AC4812
30V /6A Dual 2N Power MOSFET
General Description
30
Pb-free lead plating; RoHS compliant
6
6B03C
V DS
RDS(on),TYP@VGS=10V
RDS(on),TYP@VGS=4.5
ID
30V /6A Dual 2N Power MOSFET
29.4
Very low on-resistance RDS(on) @ VGS=4.5 V
46.2
Parameter
Maximum
Drain-Source Voltage
30
Gate-Source Voltage
20
Part ID
Package Type
Marking
Tape and reel
infomation
100% UIS Tested
AC4812
SOP8
4812
3000
100% Rg Tested
Repetitive avalanche energy L=0.1mH G
4.4
Power Dissipation A
TA=25°C
2
W
TA=70°C
1.3
Continuous Drain Current A
TA=25°C
6.0
A
TA=70°C
5.0
Pulsed Drain Current B
9.6
Avalanche Current G
1.9
ID
PD
Junction and Storage Temperature Range
-55 to 150
Parameter
Symbol
Maximum Junction-to-Ambient A
t ≤ 10s
RθJA
Maximum Junction-to-Ambient A
Steady State
Maximum Junction-to-Lead C
Steady State
RθJL
