ASA VR50 User Manual

Owner's Manual

Electronically-Tuned

AM/FM/MPX Radio

with Quartz Clock

Model VR50

Rotate this knob to the right to turn the radio on. Continue rotation untii
the desired voiume ievei is obtained.

(2) TONE CONTROL

Rotate this knob either to the ieft or right to adjust the desired tone
reproduction. Rotating the knob ciockwise will increase treble response and
counter-olockwise will increase bass response

(3) LEFT/RIGHT BALANCE CONTROL(PULL)

Pull this knob outward until it locks into outer position. Rotate it to the
left or right to obtain the desired balance between left and right speakers.
Push knob back in to return to volume control position.

© FRONT/REAR FADER CONTROL

Rotate this knob to the left or right to obtain the desired balance between
front and rear speakers in 4 speaker installations. When used in conjunction
with the Left/Right Balance Control @, you have full 4-way stereo balance
capability.

© FM/AM BAND SELECTOR

Each time this button is pressed, the radio band is changed.The indications
"AM1 "ori'AM2", "FM1" or "FM2"or"FM3" will appear in the display panel
according to you selection.

© &0MANUAL UP/DOWNTUNING

To manually select a radio station press the Up Tuning(UP) button©to advance
the unit one digit higher or Down Tuning (DN) button ® to tune downward.
Pressing either button for longer than 0.5 second will cause the radio to tune
rapidly in the selected direction.

© AUTO-STORE TUNING(AS)

PRE-SET SCAN TUNING (PS)

During radio operation, press this button momentarily to soan the twelve stations
pre-set into the memories of the AM bands or the eighteen pre-set memories of
the FM bands. The unit will stop at each pre-set station for 5 seconds before
continuing to the next pre-set station(the channel indicator number on the

display will flash). Press the button again momentarily to stop the Pre-set
Scan operation and remain on the selected frequency. Pressing the button
for longer than 1 second will activate the Auto-Store Tuning .which will
automatically scan the band and enter the six strongest stations into the six
pre-set memory positions for each band. If you have already set the pre-set
memories to your favorite stations, activating the Auto-Store feature will
erase those stations and enter the new strong stations. This feature is

most useful when travelling in a new area where you are not familiar with the
local stations.

STATION PRE-SET MEMORIES
To set any of the 6 pre-set memories, use the following procedure:

1. Turn the unit on and select the AM1 band.

2. Select the first station to be pre-set using the Manual Tuning ® &(j) .

3. Press the pre-set button to be set and continue to hold the button in. The
volume \will be muted for approximately 2 seconds and then return. The
station Is now set Into that pre-set button. To recall that station, press the
button momentarily.

4. Repeat the above procedure for the remaining 5 pre-sets on the band.

5. Select the AM2 band and enter 6 FM memories using the same procedure as
above. In similar fashion, enters pre-set memories on the FM1,FM2,FM3
Band.

LIQUID CRYSTAL DISPLAY PANEL
The Liquid Crystal Display(LCD) panel displays the frequency, time and
activated functions.
Note: It Is a characteristic of LCD panels that If subjected to cold temperatures
for an extended period of time, they will take longer to Illuminate than under
normal conditions. In addition, the visibility of the numbers on the LCD may
sightly decrease. The LCD read-out will return to normal Vitien the temperature
Increases to a normal range.

d) TIME/FREQUENCY SELECTOR (CLK|

During radio operation, push this button to call the time display on the
incorporated quartz clock. Pressing the button again will return to frequency
display, or It will automatically return after approximately 5 seconds.

SETTING CLOCK

1. Switch vehicle ignition "on" and radio "oF (time display \«ill show on LCD

Panel)

2. Press and hold the Time /Frequency Selector(CLK). at the same time. Press

the Down Tuning button © to adjust the hours , then the Up Tuning
button© to adjust the minutes.

3. After setting the correct time , release the Tlme/Frequency Selector.

WIRING DIAGRAM

SPECIFICATIONS

Size:
Operatinq Voltage: 12VDC, Negative Ground

Output Power: 50 Watts Max. Stereo Power

Output Wiring:

Output Impedance:

Tuning Range:

Sensitivity:
FM Stereo Separation:

Frequency Response: 50-10000HZ

7"(W)x 2" (H)x 6 1/8"(D)
178mm x 50mm x 156mm

Floating Ground type
designed for 4 speaker use
May also be used with 2
speaker.

Compatible with 4 or 8 ohm

speaker.

(AM) 530-171 OKHz

fFMI 87.5-107.9MHz

(AM) less than 25uV

(FM) less than 5uV

More than 23 dB

THE DRIVING HABITS OF AM AND FM RECEPTION

Although you may be familiar with both AM and FM reception In your home, you will experience
notable differences In reception while driving your car. This page will explain why these
variances occur and how they affect the broadcast you are listening to .

Both AM and FM provide excellent listening enjoyment and supply the diversified entertainment
necessary to relieve the boredom of hours "behind the wheel" of you car FM reception although
unique In Its characteristics while driving, provides a totally new sound experience unlike AM
reception. The clarity ottone, the richness of sound and the varied program content provide
hours of uninterrupted listening enjoyment. The few reception Inconveniences common to FM are
compensated by the many plus features of a sound experience rivaled only by a live sound
performance

Your new AM-FM radio or radio-tape system has been buiit to the strictest engineering standards
avaiiabie today and through quaiity components and construction wiii provide maximum perfor.
mance under all conditions A few minutes reading this page will enable you to obtain the most
from FM reception and provide answers to your questions about the differences between AM and
FM operation while driving in your car

Some facts about AM and FM reception:

1 RECEPTIONINTUNNELS

Although you will lose AM reception when driving through tunnels and under large bridges, it is
common to continue to receive FM reception.

2 THENUMBER OF STATIONS IN YOUR AREA

Depending upon your location you will usually find the number of AM stations in your area
outnumber the number FM stations, although the continuing popularity of FM reception has
significantly increased the number of FM stations nationwide.

3. RECEPTION DURING STORMS
Local electrical thunderstorm activity often produces sharp static sound when listening to AM
stations although you will find that FM is unaffected

4. ELECTRICAL INTERFERENCE
When listening to AM stations, you may experience some buzzing sounds or static when
Passing electrical roadside power lines which does not interfere with FM reception.
Conversely, FM may be affected by electrical noise from passing cars or trucks while AM r
eception is not.

5. FM RECEPTION RANGE
FM reception range is usually limited to 50 miles from the broadcast station. FM signals
radiate straight out from the broadcast antenna. They do not follow earth's cuw'e and are not
reflected back to earth by the atmosphere resulting in limited "line of sight" reception range

6. AM RECEPTION RANGE
AM stations can be received several hundred miles from the broadcast station. AM signals
follow the earth's curve and are easily reflected back to earth by the atmosphere. Therefore ,
an AM signal is easily received far from the broadcast station antenna.

FM RECEPTION WHILE YOU ARE DRIVING

Since FM signals become weaker the further you drive away from the broadcast station you
will experience flutter', noisy reception and fading in the poor signal fringe area Thr'ough the
modern circuitry in this radio, this "Fringe Area" has been greatly reduced for greater
reception area. Even with this improved circuitry eventually the FM signal will become too
weak to provide quality reception . 'When this occurs it is best to change to a stronger. Local
FM station

Although FM signals are not reflected by the atmosphere they are easily reflected by solid
objects. This effect of FM signals provides two totally differ'ent reception possibilities. First an
FM signal can "bounce" between tall buildings r'esulting in unexpected reception in many
Areas where AM reception is impossible

The same effect can result in the "loss" of an FM signal if a large obstruction is located bet.
ween you and the FM antenna, if hills or buildings between you and the antenna block the
signals.lt is possible to find reception very poor even when you are not far from the FM
Antenna

Audiovox Specialized Applications, L.L.C.

For a list of electronics products specifically designed for

The mobile environment, please visit us on the web

at:

www.asaelectronics.com.

Made in China

Tíi0 MotUé Eié^ifúñtCM COñtpúny

Audiovox Specialized Applications, llc

www.asaelec1ronics.com

90 DAY/12 MONTH LIMITED WARRANTY

AUDIOVOX SPECIALIZED APPLICATION, LLC (Ihe company) warrants to the
original retail purchaser of this product that should this productor any part
thereof, under normal use and conditions , be proven defective in material or
workmanship within 90 days from the date of original purchase, such defect(s)
will be repaired or replaced (at the company's option) without charge for parts
and repair labor. After the initial 90 day period and for a period of 12 months
from the date of original purchase,the Company will supply at no oharge a
replacement for any defective part(s), but will charge for the labor to repair the
product.

To obtain repair or replacement within the terms of this warranty, the product is
to be delivered with proof of warranty coverage (e.g.:dated bill of sale),
specification of defect(s), transportation prepaid, to an approved warranty
station, or the Company at the address shown below.

This warranty does not extend to the elimination of externally generated static or
noise, to the correction of antenna problems, to costs incurred for removal or
reinstallation of the product, or to damage to any tapes, speakers, accessories,
or electrical systems.

This warranty does not apply to any product or part thereof which , in the
opinion of the company , has been damaged through alteration, improper
installation, mishandling ,misuse, neglect, or accident, THE EXTENT CF THE
CCMPANY'S LIABILITY UNDER THIS WARRANTY IS LIMITED TCTHE REPAIR
CR REPLACEMENT PRCVIDED ABCVE, AND , IN NC EVENT, SHALL THE
CCMPANY'S LIABILITY EXCEED THE PURCHASE PRICE PAID BY THE
PURCHASER FCR THE PRCDUCT.

This warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED
WARRANTIES, INCLUDING ANY IMPLIED WARRANTY CF MERCHANTABILITY,

SHALL BE LIMITED TC THE DURATICN CF THIS WARRANTY ANYACTICN
FCR BREECH CF ANY WARRANTY HEREUNDER INCLUDING ANY IMPLIED

WARRANTY CF MERCHANTABILITY MUST BE BRCUGHT WITHIN A PERICD

CF 30 DAYS FRCM THE DATE CF CRIGINAL PURCHASE. IN NC CASE SHALL

THE CCMPANYBE LIABLE FDR ANY CDNSEOUENTIAL DR INCIDENTAL

DAMAGES FDR BREECH CF THIS DR ANY DTHER WARRANTY EXPRESS DR
IMPLIED, WHATSDEVER. No person or representative is authorized to assume

for the company any liability other that expressed herein in connection with the

sale of this product.
Some states do notallow limitations on how long an implied warranty lasts or

the exclusion or limitation of incidental or consequential damages so the above
limitations or exclusions may not apply to you. This warranty gives you specific
legal rights and you may also have other rights which vary from state to state.

AUDIDVDX SPECIALIZED APPLICATIONS, LLC
23319 COOPER DR. ELKHART, IN 46514
Visit us at

http://www.asaelecfronics.com
