ASCENDO System M5S SE Active Piano Black, System M5S SE Active Piano White ASCENDO_Technical_Data_System_M5S_SE_Active_engl.pdf
System M5S S.E. Active
plus 4 x DNA 1000.2 HE S.E.
Principle
Construction
Dimensions
(W/H/D)
Weight
Fully active high-end speaker system, can be measured in
to the listening room.
Four-way with SASB technology ( dynamic current-damped
external driver and semi-symmetrical bandpass )
Modular resonance-decoupled
mounting of the drivers
adjustable time-alignment
between 50 and 190 cmheight of listening position
Material low-magnetic V2A
combination of highly noise-absorbing bitumen and
high-density fiberboards
(MDF) to reduce mechanical
vibration
stand:
transducer:
transducer-base:
Amplifier:
Speaker:
Amplifier:
50 / 131,5 / 65 cm
40 / 148,5 / 45 cm
50 / 159 / 65 cm
360 / 155* / 255* mm
*plus 15 mm for the stands
125 kg
16,3 kg
Illustration shows optional extra
Woofer
Total system
power
Treble driver
module
Bass driver module
Finish
24 Hz (-3 dB)
per speaker 1650 Watts sinus
Tweeter
Rearward TOS /dipole
External driver
Internal driver 28 cm chassis
Cabinet
Stand
magnetostatic ribbon
tweeter
magnetostatic ribbon
tweeter
22 cm chassis
HPC membrane
phase plug
hexacone honeycomb
membrane
piano lacquer black
differing colours in piano
lacquer on request
high gloss stainless steel
matt stainless steel
Technical modifications subject to change
without further notice
