DIN Rail Surge Protection
Devices, SPD
Prosurge’s SP series surge arrester is UL1449-4th addition approved SPD especially designed for low-voltage
power supply system surge protection at the boundaries from lightning protection zone 0B-2 and higher. It is a DIN-rail
designed surge protective device featuring Prosurge’s global patented design of thermally protected MOV with special
arc-extinguish device, providing fast and reliable protection for various power supply systems. Modules feature a visual
fault indicator and an optional remote alarm contact is available to monitor the operating status of the surge protector
by signaling an alarm. The SP series has a very high short circuit current rating of 200kArms, which eliminates the
requirement for additional overcurrent protection devices.
Applications:
• Power Supplies
• Telecom
• Industrial Automation
• Railway Systems
• Photovoltaic (PV) Systems
• UPS Systems
• Electricity
• Electrical Vehicle Charging Station
• Water Treatment Systems
• Motor Control And Starter Systems
• AC/DC Distribution
• Programmable Logic Controller (PLC)
• Power Transfer Equipments
• HAVC Applications
• IT / Data Centers
• Applications-AC/DC Drives, LT Panels, MCC,
PCC, CNC Machines, PLC Etc.
• Medical Equipments
• Security Systems
Features:
• UL 1449-4th Edition Recognized Type 1CA SPD
for Type 1, 2, and 3 Application, SCCR 200 kA
• Built-in Thermally Protected High Energy
MOV Technology (Patented SMTMOV
Technology)
• High Surge Energy Capability
• Low Voltage Protection Level
• Din-Rail Mountable For Easy Installation
• Degradation Failure Indication
• Fail-Safe, Self-Protected Design
• Pluggable Module For Easy Replacement
• No Additional Over-Current Protection
Devices Required
• Meets Both Standards of UL1449-4th Edition and
IEC61643-11:2011
ASI
Automation Systems Interconnect, Inc
Innovative Interconnect and Interface Solutions
DIN Rail Surge Protection
Devices, SPD
Figure 3: 120/240V Split-phase three-wire
Figure 4: 120/240V Split-phase three-wire + ground
Figure 5: 240V, 277V, 480V, 600V Three-phase delta & WYE three-wire + ground
Figure 6: 220Y/127V,208Y/120V, Three-phase WYE(star)four-wire+ground
380Y/220V, 400Y/230V,
415Y/240V, 480Y/277V,
600Y/347V
ASI
Automation Systems Interconnect, Inc
Innovative Interconnect and Interface Solutions
DIN Rail Surge Protection
Devices, SPD
PD Models used for Single-Phase Two-Wire System
Nominal
Part No
Poles
Voltage
Maximum Continuous
Operating Voltage, MCOV
(Vac)
(Vac) L-N L-G N-G L-N L-G N-G
Voltage Protection Rating,
VPR (kV)
SP150-1P 1 120 150 150 - 0.7 0.7 -
SP180-1P 1 127 180 180 - 1.0 1.0 -
SP275A-1P 1 240 275 275 - 1.0 1.0 -
SP320-1P 1 277 320 320 - 1.2 1.2 -
SP385-1P 1 277 385 385 - 1.5 1.5 -
SP420-1P 1 347 420 420 - 1.5 1.5 -
SP550-1P 1 480 550 550 - 1.8 1.8 -
SP690-1P 1 600 690 690 - 2.5 2.5 -
SP150T 1 0 - - 150 - - 0.9
SP255T 1 0 - - 255 - - 0.9
SPD Models used for Split-Phase Two-Wire + Ground System
Nominal
Part No Poles
SP180-2P* 2 120 180 180 180 2.0 1.0 1.0
SP320-2P* 2 277 320 320 320 2.5 1.2 1.2
*This model is used for split phase applications for L-G protection mode.
Voltage
(Vac) L-N L-G N-G L-N L-G N-G
Maximum Continuous
Operating Voltage, MCOV (Vac)
Voltage Protection Rating, VPR
(kV)
ASI
Automation Systems Interconnect, Inc
Innovative Interconnect and Interface Solutions
DIN Rail Surge Protection
Devices, SPD
PD Models used for Split-Phase Three-Wire + Ground System
Nominal Voltage
Part No Poles
(Vac) L1-G L2-G N-G L1-G L2-G N-G
SP180-3P* 3 120 180 180 180 1.0 1.0 1.0
SP320-3P* 3 240 320 320 320 1.2 1.2 1.2
*This model is used for split phase applications for L1 to G, L2 to G and N to G protection mode.
PD Models used for Three-Phase Wye Three-Wire + Ground System
Nominal Voltage
Part No Poles
(Vac) L-L L-G N-G L-L L-G N-G
SP150-3P 3 120 300 150 - 1.5 0.7 -
SP180-3P 3 120 360 180 - 2.0 1.0 -
SP275A-3P 3 240 550 275 - 2.0 1.0 -
Maximum Continuous
Operating Voltage, MCOV
(Vac)
Maximum Continuous
Operating Voltage, MCOV
(Vac)
Voltage Protection Rating,
VPR (kV)
Voltage Protection Rating,
VPR (kV)
SP320-3P 3 277 640 320 - 2.5 1.2 -
SP385-3P 3 277 770 385 - 3.0 1.5 -
SP420-3P 3 347 840 420 - 3.0 1.5 -
SP550-3P 3 480 1000 550 - 4.0 1.8 -
SP690-3P 3 600 1000 690 - 5.0 2.5 -
ASI
Automation Systems Interconnect, Inc
Innovative Interconnect and Interface Solutions
DIN Rail Surge Protection
Devices, SPD
SPD Models used for Three-Phase Wye Four-Wire + Ground System
Part No Poles
Nominal
Voltage
(Vac) L-L L-N(G) N-G L-L L-N L(N)-G
Maximum Continuous
Operating Voltage, MCOV
(Vac)
Voltage Protection Rating,
VPR (kV)
SP150-4P 4
SP150-3PN 4 300 150 150* 1.5 0.7 0.9
SP180-4P 4
SP180-3PN 4 360 180 150* 1.5 0.9 0.9
SP275A-4P 4
SP275A-3PN 4 550 275 255* 2.0 1.0 0.9
SP320-4P 4
SP320-3PN 4 640 320 255* 2.5 1.2 0.9
SP385-4P 4
SP385-3PN
SP420-4P 4
SP420-3PN 4 840 420 255* 3.0 1.5 0.9
SP550-4P 4 600/347 1000 550 550 4.0 1.8 1.8
SP690-4P 4 600/347 1000 690 690 5.0 2.5 2.5
4
208/120
208/120
415/240
480/277
480/277
600/347
300 150 150 1.5 0.7 0.7
360 180 180 2.0 1.0 1.0
550 275 275 2.0 1.0 1.0
640 320 320 2.5 1.2 1.2
770 385 385 3.0 1.5 1.5
770 385 255* 3.0 1.5 0.9
840 420 420 3.0 1.5 1.5
SPD Models used for Single-Phase Two-Wire + Ground System
Maximum Continuous
Operating Voltage, MCOV
(Vac)
Voltage Protection Rating,
VPR (kV)
Part No
Poles
Nominal
Voltage
(Vac) L-N L-G N-G L-N L-G N-G
SP150-2P 2
SP150-PN 2 150 150 150 0.7 0.9 0.9
SP180-2P 2
SP180-PN
SP275A-2P 2
SP275A-PN 2 275 275 275 1.0 1.0 0.9
SP320-2P 2
SP320-PN 2 320 320 255 1.2 1.2 0.9
SP385-2P 2 277 385 385 385 3.0 1.5 1.5
SP385-PN 2 240 385 385 255 1.5 1.5 0.9
SP420-2P 2 347 420 420 420 3.0 1.5 1.5
SP420-PN 2 240 420 420 255 1.5 1.5 0.9
SP550-2P
SP690-2P 2 600 690 690 690 5.0 5.0 2.5
2 180 180 150 1.0 1.0 0.9
2 480 1000 550 550 4.0 1.0 1.0
120
150 150 150 1.5 0.7 0.7
180 180 180 2.0 1.0 1.0
120
275 275 275 2.0 1.0 1.0
240
320 320 320 2.5 1.2 1.2
277
ASI
Automation Systems Interconnect, Inc
Innovative Interconnect and Interface Solutions
DIN Rail Surge Protection
Devices, SPD
Visual Indicator & Remote Signal:
