a
tunnel or building, GPS positioning is not available.
A minimum of 4 GPS satellite signals is needed to determine current GPS position. Signal
reception might be affected in situations, such as bad weather or dense overhead obstacles
(e.g. trees and tall buildings).
Other wireless devices in the vehicle might interfere with the reception of satellite signals and
cause the reception to be unstable.
A car holder is needed when you use the device in a car. Be sure to place the device in an
appropriate place so as not to obstruct the driver’s view, or deploy ment of airbags.
iii
iv
Contents
Contents
Before You Use.........................................................................................................................................vii
PACKING LIST .....................................................................................................................VII
Before using the GPS, read the user manual attached in the package and check whether or not spare
parts are attached. Feel free to contact your retailer if you do not well find the spare parts or have
questions or problems at the time of operation.
Packing list
Before using the GPS, check all the following items are present and in good condition. If any of the
items is damaged or missing, contact your retailer im mediately.
9 GPS x 1
9 Car Adapter x 1
9 USB Cable x 1
Stylus x 1
9
9 Mount Bracket x 1
9 Mount Cradle x 1
9 User Manual x 1
9 Quick Start Guide x 1
Navigation Function
The unit is designed to provide you with route suggestions. It supports voice navigation.
Other Special Functions
¾SD Card and USB Input
The unit is designed with SD card and USB ports and can be connected to SD card or other
USB device for file loading.
¾2 GB Flash Storage
Built-in 2G Flash Storage can store map data.
¾Power Adapter Switch
Automatically adapts to voltage requirements in U.S and other countries.
¾Supporting file formats
MP3 and WMA Format files
vii
Global Positioning System
Notes and Cautions
Note and Caution in this manual are highlighted with graphics as below to indicate important
information.
Note
Caution
This User’s Manual contains information on how to install and co nfigure you r GPS device. From now on,
we will guide you through the correct configuration steps to implement your device.
Contains information that corresponds to a specific topic.
Represents essential steps, actions, or messages that should not be
ignored.
viii
Hardware Features
Chapter 1: Getting Started
Chapter 1 Getting Started
Note
Depending upon the specific model you purchased, the color of your
device may not exactly match that of device shown in this manual.
Front View
Number Component Description
1 Charge Indicator
When LED is red, the battery is being charged;
when LED is green, the battery is fully charged.
2 Microphone
3 3.5” LCD Panel
You can speak through the component in the
hand-free profile mode.
Displays the output of your device. Tap the screen
with a fingertip to select a menu or read information.
Back View
Number Component Description
1 Speaker
Sends out music, sounds, and voice.
1
Global Positioning System
Left And Right Side Views
Number Component Description
1 Stylus
2 Volume Up Key
3 Volume Down Key
4 Headphone Jack
5 Play / Pause Key
External GPS Antenna
6
Connector
7 Power Button
8 Hold Key
You can tap the screen with the stylus.
You can tune up the volume of the headphone or
speaker.
You can tune down the volume of the headphone or
speaker.
Used to connect a headphone for private listening.
When the headphone is connected to this jack, the
speaker will be turned off automatically.
You can use the key to play back or pause music.
This connector (under rubber dust cover) allows use
of an optional external antenna with magnetic
mount, which may be positioned on top of the car for
better signal reception in areas with poor reception.
Turns on and off the device.
Designed to prevent you from operation by mistake.
2
