ASI-Automation Systems Interconnect CPA3.5 Data Sheet

SPECIFICATIONS
Housing Material: PA68 Polymide, Flammable UL94V0 Housing Color: Green Screw: Zinc Plated Steel Clamp: Nickel Plated Brass Pin: Tin Plated Brass Testing torque: 2.7 in/lb Wire range: 16-30 AWG P.C.B. mounting hole: 1.1mm Nominal current: 10 A Voltage: 300 V Temperature Range: -30° C to 110° C
Miniature, Multi-Position Fixed PCB Terminal Blocks
The CPA is a single sub-miniature printed circuit board terminal block that is available in several pin spacings and from 1 to 24 positions. The CPA uses a moving metal body design for the termination of the wire to insure maximum reliability . The CPA is UL recognized and will terminate wire ranging from 16 to 30 A WG and will handle 10 amps at 300 volts. The CP A is available in a right angle version. The standard color is green, however several other colors are available upon request.
Catalog # No. of Positions Length
(mm)
CPA3.5-2SQVE 2 7 CPA3.5-3SQVE 3 10.5SQ CPA3.5-4SQVE 4 14 CPA3.5-5SQVE 5 18.5 CPA3.5-6SQVE 6 21 CPA3.5-7SQVE 7 24.5 CPA3.5-8SQVE 8 28 CPA3.5-9SQVE 9 31.5 CPA3.5-10SQVE 10 35 CPA3.5-11SQVE 11 38.5 CPA3.5-12SQVE 12 42 CPA3.5-13SQVE 13 45.5 CPA3.5-14SQVE 14 49 CPA3.5-15SQVE 15 52.5 CPA3.5-16SQVE 16 56 CPA3.5-17SQVE 17 59.5 CPA3.5-18SQVE 18 63 CPA3.5-19SQVE 19 66.5 CPA3.5-20SQVE 20 70 CPA3.5-21SQVE 21 73.5 CPA3.5-22SQVE 22 77 CPA3.5-23SQVE 23 80.5 CPA3.5-24SQVE 24 84
