QuickSpecs
Aruba 387 Series Outdoor Access Points
Overview
1
Aruba 387 Series Outdoor Access Points
802.11ad and 802.11ac Wave 2 for high speed outdoor point-to-point connectivity
Product overview
Weatherproof and temperature hardened, the Aruba 387 Series Outdoor Access Points deliver greater than one Gigabit per
second aggregate throughput. It supports distances up to 400 meters (1/4 miles) and provides resilient operation in
inclement weather. And, ease of deployment dramatically simplif
The 60GHz radios include the ability to auto
are fully integrated into the Aruba portfolio and supported with on prem
In today’s mobile era users are expecting to be connected everywhere and at any time. With the ever
devices, there will be even more demand to provide reliable connectivity between two buildings or structures. Legacy point
point solutions can be expensive, and are vulnerable to weather conditions. They can
inst
Use cases range from connecting remote buildings to providing high bandwidth to a temporary event site. Point
solutions offer an attractive option for linking two sites where a
fiber connections, or as a recovery link in the event of a line cut or crushed or flooded conduit.
The AP
performance point to point requirements,
even in extreme outdoor weather use cases.
A maximum concurrent data rate of 2.5 Gbps in the 60GHz band and 867 Mbps in the 5GHz band (for an aggregate peak on air
data rate of 3.37 Gbps) is supported.
Key Features
•
•
ies the skills needed to deploy point to point connections.
-adjust the radios between two APs that are only crudely aligned. These new APs
ise and cloud-based management.
-growing number of IoT
also require highly skilled workers for
allation and more importantly to ensure proper alignment of the APs.
-to-point
right of way is difficult to obtain, to provide a backup for existing
-387 is a dual radio solution that includes separate 5 and 60GHz radios for high
Cost effective and simple to deploy point to point solution
• Built upon Aruba’s hardened outdoor design
• Highly reliable with dual radio based 802.11ad and 802.11ac for intelligent fall back
• Delivering up to 3.37 Gbps throughput
Supports distances up to 400m
-to-
Page
QuickSpecs
Aruba 387 Series Outdoor Access Points
Overview
2
Features and Benefits
Cost effective and simple to deploy
The AP
autonomously form links. The APs only require a
optimal performance by both ends.
This also means that even if heavy winds were to move the APs, the link would intelligently self
skilled resour
The full scan range of the 60GHz radio is +/
17 degrees in elevation. The 5GHz radio uses a fixed
sector to cover the same range.
High reliability with intelligent fallback
One of the unique offering
387 is it provides a 5GHz 802.11ac radio along with a high performance 60GHz 802.11ad
radio. The 5GHz radio is bonded with the 802.11ad radio to provide:
Purpose built for outdoor deployments
Purpose
changes and persistent moisture and precipitation. They are fully sealed to
interfaces include industrial strength surge protection.
The AP
interface can now be used for console access to manage the Wi-Fi device itself.
Unique Benefits
Location Services
Industrial Design and Usage Features
-387 dramatically simplifies deployment compared to other point -to-point solutions. 802.11ad has provisions to
coarse alignment of the radios and then the link is intelligently adjusted for
ces to realign the APs.
- 45 degrees in Azimuth and +/-
s of the AP-
1. A throughput boost in good conditions
2. And an intelligent fallback for the 60GHz if impacted by heavy rainfall.
-adjust without the need to send
-built to survive in the harshest outdoor environments, the AP-387 can withstand exposure to extreme temperatures
keep out airborne contaminants. All electrical
-387 also includes an integrated Bluetooth Low Energy (BLE) interface for location services. Additionally, the BLE
Built-in Bluetooth Low-Energy (BLE) radio
• Enables location-based services for mobile engagement and asset tracking in outdoor environments.
• Bluetooth console can be used for wireless management of the AP without the need of a console cable.
Built for harsh outdoor environments
• Sealed connector interfaces to lock out dust and moisture.
• Includes industrial strength surge protection.
High speed low latency connections
• Superior support of remote network segment and other bandwidth intensive and jitter sensitive apps.
Page
QuickSpecs
Aruba 387 Series Outdoor Access Points
Overview
3
Spectrum analysis
Choose your operating mode
Unified APs can be deployed with or without a controller (Instant mode). They can also be readily switched between Controller
and Instant modes to accommodate for changing network needs.
387 offers centralized configuration, data encryption,
Other functionality includes:
themselves based on your desired mode as they power up.
• Capable of part-time or dedicated air monitoring, the spectrum analyzer remotely scans 5GHz radio bands to identify
sources of RF interference.
Wireless mesh
• Configuration of the 387 is the identical to configuring other Aruba outdoor APs for mesh usage.
Intelligent app visibility and control
• Deep packet inspection with AppRF classifies and blocks, prioritizes or limits bandwidth for 2500+ enterprise apps or
groups of apps.
• Controller mode: When managed by Aruba Mobility Controllers, AP-
policy enforcement and network services, as well as distributed and centralized traffic forwarding or,
• Controllerless (Instant) mode: As a mesh extension in Aruba Instant mode, an AP-387 adds capability and reach for
instant deployments.
• Aruba Activate significantly reduces deployment time by automating device provisioning, firmware upgrades, and
inventory management for large installations across multiple sites. APs are factory-shipped to any site and configure
Page
QuickSpecs
Aruba 387 Series Outdoor Access Points
Configuration
4
Ordering Information
Step 1: Select AP-387 Chassis
Description
Part Number
AP-387 Series Unified Outdoor Access Points
Aruba AP-387 (RW) 802.11ac/ad 802.3at POE Dual 5/60 GHz Integrated Antenna Outdoor Radio
R0K13A
Aruba AP-387 (US) 802.11ac/ad 802.3at POE Dual 5/60 GHz Integrated Antenna Outdoor Radio
R0K14A
Step 2: Add mounting bracket
Description
Part Number
AP-270-MNT-V1 AP-270 Series Outdoor Pole/Wall Long Mount Kit
JW052A
AP-270-MNT-V2 AP-270 Series Outdoor Pole/Wall Short Mount Kit
JW053A
AP-270-MNT-H1 AP-270 Series Outdoor AP Hanging or Tilt Install Mount Kit
JW054A
AP-270-MNT-H2 AP-270 Series Access Flush Wall or Ceiling Mount
JW055A
NOTE: The H2 are most commonly used with AP-387. The H1 brackets provide additional tilt beyond the +/-17 electronic
tilt provided by the AP-387.
Step 3: Add POE powering accessories if needed
Description
Part Number
Aruba PD-9001GO-INTL 30W 802.3at PoE+ 10/100/1000 Outdoor Surge Prot Intl Power Cord Injector
JW701A
Aruba PD-9001GO-NA 30W 802.3at PoE+ 10/100/1000 Otdr Surge Prot NA Power Cord Mdspan
Injector
JW700A
Aruba PD-9001GO-DC 30W 802.3at PoE+ 10/100/1000 12-24V DC in Outdoor Surge Prot Midspan
Injector
JW630A
Aruba PD-9001GR-AC 30W 802.3at PoE+ 10/100/1000 Ethernet Indoor Rated Midspan Injector
JW629A
Step 4: Add mounting kit for outdoor POE Midspan injector (optional)
Description
Part Number
Aruba PD-MOUNT-OD Outdoor PoE Midspan Injectors Pole/Mast Mount Kit
JW620A
Step 5: Select 3-prong AC power cord for indoor POE injector
Description
Part Number
PC-AC-ARG Argentina 220V AC 10A 2-meter AC Power Cord
JW113A
PC-AC-AUS Australian AC Power Cord
JW114A
PC-AC-BR Brazil AC Power Cord
JW115A
PC-AC-CHN China AC Power Cord
JW116A
PC-AC-DEN Denmark 220V AC 10A 2-meter AC Power Cord
JW117A
PC-AC-EC Continental European/Schuko AC Power Cord
JW118A
PC-AC-IL Israel 250V AC 10A 2-meter AC Power Cord
JW120A
PC-AC-IN India AC Power Cord
JW119A
PC-AC-IT Italian AC Power Cord
JW121A
PC-AC-JP Japanese AC Power Cord
JW122A
PC-AC-KOR Korea AC Power Cord
JW123A
PC-AC-NA North America AC Power Cord
JW124A
PC-AC-SWI Switzerland 220V AC 10A 2-meter AC Power Cord
JW125A
PC-AC-TW Taiwan AC Power Cord
JW126A
Page
QuickSpecs
Aruba 387 Series Outdoor Access Points
Configuration
5
PC-AC-UK UK AC Power Cord
JW127A
PC-AC-ZA South Africa 250V AC 10A 2-meter AC Power Cord
JW128A
NOTE: Outdoor power injectors ship with cable.
Step 6: Spares/Optional items for AP-387 chassis
Description
Part Number
Outdoor AP Covers and Glands 1-pk M25/5-pk M20 Cover/2-pk M16 Cover/5-pk M20 Gland/2-pk
Ground Kit
Q8N47A
Outdoor AP Metric to Standard M20 to 1/2 inch NPT 5-pk Thread Adapter
Q8N48A
Page
QuickSpecs
Aruba 387 Series Outdoor Access Points
Technical Specifications
6
AP-387 specifications
WI-FI radio specifications
Power
• AP type: Outdoor hardened, dual radio, 60GHz 11ad and 5GHz 802.11ac 2x2 MIMO
• 60 GHz 802.11ad 1x1 (2502.5 Mbps max rate) radio
- 1 Spatial Stream for up to 2.5 Gbps
- Internal scanning antenna
• 5GHz 802.11ac 2x2 MU-MIMO (867 Mbps max rate)
- Two spatial stream MIMO for up to 867 Mbps wireless data
- Internal directional antenna 9 dBi
• Software-configurable dual radio supports 5 GHz (Radio 0) and 60GHz (Radio 1)
• Supported frequency bands (country-specific restrictions apply):
- 2.400 to 2.4835 GHz (BLE)
- 5.150 to 5.250 GHz
- 5.250 to 5.350 GHz
- 5.470 to 5.725 GHz
- 5.725 to 5.850 GHz
- 5.825 to 5.875 GHz
- 57 to 64 GHz
• Available channels: Dependent on configured regulatory domain.
• Dynamic frequency selection (DFS) maximizes the use of available 5GHz RF spectrum.
• Supported radio technologies:
- 802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM)
- 802.11ad: Single carrier (SC)
• Supported modulation types:
- 802.11a/g/n/ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
- 802.11ad: BPSK, QPSK
• Transmit power: Configurable in increments of 0.5 dBm for 5 GHz
• Maximum EIRP (limited by local regulatory requirements):
- 60GHz band:
- 5GHz band:
• Maximum ratio combining (MRC) for improved receiver performance on 5 GHz.
• Cyclic delay/shift diversity (CDD/CSD) for improved downlink RF performance.
• Short guard interval for 20MHz, 40MHz, 80MHz on 5GHz.
• Low-density parity check (LDPC) for high-efficiency error correction and increased throughput.
• 802.11ac Transmit beam-forming (TxBF) for increased signal reliability and range
• 802.11ad Beam Steering
• Supported 11a/ac data rates (Mbps):
- 802.11a 6, 9, 12, 18, 24, 36, 48, 54
- 802.11n (5GHz): 6.5 to 600 (MCS0 to MCS15)
- 802.11ac: 6.5 to 867 Mbps (MCS0 to MCS9, NSS = 1 to 2 for VHT20/40/80)
• 802.11n high-throughput (HT) support: HT 20/40
• 802.11ac very high throughput (VHT) support: VHT 20/40/80/160
• 802.11ad
• 802.11n/ac packet aggregation: A-MPDU, A-MSDU
+/- 45° Azimuth Scan
+/- 17° Vertical Scan
40 dBm EIRP max
387: 34 dBm EIRP
Page
QuickSpecs
Aruba 387 Series Outdoor Access Points
Technical
Specifications
7
Other interfaces
Mou
*Recommended bracket solutions for most apps.
Mechanical
Environmental
Regulatory
• EMC Directive 2014/30/EU
• Worst-case power consumption -13.5 W
• Idle power consumption 4.5W
• Power sources sold separately
• Power over Ethernet (PoE+): 802.3at-compliant
• Power over Ethernet (PoE): 802.3af with some operational restriction.
- Max conducted power per chain for 5GHz drops to 19 dBm
• One 10/100/1000BASE-T Ethernet network interfaces (RJ-45)
- Auto-sensing link speed and MDI/MDX
- 802.3az Energy Efficient Ethernet (EEE)
• Bluetooth Low Energy (BLE) radio
- Up to 4dBm transmit power (class 2) and -91 dBm receive sensitivity
• Visual indicator (multi-color LED): For system and radio status
• Reset button: Factory reset (during device power up)
• Micro USB console interface
nting
• AP-270-MNT-V1
• AP-270-MNT-V2
• AP-270-MNT-H1 *
• AP-270-MNT-H2 *
• Dimensions/weight (excluding mount adapter):
- -18 cm (W) x 18 cm (D) x 10.1 cm (H)
- -1.198 kg
• Operating:
- Temperature: -40° C to +60° C (-40° F to +140° F)
- Humidity: 5% to 95% non-condensing
• Storage and transportation:
- Temperature: -40° C to +70° C (-40° F to +158° F)
• Operating Altitude: 3,000 m
• Water and Dust
- IP66/67
• Salt Tolerance
- Tested to ASTM B117-07A Salt Spray 200hrs
• Wind Survival: Up to 165 Mph
• Shock and Vibration ETSI 300-19-2-4
• FCC/ISED
• CE Marked
• RED Directive 2014/53/EU
Page
QuickSpecs
Aruba 387 Series Outdoor Access Points
Technical
Specifications
8
•
NOTE:
Regulatory Model Number
Certifications
Warranty
Minimum Operating System Software
Low Voltage Directive 2014/35/EU
• UL/IEC/EN 60950
• EN 60601-1-1, EN60601-1-2
For more country-specific regulatory information and approvals, please see your Aruba representative.
• AP-387: APEX0387
• CB Scheme Safety, cTUVus
• UL2043 plenum rating
• Wi-Fi Alliance certified 802.11a/b/g/n/ac
• Limited Lifetime Warranty
• 8.4. AOS and 8.4 for Instant
Page
QuickSpecs
Aruba 387 Series Outdoor Access Points
Technical
Specifications
9
RF performance table
Maximum transmit power (dBm)
per transmit chain
Receiver sensitivity (dBm)
per receive chain
802.11a 5GHz
6 Mbps
22
-90
54 Mbps
22
-73
802.11n HT20 5GHz
MCS0/8
22
-93
MCS7/15
21
-71
802.11n HT40 5GHz
MCS0/8
22
-90
MCS7/15
-68
802.11ac VHT20 5GHz
MCS0
-93
MCS9
21
-68
802.11ac VHT40 5GHz
MCS0
22
-90
MCS9
21
-63
802.11ac VHT80 5GHz
MCS0
22
-87
MCS9
21
-61
802.11ad 60GHz
MCS0
19
-
MCS9
19
-
NOTE: Maximum capability of the hardware provided (excluding antenna gain). Maximum transmit power is limited by local
regulatory settings.
21
22
Page
QuickSpecs
Aruba 387 Series Outdoor Access Points
Summary of Changes
10
Date
Version History
Action
Description of Change
03-Dec-2018
Version 1
Created
Document creation
Sign up for updates
© Copyright 2018 Hewlett Packard Enterprise Development LP. The information contained herein is
subject to change without notice. The only warranties for Hewlett Packard Enterprise products and
services are set forth in the express warranty statements accompanying such pro
Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise
shall not be liable for technical or editorial errors or omissions contained herein.
To learn more, visit
a00056120enw
ducts and services.
: http://www.hpe.com/networking
- 16325 - Worldwide - V1 - 3-December-2018
Page
Loading...
