ASA AVP-7000 OPERATING INSTRUCTIONS
VIDEO CASSETTE PLAYER
DC OPERATION W/SPECIALIZED TAPE MECHANISM
DLC COATED VIDEO HEAD
BACKLIGHTING FUNCTION BUTTONS
AVP-7000 OPERATING INSTRUCTIONS
RECOMMENDED GUIDELINES FOR USE OF A VIDEO MONITOR/TV IN A MOTOR VEHICLE
A VIDEO/MONITOR/TV is designed for rear passenger viewing only.
This product may be installed in the rear seat compartment of the vehicle, out of the driver’s view.
• Installation in any other area of the vehicle, including anywhere within the driver’s view, is illegal in
most states, provinces and countries and may lead to driver distraction resulting in an accident, injury
and/or death. If you are unsure of regulations regarding this, you should consult your local laws to
determine how this applies to you.
• Users should be aware of the possible noise distraction caused by the use of the product and should
carefully monitor the volume so as not to interefere with the driver’s attention to surrounding traffic
conditions.
CONTENTS
IMPORTANT SAFEGUARDS………………….3 SPECIAL OPERATION……………………………..12
IMPORTANT NOTES…………………………..6 IDENTIFICATION………………………….………..13
FEATURES……………………………………...7 CONNECTION……………………………………….17
MOISTURE CONDENSATION………………..8 BEFORE CALLING SERVICE PERSONNEL…….20
VIDEO HEAD CLEANING……………………..9 TROUBLE SHOOTING………………………………21
BASIC OPERATIONS………………………..10 SPECIFICATIONS……………………………………23
Thank you for purchasing AUDIOVOX VCP, developed advanced features and functions for high quality
APPAREIL ℵ LA PLUIE NI ℵ L’HUMIDIT⊃.
EXPOSING ANY PARTS OF THE BLADES.
ℵ D⊃COUVERT.
CAUTION: TO REDUCE RISK OF ELECTRIC SHOCK,
constitute a risk of electric shock to persons
performance.
To obtain the best results and to avoid malfunction, please read the following instructions carefully
before using.
WARNING: TO PREVENT ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE
AVERTISSEMENT: POUR PREVENIR LES RISQUES D’INCENDIE ET D’ELECTROCUTION, NE PAS EXPOSER CET
CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT USE THIS (POLARIZED) PLUG WITH AN EXTENSION CORD,
RECEPTACLE OR OTHER OUTLET UNLESS THE PLUG CAN BE FULLY INSERTED WITHOUT
ATTENTION: POUR ⊃VITER LES CHOCS ⊃LECTRIQUES, NE PAS UTILISER CETTE FICHE (POLARISEE) AVEC
UN CORDON PROLONGATEUR, UNE PRISE DE COURANT OU UNE AUTRE SORITE DE COURANT,
SAUF SI LES BROCHES PEUVENT ⊇TRE INSEREES ℵ FOND SANS QU’AUCUNE PARTIE NE RESTE
CAUTION
RISK OF ELECTRIC
SHOCKS DO NOT OPEN
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED PERSONNEL.
The lightning flash with the arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the VCP.
1
Note to CATV system Installer:
2
This reminder is provided to call the CATV
system installer’s attention to Article 820-40 of the
ote to CATV
NEC that provides guidelines for proper
grounding and, in particular, specifies that the
cable ground shall be connected to the grounding
system of the building, as close to the point of
cable entry as practical.
NOTE:
This equipment has been tested and found to comply
with the limit for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and is not installed and used in
accordance with the instructions may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV
technician for help.
IMPORTANT SAFEGUARDS
operating instructions and adhere to them.
Power Sources-
Object and Liquid Entry-
3
For your protection, please read these safety instructions before operating the VCP and keep this
manual for future reference.
Carefully observe all warnings, precautions, and instructions on the VCP or the ones described in the
USE
operated only from the type of power
source indicated on the marking label.
If you are not sure of the type of
electrical power supplied at your home,
consult your dealer or local power
company. For those sets designed to
operate from battery or other sources,
refer to the operating instructions.
Water and Moisture- Do not use
power line operated sets near waterfor example, near a bathtub, washbowl,
kitchen sink, or laundry tub, in a wet
basement, or near a swimming pool,
etc.
This set should be
Accessories- Do not place the set on
an unstable cart, stand, tripod, bracket,
or table. The set may fall, causing
serious injury to a child, or an adult,
and serious damage to the set. Use
only a cart stand tripod, bracket, or
table recommended by the
manufacturer.
Never push
objects of any kind into the set through
the openings as they may touch
dangerous voltage points or short out
parts that could result in fire or electric
shock. Never spill liquid of any kind on
the set.
Ventilation- The slots and openings in
the cabinet are provided for necessary
ventilation. To ensure reliable
operation of the set, and to protect it
from overheating, these slots and
openings must never be blocked or
covered.
-Never cover these slots and openings
with a cloth or other materials.
-Never block the slots and
openings by placing the set on a
bed, sofa, rug or other similar
surface.
Attachments- Do not use
attachments not recommended
by the manufacturer, as they
may cause hazards.
Cleaning-
Unplug the set from the
Portable Cart Warning-
wall outlet before cleaning it. Do not
use liquid cleaners or aerosol
cleaners. Use a cloth lightly
dampened with water for cleaning
the exterior of the set.
-Never place the set in a confined space
such as a bookcase, or built in cabinet,
unless proper ventilation is provided.
VCP and cart
combination should be moved with
care. Quick stops, excessive force,
and uneven surfaces may cause the
VCP and cart combination to overturn.
-Do not place the unit near or over
a radiator, heat register, or where it
is exposed to direct sunlight.
4
SERVICE
Damage Requiring Service
from the wall outlet and refer servicing to
Servicing-
qualified service personnel under the
following conditions:
-When the power cord is damaged or frayed.
-If liquid has been spilled or objects have
fallen into the set.
-If the set has been exposed to rain or water.
- Unplug the set
-If the set has been subject to excessive shock
by being dropped, or the cabinet has been
damaged.
-If the set does not operate normally when
following the operating instructions. Adjust only
those controls that are specified in the operating
instructions. Improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore the set to normal operation.
Do not attempt to service the set
yourself as opening or removing covers may
expose you to dangerous voltage or other
hazards.
Refer all servicing to qualified service personnel.
Replacement parts- When replacement parts are
required, be sure the service technician has used
replacement parts specified by the manufacturer
that have the same characteristics as the original
parts.
Unauthorized substitutions may result in fire,
electric shock, or other hazards.
Safety Check- Upon completion of any service or
repairs to the set, ask the service technician to
perform routine safety checks (as specified by the
manufacturer) to determine that the set is in safe
operating condition.
- When the set exhibits a distinct change in
performance this indicates a need for service.
5
Important Notes
• Note that main voltage is supplied to the unit whenever the main plug is connected to the power
supply socket.
• To avoid the risk of electric shock, do not expose the unit to rain or moisture.
• Do not attempt to open the cabinet. There are no user-serviceable parts inside. Refer all servicing to
qualified service personnel.
• Keep the unit away from radiators or other sources of heat.
• Do not operate or store this unit close to strong magnetic fields.
• Do not spill liquid of any kind onto this unit. If liquid is accidentally spilled onto the unit, immediately
remove the main plug from the supply socket, and consult a qualified service engineer.
• Avoid places subject to strong vibration.
• Do not place anything heavy on the VCP.
• Use the video player in a horizontal (flat) position only.
• Before operating, remove any paper wrapping which may have been affixed to the VCP during
manufacture. DO NOT COVER VENT OPENINGS ON TOP AND SIDES OF THE PLAYER DURING
OPERATION.
• When a cassette is inserted into the loading compartment, the power is switched on automatically as
long as the power cord is plugged into a DC outlet. DO NOT force a cassette into the compartment
when the power cord is unplugged.
• After playing a video cassette, remove it from the player. DO NOT move the player with a video
cassette in the compartment.
• Store video cassettes in their sleeve or case and position them vertically.
For your protection, record the model number
and serial numbers of your video cassette player
here. In the event your player requires servicing
or is stolen, you may need this information. You
may also wish to clip or staple your sales receipt
to this page.
Model Number:_______________________________
Serial Number:_______________________________
Date Purchased:_____________________________
Store’s Name and Address:
___________________________________________
___________________________________________
6
