Ascendo C7 User Manual

C7

USER'S MANUAL

2

Contents

1 OVERVIEW ........................................................................................................... 3

1.1 Overall Picture .............................................................................................. 3

1.2 Application ................................................................................................... 3

1.3 Safety Warning ............................................................................................. 3

1.4 Operating modes ........................................................................................ 4

1.5 Technical Data ............................................................................................. 4

2 INSTALLATION ..................................................................................................... 5

2.1 Demands of speaker location ................................................................... 5

2.2 Mounting ....................................................................................................... 5

3 SETTING UP AND TRANSPORT ............................................................................. 5

4 CONNECTION ..................................................................................................... 5

5 TOS-UNIT .............................................................................................................. 6

6 CLEANING ........................................................................................................... 6

ASCENDO GMBH
HÖLDERLINWEG 6

73257 KÖNGEN
GERMANY

Phone: [phone]
Fax: [phone]

MAIL: [e-mail]
www.ascendo.de

3

1 Overview

The ASCENDO C7 is a four-way Loudspeaker ( T OS ON) constructed with ASCENDO's SASB­Technology and ASCENDO TOS-Unit.

1.1 Overall Picture

1 TOS-Unit
2 Terminal

1.2 Application

The ASCENDO Loudspeaker C7 intended f or use in small to mid-size rooms
(< 100 m³

)

.

You can use the C7 with amplifiers in the power range of 10 W to 350 W.

1.2 Safety Warning

Warning

This Loudspeaker can produce high sound-levels. This may damage your ears permanently!

270

400

120

400

1000

4

1.4 Operating modes

You can use the C7 a single-amp setup (one power amplifier for high- and low-frequency
unit) or in a bi-amp setup (one power amplifier for the low-frequency-unit, one for the high­frequency unit).

If your setup is single-amp you must bridge the high- and low-frequency unit with a high
quality speaker cable.

1.5 Technical Data

Principle

Three-Way with SASB bass unit (TOS Off) (current
damped outer driver with semi symmetrical band
pass)

Four-Way with SASB bass unit (TOS ON)

Dimensions (W/H/D) 27 / 100 / (40-12)

Weight 30 Kg

Frequency Range 28 Hz (-3 dB) – 25.000 Hz

Power

350 W Program (min.)

Impedance 6 Ohm

Sensivity 88 db / 1W/m

Outer Chassis (Coax)

Inner Chassis
TOS Chassis

COAX

• 25 mm Neodymium-fabric-tweeter

• 17 cm Woofer with XP cone
21 cm Chassis, Kevlar cone
27 mm Magnesium tweeter no Ferrofluid

TOS function switch able

An: TOS Unit / Dipole On
Aus: TOS Unit / Dipole Off

Sockets Bi-Wiring

Technical data may change without notice

5

2. Setting up and Transport

2.1 Demands of speaker location

• Use the C7 in closed rooms only. Do not expose the speaker to high humidity, direct
water and direct sunbeam.

• Take care of a minimum distance of 2 m of the speaker to monitors (TV, computer) and
magnetic devices (audio/video-cassettes, floppy-disks, etc.).

WARNING

There may be a slight permanent imprint in soft floor-material.

2.2 Transport

Before any movement of the speaker switch of the power amplifiers and disconnect all
cables of the C7.

WARNING

Don`t try to move or transport the C7 alone! The weight affords at least two persons.

4. Connection

4 Plus Outer Chas (Coax) Mid / High
5 Minus Outer Chassis (Coax) Mid / High
6 Plus Inner Chassis Low
7 Minus Inner Chassis Low
3 Switch TOS Unit / Dipole On - Off

6

The high- and low-frequency unit can be connected as follows:

• single-wired: one cable-pair from power-amp to low-frequency unit, one cable-pair from
low-frequency unit to high-frequency unit.

• bi-wired: one cable-pair from power amp to low-frequency unit, one from the power
amp to high-frequency unit. This is recommended by ASCENDO.

• bi-amped: one cable-pair from separate amps for low- and high-frequency unit.

Take care of connecting always the plus (red) terminal of your power amp with the plus (4 +
6 / red) terminal of the speaker.

5. TOS-Unit

The conception of C7 utilizes a switch-able backfiring TOS-Unit. This Unit optimizes spectral
inhomogeneous decay times.

The system offers two complementary modes of operation:
Switch (8) in position AN (Dipole)

• 4-way dipole diversity with TOS - Unit

Switch (8) in position AUS (Hemisphere)

• One-Point-Source with homogenous hemisphere dive r s ity

6. Cleaning

Clean the enclosure and stand of the ASCENDO C7 with a dry and soft cloth.
Don’t use water or other chemical s . Don’t touc h t he tweeter and the woofer.
