ASA Electronics AVT-1940 User Manual

PPLICATIONS, L.L.C.

UDIOVOX PECIALIZED

INSTRUCTION MANUAL

19” COLOR TELEVISION

AVT-1940

The serial number is located on the rear of the set.

For future reference, please copy the number here.

Serial No.________________________________

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE RISK OF ELECTRIC SHOCK,

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED PERSONNEL.

The lightning flash with the arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the products enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.

The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and servicing
instructions in the literature accompanying the product.

WARNING

To prevent fire or shock hazard, do not expose this appliance to rain or moisture.

CAUTION

Changes or modifications not expressly approved by the manufacturer could void the user’s authority to
operate this equipment.

NOTE TO CATV SYSTEM INSTALLER

This reminder is provided to call the CATV system installer’s attention to article 820-40 of the NEC
that provides guidelines for proper grounding and in particular specifies that the cable ground shall
be connected to the grounding system of the building, as close to the cable entry as practical.

CAUTION

The AC power cord provided with this product is polarized (one blade wider than the other). To provide
power to the TV, insert the AC plug into a standard 120V 60 Hz polarized outlet.

NOTE

Never connect the plug to an electrical source other than one providing 120V 60Hz power. Use
only the attached power cord. If the polarized AC cord does not fit into a non-polarized outlet, do
not cut or file the blade. You are responsible for having the obsolete outlet replaced with a
polarized outlet.If you feel static discharge when touching the unit, and the unit does not function,
simply unplug the unit from the outlet. When you plug the unit back in, it should work normally.
Do not install power cords near any heating element or cooking appliances.

Table of Contents

Important Safeguards………………………………………………………………2
Chapter 1: Overview of your Equipment…………………………….………….4

Your TV’s Front Panel……………………………………………………….4
Your TV’s Back Panel……………………………………………………….4
Your Remote Control………………………………………………………...5
Installing your remote control batteries……………………………...6
Notes……………………………………………………………………6

Chapter 2: Connecting an Antenna or Cable to your TV…………………….7

Connecting an Antenna……………………………………………………...7
Connecting a Cable System………………………………………………...8
Connecting Other Pieces of Equipment……………………………………9
Safety Note…………………………………………………………………….9

Chapter 3: Operating Your TV…………………………………………………….10

Turning your TV on…………………………………………………………..10
Programming Your TV’s Channel Memory………………………………..10
Changing Channels………………………………………………………….11
Changing the Volume………………………………………………………..11
Changing the TV’s Channel Memory………………………………………12
Adding/Deleting a channel to memory……………………………12
Displaying the Current channel……………………………………………..12
Adjusting Video Settings…………………………………………………….13
Returning to the factory settings…………………………………..14

Descriptions of video settings……………………………………..14

Chapter 4: Using Timer Functions……………………………………………….15

Setting the Clock……………………………………………………………...15

Setting the Wake-Up Timer………………………………………….………15

Setting the Off Timer………………………………………………………….16
Canceling the Wake-up Timer or Off Timer………………………………..16
Setting the Sleep Timer………………………………………………………17

Chapter 5: Additional Features……………………………………………………18

Changing the Language of the On-Screen Menus………………………...18
Captioning………………………………………………………………………18
CC on Mute…………………………………………………………………….18
Power Restore…………………………………………………………………19
Auto Tint (option)………………………………………………………………20

Chapter 6: Troubleshooting………………………………………………………..21
Warranty……………………………………………………………………………….22

Table of Contents-1

Important Safeguards

PLEASE READ ALL THESE INSTRUCTIONS REGARDING YOUR TELEVISION EQUIPMENT AND
RETAIN FOR FUTURE REFERENCE. FOLLOW ALL WARNINGS AND INSTRUCTIONS MARKED
ON THE TV RECEIVER.

2-

13. An outside antenna system should not be
located in the vicinity of overhead power
lines or other electric light or power
circuits, where it can fall into such power
lines or circuits. When installing an
outside antenna system. Extreme care
should be taken to keep from touching
such power lines or circuits as contact with
them might be fatal.

14. Do not overload wall outlets and extension
cords as this can result in fire or electric
shock.

15. Never push objects of any kind into this
television equipment through the openings
as they may touch dangerous voltage
points or short out parts that could result in
a fire or electric shock. Never spill liquid
of any kind on the television equipment.

16. Do not attempt to service this television
equipment yourself as opening or
removing covers may expose you to
dangerous voltage or other hazards.
Refer all servicing to qualified service
personnel.

17. Unplug this television from the wall outlet
and refer servicing to qualified service
personnel under the following conditions:
a) When the power-supply cord or plug is

damaged or frayed.

b) If liquid has been spilled, or objects

have fallen into the television
equipment

c) If the television has been exposed to

rain or water.

d) If the television equipment does not

operate normally by following the
operating instructions. Adjust only
those controls that are covered by the
operating instructions as an improper
adjustment of other controls may
result in damage and will often require
extensive work by a qualified
technician to restore the TV receiver
to its normal operation.

e) If the television equipment has been

dropped or the cabinet has been
damaged.

f) When the television equipment

exhibits a distinct change in
performance this indicates a need for
service.

18. When replacement parts are required, be sure
the service technician has used replacement
parts specified by the manufacturer that have
the same characteristics as the original part.
Unauthorized substitutions may result in fire,
electric shock or other hazards.

19. Upon completion of any service or repairs to
this television equipment, ask the service
technician to perform safety checks to
determine that the television is in a safe
operating condition.

20. If an outside antenna or cable system is
connected to the television receiver, be sure
the antenna or cable system is grounded so as
to provide some protection against voltage
surges and built up static charges.
Section 810 of the National Electric Code
ANSI/NFPA No. 70-1984, provides information
with respect to proper grounding of the mast
and supporting structure, grounding of the lead
–in wire to an antenna discharge unit, size of
grounding conductors, location of antenna
discharge unit, connection to grounding
electrodes, and requirements for the grounding
electrode.

Important Safeguards- 3

Overview of your Equipment

Your TV comes with a remote control. The section below summarizes the

buttons, controls and terminals that you will use with your TV.

Your TV’s Front Panel

1. POWER

Use this button to turn your TV on or off.

2. ùùCH üü

Use these buttons to change channels on your TV, or to select items in the menu system.

3. ÿÿ VOL ÷÷

Use these buttons to change your TV’s volume, or to select items in the menu system, or to
change audio and video settings.

4. MENU

Use this button to turn the TV’s menu system on and off.

5. Remote control receiver

This receiver receives a signal from your remote control. Do not block it.

Your TV’s Back Panel

1. Antenna terminal

Use this terminal to attach an antenna or
cable system to your TV

4-Chapter 1: Overview of your Equipment

Your Remote Control

1. POWER

Use this button to turn your TV on or
off.

2. MUTE

Use this to turn the TV’s sound on
and off

3. ùùCH üü

Use these buttons to change
channels on your TV, or to select
items in the menu system.

4. ÿÿ VOL ÷÷

Use these buttons to change your
TV’s volume, to activate selections in
the menu system, or to change audio
and video settings.

5. MENU

Use this button to turn the TV’s
menu system on and off.

6. DISPLAY

Use this button to display the
channel number and status.

7. INPUT

Use this button to select the TV’s
signal source.

8. VIDEO

Use this button to display video
adjustment items.

9. 0-9

Use these buttons to change
channels.

10. SLEEP

Use this button to program the TV to
turn off after a certain time.

11. PREVIOUS

Use this button to return to the
previous channel you were watching.

Chapter 1: Overview of Your Equipment- 5

Installing your Remote Control Batteries

1. Open the battery compartment on the back of the remote control.

2. Install the two AAA- size batteries (not included) as shown. Make sure the “+” and “-“ terminals
are oriented correctly.

3. Replace the cover.

Notes

Do not mix different types of batteries, or mix an old and a new battery.
Remove and replace weak batteries. Weak batteries can leak and damage your controller. Dispose
of batteries properly: never throw them into a fire.
Point your remote at the receiver on the center of the front of the TV. Make sure the receiver is not
blocked.
The remote control can operate up to 30 feet away from the TV if you are directly facing the front of
the TV. Operating distance diminishes as you move to the sides of the TV.

6- Chapter 1: Overview of your Equipment
