ASKA ELECTRONICS M6 User Manual

M6 BLUETOOTH SPORT HEADSET

User Manual

Get started

Congratulations! Thank you for choosing M6
Bluetooth sport headset. Before using M6, users
should read this manual to familiarize
themselves with the Bluetooth functions of your
mobile phone or other devices.

Safety Rules

1. Please follow the rules described in this
manual carefully to ensure your safety. Before
using this headset, we would strongly encour­age you to read through this user manual.

2. Be more care of any edges, uneven surfaces,
metal parts, accessories and packaging to avoid
any possibility of injury.

3. Do not dismantle, repair and modify product

to avoid fire breaking, electric shocking and

product damaging completely, which are not
covered under warranty.

4. Do not use any volatile liquid to clean the
headset.

5. Do not use the headset in a hazardous
location.

Features

1. Bluetooth 4.1+EDR

2. apt-X® audio technology

3. Support connecting with 2 phones devices

4. iOS show the headset battery power status

5. Waterproof to IPX 7

6. Only support NFC receiving function

How to use

1. LED

Status LED

Power on Blue LED flashes 2 times
Power off Red LED flashes 4 times
Pairing Red LED & Blue LED flashes alternately
Standby Blue LED flashes 3 times in 5 seconds
Low battery Red LED flashes 2 times every 2 seconds

Red LED keeps lighting during charging

Charging

Blue LED keeps lighting charging finished

2. Basic Buttons Operation

Power on: Press multifunction button for 2

seconds. Blue LED flashes 2 times.

Power off: Press multifunction button for 3

seconds. Red LED turns off after flashes 4 times.

Pairing: Press multifunction button for 5

seconds. Red LED & Blue LED flashes alternate­ly.
Volume adjust: Each press on 'Volume up' or '
Volume down' buttons, one level voice volume
changes. When volume reaches to Max or Min,
"Tick" reminding voice occurs.
Play/Pause: Short press multifunction button,
music pause. Press it again, music continues.
Previous: Long press 2 seconds 'volume down'
button, music turns to previous one.
Next: Long press 2 seconds 'Volume up’, music

2

3

turns to next one.

4

Answer Call: Short press multifunction button
to answer the incoming call.
End call: Short press multifunction button,
phone call ended.
Reject call: Press 'Volume up' button for 2
seconds to reject a call.
Transfer call: During the phone call conversa­tion, press' Volume up 'button for 2 seconds, call
switches to mobile phone. Press 'Volume up'
button for 2 seconds again, call switches to
headset.
Last number redial: In standby status, continu­ously press headset multifunction button twice
to redial the last number.
Call Mute function: Press 'Volume down' button
for 2 seconds, call mute. Press 'Volume down'
button for 2 seconds again, call mute cancel.
Battery Capacity status: When headset
connects to iOS devices, iOS devices show the
headset battery power status on the upper right
corner.
Charging: new headset has enough power for
pairing and dialing out for several times. When
in low battery, please charging via USB cable for
2 hours. Red LED keep lighting during charging,

blue LED keep lighting charging finished.

Reset Mode: Connect the headset to computer

via Micro USB cable. When red LED light flashes,
headset reset finished.

5

3, Pairing (One headset support connecting 2
phone devices )

Pairing with one phone or other device

Make sure the headset is power off.
Press and hold the multifunctional button for 5
seconds to enter into the pairing mode.

Red LED & Blue LED flashes alternately,

Activate your phone or device Bluetooth
function and search for headset. From the list of
found devices on your mobile phone, select the
headset “M6” to connect it. Follow the instruc­tion to enter “0000” as PIN if the mobile phone
reminder to need. Headphone or device can be
used to play your phone music or dial phone call
etc.

Pairing with two phones or other devices at the
same time

This headset can support 2 devices multi-con­nection. It can pair with two mobile phones
simultaneously, taking the call from any of them.

After completing pairing with the first phone,

turns off the headset, then re-do the paring

procedure with another phone. Once finished

the pairing, restart the headset, it will automati­cally connect to the Phone or device of Last
connected , and short press the two key of
“volume +” and “volume -” simultaneously ,can
enable the multipoint Connect function, from

the list of found devices on another mobile
phone, select the headset “M6” to connect it.

Pairing to a phone with NFC function:

1. Turn on your phone and ensure its NFC
function is activated.

2. Turn on M6 headset.

3. Put your phone's NFC area the position of left
side M6 printed ‘NFC ’ logo.

4. When your phone need be confirmed the

connection, then press YES/OK.

5. After succeeding in connecting, you can enjoy
music, play games and watch movies, you also
can control the player via, such as 'volume up"
and "next music" function.

Kit Contents

1, 1 X Stereo Bluetooth sport headset M6
2, 1 X Charging Micro USB Cable
3, 1 X User Manual

Warning

1, You must choose a qualified charger from a

regular manufacturer to charge the headphone.
2, you must charge the headphone if it has not
been used for more than 12 months.

Specification

Bluetooth version: 4.1
Talk time: 5h
Stand-by time: 170h

4, Sound quality with apt-X® code

Featuring the apt-X code, the headsets can
connect wirelessly to any apt-X® enabled
devices, vastly improves the quality of
Bluetooth streaming, delivering CD-quality
sound.

Music play time: 5h
Wireless range: 10m

Bluetooth profiles: A2DP/ AVRCP/ HSP /HFP

Impedance: 32Ω
Sound pressure level: 91±3dB
Frequency Response: 20Hz---20 KHz
Weight: 28g
Dimension: 360x50x30mm

6

7

8

FCC Information and Copyright

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment

off and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

—

Reorient or relocate the receiving antenna.

—

Increase the separation between the equipment and receiver.

—

Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

—

Consult the dealer or an experienced radio/TV technician for help.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1)This device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired operation.

changes or modifications not expressly approved by the party responsible for compliance could

void the user's authority to operate the equipment. This equipment complies with FCC radiation

exposure limits set forth for an uncontrolled environment .The device has been evaluated to

meet general RF exposure requirement. The device can be used in portable exposure condition

without restriction.
