DATA SHEET
ARUBA RAP-100 SERIES
REMOTE ACCESS POINTS
High-performance wireless and wired
networking for SMBs, branch oces
and teleworkers
The multifunctional Aruba RAP-100 series delivers
secure 802.11n wireless and wired networking to
SMBs and access to corporate resources from
branch and home oces.
With unmatched deployment exibility, the RAP-100 series
can operate in Aruba Instant mode controlled by the
AirWave management platform or in controller-managed
mode where all network ser vices are centralized by Aruba
Mobility Controllers.
In Aruba Instant mode, trac is locally bridged but it
still provides the exibility of secure tunneling to
Mobility Controllers.
To eliminate client stickiness, the RAP-100 series includes
integrated ClientMatch technology, which continuously
gathers session performance metrics and uses this data to
every device to the best AP and radio on the WLAN, even
while users roam and RF conditions change.
The RAP-100 series also oers a wide range of enterprise-
class features, including role-based network access, policy-
based forwarding, and Adaptive Radio Management (ARM),
which optimizes Wi-Fi client performance and ensures that
Aruba APs stay clear of interference.
At locations that require greater coverage, the RAP-100 can
join an Aruba Instant WL AN cluster. Simply install additional
RAP-100s or any Aruba Instant AP and the entire cluster is
managed as one. If one Aruba Instant AP fails, another AP
automatically takes over with no disruption.
With a wireless data rate up to 300 Mbps in the 2.4-GHz
and 5-GHz radio bands, the RAP-100 series has one
10/100/1000BASE-T Ethernet uplink, one 10/100BASE-T
local Ethernet port and one USB port to connect to 3G and
4G networks.
When operating in Aruba Instant mode, the cloud-based
Aruba Activate service dramatically reduces RAP-100 series
deployment time by performing zero-touch provisioning,
rmware upgrades and inventory management. With
Aruba Activate, R AP-100s are factory-shipped to remote
deployment sites and obtain their congurations
automatically when powered up.
ADVANCED FEATURES
• ClientMatch technology eliminates sticky clients by
continuously gathering session performance metrics
and using this information to steer them to the best AP
and radio.
• ARM technology delivers best-in-class RF management,
including automatic transmit power and channel control
with auto coverage-hole correction.
• Zero-touch provisioning as well as automated rmware
upgrades and inventory management with the cloud-
based Aruba Activate service.
• Spectrum analyzer remotely scans the 2.4-GHz and 5-GHz
radio bands to identify sources of RF interference.
• Security:
- With an OpenDNS service subscription, Aruba
Instant RAPs delivers integrated web ltering, malware
and botnet protection to every device connected to
the WLAN
- Integrated Trusted Platform Module (TPM) for secure
storage of credentials and keys
- SecureJack-capable for secure tunneling of wired
Ethernet trac
DATA SHEET
ARUBA RAP-100 SERIES REMOTE ACCESS POINTS
- VPN conguration functionality enables the Instant
AP to create a single VPN tunnel to an Aruba Mobility
Controller in the data center. The Mobility Controller
acts solely as a VPN end-point and does not supply the
Instant AP with any conguration.
WIRELESS RADIO SPECIFICATIONS
• AP type: Dual-radio, dual-band 802.11n indoor
• Software-congurable dual radio supports 2.4 GHz and
5 GHz
• 2x2 MIMO with two spatial streams and up to 300 Mbps
wireless data rate per radio
• Supported frequency band (country-specic
restrictions apply):
- 2.4000 GHz to 2.4835 GHz
- 5.150 to 5.250 GHz
- 5.250 to 5.350 GHz
- 5.470 to 5.725 GHz
- 5.725 to 5.875 GHz
• Available channels: Managed by Aruba Instant or
Mobility Controller, depending upon the congured
regulatory domain
• Supported radio technologies:
- 802.11b: Direct-sequence spread-spectrum (DSSS)
- 802.11a/g/n: Orthogonal frequency-division
multiplexing (OFDM)
- 802.11n: 2x2 MIMO with two spatial streams
• Supported modulation types:
- 802.11b: BPSK, QPSK, CCK
- 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM
• Transmit power: Congurable in increments of 0.5 dBm
• Maximum (aggregate) transmit power (limited by local
regulatory requirements):
- 2.4-GHz band: +21 dBm
- 5-GHz bands: +21 dBm
• Advanced Cellular Coexistence (ACC) feature to eectively
deal with interference from cellular systems
• Maximum ratio combining (MRC) for improved
receiver performance
• Cyclic delay diversity (CDD) for improved downlink
RF performance
• Short guard interval for 20-MHz and 40-MHz channels
• Space-Time Block Coding (STBC) for increased range and
improved reception
• Supported data rates (Mbps):
- 802.11b: 1, 2, 5.5, 11
- 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
- 802.11n: MCS0 to MCS15 (6.5 Mbps to 300 Mbps)
• 802.11n high-throughput (HT) support: HT 20/40
• 802.11n packet aggregation: A-MPDU, A-MSDU
POWER
• Supported power sources:
- 802.3af (PoE) or 802.3at (PoE+) on uplink Ethernet port
Note: When using PoE, the USB port will be enabled only
when an 802.3at-compliant source is used
- 12 volts from external power adapter (sold separately)
• Maximum power consumption:
- Without USB device connected: 12.5 watts
- With USB device: 15 watts
ENCRYPTED THROUGHPUT
• Max IPsec encrypted wired throughput = 20 Mbps
ANTENNAS
• RAP-108: Two RP-SMA connectors for external
dual-band antennas
• RAP-109: Four integrated omni-directional antennas for
2x2 MIMO with maximum antenna gain of 5.0 dBi in both
2.4 GHz and 5 GHz. Built-in antennas are optimized for
vertical orientation
INTERFACES
• Network:
- ENET0 (uplink): One 10/100/1000BASE-T Ethernet (RJ-45),
auto-sensing link speed and MDI/MDX
- ENET1 (local): One 10/100BASE-T Ethernet (RJ-45),
auto-sensing link speed and MDI/MDX
• One port for DC power connector
• One USB 2.0 port (Type A connector)
• One serial console interface (RJ-45)
• Visual indicators (LEDs):
- Power/system status
- Ethernet link status (2x)
- Radio status (2x)
• Kensington security slot
• Reset button
DATA SHEET
ARUBA RAP-100 SERIES REMOTE ACCESS POINTS
MOUNTING
• Desktop (vertical): Using stand supplied with product
• Wall (vertical): Using optional wall mount accessory
• Ceiling (horizontal, not recommended for RAP-109): Using
optional ceiling mount accessories
MECHANICAL
• Dimensions (unit):
- Excluding desk mount:
> 160 mm (W) x 43 mm (D) x 160 mm (H)
> 6.30” (W) x 1.69” (D) x 6.30” (H)
- With desk mount:
> 181 mm (W) x 72 mm (D) x 160 mm (H)
> 7.13” (W) x 2.83” (D) x 6.30” (H)
• Weight (unit):
- Excluding desk mount: 385 g (13.6 oz)
- With desk mount: 460 g (16.2 oz)
• Dimensions (shipping)
- 230 mm (W) x 220 mm (D) x 90 mm (H)
- 9.06” (W) x 8.66” (D) x 3.5” (H)
• Weight (shipping): 750 g (1.65 lbs)
REGULATORY MODEL NUMBERS
• RAP-108: APINR108
• RAP-109: APINR109
CERTIFICATIONS
• CB Scheme Safety, cTUVus
• Wi-Fi certied 802.11a/b/g/n
WARRANTY
• Limited lifetime warranty
MINIMUM SOFTWARE VERSIONS
• ArubaOS 6.2.0.0
• Aruba Instant 3.2.0.0
ENVIRONMENTAL
• Operating:
- Temperature: 0° C to +40° C (+32° F to +104° F)
- Humidity: 5% to 93% non-condensing
• Storage and transportation:
- Temperature: -40° C to +70° C (-40° F to +158° F)
REGULATORY
• FCC/Industry of Canada
• CE Marked
• R&TTE Directive 1995/5/EC
• Low Voltage Directive 72/23/EEC
• EN 300 328
• EN 301 489
• EN 301 893
• UL/IEC/EN 60950
• EN 60601-1-1, EN60601-1-2
For more country-specic regulatory information and
approvals, please see your Aruba representative.
RF PERFORMANCE TABLE
DATA SHEET
ARUBA RAP-100 SERIES REMOTE ACCESS POINTS
Maximum transmit power (dBm)
per transmit chain
802.11b 2.4 GHz
1 Mbps 18.0 -92.0
2 Mbps 18.0 -92.0
5.5 Mbps 18.0 -90.0
11 Mbps 18.0 -88.0
802.11g 2.4 GHz and 802.11a 5 GHz
6 Mbps 18.0
54 Mbps 16.0 -75.0
802.11n HT20 2.4 GHz and 5 GHz
MCS0/8
MCS7/15
802.11n HT40 2.4 GHz and 5 GHz
MCS0/8 18.0 -85.0
MCS7/15 14.0
Maximum capability of the hardware provided. Maximum transmit power will be limited by local regulatory settings.
18.0 -88.0
14.0 -71.0
Receiver sensitivity (dBm)
per receive chain
-88.0
-68.0
RAP-109 ANTENNA PATTERN PLOTS
Horizontal or azimuth plane (top view)
2.452 GHz 5.500 GHz
DATA SHEET
ARUBA RAP-100 SERIES REMOTE ACCESS POINTS
Elevation plane (front view)
Elevation plane (side view)
2.452 GHz 5.500GHz
2.452 GHz 5.500 GHz
DATA SHEET
ARUBA RAP-100 SERIES REMOTE ACCESS POINTS
ORDERING INFORMATION
Part Number Description
RAP-100 Series Remote Access Points
JW264A Aruba RAP-108 (RW) 802.11a/b/g/n Dual 2x2:2 Radio Antenna Connectors Remote AP
JW267A Aruba RAP-108 (US) 802.11a/b/g/n Dual 2x2:2 Radio Antenna Connectors Remote AP
JW265A Aruba RAP-108 (IL) 802.11a/b/g/n Dual 2x2:2 Radio Antenna Connectors Remote AP
JW266A Aruba RAP-108 (JP) 802.11a/b/g/n Dual 2x2:2 Radio Antenna Connectors Remote AP
JW270A Aruba RAP-109 (RW) 802.11a/b/g/n Dual 2x2:2 Radio Integrated Antenna Remote AP
JW273A Aruba RAP-109 (US) 802.11a/b/g/n Dual 2x2:2 Radio Integrated Ant Remote AP
JW271A Aruba RAP-109 (IL) 802.11a/b/g/n Dual 2x2:2 Radio Integrated Antenna Remote AP
JW272A Aruba RAP-109 (JP) 802.11a/b/g/n Dual 2x2:2 Radio Integrated Antenna Remote AP
RAP-100 Series Remote Access Points (FIPS/TAA)
JW268A Aruba RAP-108 (RW) FIPS/TAA-compliant 802.11a/b/g/n Dual 2x2:2 Radio Antenna Connectors Remote AP
JW269A Aruba RAP-108 (US) FIPS/TAA-compliant 802.11a/b/g/n Dual 2x2:2 Radio Antenna Connectors Remote AP
JW274A Aruba RAP-109 (RW) FIPS/TAA-compliant 802.11a/b/g/n Dual 2x2:2 Radio Integrated Antenna Remote AP
JW275A Aruba RAP-109 (US) FIPS/TAA-compliant 802.11a/b/g/n Dual 2x2:2 Radio Integrated Antenna Remote AP
JY749A Aruba RAP-108 (JP) FIPS/TAA-compliant 802.11a/b/g/n Dual 2x2:2 Radio Antenna Connectors
JY750A Aruba RAP-109 (JP) FIPS/TAA-compliant 802.11a/b/g/n Dual 2x2:2 Radio Integrated Antenna
Accessories
JW057A RAP-100-MNT RAP-100 Series AP Wall and Ceiling Mount Kit
JW621A AP-AC-UN 12V/18W Indoor AP AC Universal Power Adapter
JW622A AP-AC-12V18 12V/18W Indoor AP AC Power Adapter without Power Cord
JW627A PD-3510G-AC 15.4W 802.3af PoE 10/100/1000Base-T Ethernet Midspan Injector
