Ascot GT-WS-07w User Manual

Digital Radio-controlled weather station

User´s Guide

Now you have purchased an Ascot product.

After Sales Support

Now you have purchased a Ascot product you can rest

assured in the knowledge that as well as your 3 year parts

and labour warranty you have the added peace of mind of

dedicated helplines and web support.

MODEL No.:

GT-WS-07s. GT-WS-07w, GT-WS-06s
GT-WS-06w, GT-WT-01

Contents

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

2

3 Introduction
3 Safety
6 This is what the weather station offers
7 Overview of weather station
10 Initial use
13 About the time signal
16 Select location
21 Displays
23 Time functions
25 Weather data
31 Moon phases
32 Other functions
35 Cleaning
36 Faults and rectification
37 Technical data
38 Conformity declaration
38 Disposal
39 Warranty card

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

3

Introduction

Safety

Please read carefully through the following information
and keep these instructions, in case you need to refer to
them later. If you pass the product on to someone else,
please also include these instructions.

Designated use

The weather station - comprised of the base station and radio sensor

- displays various weather data (air pressure, temperature, etc.) from
the vicinity. From the measured weather data, the weather station
determines a weather forecast. The weather station also displays the
date, time and moon phases and also has an alarm function.
The weather station is unsuitable for commercial use in weather
forecasting or in weather data measurement.

Congratulations on choosing to buy a Ascot product. By doing

so you now have the assurance an peace of mind that comes

with purchasing a product made by one of Europe´s leading

manufacturer.

All products brought to you by Ascot are manufactured to the
highest standards of performance and safety, an, as part of our
philosophy of customer service and satisfaction, are backed by

our comprehensive 3 Year Warranty.

Please fill in an return the Warranty Card to the adress provid-

ed. We hope you will enjoy using youy purchase for many years

to come.

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

4

Hazards for children

! Batteries can be life-endangering if swallowed. Therefore, keep

the weather station, radio sensor and batteries out of reach of
small children. If a battery has been swallowed, medical assist­ance must immediately be sought.

! Keep children away from packaging material and the small parts

in the scope of delivery. Suffocation hazard if swallowed.

Injury hazard

! Caution: Explosion hazard with improper handling of batteries.

Batteries must not be charged, reactivated with other means,
dismantled, thrown into fire or short-circuited.

! Avoid contact with skin, eyes and mucous membranes. When

coming into contact with battery acid, immediately rinse the
affected areas with plenty of clear water and immediately
contact a doctor.

Caution – property damage

! Protect the base station and radio sensor from dust, impact,

extreme temperatures and direct sunshine.

! Protect the base station from moisture. Exclusively position base

station in a dry, enclosed space.

! The radio sensor is protected from moisture, but must be

protected from direct moisture, e.g. rain.

! Rubberized feet to prevent slipping are located on the bottom of

the base station. As the furniture/floor surfaces are made of
diverse materials and are treated with diverse care products, it
cannot be entirely ruled out that some of these materials contain
components, which could attack and soften the rubber lining. If
necessary, place a non-slip base under the base station.

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

5

! Remove the batteries from the base station and radio sensor, if

they become depleted or if you are not using the weather station
for a longer period of time. This way, you avoid damage that
could result from leakage.

! Do not expose the batteries to any extreme conditions by e.g.

laying them on a radiator or under direct sunlight. Increased
leakage hazard!

! Clean the battery and appliance contacts prior to insertion, if

required.

! Only use batteries of the same type, do not use different types or

used and new batteries together.

! Do not carry out any changes to the device. Only allow repairs to

be carried out by a professional workshop and pay attention to
the guarantee conditions.

! Do not use harsh or abrasive detergents for cleaning the weather

station. This could scratch the surfaces.

Contents of delivery

! Weather station, comprised of the base station and radio sensor
! 2 batteries type LR6 (AA) / 1.5 V (base station)
! 2 batteries type R03 (AAA) / 1.5 V (radio sensor)
! Operating instructions with guarantee
! Quick Reference Guide

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

6

This is what the weather station offers

Weather station

! Precise time through reception of a time indicator signal
! 12-hour or 24-hour display for two time zones
! Date and day of week display
! Inside temperature display in °C/°F
! Outside temperature display in °C/°F with up to three sensors at

various measuring points

! Inside and outside humidity display
! Minimum/maximum display for temperature, atmospheric

humidity and barometric pressure

! Weather trend display and temperature trend display
! Current and historical air pressure trend display
! Symbols for the weather forecast
! Moon phase display
! Battery control display

Sensor

! Temperature display in °C/°F
! Humidity display
! Range of up to 100 metres (in open space)

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

7

Overview of weather station

Base station - view from front and top

Display, see page 21

Illuminate display / activate alarm repeat function

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

8

Base station - right side view

Display stored MIN and
MAX data

Set values (reduce)
Start radio reception manuall

Set values (increase)
Switch alarm function on
and off

Activate setting mode
Save entered settings

Query weather data from
the existing radio sensors

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

9

Base station - back

Battery compartment

Set air pressure at location (reduce)

Activate setting mode for air pressure

Set air pressure at location (increase)

With the other type of weather station,
the BARO buttons are on the left side.

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

10

Radio sensor

Initial use

Inserting batteries

Proceed in the order shown and first insert the batteries
into the radio sensor and only afterwards into the base
station. Only this way, can the weather station function
faultlessly.

Battery compartment

Accelerate radio
transmission to
base station
manually

Change degree of
measurement for
temperature

Set sensor number

(transmission channel)

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

11

Radio sensor

1. Remove the battery compartment lid on the back of the radio
sensor.

2. Insert two type R03 (AAA) / 1.5 V batteries, as shown on the base
of the battery compartment.
Pay attention to the correct polarity (+/-) of the batteries.

3. Reattach the battery compartment lid.

Using additional radio sensors

The weather station is supplied with one radio sensor. However, you
can operate the weather station with up to three radio sensors. Addi­tional radio sensors are available through our Service centre, see
page 46.

! The radio sensors can be situated in different rooms or outdoors.
! Each sensor must have its own sensor number (sensor number =

number of the transmission channel) allocated to it (1 to 3).

! For the snow and frost warning, the weather station only evalu-

ates the data of the sensor with the lowest number (default is 1).

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

12

Procedure:

1. Remove the battery compartment lid on the back of the radio
sensors.

2. Set a dedicated sensor number for each radio sensor using the
slide switches.

3. Reattach the battery compartment lids onto the radio sensors.

4. Keep the CHANNEL button pressed on the base station until the
display for weather data OUT flashes.
The base station will now access the weather data for all availa­ble radio sensors.

Base station

1. Fold open the battery compartment lid.

2. Insert two type LR6 / 1.5 V batteries, as shown on the base of the
battery compartment. Pay attention to the correct polarity (+/-).

3. Reattach the battery compartment lid and fold it shut.

4. Wait for approx. 30 minutes. The base station requires this time
in order to gather all of the weather data and receive radio sig­nals from the time indicator signal.

Setting air pressure

The air pressure depends on the altitude, i.e. in the mountains, there
is lower air pressure than in lowlands.

For the proper function of your weather station, you therefore need
to enter the current air pressure value of your device location. You
can obtain information on this on the Internet or from the local
authorities of your town or municipality. When you have entered the
current (related to sea level) air pressure in the weather station, this
always shows the sea-level-related air pressure of the location.

1. Keep the SET/BARO button pressed until the display that shows
the air pressure begins to flash.

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

13

2. Using the BARO- / BARO+ buttons, set the air pressure. Pay
attention to what is shown in the display.

3. Then, press SET/BARO again.

If you keep the BARO- / BARO+ pressed, the values move
forward more quickly.

About the time signal

General

The radio-controlled clock that is integrated into the weather station
receives its radio signals from the time indicator signal MSF.

As soon as the base station is supplied with power by the batteries,
it switches onto receiving and searches for the signal from transmit­ter MSF. If the time signal has been received through the ferrite bar
antenna built into the radio-controlled alarm clock at a sufficient
strength, the date and time will be shown in the display.

The base station switches on several times a day and synchronises its
time with the radio signal from transmitter MSF. In the case of non­receipt, e.g. with strong lightning storms, the device continues to
run accurately and only switches to receiving automatically at the
next designated time.

Start radio reception manually

When the batteries are inserted in the base station, all indications
will briefly been shown in the display. The display will also briefly illu­minate and sound a beep tone.

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

14

After this, the device switches to receiving, whereby the radio
wave number shows the quality of the reception: The more
radio waves are displayed, the better the reception.

As soon as the signal is received with sufficient strength, the relevant
data is shown in the display and the transmitter tower symbol is
constantly displayed. This process can take a few minutes.

Effective immediately, the weather station switches to receiving
several times a day and compares the displayed time with that from
the time signal transmitter.

If a week signal is received the base station will stop the receiving
process and the tower symbol will not be shown. The receiving proc­ess will start again later.

In this case, the time continues to run normally, from the start time
of "00:00".

! First, check whether the location of the base station is suitable,

see page 16.

! You can restart the receiving process again manually, see

page 15, or

! Wait until the base station automatically switches to receiving

again later. Reception is usually better during the night.

! If reception is not possible at your location, you can set the time

and date manually, see next chapter.

Set time and date manually

1. Keep the MODE/SET. pressed until the year flashes in the dis­play.

2. Using the +/ or -/ /ZONE buttons, set the year.

3. Press the MODE/SET. button to save the setting.
The month flashes in the display.

4. Using the +/ or -/ /ZONE buttons, set the month.

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

15

5. Press the MODE/SET. button to save the setting.
The date flashes in the display.

6. Using the +/ or -/ /ZONE buttons, set the date.

7. Press the MODE/SET. button to save the setting.
The hour flashes in the display.

8. Using the +/ or -/ /ZONE buttons, set the correct hour.

9. Press the MODE/SET. button to save the setting.
The minute flashes in the display.

10. Using the +/ or -/ /ZONE buttons, set the correct minute.

11. Press the MODE/SET. button to save the setting.
In the display, the 12-hour and 24-hour time format flashes.

With the 12-hour format, the afternoon hours are identified
in the display with PM.

12. Using the +/ or -/ /ZONE buttons to set the required time
format.

13. Press the MODE/SET. button to save the setting.
In the display, the zone setting (+11/-11) flashes.

14. Using the +/ or -/ /ZONE buttons, set the time difference to
another metropolis or region (if required).

15. For additional information regarding the time zone function, see
page 34.

16. Press the MODE/SET. button to end the process.

Start radio reception manually

If the adjacent radio signal symbol is no longer displayed, the
radio signals of the time signal transmitter are no longer
being received. The time display nevertheless continues to
run accurately.

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

16

In order to start the reception of the time signal manually, keep the

-/ /ZONE button pressed until the radio signal symbol is displayed

again and the weather station is switched to reception.

Please note:

! If the reception was not successful, the reception symbol disap-

pears after several minutes and the time in the display continues
to run normally.

! With successful reception, the radio-controlled alarm clock sets

itself to the time of the time signal transmitter. If you have
already carried out manual time and date settings, these are
automatically adjusted.

Select location

ATTENTION

- Protect the base station and radio sensor from dust,
impact, extreme temperatures and direct sunshine.

- Protect the base station from moisture. Exclusively posi­tion base station in a dry, enclosed space.

- The radio sensor is protected from moisture, but must be
protected from direct moisture, e.g. rain.

General

The base station and radio sensor exchange data through a radio
frequency. Therefore, the location is crucial to the range of the radio
connection.

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

17

Please note:

! The maximum allowable distance between the base station and

the sensor is 100 metres. However, this range is only possible
with "direct visible contact".

! Blocking building materials, e.g. reinforced concrete reduce or

prevent radio reception between the base station and radio
sensor.

! Devices, such as televisions, cordless telephones, computers and

neon tubes can also disrupt the radio reception.

! Do not place the base station and radio sensor directly on the

ground. This limits the range.

! At low temperatures during the winter, the performance of the

radio sensor batteries can fall significantly. This reduces the
transmission range.

Regarding the radio reception between the time signal transmitter
and the base station, please note the following points:

! Preferably set up the base station near a window.
! Keep a distance to televisions, PCs and monitors. Base stations of

cordless telephones should also not be in the direct vicinity of
the weather station.

! Reception is usually better during the night. If the alarm clock

should not have any reception during the daytime, it could be
that the signal will immediately be received at night and at full
strength.

! The weather, e.g. an intense lighting storm, can cause reception

problems.

! The transmitter can occasionally be switched off temporarily,

e.g. for maintenance works.

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

18

Base station

DANGER

When installing on a wall, please ensure that no electric
cables, gas and water pipes are not buried beneath the wall
surface before drilling any holes.

A

B A

A

B

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

19

! The base station can be stood up or suspended. The base station

has a fold-down stand (A) and two suspension loops (A) for this
purpose.

! The stand has three locking positions.
! Preferably set up or suspend the base station near a window.

This is usually the best reception site.

B

B

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

20

Radio sensor

! Stand or suspend the radio sensor at a location where it is

protected from direct weather influences (rain, sun, wind, etc.).
Suitable locations are e.g. below a canopy or in a carport.

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

21

Displays

Base station

1

2

3

4

5

6

6 5

1

2

3

4

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

22

Radio sensor

1

Display, see page 25

2

Date and day of week display, see page 23

3

Moon phase display, see page 31

4

Date and alarm time display, see page 23

5

Air pressure display, see page 28

6

Weather forecast, see page 29

Temperature

Humidity

set sensor number
(= transmission channel)

Symbol for radio link between base station and radio sensor
(displayed only during radio transmission)

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

23

Time functions

Time and date

Alarm function

You can set two different alarm times with the base station For
example, you can be woken up in the morning and after your after­noon nap, by activating both alarms.

1. Select the required alarm time by pressing the MODE/SET. but­ton (A1 or A2).

Current day of week

12-hour format

Time zones

Time in hours,

minutes + seconds

Day and month

Symbol for radio reception from time signal transmitter

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

24

2. Keep the MODE/SET. pressed for approx. 2 seconds, when you
have selected the required alarm time.
The hour display of the alarm time (A1 or A2) flashes.

3. Using the +/ or -/ /ZONE buttons, set the required alarm
hour.

4. Press the MODE/SET. button to save the setting.
The minute flashes in the display.

5. Using the +/ or -/ /ZONE buttons, set the required alarm
minute.

6. Press the MODE/SET. button to save the setting.
The alarm time is set and activated.

Switch alarm function on and off

The alarm function is switched on an off using the +/ button.

! Press 1x: A1 is active is displayed

! Press 2x: A2 is active is displayed

! Press 3x: and A1 and A2 are active is displayed

! Press 4x: and A1 and A2 are no longer active is

extinguished

End alarm

At the set time, you will be woken up by an alarm signal, whereby the
signal will increase in intensity, the longer the alarm sounds.

! Alarm repeat - Press the LIGHT/SNOOZE button repeatedly, in

order to disrupt the alarm for 5 minutes. This process can be
repeated several times.

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

25

! Switch off alarm completely - Press any button on the base station

in order to end the alarm.

! Autostop function - If you do not press any button, the alarm will

switch off automatically after 2 minutes.

! After 24 hours, the alarm will sound again.

Alarm repeat

! Press the LIGHT/SNOOZE button 1x.

The alarm becomes silent for approx. 5 minutes. After this, the devic­es switches itself back on and wakes you up again. This process can
be repeated several times.

Weather data

Temperature and humidity

This area is divided into two parts in the display. The top section OUT
[OUTSIDE] shows the values measured by the radio sensor, the

bottom section IN [INSIDE ] shows the data recorded by the base
station. For technical reasons, the relative humidity can only be
determined within the temperature range of 0 - 60°C.

If "LL" is shown in the OUT [OUTSIDE] section of the
display, the humidity is either a) outside of the measure­ment range of 20% or b) the outside temperature has fallen

below 0°C. In case b), "LL" is displayed for technical reasons.

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

26

With the CHANNEL button, you can switch between the
radio sensors:
CH1, CH2, CH3 or automatic switching between all sensors.
If fewer than three sensors are in use, non-existent radio
sensor are skipped with the switching. If only one radio
sensor is in use (standard), the auto-switching function is
not available.

1

Current transmission channel to the base station

2

Stored maximum and minimum values

3

Trend for temperature, see page 28

4

Battery replacement display, see page 32

5

Trend for humidity, see page 28

6

Humidity in %

7

Degree of measurement for temperature °C or °F

8

Temperature

9

Indication that the sensors are automatically checked
sequentially (only if more than one sensor is being used)

1

2 3

4

5

6

78

9

Display area

Radio sensor

OUT

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

27

With the MIN/MAX button, you can obtain a display of the highest
and lowest values for the last 24 hours in relation to the temperature
and humidity.

! Press 1x: the MAX values are displayed
! Press 2x: the MIN values are displayed
! Press 3x: normal display

The MIN and MAX values are automatically deleted each night at
12:00 a.m.

1

Stored maximum and minimum values

2

Trend for temperature, see page 28

3

Battery replacement display, see page 32

4

Trend for humidity, see page 28

5

Humidity in %

6

Degree of measurement for temperature °C or °F

7

Temperature

Display area

Base station

IN

1 2

3

4

5

67

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

28

The weather station also has a frost alarm. For additional
information on this, see page 30.

Weather trend

For the temperature and humidity values measured by the base
station and radio sensor, the trend is shown in the form of an arrow.

Air pressure

The trend of the air pressure within the last 12 hours is displayed in
the form of a bar diagram. The scale goes from -1 (1 hour ago) to -12
(12 hours ago).

Next to the bar diagram, the current air pressure is displayed in hPA
(hectopascals).

! Press the MIN/MAX button in order to have the highest stored

value during the last 12 hours displayed. By pressing again, the
lowest measured value is displayed.

rising constant

falling

Temperature

Humidity

trend

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

29

The MAX and MIN values are continuously measured and stored. It is
therefore not possible to manually delete these values.

In conjunction with the weather forecast, see next chapter, other
weather indications are possible. Two examples:

! Weather forecast shows rain, the air pressure is falling quickly

and intensively >> strong rain is likely.

! Weather forecast shows rain, the air pressure has risen during

the last 12 hours, but has fallen again during the last 3 hours >>
light rain is likely.

Weather forecast

After initial operation, the details regarding the weather
forecast cannot yet be used for approx. 12 hours, as the
weather station needs this time to gather and evaluate the

weather data.

The weather forecast results from the gathered weather data and
the measured changes in air pressure.

The forecast relates to the area around the weather station with a
radius of approx. 30 - 50 km for a period of the next 12 to 24 hours.

The precision of the weather forecast is approximate only.

sunny

slightly cloudy

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

30

Frost warning - When the radio sensor measures a temperature of
between + 1 °C and -1 °C, a risk of frost exists and a snowflake symbol
flashes. If the temperature falls below -1 °C for a constant period of
time, the snowflake symbol is displayed steadily.

Please note: Even if the temperature alarm is not displayed,
there is always a risk of frost/black ice with temperatures
around freezing point. The outside sensor can only measure the
local temperature at the installation site.

Only if a radio sensor is in use. With a frost alarm, the radio
sensor with the lowest sensor number is always evaluated.

If the symbols for the weather forecast start to flash and the air pres­sure falls, this is an indication of weather deterioration, e.g. because
of a storm front closing in.

However, the requirement for a correct display is that you have set
the air pressure at your location, see page 12.

cloudy

rainy

snowfall

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

31

When the air pressure rises again, the symbols are displayed
constantly again.

In the top section, an arrow indicates the weather trend. If it points
up or down, the air pressure has risen or fallen by more than 1 hPa
within one hour.

Moon phases

The displayed moon phases are automatically updated with the date

constant air pressure = weather unchanged

rising air pressure = weather improving

falling air pressure = weather deteriorating

full moon

waning moon

new moon

new moon waxing moon

full moon

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

32

Other functions

Switch light on

! Press the LIGHT/SNOOZE button in order to switch on the

display lighting for several seconds.

Battery replacement display

There is a battery change display for each of the base station
and radio sensor.

When the symbol for the battery change is displayed, the inserted
batteries in the base station (symbol next to IN)/radio sensor
(symbol next to OUT) need to be replaced with new ones. Then,
proceed as described from page 10 .

Please note:

! The battery replacement display for the radio sensors (symbol

next to OUT) indicates the battery replacement for the respec­tive displayed channel number.

! With a battery change, the settings are all lost. After the battery

change, proceed as described from page 13 .

! Always replace all of the batteries and only use those specified in

the "Technical data".

! Pay attention to the correct polarity (+/-) of the batteries when

inserting them.

! Dispose of old batteries in an environmentally compatible

manner, see page 38.

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

33

Change degree of measurement for temperature

The temperature can only be displayed in either °C or in °F on the
base sensor and radio sensor.

Base unit

! Keep the MIN/MAX button pressed for approx. 2 seconds, in

order to change the displayed unit of measurement.

Radio sensor

1. Open the battery panel on the back.

2. Press the C/F button 1x.

Reset weather station

If obviously incorrect values are being displayed, you should reset
the weather station to its factory settings.

1. Remove the batteries from the weather station and reinsert
them.
When the batteries are inserted in the base station, all indica­tions will briefly been shown in the display. The display will also
briefly illuminate and sound a beep tone.
After approx. 20 seconds, the display begins to flash and the data
from the radio sensors is queried.

2. Pay attention to the displayed values.

3. If incorrect values continue to be displayed: Remove the
batteries from the radio sensors used and reinsert them.

4. Proceed as described from page 10.

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

34

In order to accelerate the data interchange between the
weather station and radio sensor, you can keep CHANNEL
pressed on the weather station until the display flashes and
press the TX button on the appropriate radio sensor. With
this, the weather data will be directly transmitted to the
base station.

Have time displayed in a different time zone

The requirement for this is that you have also entered the time in a
second time zone, see from page 14.

1. Press the -/ /ZONE button if you intend to have the time in a
second time zone displayed.
Next to the time, ZONE is displayed.

2. Press -/ /ZONE again, if the originally displayed time should
appear again.

Each country is allocated to a time zone, whereby countries with a
very large east-west expansion frequently extend over several time
zones.

Russia, for example, extends across 9 time zones, Canada extends
over 5 time zones.

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

35

In the western hemisphere, it is earlier than in Europe and in the
eastern hemisphere, it is later.

In the diagram, each vertical line represents one our more or one
hour less (-).

For example, if you intend to set the time for a country that is 7 hours
east of your location, you must enter +7 (hours) as a value.

Cleaning

! If required, wipe the weather station with a slightly dampened

cloth.

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

36

Faults and rectification

Fault Possible causes and solution

The MSF signal for the time can­not be received.

- Check the location, see page 16.

- Start the radio reception manu­ally, if necessary, see page 15.

- Set the time manually, see
page 14.

The temperature display of the
sensor appears too high.

- Check whether the sensor is
exposed to direct sunlight.

The weather station does not
receive any sensor signals.

- Ensure that no electrical disrup­tion sources are near the sensor
or the base station.

- Check the batteries in the sen­sor.

- Start the radio reception manu­ally: Keep the

CHANNEL button

pressed on the base station until
the display for weather data

OUT flashes. You can also keep

the TX button pressed in the
battery compartment of the
radio sensor in order to transfer
the data to the base station
more quickly.

- Move the weather station closer
to the sensor or vice versa.

The display is illegible, the func­tion is unclear or the values are
obviously incorrect.

- Reset the weather station to its
original factory settings, see
page 33.

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

37

Technical data

Base station: GT-WS-07s / GT-WS-07w

GT-WS-06s / GT-WS-06w
Batteries: 2 x LR6 (AA) / 1.5 V
Measurement range
of the temperature 0 °C to +50 °C
Measurement precision: max. +/- 1°C within a measurement range

of 0 to 40°C
Resolution: 0.1°C
Measurement range
of humidity: 20% to 90% relative humidity
Measurement precision: +/- 10% relative humidity
Resolution: 1%
Sensor: GT-WT-01
Batteries: 2 x type R03 (AAA) / 1.5 V
Measurement range of
the temperature: -15 °C to +60 °C
Transmission frequency 433 MHz
Range: max. 100 metres (in free space)

As our products are constantly being further developed and
improved, design and technical changes are possible.

In the display, HH / LL is shown in
the display instead of the measu­red values for temperature/
humidity.

- The values are above/below the
measurement range, see
"Technical data".

- The measured outside
temperature is less than 0°C.

HELPLINE No. U K / N.IRELAND 0800 328 60 20 REP. IRELAND 00 800 44 67 58 88

WEB SUPPORT [e-mail]

38

Conformity declaration

Globaltronics GmbH & Co. KG hereby declares that this radio­controlled weather station complies with the basic requirements
and other regulations of Directive 1999/5/EC. You can find the full
conformity declaration on the Internet at www.gt-support.de.

Disposal

Dispose of the packaging in an environmentally appropriate
manner. The appliance must not be disposed of with house­hold waste. If the appliance should no longer usable,
remove the batteries from the appliance. Ask the local waste
removal association about the necessary disposal measures.

Batteries and rechargeable batteries are not permitted to be
disposed of with household waste. Every consumer is legally
obligated to submit batteries and rechargeable batteries to
the collection centre of his local municipality, district or to
retailers. All batteries and rechargeable batteries can there­by disposed of in an environmentally friendly manner.

Batteries and rechargeable batteries containing toxins are
identified with this symbol and with chemical symbols
(Cd for cadmium, Hg for mercury, Pb for lead).

Cd
Hg

Pb

Digital Radio-controlled
weather station

3 YEAR WARRANTY CARD

Name

Adress

Email TelNo

Model No.

Location of purchase

Warranty card

E44059

11/2011

Dario London Service Centre
PO Box 70

Chislehurst

BR7 5YH

UK

Hotline - UK: 0800 / 328 6020

Hotline - Ireland: 00800 / 4467 5888
Mail: [e-mail]

Please send your completed Warranty Card to:
