ARUBA JX945A User Guide
QuickSpecs
Aruba 300 Series Access Points
Overview
1
Aruba 300 Series Access Points
Entry-level 802.11ac Wave 2 Access Points
Product overview
The entry-level Aruba 300 Series Wave 2 access points deliver high performance and superb user experience for medium
density environments. Featuring 3x3:3SS MU
integrated Aruba Beacons, the 300 Series enables an all wireless digital work environment in a cost
With a maximum concurrent data rate of 1,300 Mbps in the 5GHz band and
Mbps in the 2.4GHz band (for an aggregate peak
data rate of 1.
for enterprises. It is ideal for cost
The high performance and medium density 802.11ac 300 Series supports multi
(3SS). It provides simultaneous data transmissi
network efficiency.
The 300 Series includes the enhanced ClientMatch technology that extends the client steering technology with MU
awareness. It automatically identif
Aruba access point. By grouping MU
simultaneous transmission to these devices, incre
device types, help customers achieve the best WLAN performance in a mixed device environment during the technology transition
period.
The 300 Series also has an integrated Bluetoo
battery
notification capabilities. It enables businesses to leve
user experience and increase the value of the wireless network for organizations.
-MIMO capability, Aruba advanced ClientMatch radio management, and
-effective manner.
300
6Gbps), the entry-level 300 Series brings an always-on wireless network experience with the performance required
-powered Aruba Beacons while also providing advanced location and indoor way finding, and proximity-based push
-sensitive high density environments across verticals.
-user MIMO (MU-MIMO) and 3 spatial streams
on to multiple devices (up to two), maximizing data throughput and improving
ies MU-MIMO capable mobile devices and steers those devices to the closest MU-MIMO capable
-MIMO capable mobile devices together, the network starts taking advantage of the
asing its overall capacity. These dynamic roaming policies that are based on
th Aruba Beacon that simplifies the remote management of a network of large-scale
rage mobility context to develop applications that will deliver an enhanced
-MIMO client
Page
QuickSpecs
Aruba 300 Series Access Points
Overview
2
Features and Benefits
Unique Benefits
in the 2.4GHz band
Supports priority handling and policy enforcement for unified communication apps, including Microsoft Skype for
power consumption exceeds the
Choose your Operating Mode
Aruba 300 Series APs
in migration path allows 300 Series instant APs to
• Remote AP (RAP) for branch deployments.
• Dual Radio 802.11ac Access Point with Multi-User MIMO
• Built-in Bluetooth Low-Energy (BLE) radio
• Advanced Cellular Coexistence (ACC)
• Quality of service for Unified Communication apps
• RF Management
• Intelligent app visibility and control
• Security
• Intelligent Power Monitoring (IPM):
- Supports up to 1,300Mbps in the 5GHz band (with 3SS/VHT80 clients) and up to 300Mbps
(with 2SS/HT40 clients).
- Enables location-based services with BLE-enabled mobile devices receiving signals from multiple Aruba Beacons
at the same time.
- Enables management of your deployment of battery-powered Aruba Beacons.
- Minimizes interference from 3G/4G cellular networks, distributed antenna systems and commercial small
cell/femtocell equipment.
-
Business with encrypted videoconferencing, voice, chat and desktop sharing.
- Adaptive Radio Management (ARM) technology automatically assigns channel and power settings, provides
airtime fairness, and ensures that APs stay clear of all sources of RF interference to deliver reliable, highperformance WLANs.
- The Aruba 300 Series APs can be configured to provide part-time or dedicated air monitoring for spectrum
analysis and wireless intrusion protection, VPN tunnels to extend remote locations to corporate resources, and
wireless mesh connections where Ethernet drops are not available.
- AppRF technology leverages deep packet inspection to classify and block, prioritize, or limit bandwidth for
thousands of applications in a range of categories.
- Integrated wireless intrusion protection offers threat protection and mitigation, and eliminates the need for
separate RF sensors and security appliances.
- IP reputation and security services identify, classify, and block malicious files, URLs and IPs, providing
comprehensive protection against advanced online threats.
- Integrated Trusted Platform Module (TPM) for secure storage of credentials and keys.
- Enables the AP to continuously monitor and report its actual power consumption and optionally make
autonomous decisions to disable certain capabilities.
- For the 300 Series Access Points, the IPM power-save feature applies when the unit is powered by an 802.3af
PoE source. By default, the USB interface will be the first feature to turn off if AP
available power budget. In rare cases it may be necessary to take additional power saving measures, but in most
cases, the 300 Series APs will operate in unrestricted mode.
offer a choice of operating modes to meet your unique management and deployment requirements.
• Controller-managed mode - When managed by Aruba Mobility Controllers, Aruba 300 Series APs offer centralized
configuration, data encryption, policy enforcement and network services, as well as distributed and centralized traffic
forwarding.
• Aruba Instant mode - In Aruba Instant mode, a single AP automatically distributes the network configuration to other
Instant APs in the WLAN. Simply power-up one Instant AP, configure it over the air, and plug in the other APs - the entire
process takes about five minutes. If WLAN requirements change, a builtbecome part of a WLAN that is managed by a Mobility Controller.
Page
QuickSpecs
Aruba 300 Series Access Points
Overview
3
•
For large installations across multiple sites, the Aruba Activate service significantly reduces deployment time by automating device
provisioning, firmware upgrades, and inventory management. With Aruba Activate, Instant APs are factory
configure themselves when powered up.
300
WI
VHT80 client
• Space-time block coding (STBC) for increased range and improved reception
Air monitor (AM) for wireless IDS, rogue detection and containment.
• Spectrum analyzer, dedicated or hybrid, for identifying sources of RF interference.
• Secure enterprise mesh.
-shipped to any site and
Series Access Point
• AP-304 (controller-managed) and IAP-304 (Instant):
- 5GHz 802.11ac 3x3 MIMO (1,300Mbps max rate) and 2.4GHz 2x2 MIMO (300Mbps max rate) radios, with a
total of three dual-band RP-SMA connectors for external antennas
• AP-305 (controller-managed) and IAP-305 (Instant):
- 5GHz 802.11ac 3x3 MIMO (1,300Mbps max rate) and 2.4GHz 802.11n 2x2 MIMO (300Mbps max rate) radios,
with a total of three integrated omni-directional downtilt dual-band antennas
-FI Radio Specifications
• AP type: Indoor, dual radio, 5GHz 802.11ac 3x3 MIMO and 2.4GHz 802.11n 2x2 MIMO
• Software-configurable dual radio supports 5GHz (Radio 0) and 2.4GHz (Radio 1)
• 5GHz: Three spatial stream Single User (SU) MIMO for up to 1,300Mbps wireless data rate to individual 3x3
devices
• 5GHz: Two spatial stream Multi User (MU) MIMO for up to 867Mbps wireless data rate to up to two (1x1 VHT80) MU-
MIMO capable client devices simultaneously
• 2.4GHz: Two spatial stream Single User (SU) MIMO for up to 300Mbps wireless data rate to individual 2x2 HT40 client
devices
• Support for up to 255 associated client devices per radio, and up to 16 BSSIDs per radio
• Supported frequency bands (country-specific restrictions apply):
- 2.400 to 2.4835GHz
- 5.150 to 5.250GHz
- 5.250 to 5.350GHz
- 5.470 to 5.725GHz
- 5.725 to 5.850GHz
• Available channels: Dependent on configured regulatory domain
• Dynamic frequency selection (DFS) optimizes the use of available RF spectrum
• Supported radio technologies:
- 802.11b: Direct-sequence spread-spectrum (DSSS)
- 802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM)
• Supported modulation types:
- 802.11b: BPSK, QPSK, CCK
- 802.11a/g/n/ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
• Transmit power: Configurable in increments of 0.5 dBm
• Maximum (conducted) transmit power (limited by local regulatory requirements):
- 2.4GHz band: +18 dBm per chain, +21 dBm aggregate (2x2)
- 5GHz band: +18 dBm per chain, +23 dBm aggregate (3x3)
- NOTE: conducted transmit power levels exclude antenna gain. For total (EIRP) transmit power, add antenna
gain
• Advanced Cellular Coexistence (ACC) minimizes interference from cellular networks
• Maximum ratio combining (MRC) for improved receiver performance
• Cyclic delay/shift diversity (CDD/CSD) for improved downlink RF performance
• Short guard interval for 20MHz, 40MHz and 80MHz channels
Page
QuickSpecs
Aruba 300 Series Access Points
Overview
4
•
WI
in antennas are optimized for horizontal ceiling mounted orientation of
Other Interfaces
Power
5.5W (DC) for a 5W/1A USB device
Low-density parity check (LDPC) for high-efficiency error correction and increased throughput
• Transmit beam-forming (TxBF) for increased signal reliability and range
• Supported data rates (Mbps):
• 802.11n high-throughput (HT) support: HT 20/40
• 802.11ac very high throughput (VHT) support: VHT 20/40/80
• 802.11n/ac packet aggregation: A-MPDU, A-MSDU
-FI Antennas
• AP-304/IAP-304: Three RP-SMA connectors for external dual band antennas. Worst-case internal loss between radio
• AP-305/IAP-305: Three integrated dual-band downtilt omni-directional antennas for 3x3 MIMO with maximum antenna
- 802.11b: 1, 2, 5.5, 11
- 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
- 802.11n (2.4GHz): 6.5 to 300 (MCS0 to MCS15)
- 802.11n (5GHz): 6.5 to 450 (MCS0 to MCS23)
- 802.11ac: 6.5 to 1,300 (MCS0 to MCS9, NSS = 1 to 3 for VHT20/40/80
interface and external antenna connectors (due to diplexing circuitry): 0.8dB in 2.4GHz and 1.6dB in 5GHz.
gain of 3.9dBi in 2.4GHz and 5.4dBi in 5GHz. Builtthe AP. The downtilt angle for maximum gain is roughly 30 degrees.
- The maximum gain of the combined (summed) antenna patterns for all elements operating in the same band is
5.4dBi in 2.4GHz and 7.6dBi in 5GHz.
• One 10/100/1000BASE-T Ethernet network interface (RJ-45)
• 802.3az Energy Efficient Ethernet (EEE)
• USB 2.0 host interface (Type A connector)
• Bluetooth Low Energy (BLE) radio
• Up to 3dBm transmit power (class 2) and -92dBm receive sensitivity
• Integrated antenna with roughly 30 degrees downtilt and peak gain of 2.3dBi (AP-304/IAP-304) or 3.4dBi (AP-305/IAP-
• Visual indicators (multi-color LEDs): for System and Radio status
• Reset button: factory reset (during device power up)
• Serial console interface (proprietary; optional adapter cable available)
• Kensington security slot
Sources and Consumption
• The AP supports direct DC power and Power over Ethernet (POE)
• When both power sources are available, DC power takes priority over POE
• Power sources are sold separately
• Direct DC source: 12Vdc nominal, +/- 5%
• Power over Ethernet (POE): 48 Vdc (nominal) 802.3af/802.3at compliant source
• Maximum (worst-case) power consumption: 13W (POE) or 12W (DC)
- Auto-sensing link speed and MDI/MDX
305)
- Interface accepts 2.1/5.5-mm center-positive circular plug with 9.5-mm length
- Unrestricted functionality with 802.3at POE
- When using IPM, the AP may enter power-save mode with reduced functionality when powered by an 802.3af
POE source (see details on Intelligent Power Monitoring elsewhere in this datasheet)
- Without IPM, the USB port is disabled when the AP is powered by and 802.3af POE source
- Excludes power consumed by external USB device (and internal overhead); this could add up to 6.5W (POE) or
