Ascendo C8-C User Manual

C8-C

USER'S MANUAL

2

Contents

1 OVERVIEW .............................................................................................................. 3

1.1 Overall Picture ................................................................................................. 3

1.2 Application ...................................................................................................... 3

1.3 Safety Warning ................................................................................................ 3

1.4 Operating modes ........................................................................................... 4

1.5 Technical Data ............................................................................................... 4

2 INSTALLATION ........................................................................................................ 5

2.1 Demands of speaker location ..................................................................... 5

2.2 Mounting .......................................................................................................... 5

3 TRANSPORT ............................................................................................................. 6

4 CONNECTION ........................................................................................................ 6

5 TOS-UNIT ................................................................................................................. 7

6 CLEANING .............................................................................................................. 7

ASCENDO GMBH
HÖLDERLINWEG 6

73257 KÖNGEN
GERMANY

Phone: [phone]
Fax: [phone]

MAIL: [e-mail]
www.ascendo.de

1. Overview

The ASCENDO C8-C is a

four

Technology and ASCEND

O TOS

1.1 Overall Picture

1 TOS-Unit
2 Terminal
3 Base

1.2 Application

The ASCENDO Loudspeaker

(< 100 m³

)

.

You can use the C8-C

with amplifiers in the power range of 10 W to 350 W.

1.2 Safety Warning

Warning

This Loudspeaker can produce high sound

-way Loudspeaker (TOS ON) constructed

with ASCENDO's SASB

-Unit.

C8-C intended for use in small to mid-

size rooms

-levels. This m

ay damage your ears permanently

3

-

!

4

1.4 Operating modes

You can use the C8-C a single-amp setup (one power amplifier for high- and low-frequency
unit) or in a bi-amp setup (one power amplifier for the low-frequency-unit, one for the high­frequency unit).

If your setup is single-amp you must bridge the high- and low-frequency unit with a high
quality speaker cable.

1.5 Technical Data

Principle

Three-Way with SASB bass unit (TOS Off) (current damped
outer driver with semi symmetrical band pass)

Four-Way with SASB bass unit (TOS ON)

Dimensions (W/H/D)

28 / 95 / 40 cm

Weight

45 Kg

Frequency Range

29 Hz (-3 dB) – 32.000 Hz

Power

350 W Program (min.)

Impedance

6 Ohm

Sensivity

88 db / 1W/m

Outer Chassis (Coax)

Inner Chassis
TOS Chassis

COAX

• 25 mm Neodymium-fabric-tweeter

• 17 cm Woofer with XP cone
21 cm Chassis, Kevlar cone
Ribbon-tweeter

TOS function switch able

An: TOS Unit / Dipole On
Aus: TOS Unit / Dipole Off

Sockets

Bi-Wiring

Technical data may change without notice

2. Installation

2.1

Demands of speaker location

· Use the C8-C

in closed rooms only. Do not expose the speaker to high humidity, direct

water and direct sunbeam.

·

Take care of a minimum distance of 2 m of the speaker to monitors (TV, computer) and

magnetic devices

(audio/video

WARNING

There may be a slight permanent imprint in soft floor

2.2 Mounting
WARNING

Don’t try to mount the System

need at least two persons t

1.

Place the base(3) carefully at the

desired place.

2.

Adjust the base (3) for your specific

hearing position.

3. Place the C8-C

carefully

the base.

Take care not to touch the

diaphragm of the coax

4

Connect the units with your power

amplifier(s). See section

-cassettes, floppy-disks, etc.).

-material.

C8-C

alone. The weight is too much for a single person. You

o build up the system.

on top of

-chassis.

4.

5

3. Transport

1.

Switch off the power amplifiers a

2. Pull off C8-C

from the base (3). Take care not to touch the diaphragm of the coax

chassis.

3.

Place the base (3) at its new position

4. Connection

4 Plus Outer Chas
5 Minus

Outer Chassis (Coax)

6 Plus

Inner Chassis

7 Minus

Inner Chassis

8 Switch

TOS Unit / Dipol

Warning

Don’t try to move the C8-C

least two persons to build up the system.

nd disconnect all cables of the C8-C.

.

(Coax) Mid / High

Mid / High
Low
Low

e On - Off

alone. The weight is too much for a single person. You need at

6

-

7

The C8-C can be connected as follows:

· single-wired: one cable-pair from power-amp to outer chassis (4+5) unit, one bridge-
cable pair from outer chassis (4+5) to inner chassis (6+7).

· bi-wired: one cable-pair from power amp to outer chassis (4+5), one from the power
amp to inner chassis (6+7). This is recommended by ASCENDO.

· bi-amped: one cable-pair from separate amps outer chassis (4-5) and inner chassis (6+7)

Take care of connecting always the plus (red) terminal of your power amp with the plus (4 +
6 / red) terminal of the speaker.

5. TOS-Unit

The conception of C8-C utilizes a switch-able backfiring TOS-Unit. This Unit optimizes spectral
inhomogeneous decay times.

The system offers two complementary modes of operation:
Switch (8) in position AN (Dipole)

· 4-way dipole diversity with TOS - Unit

Switch (8) in position AUS (Hemisphere)

· One-Point-Source with homogenous hemisphere diversity

6. Cleaning

Clean the enclosure and stand of the ASCENDO C8-C with a dry and soft cloth.
Don’t use water or other chemicals. Don’t touch the tweeter and the woofer.
